Show Tec Kanjo Spot 10 V2 User manual

Kanjo Spot 10 V2
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 45010
MANUAL
ENGLISH

1
Ordercode: 45010
Kanjo Spot 10
Table of contents
Warning...........................................................................................................................................................................2
Safety Instructions .....................................................................................................................................................2
Operating Determinations.......................................................................................................................................4
Rigging........................................................................................................................................................................4
Connection with the mains.....................................................................................................................................5
Return Procedure......................................................................................................................................................6
Claims .........................................................................................................................................................................6
Description of the device.............................................................................................................................................7
Features......................................................................................................................................................................7
Frontside .....................................................................................................................................................................7
Backside .....................................................................................................................................................................8
Installation ......................................................................................................................................................................8
Set Up and Operation...................................................................................................................................................8
Control Modes...........................................................................................................................................................9
One Kanjo (Auto and Manual)............................................................................................................................9
One Kanjo (Sound-controlled).............................................................................................................................9
Multiple Kanjos (Master/Slave control)...............................................................................................................9
Multiple Kanjos (DMX Control)...........................................................................................................................10
Fixture Linking...........................................................................................................................................................11
Data Cabling...........................................................................................................................................................11
Control Panel...........................................................................................................................................................12
Control Mode ..........................................................................................................................................................12
DMX Addressing......................................................................................................................................................12
Menu Overview.......................................................................................................................................................13
Main Menu Options................................................................................................................................................14
1. DMX-512 Mode.................................................................................................................................................14
2. Pan/Tilt Reverse Mode ....................................................................................................................................14
3. Operation Modes ............................................................................................................................................15
4. Channel Mode.................................................................................................................................................15
5. Display Settings.................................................................................................................................................15
6. Display Reverse Mode.....................................................................................................................................15
7. Reset ..................................................................................................................................................................16
8. Manual Mode...................................................................................................................................................16
9. Manual DMX Adjustment Mode (optional).................................................................................................16
DMX Channels.........................................................................................................................................................17
8 channels.............................................................................................................................................................17
10 channels...........................................................................................................................................................18
Maintenance................................................................................................................................................................19
Replacing the Fuse.................................................................................................................................................19
Static Gobo Wheel and Color Wheel.......................................................................................................................20
Troubleshooting ...........................................................................................................................................................20
No Light.....................................................................................................................................................................20
No Response to DMX..............................................................................................................................................20
Product Specifications................................................................................................................................................22
Dimensions ...................................................................................................................................................................23
Notes..............................................................................................................................................................................24

2
Ordercode: 45010
Kanjo Spot 10
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• Showtec Kanjo Spot 10
• IEC power cable (1,5 m)
• 1 bracket and 2 screws for truss mounting
• User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
• be qualified
• follow the instructions of this manual

3
Ordercode: 45010
Kanjo Spot 10
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the rotating gobo otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmer pack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Moving head must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 45010
Kanjo Spot 10
•The user is responsible for correct positioning and operating of the Kanjo. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Kanjo is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the Kanjo, with the mounting bracket, to the trussing system.
•The Kanjo must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Kanjo, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 45010
Kanjo Spot 10
The Kanjo can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International EU Cable UK Cable US Cable Pin
L BROWN RED YELLOW/COPPER PHASE
N BLUE BLACK SILVER NEUTRAL
YELLOW/GREEN GREEN GREEN PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 45010
Kanjo Spot 10
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 45010
Kanjo Spot 10
Description of the device
Features
The Kanjo Spot 10 is an ultra-compact moving head, equipped with a 10W White LED.
The Kanjo Spot 10 is the ideal solution for small clubs and mobile DJs.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 26W
Light source: 1 x 10W White LED
Static gobo and color wheel
DMX channels: 8, 10 channels
4-digit LED display
Control modes: Auto, Manual, Sound, Slave, DMX
Control protocol: DMX-512
Manual focus
Dimmer: 0-100%
Strobe: 0-20Hz
Pan: 540°
Tilt: 230°
Pan/Tilt resolution: 16-bit
Beam Angle: 13°
Housing: Metal & flame retardant plastic
Certification: CE
Fuse: F3AL/250V
Dimensions: 175 x 150 x 278 mm (LxWxH)
Weight: 2,6 kg
Frontside
Fig. 01
01) 10W White LED
02) 4-digit LED display + control buttons
03) Built-in microphone

8
Ordercode: 45010
Kanjo Spot 10
Backside
Fig. 02
04) 3-pin DMX signal connector IN
05) 3-pin DMX signal connector OUT
06) IEC power connector 100-240V IN + Fuse F3AL/250V
07) Cooling fan
Installation
Remove all packing materials from the Kanjo Spot 10. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 45010
Kanjo Spot 10
Control Modes
There are 5 modes: • Stand-alone (Auto)
•Manual
•Sound-controlled
•Master/Slave
•DMX-512 (8CH, 10CH)
One Kanjo (Auto and Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Kanjo is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 15-16 for more information about the Auto mode and Manual mode.
One Kanjo (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Kanjo will react to the beat of the
music. Please see page 15 for more information about the sound-control options.
Multiple Kanjos (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Kanjo.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 15-16 (Auto, Manual
or Sound-controlled mode). This means that you can set your desired operation mode on the
master device and all slave devices will react the same as the master device.
Multiple Kanjos (Master/Slave control)
Fig. 03

10
Ordercode: 45010
Kanjo Spot 10
Multiple Kanjos (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Kanjos and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Kanjos DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

11
Ordercode: 45010
Kanjo Spot 10
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important: Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

12
Ordercode: 45010
Kanjo Spot 10
The Kanjo Spot 10 can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LED display
B) MENU button
C) UP button
D) DOWN button
E) ENTER button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Kanjo will respond to the controller.
Please note, when you use the controller, the unit has 10 channels.
When using multiple Kanjos, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Kanjo should be 1(001); the DMX address of the second Kanjo
should be 1+10=11 (011); the DMX address of the third Kanjo should be 11+10=21 (021), etc.
Please, be sure that you do not have any overlapping channels in order to control each Kanjo correctly.
If two or more Kanjos are addressed similarly, they will work similarly.
Controlling:
After having addressed all Kanjo fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Kanjo will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Kanjo Spot 10.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 55 seconds
When no button is pressed for 55 seconds, the display will turn off.
To light up the display, you have to press the MENU, UP, DOWN or ENTER button.
Once you have pressed the button, the display will light up.

13
Ordercode: 45010
Kanjo Spot 10
Menu Overview

14
Ordercode: 45010
Kanjo Spot 10
Main Menu Options
1. DMX-512 Mode
2. Pan/Tilt Reverse Mode
3. Operation Modes
4. Channel Mode
5. Display Settings
6. Display Reverse Mode
7. Reset
8. Manual Mode
9. Manual DMX Adjustment Mode (optional)
1. DMX-512 Mode
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose the desired DMX address.
The adjustment range is between .
04) Press the ENTER button to confirm the address.
2. Pan/Tilt Reverse Mode
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to toggle between the following options:
Normal mode
Pan normal/ Tilt reversed
Pan reversed/Tilt normal
Pan and Tilt reversed
04) As you toggle through the available options, the moving head will flip accordingly.
05) Press the ENTER button to confirm your choice.

15
Ordercode: 45010
Kanjo Spot 10
3. Operation Modes
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose one of the 4 options:
Slave mode
Auto 1
Auto 2
Sound-controlled
04) When the display shows , press the ENTER button to activate the Slave mode. The device will
now react the same as its master.
05) When the display shows , press the ENTER button to run auto program # 1.
06) When the display shows , press the ENTER button to run auto program # 2.
07) When the display shows , press the ENTER button to activate the Sound-controlled mode. The
device will now react to the beat of the background music.
08) Once you have chosen your desired operation mode (in steps 3-7), press the MENU button to
activate it.
09) The device is now operating in the desired operation mode.
4. Channel Mode
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose one of the two available modes: .
04) Press the ENTER button to confirm your choice.
5. Display Settings
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose between the two options:
Display continuously ON
Display OFF after 55 seconds
04) Press the ENTER button to confirm your choice.
6. Display Reverse Mode
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose between the two options:
Normal view
Vertical flip view
04) Press the ENTER button to confirm your choice.

16
Ordercode: 45010
Kanjo Spot 10
7. Reset
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to activate/cancel reset. Choose between .
04) If the display shows , press the ENTER button. The device will reset the settings.
05) If the display shows , press the ENTER button. The device will return to the main menu.
8. Manual Mode
01) While in main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to choose between the two options:
Manual Mode ON
Manual Mode OFF
04) If the display shows , press the ENTER button.
05) Now it is possible to manually adjust the DMX channels (Manual DMX Adjustment Mode, see below).
06) The channel numbers correspond with their DMX functions (see chapter DMX Channels, page 17).
9. Manual DMX Adjustment Mode (optional)
Manual Mode (see above) must be set to ON for this mode to work.
For more information about the DMX channel functions, please see chapter DMX Channels,
page 17.
01) While in main menu, press the UP/DOWN buttons to choose one of the 8 or 10 available DMX
channels (depends on the currently active channel mode): .
02) Press the ENTER button to enter.
03) Press the UP/DOWN buttons to set the DMX channel values. The adjustment range of each channel is
between .
04) Press the ENTER button to save changes.

17
Ordercode: 45010
Kanjo Spot 10
DMX Channels
8 channels
Channel 1 – Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 230° and stopped at any position you wish.
Channel 3 – PAN/TILT Speed
0-255 From Max Speed (0) to Min. Speed (255)
Channel 4 – Color Wheel
0-15 White
16-31 Red
32-47 Green
48-63 Blue
64-79 Yellow
80-95 Magenta
96-111 Cyan
112-127 Orange
128-255 Color rotation, from slow to fast
Channel 5 – Static Gobo Wheel + Gobo shake
0-7 Off
8-15 Gobo 1
16-23 Gobo 2
24-31 Gobo 3
32-39 Gobo 4
40-47 Gobo 5
48-55 Gobo 6
56-63 Gobo 7
64-127 Gobo rotation, from slow to fast
128-143 Not functional
144-159 Gobo 1 shake effect, from slow to fast
160-175 Gobo 2 shake effect, from slow to fast
176-191 Gobo 3 shake effect, from slow to fast
192-207 Gobo 4 shake effect, from slow to fast
208-223 Gobo 5 shake effect, from slow to fast
224-239 Gobo 6 shake effect, from slow to fast
240-255 Gobo 7 shake effect, from slow to fast
Channel 6 – Dimmer
0-255 Dimmer intensity, from dark to brightest
Channel 7 – Strobe/Shutter Dimmer must be open
0-7 Off
8-127 Strobe ON, from low to high frequency
128-255 Random strobe, from low to high frequency

18
Ordercode: 45010
Kanjo Spot 10
Channel 8 – Functions
0-93 Not functional
94 Reset settings
95 Restore factory settings
96-255 Sound-controlled Mode
10 channels
Channel 1 – Horizontal movement (Pan)
Move the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 – Pan fine 16 bit
Channel 3 – Vertical movement (Tilt)
Move the slider up, in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 230° and stopped at any position you wish.
Channel 4 – Tilt fine 16 bit
Channel 5 – PAN/TILT Speed
0-255 From Max Speed (0) to Min. Speed (255)
Channel 6 – Color Wheel
0-15 White
16-31 Red
32-47 Green
48-63 Blue
64-79 Yellow
80-95 Magenta
96-111 Cyan
112-127 Orange
128-255 Color rotation, from slow to fast
Channel 7 – Static Gobo Wheel + Gobo shake
0-7 Off
8-15 Gobo 1
16-23 Gobo 2
24-31 Gobo 3
32-39 Gobo 4
40-47 Gobo 5
48-55 Gobo 6
56-63 Gobo 7
64-127 Gobo rotation, from slow to fast
128-143 Not functional
144-159 Gobo 1 shake effect, from slow to fast
160-175 Gobo 2 shake effect, from slow to fast
176-191 Gobo 3 shake effect, from slow to fast
192-207 Gobo 4 shake effect, from slow to fast
208-223 Gobo 5 shake effect, from slow to fast
224-239 Gobo 6 shake effect, from slow to fast
240-255 Gobo 7 shake effect, from slow to fast

19
Ordercode: 45010
Kanjo Spot 10
Channel 8 – Dimmer
0-255 Dimmer intensity, from dark to brightest
Channel 9 – Strobe/Shutter Dimmer must be open
0-7 Off
8-127 Strobe ON, from low to high frequency
128-255 Random strobe, from low to high frequency
Channel 10 – Functions
0-93 Not functional
94 Reset settings
95 Restore factory settings
96-255 Sound-controlled Mode
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The Kanjo Spot 10 requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light
output very quickly.
The cooling fans, color wheel, the gobo wheel, the gobos and the internal lenses should be cleaned
monthly, with a soft brush.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out.
If the fuse burns out, the product will not function whatsoever. If this happens, follow the directions below:
01) Unplug the unit from electric power source.
02) Insert a flat-headed screwdriver into a slot in the fuse cover. Gently pry up the fuse cover. The fuse
will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder. Reinsert the fuse cover. Be sure to use a fuse of the
same type and specification. See the product specification label for details.
