Show Tec Stage Blinder 2 Blaze User manual

Stage Blinder 2 Blaze V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 30782
MANUAL
ENGLISH

1
Ordercode: 30782
Stage Blinder 2 Blaze
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Overview ........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Stage Blinder (Auto, Built-in programs, Manual and Halogen) ...............................................................9
Multiple Stage Blinders (Master/Slave control) ....................................................................................................9
Multiple Stage Blinders (DMX Control) .................................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................15
1. DMX Address/DMX Configuration ....................................................................................................................15
2. Manual Color mode ...........................................................................................................................................16
3. Halogen .................................................................................................................................................................16
4. Auto........................................................................................................................................................................17
5. Program .................................................................................................................................................................17
5.1. Program 1...........................................................................................................................................................18
5.2. Programs 2-8......................................................................................................................................................18
6. Master/Slave.........................................................................................................................................................18
7. Settings...................................................................................................................................................................19
7.1. Curves Select.....................................................................................................................................................19
7.2. Dimmer Speed ..................................................................................................................................................20
7.3. DMX Fail..............................................................................................................................................................20
7.4. DMX Sync ...........................................................................................................................................................20
7.5. Lock.....................................................................................................................................................................21
7.6. Key Backlight .....................................................................................................................................................21
7.7. Factory................................................................................................................................................................21
8. Information............................................................................................................................................................21
DMX Channels .............................................................................................................................................................22
1 Channel..................................................................................................................................................................22
4 Channels ................................................................................................................................................................22
8 Channels ................................................................................................................................................................22
9 Channels ................................................................................................................................................................23
Maintenance....................................................................................................................................................................24
Troubleshooting ...............................................................................................................................................................24
No Light.........................................................................................................................................................................24
No Response to DMX..................................................................................................................................................24
Product Specifications....................................................................................................................................................26
Dimensions........................................................................................................................................................................27
Notes ..................................................................................................................................................................................28

2
Ordercode: 30782
Stage Blinder 2 Blaze
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Showtec Stage Blinder 2 Blaze
●Pro power True 1 to Schuko power cable (1,5 m)
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing
for lower operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 30782
Stage Blinder 2 Blaze
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Never modify, bend, mechanically strain, put pressure on, pull or heat up the power cord.
●Never strain the cable insert or the female part in the device. There must always be sufficient cable going
to the device. Otherwise, the cable will be damaged, which can cause serious damage.
●Never remove warning or informative labels from the unit.
●Never use anything to cover the ground contact.
●Never lift the device holding it by the projector-head, as the mechanics may be damaged. Always hold
the device by the transport handles.
●Never place any material over the LEDs or lens.
●Never look directly into the light source.
●Never leave any cables lying around.
●Never use the device during thunderstorms, unplug the device immediately.
●Never leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within children’s
reach, as they are potential sources of danger.
●Do not insert objects into air vents.
●Do not open the device and do not modify the device.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this will reduce the device’s life.
●Do not touch the device’s housing bare-handed during its operation (housing becomes hot). Allow the
device to cool for at least 5 minutes before handling.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only operate the device after having checked if the housing is firmly closed and all screws are tightly
fastened.
●Only operate the device after having familiarized with its functions.
●Avoid flames and do not put close to flammable liquids or gases.
●Always keep the case closed while operating.
●Always allow a free air space of at least 80 cm around the unit for ventilation.
●Always disconnect power from the mains, when device is not used or before cleaning! Only handle the
power cord holding it by the plug. Never pull out the plug by tugging the power cord.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power cord
from time to time.
●Make sure that the core diameter of extension cords and power cords is sufficient for the required power
consumption of the device.
●If the lens or LEDs are obviously damaged, they have to be replaced to prevent its functions from being
impaired, due to cracks or deep scratches.
●If the external cable is damaged, it has to be replaced by a qualified technician.
●If device was dropped or struck, disconnect mains power supply immediately. Have a qualified engineer
inspect for safety before operating.
●If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the device
switched off until it has reached room temperature.
●If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
●For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
●Never attempt to bypass the thermostatic switch or fuses.
●For replacement use fuses of same type and rating only.
●The user is responsible for correct positioning and operating of the device. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
●This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to
earth.
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.

4
Ordercode: 30782
Stage Blinder 2 Blaze
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light output and the illuminated surface must be bigger than 0,8
meter.
●In order to eliminate wear and improve the device’s lifespan, during periods of non-use, completely
disconnect from power source via breaker or by unplugging.
●The maximum ambient temperature ta= 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40°C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
●If the Stage Blinder is lowered from the ceiling or high joists, professional trussing systems have to be
used.
●Use a clamp to mount the Stage Blinder, with the mounting bracket, to the trussing system.
●The Stage Blinder must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
●When rigging, derigging or servicing the Stage Blinder, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.

5
Ordercode: 30782
Stage Blinder 2 Blaze
The Stage Blinder 2 Blaze can be placed on a flat surface or fitted to any kind of truss with a clamp.
Improper installation can cause serious damage to people and property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

6
Ordercode: 30782
Stage Blinder 2 Blaze
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 30782
Stage Blinder 2 Blaze
Description of the device
Features
The Showtec Stage Blinder 2 Blaze is a compact and powerful blinder with high output and great effects.
●Very punchy 2-head blinder
●RGB blaze effect
●Manual Pan adjustment of each head
●Input voltage: 100-240V AC, 50/60Hz
●Power consumption: 205W
●Refresh rate: 4000Hz
●DMX channels: 1, 4, 8, 9 channels
●Light source: 2 x 100W Dual-White COB, SMD RGB Blaze
●Color temperature: 2100-3200K
●Pod movement: +/- 20° stepless
●Beam angle: 45°
●Field angle: 84°
●Dimmer: 0-100%
●Strobe: 0-20Hz
●IP rating: IP65
●Housing: Black powder-coated metal
●DMX control: via standard DMX controller
●Onboard: OLED display for easy setup
●Control: Auto, Built-in programs, Manual, Halogen, Master/Slave, DMX-512
●Connections: Pro power True 1 power connector IN/OUT IP65, 3-pin DMX connector IN/OUT IP65
●Cooling: Cooling fans
●Dimensions: 400 x 220 x 262 mm (LxWxH)
●Weight: 7,3 kg
Note: Knowledge of DMX is required to fully utilize this unit.
Overview
Fig. 01
01) Mounting bracket
02) Safety eye
03) Adjustment screw
04) 2 x 100W Dual-White COB, SMD RGB Blaze

8
Ordercode: 30782
Stage Blinder 2 Blaze
Backside
Fig. 02
05) Pro power True 1 power connector OUT IP65
06) Pro power True 1 power connector IN IP65
07) OLED display + control buttons
08) 3-pin DMX signal connector IN IP65
09) 3-pin DMX signal connector OUT IP65
Installation
Remove all packing materials from the Stage Blinder 2 Blaze. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

9
Ordercode: 30782
Stage Blinder 2 Blaze
Control Modes
There are 6 modes:
●Auto
●Built-in programs
●Manual
●Halogen
●Master/Slave
●DMX-512 (1CH, 4CH, 8CH, 9CH)
One Stage Blinder (Auto, Built-in programs, Manual and Halogen)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Stage Blinder is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 16-18 for more information about Auto, Built-in programs, Manual and Halogen.
Multiple Stage Blinders (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Stage Blinder and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
05) Link the units as shown in fig. 03. Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third and fourth units. You can
use the same functions on the master device as described on pages 16-18 (Auto, Built-in programs,
Manual and Halogen). This means that you can set your desired operation mode on the master
device and all slave devices will react the same as the master device.
Multiple Stage Blinders (Master/Slave control)
Fig. 03

10
Ordercode: 30782
Stage Blinder 2 Blaze
Multiple Stage Blinders (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Stage Blinder and other devices.
05) Link the units as shown in fig. 04. Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's Pro power True 1 socket, then
plug the other end of the mains power cord into proper electric power supply sockets, starting with
the first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Stage Blinders DMX Set Up
Fig. 04
Note: Link all cables before connecting electric power

11
Ordercode: 30782
Stage Blinder 2 Blaze
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Stage Blinders on a DMX data link: 30 fixtures
Maximum recommended number of Stage Blinders on a power link @110V: 8 fixtures
Maximum recommended number of Stage Blinders on a power link @240V: 17 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
●DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
●DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
●DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
●DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
●DAP Audio data cable FL08 DMX/AES-EBU, XLR/M 5-pin > XLR/F 5-pin.Ordercode FL08150 (1,5 m),
FL083 (3 m), FL086 (6 m), FL0810 (10 m), FL0820 (20 m).
●DAP Audio DMX adapter: 5-pin > 3-pin. Ordercode FLA29.
●DAP Audio DMX adapter: 3-pin > 5-pin. Ordercode FLA30.
●DAP Audio DMX Terminator 3-pin. Ordercode FLA42.
●DAP Audio DMX Terminator 5-pin. Ordercode FLA43.
Note: connect the Stage Blinder 2 Blaze with the dedicated special XLR cables for outdoor use.
FL73150 –Neutrik DMX Cable 3-pin XLR IP65 (1,5 m)
FL733 –Neutrik DMX Cable 3-pin XLR IP65 (3 m)
FL736 –Neutrik DMX Cable 3-pin XLR IP65 (6 m)
FL7310 –Neutrik DMX Cable 3-pin XLR IP65 (10 m)

12
Ordercode: 30782
Stage Blinder 2 Blaze
The Stage Blinder 2 Blaze can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) OLED display
B) UP button
C) MODE button
D) DOWN button
E) SET button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Stage Blinder will respond to the controller.
Please note when you use the controller, the unit has 9channels.
When using multiple Stage Blinders, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Stage Blinder should be 1(001); the DMX address of the second
Stage Blinder should be 1+9=10 (010); the DMX address of the third Stage Blinder should be 10+9=19
(019), etc. Please, be sure that you do not have any overlapping channels in order to control each Stage
Blinder correctly. If two or more Stage Blinders are addressed similarly, they will work similarly.
Controlling:
After having addressed all Stage Blinder fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Stage Blinder will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the problem may be:
●The XLR cable from the controller is not connected with the input of the Stage Blinder.
●The controller is switched off or defective, the cable or connector is defective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MODE, SET, UP or DOWN button.
Once you have pressed the button, the display will light up.

13
Ordercode: 30782
Stage Blinder 2 Blaze
Menu Overview

14
Ordercode: 30782
Stage Blinder 2 Blaze

15
Ordercode: 30782
Stage Blinder 2 Blaze
Main Menu Options
01) Upon start-up, the display will show:
02) After 2 seconds, the display will show:
03) Press the UP/DOWN buttons to toggle through the menus.
04) Press the SET button to open the desired menu.
05) Press the MODE button to return to the previous screen.
1. DMX Address/DMX Configuration
With this menu you can set the device’s DMX starting address and choose a DMX channel mode.
01) While in the main menu, press the UP/DOWN buttons to choose DMX.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose ADDRESS or CHANNELS.
04) Once you have chosen ADDRESS, press the SET button to open the submenu.
05) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between 001-
512.
06) Once you have chosen CHANNELS, press the SET button to open the submenu.
07) Press the UP/DOWN buttons to choose 1, 4, 8 or 9 DMX channels.

16
Ordercode: 30782
Stage Blinder 2 Blaze
2. Manual Color mode
With this menu you can set the static colors.
01) While in the main menu, press the UP/DOWN buttons to choose MANUAL.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle through the static colors: Cold White (1-2), Warm White (1-2),
Red, Green and Blue.
04) Once you have chosen the desired color, press the SET button to adjust the color intensity.
05) Press the UP/DOWN buttons to set the color intensity. The adjustment range is between 0-255, from
dark to brightest.
3. Halogen
With this menu you can set the halogen function.
01) While in the main menu, press the UP/DOWN buttons to choose HALOGEN.
02) Press the SET button to open this menu.
03) Press the UP/DOWN buttons to toggle through the 2 options: Halogen 1-2.
04) Once you have chosen the desired halogen, press the SET button to adjust the color intensity.
05) Press the UP/DOWN buttons to set the color intensity. The adjustment range is between 0-255, from
dark to brightest.

17
Ordercode: 30782
Stage Blinder 2 Blaze
4. Auto
With this menu, you can activate the auto show.
01) While in the main menu, press the UP/DOWN buttons to choose AUTO.
02) Press the SET button to open the menu. The display will show:
03) Press the UP/DOWN buttons to select YES or NO. Press the SET button to confirm your choice.
04) If you have chosen YES, the device will start the auto program.
05) If you have chosen NO, the device will keep its current settings.
5. Program
With this menu, you can set the preset colors or the program speed and the strobe frequency of the built-
in programs.
01) While in the main menu, press the UP/DOWN buttons to choose PROGRAM.
02) Press the SET button to enter the menu. The display will show:
03) Press the UP/DOWN buttons to choose MODE and press the SET button to enter the menu.
04) The display will show:
05) Press the UP/DOWN buttons to choose one of the 8 built-in programs. Press the SET button to confirm
your choice.

18
Ordercode: 30782
Stage Blinder 2 Blaze
5.1. Program 1
01) If you have chosen program 01, the display will show:
02) Press the UP/DOWN buttons to choose one of the 2 options:
●COLOR
●STROBE
03) Press the SET button to enter the desired menu.
04) If you have chosen COLOR, press the UP/DOWN buttons to choose one of the 14 color macros. Press
the SET button to save your settings.
05) If you have chosen STROBE, press the UP/DOWN buttons to set the strobe frequency. The adjustment
range is between 0-99, from OFF to high frequency. Press the SET button to save your settings.
5.2. Programs 2-8
01) If you have chosen one of the programs 02-08, the display will show:
02) Press the UP/DOWN buttons to choose one of the 2 options:
●SPEED
●STROBE
03) Press the SET button to enter the desired menu.
04) If you have chosen SPEED, press the UP/DOWN buttons to set the built-in program’s speed. The
adjustment range is between 1-100, from slow to fast. Press the SET button to save your settings.
05) If you have chosen STROBE, press the UP/DOWN buttons to set the strobe frequency. The adjustment
range is between 0-99, from OFF to high frequency. Press the SET button to save your settings.
6. Master/Slave
With this menu, you can set the device as a slave.
01) While in the main menu, press the UP/DOWN buttons to choose SLAVE.
02) Press the SET button to enter the menu. The display will show:
03) Press the UP/DOWN buttons to choose YES or NO.
04) Press the SET button to confirm your choice.
05) If you have chosen YES, the device will be set as a slave and will react the same as the master
device.

19
Ordercode: 30782
Stage Blinder 2 Blaze
7. Settings
With this menu you can set the device’s settings.
01) While in the main menu, press the UP/DOWN buttons to choose SETTINGS.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle through the following menus: CURVES SELECT, DIMMER SPEED,
DMX FAIL, DMX SYNC, LOCK, KEY BACKLIGHT and FACTORY.
04) Press the SET button to open the menu.
7.1. Curves Select
With this menu, you can adjust the dimming of the device by choosing a dimming curve.
01) Press the UP/DOWN buttons to choose one of the 4 dimming curves:
02) Press the SET button to confirm your choice.
