Show Tec X-Terminator User manual

X-Terminator V2
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 43157
MANUAL
ENGLISH

1
Ordercode: 43157
X-Terminator
Table of contents
Warning........................................................................................................................................................................... 2
Unpacking Instructions ............................................................................................................................................. 2
Safety Instructions ..................................................................................................................................................... 3
Operating Determinations....................................................................................................................................... 4
Laser safety for a Class 3B Laser Product .............................................................................................................. 5
Rigging........................................................................................................................................................................ 6
Connection with the mains ..................................................................................................................................... 7
Return Procedure...................................................................................................................................................... 8
Claims ......................................................................................................................................................................... 8
Description of the device............................................................................................................................................. 9
Features ...................................................................................................................................................................... 9
Frontside ..................................................................................................................................................................... 9
Backside ...................................................................................................................................................................10
IR Remote Control...................................................................................................................................................11
Installation ....................................................................................................................................................................11
Set Up and Operation.................................................................................................................................................11
Control Modes.........................................................................................................................................................13
One X-Terminator (Stand-alone) .......................................................................................................................13
One X-Terminator (Sound-controlled) ..............................................................................................................13
Multiple X-Terminators (Master/Slave Mode)................................................................................................... 13
Multiple X-Terminators (DMX Control) ...............................................................................................................14
Fixture Linking ...........................................................................................................................................................15
Data Cabling ...........................................................................................................................................................15
Control Panel ...........................................................................................................................................................16
Control Mode ..........................................................................................................................................................16
DMX Addressing ...................................................................................................................................................... 16
Menu Overview.......................................................................................................................................................17
Main Menu Options ................................................................................................................................................18
1. Built-in Shows.....................................................................................................................................................18
2. Sound-controlled Effect ..................................................................................................................................18
3. Master/Slave Mode .........................................................................................................................................18
4. DMX Mode ........................................................................................................................................................18
5. System Settings .................................................................................................................................................19
DMX Channels .........................................................................................................................................................19
2 channels .............................................................................................................................................................19
11 channels ...........................................................................................................................................................20
Maintenance................................................................................................................................................................22
Replacing the Fuse .................................................................................................................................................22
Troubleshooting ...........................................................................................................................................................22
No Light..................................................................................................................................................................... 22
No Response to DMX..............................................................................................................................................22
Product Specifications................................................................................................................................................24
Dimensions ...................................................................................................................................................................25

2
Ordercode: 43157
X-Terminator
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec X-Terminator
IEC power cable – 1,75 m
2 keys for the Interlock
Mounting bracket + 2 mounting screws
IR remote control
Remote control plug
User manual

3
Ordercode: 43157
X-Terminator
Safety Instructions
Every person involved with the installation, operation and maintenance of this device have to:
• be qualified
• follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never aim the laser beam at people or animals!
•Never use the device during thunderstorms, unplug the device immediately.
•Never point a laser at aircraft, this is a federal offense.
•Never point unterminated laser beams into the sky.
•Never open the laser housing. The high laser power levels inside of the protective housing can start
fires, burn skin and will cause instant eye injury.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not open the device and do not modify the device.
•Do not point lasers at highly reflective surfaces such as windows, mirrors and shiny metal. Even laser
reflections can be hazardous.
•Do not expose the output optic (aperture) to cleaning chemicals
•Do not use laser if the laser appears to be emitting only one or two beams
•Do not use laser if housing is damaged or open, or if optics appear damaged in any way.
•Do not operate laser without first reading and understanding all safety and technical data in this
manual. Never look into the laser aperture or laser beams
•Do not switch the device on and off in short intervals, as this would reduce the device’s life.
•Do not shake the device. Avoid brute force when installing or operating the device.
•After set up and prior to public use, test laser to ensure proper function. Do not use the laser if any
defect is detected. Do not use, if the laser emits only one or two laser beams rather than
dozens/hundreds, as this could indicate damage to the diffraction grating optic, and could allow
emission of higher laser levels.
•Only use device indoor, avoid contact with water or other liquids.
•Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always check the regulations when using a class 3B laser product.

4
Ordercode: 43157
X-Terminator
•Always check and position the laser before anybody enters the room, when the laser is facing an
area with people
•Always keep case closed while operating.
•Always allow free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the external cable is damaged, it has to be replaced by a qualified technician.
•If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
•If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The operation of a class 3B laser show laser is only allowed if the show is controlled by a skilled and
well-trained operator familiar with the data included in this manual.
•The user is responsible for correct positioning and operating of the X-Terminator. The manufacturer
will not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•The laser will only work between 10-40ºC.
•After 3 hours working, you must shut off the laser and let the laser diode cool off for 30 minutes,
otherwise the laser could be damaged and the warranty becomes void.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be more than 1 meter.
●The maximum ambient temperature ta = 35°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 30° C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!

5
Ordercode: 43157
X-Terminator
Laser safety for a Class 3B Laser Product
Laser Light is different from any other light source with which you may be familiar with. The light from this
product can potentially cause instant eye injury if not set up and used properly.
Laser light is thousands of times more concentrated than light from any other kind of light source. This
concentration of light power can cause instant eye injuries, primarily by burning the retina (the light
sensitive portion at the back of the eye). Even if you cannot feel “heat” from a laser beam, it can still
potentially injure or blind you or your audience.
Even very small amounts of laser light are potentially hazardous even at long distances. Laser eye injuries
can happen quicker than you can blink.
It is incorrect to think that because these laser products split the laser into hundreds of beams or the laser
beam is scanned out in high speed, that an individual laser beam is safe for eye exposure. This laser
product uses dozens of milliwatts of laser power (Class 3B levels internally). Many of the individual beams
are potentially hazardous to the eyes.
It is also incorrect to assume that because the laser light is moving, it is safe. This is not true. Nor, do the
laser beams always move. Since eye injuries can occur instantly, it is critical to prevent the possibility of
any direct eye exposure. According to the laser safety regulation, it is not legal to aim Class 3B lasers in
areas which people can get exposed. This is true even if it is aimed below people’s faces, such as on a
dance floor.
CAUTION! Only Laser Safety Officers who are officially certified by a regulatory body or authorized
training organization are allowed to use class 3B lasers in public. The Laser Safety Officer is responsible for
all aspects when using this laser, including following all locally applicable safety laws and regulations.
The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this laser.
CAUTION: AVOID EXPOSURE TO BEAM: Avoid direct eye contact with laser
light. Never intentionally expose your eyes or others to direct laser radiation.
Compliance Statement
Your X-Terminator laser has been designed to comply with FDA and IEC Standards for its classification.
The X-Terminator is a Class 3B laser product.
Laser Safety and Compliance Information
The X-Terminator is manufactured to comply with the IEC 60825-1 and in accordance with U.S. Food and
Drug Administration (FDA) Standards Listed under FDA Document 21 CFR 1040 and subsequent laser
notices.
Product Classification and Manufacturing Label Identification
Laser Classification Class 3B
Cooling Cooling fan and TE Cooling
Laser medium (Output) wavelength 650 nm / Red (Laser Diode), >100 mW
wavelength 532 nm / Green (DPSS), >30 mW
Laser Output 130 mW
Beam Diameter <5mm at aperture
Pulse Data All pulses < 4Hz (>0.25sec)
Divergence (each beam) <2 mrad
Divergence (total light) <160 degrees
The legal requirements for using laser entertainment products vary from country to country. The user is
responsible for the legal requirements at the location/country of use.
Further guidelines and safety programs for safe use of lasers can be found in the ANSI Z136.1 Standard
“For Safe Use of Lasers”, available from www.laserinstitute.org. Many local governments, corporations,
agencies, military and others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser
Display guidance can be obtained via the International Laser Display Association, www.laserist.org.

6
Ordercode: 43157
X-Terminator
CAUTION: The use of corrective eye wear or optics for viewing at distances such as telescopes or
binoculars within a distance of 100mm may pose an eye hazard.
This laser product is a Class 3B laser and has an interlocked
housing.
There are no user serviceable parts inside. Tampering or
removing warranty seals will void your products limited
warranty.
Combo label with the Product Model Number, Serial Number,
Date of Manufacturing, Laser Light Warning Label, Warranty
Void Label and Interlocked Housing Label
Proper Usage Safety and Compliance Information
According to FDA Regulations you should
operate this product as stated on the left.
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
●If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
●Use a clamp to mount the projector, with the mounting-bracket, to the trussing system.
●The projector must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
a safety cable.
●When rigging, derigging or servicing the projector, always make sure that the area below the
installation is unavailable for any unauthorized persons.
Improper installation can cause serious injuries and damage of property !

7
Ordercode: 43157
X-Terminator
The X-Terminator can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious damage to people and property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International EU Cable UK Cable US Cable Pin
L BROWN RED YELLOW/COPPER PHASE
N BLUE BLACK SILVER NEUTRAL
YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!

8
Ordercode: 43157
X-Terminator
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

9
Ordercode: 43157
X-Terminator
Description of the device
Features
The X-Terminator is a laser effect with high output and great effects.
•When using multiple units together, you can make a dazzling and cost effective beam show
•Power Input: AC 100-240V, 60/50Hz
•Power Consumption: 40 Watt
•Beam Diameter <5mm at aperture
•Laser Class: 3B
•Strobe: 0-30Hz
•Laser Safety: EN/IEC 60825-1 Ed 2, 2007-03
•LED Color: Red, Green, Blue + White and Amber
•Laser Color: Red, Green
•Light source: 12 x 0,5W LED
•Laser Power: 130mW (100mW 650nm Red, 30mW 532nm Green)
•Control Modes: DMX-512, Built-in Programs, Master/Slave, Sound-controlled, IR remote controlled
•Divergence (each beam) <2 mrad; Divergence (total light) <160 degrees
•3-pin DMX In and 3-pin DMX Out
•Clear red LED display for all settings
•Compact strong metal housing
•Sound-controlled via built-in microphone
•2 and 11 DMX channel modes
•Safety Features: Key switch, Interlock
•Fuse: 1,6AL/250V
•Dimensions: 335 x 215 x 197 mm (LxWxH)
•Weight: 2,5 kg
Frontside
Fig. 01
01) LED lens A
02) Remote control LED indicator
03) Laser lens
04) LED lens B
05) Cooling fan
06) Mounting bracket with inclined screw

10
Ordercode: 43157
X-Terminator
Backside
Fig. 02
07) Safety eye
08) 3-pin DMX signal connector OUT
09) 3-pin DMX signal connector IN
10) LED Display + LED indicators + control buttons
11) Sound sensitivity control
12) Ground/earth connection
13) IEC Power connector AC 100-240V OUT
14) IEC Power connector AC 100-240V IN + Fuse 1,6AL/250V
15) Interlock
16) Remote control plug

11
Ordercode: 43157
X-Terminator
IR Remote Control
Button Function Description
On / Off Power on / off
Auto Mode Set the auto mode
Sound-controlled Mode Set the sound-controlled mode
LED Mode Set the LED mode
Laser Mode Set the laser mode
Flash Mode Set the flash mode
Auto / Sound switch Switch between auto / sound modes
Pause Play/pause the show
Color changing Select the LED color
Numeric keys Program speed adjustment (1-9)
Attention:
Any settings saved with the remote control will be stored until the system has been rebooted.
Installation
Remove all packing materials from the X-Terminator. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply. The device can be music-controlled by its built-in
microphone.

12
Ordercode: 43157
X-Terminator
The Interlock plug/remote plug and safety keys are included in the box.
The interlock is the “included-in-the-box” successor for the optional remote interlock (51316)
They should be kept with the X-Terminator laser !!!
The following safety precautions should be followed:
●The interlock plug should be placed on the backside (16) of your
X-Terminator laser.
●The keys should be put into the lock (15) of your X-Terminator
laser.
Warning
Exclusion of liability
Be aware that in some countries, there are additional regulations, regarding the use of laser devices.
Therefore, we strongly advise you to verify your national laws with your authorities: We do not take any
responsibility for eventual discrepancies, changes or adaptions regarding lawful use of laser devices.

13
Ordercode: 43157
X-Terminator
Control Modes
There are 4 modes: Stand-alone (built-in programs)
Sound-controlled
Master/Slave
DMX-512 (11CH)
One X-Terminator (Stand-alone)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the X-Terminator is not connected by a DMX-cable, it functions as a stand-alone device.
05) Please see page 18 for more information about the Built-in auto programs.
One X-Terminator (Sound-controlled)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the X-Terminator is not connected with a DMX-cable, it functions as a stand-alone device.
05) Please see page 18 for more information about the Sound-controlled mode.
Multiple X-Terminators (Master/Slave Mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the X-Terminators.
The pins: 01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in Fig. 03, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on page 18 (Built-in or Sound-controlled).
This means that you can set your desired operation mode on the master device and all slave
devices will react the same as the master device.
Multiple X-Terminators Master/Slave Set Up
Fig. 03

14
Ordercode: 43157
X-Terminator
Multiple X-Terminators (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 1 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-p XLR cable to connect the X-Terminators and other devices.
05) Link the units as shown in Fig. 04, Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple X-Terminators DMX Set Up
Fig. 04
Note: Link all cables before connecting electric power

15
Ordercode: 43157
X-Terminator
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important: Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio Certified DMX Data Cables
• DAP Audio cable for all-round use. bal. XLR/M 3 p. > XLR/F 3 p.
Ordercode FL01150 (1,5m.), FL013 (3m.), FL016 (6m.), FL0110 (10m.), FL0115 (15m.), FL0120 (20m.).
• DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5m.), FL713 (3m.), FL716 (6m.), FL7110 (10m.).
The X-Terminator can be operated with a controller in control mode or without the controller in stand-
alone mode.

16
Ordercode: 43157
X-Terminator
Control Panel
A) LED display
B) MODE button
C) UP button
D) DOWN button
E) ENTER button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the X-Terminator will respond to the controller.
Please note when you use the controller, the unit has 11 channels.
When using multiple X-Terminators, make sure you set the DMX addresses right.
Therefore, the DMX address of the first X-Terminator should be 1(001); the DMX address of the second X-
Terminator should be 1+11=12 (012); the DMX address of the third X-Terminator should be 12+11=23 (023),
etc. Please, make sure that you do not have any overlapping channels in order to control each X-
Terminator correctly.
If two or more X-Terminators are addressed similarly, they will work similarly.
Controlling:
After having addressed all X-Terminator fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the X-Terminator will automatically detect whether DMX-512 data is received or
not. If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the X-Terminator.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MODE, UP, DOWN or ENTER button.
Once you have pressed one of the buttons, the display will light up.

17
Ordercode: 43157
X-Terminator
Menu Overview

18
Ordercode: 43157
X-Terminator
Main Menu Options
Built-in programs
Sound-controlled
Master/Slave
DMX-512
System Settings
1. Built-in Shows
01) Press the MODE button until the display shows .
02) Press the ENTER button to enter the menu.
03) Press the UP and DOWN buttons to run one of the built-in shows: .
04) Once your preferred show has been chosen, press the ENTER button to proceed to
speed settings.
05) Press the UP and DOWN buttons to adjust the speed of your preferred built-in show:
. The higher the value the faster the speed.
2. Sound-controlled Effect
This effect makes the unit respond to the beats of background music, being intercepted by the built-in
microphone.
01) Press the MODE button until the display shows .
02) Press the ENTER button to enter the menu.
03) Press the UP and DOWN buttons to run one of the sound-controlled shows: .
04) Turn the control (11) on the rear panel to the left or right to, respectively, decrease or increase
sensitivity of the device to background music.
3. Master/Slave Mode
01) Press the MODE button until the display shows .
02) Press the ENTER button. will appear on the display.
03) The laser is now operating in Slave mode and it will react the same as the master device.
4. DMX Mode
With this menu you can set the desired DMX address.
01) Press the MODE button until the display shows .
02) Press the ENTER button again, the display will show .
03) Press the ENTER button to enter the DMX Mode menu.
04) Press UP and DOWN buttons to choose one of the two available DMX modes:
2 channels
11 channels
05) If the display shows , press the ENTER button to enter the menu.
06) Press the UP and DOWN buttons to select the DMX address between .
07) If the display shows , press the ENTER button to enter the menu.
08) Press the UP and DOWN buttons to select the DMX address between .

19
Ordercode: 43157
X-Terminator
5. System Settings
01) Press the MODE button until the display shows .
02) Press the ENTER button to enter the menu.
03) There are 3 options available. Press the UP and DOWN buttons to toggle between them:
Power saving mode
System Reset
Test Mode
If the display shows , press the ENTER button to enter the menu.
04) Press UP and DOWN buttons to choose between .
05) If the device is set to ON, it is operating in the power saving mode. If the device is set to OFF, the
power saving mode is inactive.
If the display shows , press the ENTER button to enter the menu.
06) will appear shortly on the display.
07) When it disappears, the device will return to the previously active mode and the settings will be reset
to the factory values.
If the display shows , press the ENTER button to enter the menu.
08) It is now possible to test if all the features available on the device work properly.
09) It is possible to use the included remote control (page 11, Remote Control).
DMX Channels
2 channels
Channel 1 – Built-in programs
0-9 Off
10-26 AUT0
27-43 AUT1
44-60 AUT2
61-77 AUT3
78-94 AUT4
95-111 AUT5
112-127 AUT6
128-145 SOU0
146-163 SOU1
164-181 SOU2
182-199 SOU3
200-217 SOU4
218-235 SOU5
236-255 SOU6
Channel 2 – Speed (Ch 1 must be set between 10-127 )
0-255 Speed control, from slow to fast
