TEL AFA1000/2 MK2 Installation instructions

Installation & Operating Manual
Temperature Electronics Ltd.
Unit 2, Wren Nest Road
Glossop, SK13 8HB
United Kingdom
AFA1000/2 MK2
Airow Controller

Version 01 / p.2
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
Table of Contents
1 Safety 5
1.1 Safety Practices 5
1.2 Warning Notices 5
1.3 Precautions 5
1.4 General Operating
Conditions 6
1.5 Environmental Conditions 6
1.6 Electrical Safety
7
1.7 Electrical Protection
8
1.8 EMC Compliance
8
1.9 Warning Labels
8
2 OverviewoftheAirowMonitor       10
5
2.1 Operator Display Panel 10
2.2 Display Features 11
2.3 Displayed Alarms and Events 12
2.4 Additional Alarms and Events 13
2.5 LED Indicators 13
2.6 Audible Alarm
Sounder 13
2.7 Pushbuttons
14
2.8 Diagnostics Menu 15
2.9 External Connections 17
3 Functions and Operation 21
3.1 Airowfunctions          21
3.2 Pushbutton functions 22
3.3 Input functions
24
4 Components 29
4.1 Inverter Control 29
4.2 Damper Control 30
4.3 Auxiliary Components
31

Version 01 / p.3
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
Table of Contents
5 Installation 33
5.1 Installation of Standard Components 33
5.2 Typical Installation Diagrams 34
5.3 Dimensions and Cut out details 35
5.4 SM6AirowsensorInstallation 36
6 Conguration&Calibration        38
6.1 Conguration           38
6.2 Start Up 38
6.3 Calibration 39
6.4 Calibration Notes 40
7 Auxiliary features and connections 60
7.1 Optional input function - Temperature Sensor 62
7.2 Optional input function - Close Sash Alarm 64
8 RS485 Coms output 70
8.1 Overview and connections 70
8.2 Congurationsettings          71
8.3 Testing and troubleshooting 73
8.4 CongManager          74
9 Warranty 77

1. SAFETY

Version 01 / p.5
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
1 SAFETY
1.1 Safety Practices
This document describes the general safety practices and precautions that must be
observed when operating the Airow Monitor.
This advice is intended to supplement, not supersede, the normal safety codes in the
user’s country. The information provided does not cover every safety procedure that
should be followed. Ultimately, maintenance of a safe laboratory environment is the
responsibility of the user and the user’s organisation.
Please consult all documentation supplied with the Airow Monitor before starting
to work. Carefully read the safety information in this document and in the other
documentation supplied. When setting up the equipment or performing analysis or
maintenance procedures, strictly follow the instructions provided.
1.2 Warning Notices
Within this User Guide WARNINGS are used to highlight information or instructions
that must be followed in order to avoid personal injury to yourself or other people in
the vicinity, eg. switch o the mains voltage before any maintenance.
WARNINGS appear as below:
1.3 Precautions
The following precautions must be observed when using the Airow Monitor
and associated systems:
• Be sure that the voltage of the Airow Monitor equipment corresponds to the
voltage available where it is to be installed.
• Never remove the side or back panels of the Airow Monitor without rst shutting
down the equipment and disconnecting the power supply.

Version 01 / p.6
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
1.4 General Operating Conditions
The Airow Monitor and equipment have been designed and tested in
accordance with the safety requirements of the International Electrotechnical
Commission (IEC). The Airow Monitor conforms to IEC61010-1 (Safety Requirements
for electrical equipment for measurement, control and laboratory use) as it applies
to IEC Class 1 (earthed) appliances, and therefore meets the requirements of EC
directive 73/23/EEC.
If possible, avoid any adjustment, maintenance or repair to the eqipment whilst
covers are open or it is operative. However, if any adjustment, maintenance or repair
is necessary while the covers are open, this must be done by a skilled person who is
aware of the hazards involved.
Whenever circumstances arise that mean an Airow Monitor may be unsafe,
make it inoperative. In particular, an Airow Monitor may be unsafe if it:
• Shows visible damage.
• Fails to perform correctly.
• Has been subjected to severe transport stresses.
• Has been subjected to prolonged storage in unfavorable conditions.
1.5 Environmental Conditions
The Airow Monitor should only be used under the following conditions:
• Indoors.
• In ambient temperatures between 5°C and 40°C.
• With relative humidity below 80% for temperatures up to 31°C, decreasing linearly
to 50% relative humidity at 40°C.
• Electrical supply uctuations not exceeding +10% of the nominal voltage.

Version 01 / p.7
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
1.6 Electrical Safety
The Airow Monitor and associated equipment are designed to protect the user from
potential electrical hazards. This section describes some recommended electrical safety
practices.
The Airow Monitor and associated equipment must be correctly connected to a suitable
electrical supply. The supply must have a correctly installed protective conductor (earth
or ground) and must be installed and checked by a qualied electrician before initial
power up.
When working with the Airow Monitor System:
• Connect the equipment to a correctly installed mains power outlet that has a protective
conductor connection.
• Do not operate the equipment with any covers or internal parts removed.
• Disconnect the equipment from all live voltage sources before opening it to make any
adjustments, replacements, maintenance or repair. If the opened equipment must be
operated for further adjustment, maintenance or repair, this must only be done by a
supplier’s Service Engineer.
If it is possible that the equipment is no longer electrically safe for use, make the
equipment inoperative and secure it against any unauthorised or unintentional operation.
The electrical safety of the equipment is likely to be impaired if:
• It has any signs of visible damage.
• If it has been subjected to prolonged storage in unfavourable conditions.
• If it has been subjected to severe stress during transportation.
Any interruption of the protective conductor inside or outside
theAirowMonitorSystem,ordisconnectionoftheprotective
conductor terminal is likely to make the equipment dangerous.
Intentional interruption of the protective conductor is prohibited.

Version 01 / p.8
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
1.7 Electrical Protection
Observe the following electrical protection precautions:
• Insulation: Class I rating for external circuits. Only connect equipment that meets
the requirements of IEC 61010-1, IEC 60950 or equivalent standards.
• Installation Category: The equipment is able to withstand transient over-voltages
typically present on the mains supply. The normal level of transient over-voltages is
impulse withstand (overvoltage) Category II of IEC 60364-4-443.
• Pollution Degree 2: Normally only non-conductive pollution occurs. Occasionally,
however, temporary conductivity caused by condensation must be expected.
1.8 EMC Compliance
EC Directive
The Airow Monitor System is designed and tested to meet the requirements of
the EC directive 89/336/EEC and 93/68/EEC and complies with the EMC standard
EN61326 (EMC standard for electrical equipment for measurement, control and
laboratory use) and EN55011 (ISM) Class A (RF emissions).
FCC Rules and Regulations
The Airow Monitor System is classied as a digital device used exclusively as
industrial, commercial or medical test equipment. It is exempt from the technical
standards specied in Part 15 of the FCC Rules and Regulations based on Section
15.103 (c).
1.9 Warning Labels
Warning labels attached to the equipment draw attention to specic hazards - refer
to this guide and other documentation provided with the equipment for more details
concerning potential hazards and any precautions or other actions that must be
taken.

2. OVERVIEW OF THE
AIRFLOW MONITOR

Version 01 / p.10
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2 OVERVIEW OF THE
AIRFLOW CONTROLLER
2.1 Operator Display Panel
Airow bar graph or Alarm Time Line
Velocity display m/sec or fpm or
Plain Text “Air Safe / Air Fail”
Control Pushbutton Icons
Control Pushbuttons
LED indicators
Function and up/down buttons
for Menu Conguration and
Calibration.
ENTER – also used as
Mute button for audible alarm
Note:
Access to the Calibration and Conguration menus is password protected
and is factory set. To access and or change the password contact the
supplier for the engineers password and enter the Passwords in the Main
Menu or alternatively use a Laptop connected to the Com port and use the
Upload/Download software provided.

Version 01 / p.11
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.2 Display Features
TheAirowMonitordisplayhasthefollowingfeatures:
The digital display is a backlit, full colour high resolution graphic unit with a visual display area of
approx 45 x 34mm. The display operates through the software allowing the generation of gures,
wording and icons. The display background colour can be provided as either Blue or Black.
The display shows the fume cupboard face velocity in m/sec or fpm when enabled or the alternative
with no velocity reading but showing AIR FAIL / AIR SAFE as continuous display. All of the above are
congurable via the alarm key pad.
The displayed face velocity colour will change when in an alarm condition:-
Air Safe = White / Low or High Air Alarm = Red / Warning Air Alarm = Amber.
An ‘event time line’ segmented into 60 x 1 minute segments will scroll across the display (when
enabled) .This takes the form of a graphical scale ranged over 0-1.00 m/sec that will progress from the
right hand side to the left hand side of the screen – representing the airow value at each segment.
The segment colour will change if the value is in the range of an airow alarm:-
Air Safe = White / Low or High Air Alarm = Red / Warning Air Alarm = Amber.
The alternative to the event time line is a dynamic ‘bar graph’ representing the airow velocity.
The display shows an up or down arrow Icon in the bottom right hand corner of the screen when an
input function is set to Hi / Lo (2 speed operation). The Up arrow indicates High speed and the Down
arrow indicates Low speed.
The display shows a Horn icon (with line through it) when the audible alarm is in the Muted condition
The display backlight will dim to a xed low level when certain functions are active to save energy:-
FanO- display backlight reduces until Fan On is selected.
Backlight will resume to normal level whilst Set Up or Diagnostics menus are accessed.
Setback Input is active - display backlight reduces until input is not active.
Backlight will resume to normal level whilst Set Up or Diagnostics menus are accessed.

Version 01 / p.12
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.3 Displayed Alarms and Events
Sash High will be displayed when the Sash alarm is enabled and the sash is raised above
the max safe working opening. Sash High will alternate on/o with the velocity
reading.
Ext Alarm will be displayed when the external alarm input is activated (when enabled) Ext
Alarm will alternate on/o with the velocity reading
Air Fail will be displayed if the airow is less than the Low air alarm point. Air Fail will
alternate on/o with the velocity reading
High Air will be displayed if the airow is more than the High air alarm point. High Air will
alternate on/o with the velocity reading
Set-back will be displayed if the night set-back function is activated. Setback will alternate
on/o with the velocity reading and the display backlight will dim.
Alm Dis will be displayed if the alarm disable function is activated (when enabled) Alarm
Disable will alternate on/o with the velocity reading
Close Sash will be displayed if the sash is raised and the operator is not present (when
enabled) Close Sash will alternate on/o with the velocity reading
Emergency will be displayed if the Emergency input is activated. Emergency will alternate
on/o with the velocity reading
Up/Down Arrow will be displayed if Hi/Lo 2 Speed operation is enabled.
OFF will be displayed if pushbutton 1 is set to Fan On/O and hide airow is enabled
if the Fan is switched o. The display backlight will dim in a Fan o condition.
Start Up will be displayed if pushbutton 1 is set to Fan On/O and the start up timer is
enabled xxx seconds if the Fan is switched on. The remaining start up time is
displayed.

Version 01 / p.13
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.4 Additional Alarms and Events
Mains Fail - will be displayed if the power fails to the monitor (when enabled)
*Note – this is an optional extra feature that requires an
additional battery unit
Low Temp - will be displayed if the fume cupboard temperature drops
below the low temp alarm point (when enabled). This display will
alternate on/o with the velocity reading.
*Note – this is an optional extra feature that requires an
additional temperature sensor
High Temp - will be displayed if the fume cupboard temperature rises above
the high temp alarm point (when enabled) *Note – this is an
optional extra feature that requires an additional temperature
sensor
2.5 LED Indicators
The alarm unit has three LED indicators:
RED – Alarm
Amber – Caution
Green – Safe
The RED Alarm LED will be permanently illuminated if pushbutton 1 is set to Fan
On/O and is switched o.
2.6 Audible Alarm Sounder
The AFA1000/2 has an audible sounder with local or remote mute facility. The
audible alarm can be permanently disabled in the cal cong menu.
The audible alarm is muted if Fan O is selected on pushbutton 1 or when the Mute,
Setback or Alarm Disable input functions are active.
The display will show a Mute Icon in the bottom left hand side of the screen
whenever the audible alarm is muted or disabled.
If an Input is set to the Mute function the keypad mute Enter button is disabled and
the audible alarm is only mutable using the selected Mute input.

Version 01 / p.14
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.7 Pushbuttons
The AFA1000/2 has 3 menu congurable pushbuttons. Each pushbutton can be congured to a
dierent function. The pushbutton Icon and status is shown on the display above the pushbutton.
a. Pushbutton 1
FanOn/O– will be displayed when the pushbutton is set to FAN operation.
ExtFanOn/O– will be displayed when the pushbutton is set to Extract Fan operation.
b. Pushbutton 2
LightsOn/O– will be displayed when the pushbutton is set to Lights operation.
UVLightsOn/O– will be displayed when the pushbutton is set to UV Lights operation.
PumpOn/O– will be displayed when the pushbutton is set to Pump operation.
D/FFanOn/O– will be displayed when the pushbutton is set to Downow fan operation.
c. Pushbutton 3
LightsOn/O– will be displayed when the pushbutton is set to Lights operation.
GasOn/O– will be displayed when the pushbutton is set to Gas solenoid operation.
SocketsOn/O– will be displayed when the pushbutton is set to Sockets operation.
S/Back O/R – will be displayed when the pushbutton is set to Setback Override operation.
d. Enter
The alarm has an Enter button -- this is multi-functional as follows:-
Press Enter momentarily when alarm is sounding will mute the alarm.
Press Enter for 5 secs will gain access to Calibration and Conguration menus (both menus
password protected).
e. +& -
The alarm has + / - buttons that can be used to scroll through the calibration and conguration menu
or to select options or values.

Version 01 / p.15
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.8 Diagnostics Menu
The AFA1000/2 has a diagnostics menu that shows current Input and Output status,
Coms data and also includes an Alarm Test function.
To access the diagnostics menu press the ‘+’ and ‘-’ buttons together whilst in the run
screen.
The diagnostics sub menu will appear showing the following options-
a. Alarm Test
b. Coms data
c. I/O Status
d. Done
Use the +/- buttons to scroll and Enter to select the required parameter.
a. Alarm Test - the Screen will show “Testing Safe LED” and the Green Safe LED will
illuminate. The screen will then show “Testing Warning LED” and the Amber Warning
LED will illuminate. The screen will then show Testing Alarm” and the Red Alarm LED
will illuminate and the audible alarm will sound.
The screen will then return to the Diagnostics menu.
b. Coms data - the Screen will show the coms setting data for the relevant selected
protocol:-
Protocol = None/TEL/Modbus/BACnet
ID = Slave ID for Modbus or Device Instance for BACnet
Baud Rate = Shows selected Baud Rate
Parity = Shows selected Parity
Tx & Rx = the display will show the current data packets sent and received, the
displayed value will rollover to zero when the maximum count is reached.
c. I/O Status - when selected the following options are shown:-
Input Data
Output Data
Sensor Data
Done

Version 01 / p.16
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
InputData:-
Input 1 - 0 / O / On / Not Used
Input 2 - 0 / O / On / Not Used
Input 3 - 0 / O / On / Not Used
0 = Analogue Input e.g. Sash Position sensor Input Voltage (0-5VDC)
O = Input Open
On = Input Closed
Not Used = Input not assigned
OutputData:-
Output 1 - O / On
Output 2 - O / On
Output 3 - O / On
Output O = Output Open or not assigned
Output On = Output Closed
SensorData:-
Airow 00.0 %
Temperature °C
Airow % = Output of airow sensor in %, 100% = no airow
Temperature = Temperature in °C or °F - (when enabled)
Done - returns to Diagnostics menu.
d. Done - when selected the controller returns to the run screen.

Version 01 / p.17
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
2.9 External Connections
TheAFA1000/EhasthefollowingInputs:-
Input 1
Volt free input congurable for normally closed, normally open relays or Analogue 0-5VDC Input
This input can be congured as:-
Digital Input Functions (Closed or Open volt free contact):-
Alarm disable Night set-back
External alarm Emergency
Sash High High / Low
Sash Warning Mains Fail
Fan Stop
Mute
Analogue Input Functions:-
Temperature
Input 2
Volt free input congurable for normally closed, normally open relays or Analogue 0-5VDC Input
This input can be congured as:-
Digital Input Functions (Closed or Open volt free contact):-
Alarm disable Night set-back
External alarm Emergency
Sash High High / Low
Sash Warning Mains Fail
Fan Stop
Mute
Analogue Input Functions:-
Temperature

Version 01 / p.18
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
Input 3
Volt free input congurable for normally closed, normally open relays or Analogue 0-5VDC Input
This input can be congured as:-
Digital Input Functions (Closed or Open volt free contact):-
Alarm disable Night set-back
External alarm Emergency
Sash High High / Low
Sash Warning Mains Fail
Fan Stop
Mute
Analogue Input Functions:-
Temperature
TheAFA1000/2hasthefollowingOutputs:-
Relay Output 1
Volt free relay output congurable as normally closed or normally open relays.
Relay Output 2
Volt free relay output congurable as normally closed or normally open relays.
Relay Output 3
Volt free relay output congurable as normally closed or normally open relays.
Analogue Output 1
0-10VDC retransmission of face velocity over 0-1.00m/sec e.g. 0.50m/sec = 5VDC.
Com Port
RS 485 to enable connection to Laptop or PC for full diagnostics, logging or setting up and for
communications to building computer system (BMS)
See section 8 for other specic information on Modbus RTU and BACnet options and settings.
Power supply
Low voltage DC power supply from Mains power adaptor.

Version 01 / p.19
AFA1000/2 MK2 Airflow Monitor
Installation & Operating Manual
Optional Inputs
Temperature Sensor
Bespoke Temperature sensor for connection into inputs 1, 2 or 3 to give temperature
display with high and low temperature alarms.
PIR Occupancy Sensor
Auxiliary PIR used for Close Sash alarm based on Fume Cupboard occupancy.
Mains Fail battery unit
Auxiliary plug in battery unit for Mains Fail alarm.
See Menu Block Diagram document for other specic operations and indications.

3. FUNCTIONS & OPERATION
