Show Tec Booster 2 User manual

Service Manual
BOM code(26-024-0040-00)
Website:www.highlite.nl
E-male sales:[email protected]
E-mail export:[email protected]
Rev1.0

Complete Exploded View
& Parts List

Physical Dimensions

Complete Exploded View

Complete Exploded View Parts List
Item part Number Description Qty
1 22-003-0003-00 Screws 12
2 23-150-0028-00 Top Cover 1
3 20-002-0019-00 Fuse Holder 1
4 20-001-0017-00 Fuse 1
5 25-003-0003-00 Cable NUT 1
6 17-001-0022-00 Power Cable 1
7 27-001-0534-00 KIT DMX-F DMX SOCKET 5PIN 2
8 22-001-0037-00 Screws 9
9 27-001-0217-00 KIT DD-2 1
10 23-001-0364-00 Chassis 1
11 25-014-0002-00 Rubber Feet 4
12 22-001-0037-00 Screws 9
13 27-001-0531-00 KIT DMX-F DMX Socket 3PIN 2
14 27-001-0533-00 KIT DMX-M DMX SOCKET 5PIN 1
15 27-001-0532-00 KIT DMX-M DMX SOCKET 3PIN 1

PCB Schematic
Diagrams

120V
0V
0V
9V
0V
9V
120V
TRAN SFOR M ER
1.8VA
100m A
S-
S+
RED LED
120V U SE J5,J6
120V 230V CH AN G E TR A N SFO R M ER
230V U SE FU SED
230V NO USE FUSE
3
2
1
J1
DM X- IN
DI 4
RO 1
GND
5
DE
3
RE
2
D/R
6
D/R
7
VCC 8
U1
75176
12
C1
104
12
R8
100K
12
R9
100K
5
1
3
24
J7
DM X- IN- 5P
1 2 3 45
6 7
T1
1
2
F1
FUSE
A
1K2
D5
1N4007
A
1K2
D6
1N4007
12
C2
470U/25V
12
C3
474
VI
1
GND
2
VO 3
U7
L M 7805
12
C4
100U/16V
12
C5
104
1
J3
1
J4
12
J5
12
J6
21
D3
LED
12
R16
510R
GND
+5V
N- IN
L-IN
GND
GND
+5V
GND
+5V
+5V
GND
L-IN N- IN
DM X
1
2
J40
N- IN
L3
600R@ 100M
L2
600R@ 100M
L 1 600R@ 100M
Schematic Diagram for DD-2A

120V
0V
120V
0V
9V
0V
9V
1.8VA
120V
120V
0V
0V
9V
9V
0V
1.8VA
TRAN SFOR M ER
TRAN SFOR M ER
100m A
100m A
120V U SE J14,J15
120V U SE J22,J23
S-
S+
S-
S-
S-
S+ S+
S+
230V U SE FU SED
120V 230V CH A N G E TR AN SFO R M ER
120V 230V C H AN G E TR AN SFO R M ER
230V USE FUSED
230V N O U SE FU SE
230V N O U SE FU SE
12
R13
330R
12
R14
4K 7
12
R15
330R
DI 4
RO 1
GND
5
DE
3
RE
2
D/R
6
D/R
7
VCC 8
U11
75176
3
2
1
J9
DMX- OUT
15
3
4
2
J32
DMX- OUT- 5P
1 2 3 45
6 7
T2
12
F2
FUSE
A
1K2
D1
1N4007
A
1K2
D2
1N4007
12
C6
470U/25V
12
C7
474
VI
1
GND
2
VO 3
U3
LM7805
12
C8
100U/16V
12
C9
104
12
J14
12
J15
12
C22
104
1 2 3 45
6 7 8
U14
6N137
DI
4
RO
1
GND
5
DE 3
RE 2
D/R 6 D/R 7
VCC 8
U12
75176
12
R4
330R
12
R5
4K 7
12
R6
330R
DI 4
RO 1
GND
5
DE
3
RE
2
D/R
6
D/R
7
VCC 8
U9
75176
3
2
1
J20
DMX- OUT
15
3
4
2
J33
DMX- OUT- 5P
1 2 3 45
6 7
T4
1
2
F4
FUSE
A
1K2
D7
1N4007
A
1K2
D8
1N4007
12
C15
470U/25V
12
C16
474
VI
1
GND
2
VO 3
U10
LM7805
12
C17
100U/16V
12
C18
104
12
J22
12
J23
12
C19
104
1 2 3 45
6 7 8
U13
6N137
DI
4
RO
1
GND
5
DE 3
RE 2
D/R 6 D/R 7
VCC 8
U15
75176
+5V
VCC1
VCC1
DMX
VCC1
L-IN N-IN
VCC1
+5V
VCC1
VCC1
VCC2
DMX
L-IN N-IN
VCC2
+5V
VCC2
VCC2
VCC2
VCC2
12
J8
12
J2
N-IN
N-IN
N-IN
L6
600R @ 100M
L5
600R @ 100M
L4
600R @ 100M
L9
600R @ 100M
L8
600R @ 100M
L7
600R @ 100M
L10600R @ 100M
L11
600R @ 100M
L12600R @ 100M
L13
600R @ 100M
L14
600R @ 100M
L15
600R @ 100M
Schematic Diagram for DD-2B

Bill of Materials for KIT DD-2
(
27-001-0217-00
)
Item Part Number Description Qty Location
1 01-004-0001-00 Regulator L7805CV 1.5A 3 U3,U7,U10
2 01-005-0008-00 IC SN75176 DIP8 5 U1,U9,U11,U12,U15
3 01-006-0015-00 IC 6N137 QTC DIP8 2 U13,U14
4 02-001-0038-00 CF-Resistance 330 OHM 4 R4,R6,R13,R15
5 02-001-0042-00 CF-Resistance 510 OHM 1 R16
6 02-001-0062-00 CF-Resistance 4.7K OHM 2 R5,R14
7 02-001-0091-00 CF-Resistance 100K OHM 2 R8,R9
8 03-002-0011-00 Electrolytic Capacitor 100uF/16V 3 C4,C8,C17
9 03-002-0026-00 Electrolytic Capacitor 470uF/25V 3 C2,C6,C15
10 03-003-0011-00 MONO Capacitor 0.1uF/63V 6 C1,C5,C9,C18,C19,C22
11 03-003-0012-00 Mono Capacitor 0.47uF/63V 3 C3,C7,C16
12 04-001-0003-00 Diode 1N4007 DO-41 1A/1000V 6 D1,D2,D5-D8
13 10-005-0068-01 Transformer 3 T1,T2,T4
14 12-006-0011-00 LED Red 1 D3
15 16-001-0049-00 Terminal Blade 2 J3,J4
16 16-001-0104-00 Header 2.00mm 3Pin 5 J7,J9,J32,J20,J33
17 28-001-0759-00 Part DD-2 SMD-KIT 1

Bill of Materials for KIT DD-2 SMD
(
28-001-0759-00
)
Item Part Number Description Qty Location
1 07-007-0087-00 SMD Coil 15 L1-L15
2 18-001-0025-01 PCB DD-2 1

Schematic Diagram for DMX-F

Bill of Materials for KIT DMX-F
(
27-001-0531-00
)
Item Part Number Description Qty Location
1 16-001-0121-0
0
Header 2.00mm 3pin 1 J2
2 16-001-0210-0
0
XLR 3Pin 1 J1
3 18-001-0248-0
0
PCB DMX-F 1

Bill of Materials for KIT DMX-F
(
27-001-0534-00
)
Item Part Number Description Qty Location
1 16-001-0121-00 Header 2.00mm 3pin 1 J2
2 16-001-0214-00 XLR 5Pin 1 J1
3 18-001-0248-00 PCB DMX-F 1

Schematic Diagram for DMX-M

Bill of Materials for KIT DMX-M
(
27-001-0532-00
)
Item Part Number Description Qty Location
1 16-001-0121-00Header 2.00mm 3pin 1 J2
2 16-001-0209-00XLR Chassis Connectors 3Pin 1 J1
3 18-001-0249-00PCB DMX-M 1

Bill of Materials for KIT DMX-M
(
27-001-0533-00
)
Item Part Number Description Qty Location
1 16-001-0121-00 Header 2.00mm 3pin 1 J2
2 16-001-0213-00 XLR 5Pin 1 J1
3 18-001-0249-00 PCB DMX-M 1
