Show Tec LED Dim Pro User manual

LED Dim Pro
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 50546
MANUAL
ENGLISH

1
LED Dim Pro
50546
Table of contents
Warning ...............................................................................................................................................................................2
Unpacking Instructions.................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................3
Connection with the mains.........................................................................................................................................3
Return Procedure..........................................................................................................................................................4
Claims..............................................................................................................................................................................4
Description of the device ................................................................................................................................................5
Overview ........................................................................................................................................................................5
Controller Front...................................................................................................................................................................6
Controller Side....................................................................................................................................................................7
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
DMX Mode .....................................................................................................................................................................8
DMX Fail Mode ..............................................................................................................................................................8
Scene Mode ..................................................................................................................................................................8
Chase Mode..................................................................................................................................................................9
Menu Structure ...................................................................................................................................................................9
Specifications...................................................................................................................................................................10
Dimensions........................................................................................................................................................................10

2
LED Dim Pro
50546
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
LED Dim Pro4
Remote Control
User manual
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this device away from rain and moisture!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!

3
LED Dim Pro
50546
Never remove warning or informative labels from the unit.
Do not open the device and do not modify the device.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Only use device indoor, avoid contact with water or other liquids.
Avoid flames and do not put close to flammable liquids or gases.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
Repairs, servicing and electric connection must be carried out only by Showtec.
WARRANTY: Till one year after date of purchase.
Operating Determinations
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The maximum ambient temperature ta= 45°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 45° C.
If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion,
crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

4
LED Dim Pro
50546
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

5
LED Dim Pro
50546
Description of the device
The LED Dim Pro is a very user friendly LED dimmer for RGB and RGBW strips. It can be used to control 12V
or 24V constant voltage LED strips by DMX. Besides DMX control, it can also be used as stand-alone
controller for one scene or chase. You can program a scene or chase, which becomes active if DMX fail
occurs. The user interface is very friendly due to the menu with large display and language select
(NL,EN,DE). It can handle 20A at 12V and 20A at 24V. For example you can use it for 4 x 5A, 2 x 8A or 3 x
6A, as long as the total load does not exceed 20A and the channel load does not exceed 8A. The power
input must be supplied by an external (optional) power supply, which can vary between 12V and 24V
depending on the connected LED strip.
Features
Menu display with NL, EN & DE language selection
DMX fail back up function
Stand-alone function
RGBW Control for 12V & 24V strips
Selectable PWM frequency
IR Remote for controlling without DMX
Overview

6
LED Dim Pro
50546
Controller Front
IR Eye
DMX Signal indicator
Mode button
Up button
Down button
Enter button
Display

7
LED Dim Pro
50546
Controller Side
Signal Out connector (RGBWV+)
Power In connector
Outgoing data signal
Incoming data signal
Extra IR connector

8
LED Dim Pro
50546
Installation
Remove all packing materials from the LED Dim Pro. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
DMX Mode
Press the button to switch between “DMX Address” and “If DMX Fail” mode.
Setup DMX address:
Use the buttons to select an address between 001-512.
DMX Fail Mode
Use the buttons to select “Play Chase” or “Play Scene”.
Scene Mode
Press the button to switch between the R/G/B/W channels.
Use the buttons to set the channel value.
Press the button to exit the Scene Mode.

9
LED Dim Pro
50546
Chase Mode
Press the button to switch between the eight options.
Use the buttons to set the values.
Press the button to exit the Chase Mode.
Menu Structure

10
LED Dim Pro
50546
Specifications
Power supply:
DC 12-24V
Load @ 12V:
max 8A/Channel (20A Total/240W)
Load @ 24V:
max 8A/Channel (20A Total/480W)
Selectable PWM frequencies:
100Hz, 2kHz, 8kHz, 16kHz
Housing:
Metal, grey powder coated
DMX In:
RJ45
DMX Out:
RJ45
12/24V DC input:
2-pin green terminal
Ingress protection rating:
IP20
Operating Temperature:
0 ºC to +40 ºC
Storage Temperature:
-20 ºC to +70 ºC
Dimensions (LxWxH):
195x140x80mm
Weight:
0.85Kg
Dimensions
