Show Tec ACT Fresnel 50 WW User manual

ACT Fresnel 50 WW V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Order code: 34011
MANUAL
ENGLISH

1
Order code: 34011
ACT Fresnel 50 WW
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................5
Angle Adjustment ......................................................................................................................................................5
Connection with the Mains.........................................................................................................................................6
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the Device ................................................................................................................................................7
Features ..........................................................................................................................................................................7
Overview ........................................................................................................................................................................7
Installation...........................................................................................................................................................................9
Setup and Operation ........................................................................................................................................................9
Multiple Fixtures Power Linking ...................................................................................................................................9
Beam Angle Adjustment .............................................................................................................................................9
Barndoor Installation ..................................................................................................................................................10
Color Frame Installation.............................................................................................................................................10
Control Modes.............................................................................................................................................................11
One ACT Fresnel (Manual Control) ......................................................................................................................11
Multiple ACT Fresnels (DMX Control) ....................................................................................................................12
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Main Menu Overview.................................................................................................................................................15
Start-up..........................................................................................................................................................................16
Main Menu Options....................................................................................................................................................16
1. DMX Functions......................................................................................................................................................16
1.1 DMX Address ......................................................................................................................................................17
1.2 DMX Channel Mode .........................................................................................................................................17
1.3 DMX Fail...............................................................................................................................................................17
1.4 View DMX Value ................................................................................................................................................17
2. Manual Settings ...................................................................................................................................................18
3. Fixture Settings......................................................................................................................................................18
4. Display Settings ....................................................................................................................................................19
5. Fixture Test .............................................................................................................................................................19
5.1 Manually Defined ..............................................................................................................................................19
6. Fixture Information ...............................................................................................................................................20
7. Special Functions.................................................................................................................................................20
DMX Channels .............................................................................................................................................................21
1 Channel..................................................................................................................................................................21
2 Channels ................................................................................................................................................................21
Maintenance....................................................................................................................................................................22
Replacing the Fuse.....................................................................................................................................................22
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25

2
Order code: 34011
ACT Fresnel 50 WW
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture will be returned in the original factory box and
packing.
Your shipment includes:
●Showtec ACT Fresnel 50 WW
●Barndoor
●Color frame
●Schuko to pro-power cable (1,5 m)
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual

3
Order code: 34011
ACT Fresnel 50 WW
Before the initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
●Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
●Never modify, bend, mechanically strain, put pressure on, pull or heat up the power cord.
●Never strain the cable insert. There must always be sufficient cable going to the device. Otherwise,
the cable will be damaged, which can cause serious damage.
●Never remove warning or informative labels from the unit.
●Never use anything to cover the ground contact.
●Never place any material over the lens.
●Never look directly into the light source.
●Never leave any cables lying around.
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals, as this will reduce the device’s life.
●Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Only use the device indoors, avoid contact with water or other liquids.
●Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
●Only operate the device after having familiarized with its functions.
●Avoid flames and do not put close to flammable liquids or gases.
●Always keep the covers closed while operating.
●Always allow free space of at least 0,5 m around the unit for ventilation.
●Always disconnect power from the mains when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
●Make sure that the device is not exposed to extreme heat, moisture or dust.
●Make sure that the available voltage is not higher than stated on the rear panel.
●Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
●If the lens is obviously damaged, it has to be replaced to prevent its functions from being impaired,
due to cracks or deep scratches.
●If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
●If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water may damage your device. Leave the
device switched off until it has reached room temperature.
●If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
●For adult use only. The device must be installed beyond the reach of children. Never leave the unit
running unattended.
●Never attempt to bypass the thermostatic switch or fuses.
●For replacement use fuses of same type and rating only.
●The user is responsible for correct positioning and operating of the device. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.

4
Order code: 34011
ACT Fresnel 50 WW
●This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
●Repairs, servicing and electric connection must be carried out by a qualified technician.
●WARRANTY: Till one year after date of purchase.
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light output and the illuminated surface must be bigger than 1 m.
●In order to eliminate wear and improve the device’s lifespan, during periods of non-use, completely
disconnect from power source via breaker or by unplugging.
●The maximum ambient temperature ta= 40 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!

5
Order code: 34011
ACT Fresnel 50 WW
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
●If the device is lowered from the ceiling or high joists, professional trussing systems have to be used.
●Use a clamp to mount the device with the mounting bracket to the trussing system.
●The device must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
●If the barndoor or the color filter is installed, it must be secured with a safety cable.
●When rigging, derigging or servicing the device, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
Improper installation can cause serious injuries and/or damage of property!
Angle Adjustment
You can adjust the angle of the device with the adjustment handle (06).
01) Turn the adjustment handle (06)counterclockwise to release it.
02) Tilt the device at the desired angle (see Fig. 01).
03) Turn the adjustment handle (06) clockwise to tighten it. Make sure that the device cannot move
freely after the adjustment handle (06) is tightened.
Fig. 01

6
Order code: 34011
ACT Fresnel 50 WW
Connection with the Mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Order code: 34011
ACT Fresnel 50 WW
Description of the Device
Features
The Showtec ACT Fresnel 50 WW is a compact theater spot suitable for galleries, museums, exhibition
halls, and theaters, where high CRI performance is essential. The device is equipped with a high quality
molded-glass Fresnel lens.
●Input voltage: 100–240 V AC, 50/60 Hz
●Power consumption: 57 W
●Light source: 1 x 50 W Warm White COB LED
●Beam angle: 10°–58° (manual adjustment)
●Output: 10° –3430 lx @ 2 m
58° –402 lx @ 2 m
●Color temperature: 3200 K
●Light quality: CRI 98
●Dimmer: 0–100 %
●Strobe effect: Yes
●Zoom: Manual
●Connections: Pro-power connectors IN/OUT, 3-pin DMX signal connectors IN/OUT
●DMX channels: 1- and 2-channel mode
●Control: DMX, Manual
●Display: OLED
●Housing: Extruded aluminum
●Color: Black
●Cooling: Internal fan
●IP Rating: IP20
●Fuse: T1 AL/250 V AC
●Dimensions: 245 x 165 x 239 mm (L x W x H) (without accessories)
●Weight: 1,8 kg (without accessories)
Overview
Fig. 02
01) Spring-loaded screw
02) Color frame clip
03) Fresnel lens
04) 3 x Color frame holders
05) Zoom control
06) Adjustment handle
07) Safety eye
08) Mounting bracket

8
Order code: 34011
ACT Fresnel 50 WW
Backside
Fig. 03
09) Control panel: OLED display and control buttons
10) 3-pin DMX signal connector OUT
11) Fuse T1 AL/250 V AC
12) Pro-power connector OUT 100–240 V, 7A, 50/60 Hz (Gray)
13) Pro-power connector IN 100–240 V, 7A, 50/60 Hz (Blue)
14) 3-pin DMX signal connector IN
15) Manual dimmer control
Accessories
Fig. 04
Fig. 05
16) Safety eye –barndoor
17) Safety eye –color frame

9
Order code: 34011
ACT Fresnel 50 WW
Installation
Remove all packing materials from the ACT Fresnel 50 WW. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Setup and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120 V specification product on 230 V power, or vice versa.
Connect the device to the main power supply.
Multiple Fixtures Power Linking
The ACT Fresnel 50 WW supports power linking. Power can be relayed to another device via the power
OUT connector. Note that the input and the output connectors have different designs: one type cannot
be connected to the other.
To link fixtures in a chain, a hard usage cable with appropriate cable jacket must be used. Power linking
cables are available for purchase from Highlite International.
To prevent power overload and damage to the fixture, do not link more fixtures in one chain than
recommended. After you have reached the maximum number of fixtures, use a new power outlet.
Maximum recommended number of fixtures on a power link @ 110 V: 10 fixtures
Maximum recommended number of fixtures on a power link @ 240 V: 15 fixtures
Beam Angle Adjustment
The beam angle of the ACT Fresnel 50 WW can be adjusted manually in the range 10°–58°. To adjust the
beam angle, follow the steps below:
01) Turn the zoom control (05)counterclockwise to loosen it.
02) Slide the zoom control (05) forwards or backwards to achieve the desired beam angle (see Fig. 06).
03) After adjusting the beam angle, turn the zoom control (05)clockwise to tighten it. Do not
overtighten it.
Fig. 06

10
Order code: 34011
ACT Fresnel 50 WW
Barndoor Installation
The ACT Fresnel 50 WW is delivered with a barndoor. To install the barndoor, follow the steps below:
01) Push the spring-loaded screw (01) and at the same time lift the color frame clip (02) and flip it
backwards (see Fig. 07).
02) Insert the barndoor into the color frame holders (04) (see Fig. 08).
03) Pull the color frame clip (02) downwards to release the spring-loaded screw (01) (see Fig. 09). The
barndoor will be locked in position.
04) Secure the barndoor to the trussing with an appropriate secondary attachment, for example a
safety cable. See Rigging on page 5.
Fig. 07
Fig. 08
Fig. 09
Make sure that the barndoor is locked in position with the color frame clip before using
the ACT Fresnel 50 WW.
Color Frame Installation
The ACT Fresnel 50 WW is delivered with a color frame. You can insert a color gel or a diffusion filter into
the color frame. To install the color frame, follow the steps below:
01) Push the spring-loaded screw (01) and at the same time lift the color frame clip (02) and flip it
backwards (see Fig. 10).
02) Insert a color gel or a diffusion filter into the color frame.
03) Insert the color frame into the color frame holders (04) (see Fig. 11).
04) Pull the color frame clip (02) downwards to release the spring-loaded screw (01) (see Fig. 12). The
color frame will be locked in position.
05) Secure the color frame to the trussing with an appropriate secondary attachment, for example a
safety cable. See Rigging on page 5.
Fig. 10
Fig. 11
Fig. 12
Make sure that the color frame is locked in position with the color frame clip before using
the ACT Fresnel 50 WW.

11
Order code: 34011
ACT Fresnel 50 WW
Control Modes
There are 2 modes:
●Manual control
●DMX-512 (1CH, 2CH)
One ACT Fresnel (Manual Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Secure the device with a safety cable (order code 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
When the ACT Fresnel is not connected with a DMX cable, it functions as a stand-alone device. It can
be controlled via the manual dimmer control or the menu settings.
Manual control via the manual dimmer control
01) Select the option Rotary Knob in the Manual Settings menu. Refer to 2. Manual Settings on
page 18 for more information.
02) Exit the submenu and return to the start screen. The start screen shows now the following:
03) Turn the manual dimmer control (15)to adjust the intensity of the light. The adjustment range is
between 0 and 255 (from 0 to 100 %). The current value of the dimmer is displayed on the screen.
Note: If you do not return to the start screen you cannot adjust the dimmer. The manual dimmer
control (15)is not functional, if you do not exit the menu and return to the start screen.
Note: In this mode you can control only the intensity of the light. It is not possible to add a strobe effect.
Manual control via the menu settings
01) Select the option Manually Defined in the Manual Settings menu. Refer to 2. Manual Settings on
page 18 for more information.
02) Select values for the Dimmer and the Strobe in the Fixture Test menu. Refer to 5.1 Manually Defined
on page 19 for more information.
03) Exit the submenu and return to the start screen to activate the manual settings. The start screen
shows now the following:
Note: If you do not return to the start screen, the manual settings will not be activated.

12
Order code: 34011
ACT Fresnel 50 WW
Multiple ACT Fresnels (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Secure the device with a safety cable (order code 70140 / 70141).
03) Use a 3-pin DMX cable to connect the ACT Fresnel and other devices.
04) Link the units as shown in Fig. 13. Connect a light controller to the first unit's DMX "in" socket, using a
DMX cable. Connect the first unit’s "out" socket with the second unit's "in" socket, using a DMX
cable. Repeat this process to link the rest of the units.
05) Supply electric power: Plug electric mains power cords into each unit's power IN socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
06) Refer to 1. DMX Functions on pages 16–17 for more information about the DMX settings.
Fig. 13
Note: Link all cables before connecting electric power

13
Order code: 34011
ACT Fresnel 50 WW
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of an optically
isolated DMX splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
●DAP Audio 110 Ohm cable with digital signal transmission. Order code FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
●DAP Audio DMX Terminator 3-pin. Order code FLA42.
Note: Use of 3-pin XLR audio cables for DMX data transmission might lead to signal degradation and
unreliable operation of the DMX network.

14
Order code: 34011
ACT Fresnel 50 WW
Control Panel
A) OLED display
B) ENTER button
C) DOWN button
D) UP button
E) MENU button
Fig. 14
DMX Addressing
The control panel on the back side of the fixture allows you to assign the fixture a DMX address, which is
the first channel with which the ACT Fresnel will respond to a DMX controller.
When using multiple ACT Fresnels, make sure you set the DMX addresses right. The device has 2channels.
Therefore, the DMX address of the first ACT Fresnel should be 1 (001); the DMX address of the second
ACT Fresnel should be 1+2=3 (003); the DMX address of the third ACT Fresnel should be 3+2=5 (005), etc.
Make sure that you do not have any overlapping channels in order to control each ACT Fresnel correctly.
If two or more ACT Fresnels are addressed similarly, they will work similarly.
Controlling:
After having addressed all ACT Fresnels, you may now start operating these via your lighting controller.
After switching on, the ACT Fresnel will automatically detect whether DMX 512-data is received or not. If
there is no data received at the DMX input, the problem may be:
●The DMX cable from the controller is not connected with the input of the ACT Fresnel.
●The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert a termination plug (with 120 Ohm) in the last fixture in order to ensure proper
transmission on the DMX data link.

15
Order code: 34011
ACT Fresnel 50 WW
Main Menu Overview

16
Order code: 34011
ACT Fresnel 50 WW
Start-up
Upon start-up the display will show a splash screen with the name of the device:
Immediately afterwards, the display will show the start screen. The start screen provides information about
the current control mode of the device and the temperature of the LEDs.
Manual mode via the manual
dimmer control
Manual mode via the menu
DMX mode
●Use the MENU button to exit the current submenu, to return to the Main Menu or to return to the start
screen.
●Use the UP/DOWN buttons to navigate through the menus or to increase/decrease numeric values.
●Use the ENTER button to open the desired menu, to confirm your choice or to set the currently
selected value.
Note:
If no button is pressed, after 30 seconds of inactivity the display will turn off. Press any button to turn the
display on. Refer to 4. Display Settings on page 19 for more information.
Main Menu Options
The main menu has the following options:
01) Press the UP/DOWN buttons to navigate through the Main Menu.
02) Press the ENTER button to open the menus.
1. DMX Functions
In this menu you can configure the DMX settings of the device.
01) Press the UP/DOWN buttons to scroll through the following options:
02) Press the ENTER button to confirm your choice.

17
Order code: 34011
ACT Fresnel 50 WW
1.1 DMX Address
In this pop-up submenu you can set the starting DMX address of the device.
01) Press the UP/DOWN buttons to select the starting DMX address of the device. The selection range is
between 1 and 512.
02) Press the ENTER button to confirm the selection.
1.2 DMX Channel Mode
In this pop-up submenu you can select the DMX channel mode.
01) Press the UP/DOWN buttons to select the desired DMX channel mode. There are 2 options available:
1 Channel
2 Channel
02) Press the ENTER button to confirm the selection.
1.3 DMX Fail
In this pop-up submenu you can determine the behavior of the device in case of a DMX signal failure.
01) Press the UP/DOWN buttons to select one of the following 3 options:
●Manually Defined: The device will use the dimmer value selected with the manual dimmer
control (15)in manual mode. Refer to One ACT Fresnel (Manual Control) on
page 11 for more information
●Hold: The device will use the last properly received DMX signal
●Blackout: The device will black out the light output
02) Press the ENTER button to confirm your choice.
1.4 View DMX Value
In this submenu you can view the currently selected DMX value for each DMX channel. If you have
selected 1-channel DMX mode, only the Dimmer value will be visible on the screen. If you have selected
2-channel DMX mode, both the Dimmer and the Strobe values will be visible on the screen.
1-channel DMX mode
2-channel DMX mode

18
Order code: 34011
ACT Fresnel 50 WW
2. Manual Settings
In this menu you can select how the device will be operated manually.
01) Press the ENTER button to open the pop-up submenu for the manual mode settings.
02) Press the UP/DOWN buttons to select one of the following 2 options:
●Rotary Knob: The dimming of the light output is controlled manually with the manual
dimmer control (15).Refer to One ACT Fresnel (Manual Control) on page 11
for more information
●Manually Defined: The dimming of the light output is controlled manually via the menu. Refer
to One ACT Fresnel (Manual Control) on page 11 for more information
03) Press the ENTER button to confirm your choice.
3. Fixture Settings
In this menu you can adjust the fixture settings.
01) Press the UP/DOWN buttons to toggle between Dimmer Curve and Dimmer Speed.
●Dimmer Curve: There are 4 options available: Linear, Square Law, Inverse Square Law and
S-Curve
●Dimmer Speed: There are 2 options available: LED (instant dimming without delay) and
Halogen (delayed dimming, imitating the behavior of a halogen lamp)
02) Press the ENTER button to confirm your choice.

19
Order code: 34011
ACT Fresnel 50 WW
4. Display Settings
In this menu you can adjust the display settings of the device.
01) Press the UP/DOWN buttons to scroll through the following options:
02) Press the ENTER button to confirm the selection and open the pop-up submenu where you can
adjust the settings.
03) Press the UP/DOWN buttons to select the desired setting.
04) Press the ENTER button to confirm the selection.
The available options are:
●Display Inverse: The OLED display will be rotated at 180° (NO/YES)
●Backlight Auto Off: The backlight of the OLED display will not turn off automatically after 30
seconds of inactivity (NO/YES)
●Display Contrast: The adjustment range is between 0 and 30 (from low to high contrast)
5. Fixture Test
In this menu you can perform test of the device’s parameters and adjust manually the dimmer and
strobe values.
01) Press the UP/DOWN buttons to select one of the following 2 options:
●Auto Test: The device performs an auto test of its parameters.
●Manually Defined: See 5.1 Manually Defined for more information
02) Press the ENTER button to confirm your choice.
5.1 Manually Defined
In this submenu you can manually adjust the dimmer and strobe values.
01) Press the UP/DOWN buttons to toggle between Dimmer and Strobe:
02) Press the ENTER button to confirm your selection and open the respective pop-up submenu where
you can adjust the values.
03) Press the UP/DOWN buttons to adjust the values. The adjustment range is between 0 and 255.
04) Press the ENTER button to confirm your choice.
