Show Tec LED Par 64 Q4-12 User manual

LED Par 64 Q4-12 V1
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 42466
MANUAL
ENGLISH

Ordercode: 42466
LED Par 64 Q4-12
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions.........................................................................................................................................................2
Operating Determinations..........................................................................................................................................4
Rigging............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside..........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation.......................................................................................................................................................8
Color frame retaining clip...........................................................................................................................................9
Control Modes...............................................................................................................................................................9
One Par (Built-in pograms and Auto) ....................................................................................................................9
One Par (Sound-controlled)....................................................................................................................................9
Multiple Pars (Master/Slave control)....................................................................................................................10
Multiple Pars (DMX Control)...................................................................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel...............................................................................................................................................................13
Control Mode..............................................................................................................................................................13
DMX Addressing..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................15
1. Built-in programs ..................................................................................................................................................15
2. Auto Mode............................................................................................................................................................16
3. DMX-512 Mode ....................................................................................................................................................16
4. Master/Slave Mode.............................................................................................................................................16
5. Sound-controlled Mode.....................................................................................................................................17
DMX Channels.............................................................................................................................................................17
4 channel ..................................................................................................................................................................17
5 channels.................................................................................................................................................................17
8 channels.................................................................................................................................................................18
Maintenance....................................................................................................................................................................20
Replacing the Fuse.....................................................................................................................................................20
Troubleshooting................................................................................................................................................................21
No Light.........................................................................................................................................................................21
No Response to DMX..................................................................................................................................................21
Product Specifications....................................................................................................................................................23
Dimensions........................................................................................................................................................................24
Notes..................................................................................................................................................................................26
1

Ordercode: 42466
LED Par 64 Q4-12
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
•Showtec LED Par 64 Q4-12
•1 x color frame
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
2

Ordercode: 42466
LED Par 64 Q4-12
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
3

Ordercode: 42466
LED Par 64 Q4-12
•The user is responsible for correct positioning and operating of the Par. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
4

Ordercode: 42466
LED Par 64 Q4-12
The Par can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
5

Ordercode: 42466
LED Par 64 Q4-12
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
6

Ordercode: 42466
LED Par 64 Q4-12
Description of the device
Features
The LED Par 64 Q4-12 is a LED parcan fixture, with high output and great effects.
•Input voltage: 100-240V, 60/50Hz
•Power consumption: 70W
•DMX channels: 4, 5 and 8 channels
•4-digit LED display
•Light source: 12 x 4-in-1 8W RGBW LED
•Light output: 3140lux
•Color mixing: RGBW
•Control modes: Built-in programs, Auto, DMX-512, Master/Slave, Sound-controlled
•Control protocol: DMX-512
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Beam angle: 40º
•Housing: Metal & Flame retardant plastic
•Connections: Schuko & 3-pin DMX IN and OUT
•Fuse: 1,5A/250V
•Dimensions: 285 x 255 x 400 mm (LxWxH)
•Weight: 3,2 kg
Frontside
Fig. 01
01) Mounting brackets with inclination screws
02) Color frame retaining clip
03) 12 x 4-in-1 8W RGBW LED
7

Ordercode: 42466
LED Par 64 Q4-12
Backside
Fig. 02
04) 4-digit LED display + menu buttons
05) 3-pin DMX signal connector OUT
06) 3-pin DMX signal connector IN
07) Fuse: 1,5A/250V
Installation
Remove all packing materials from the LED Par 64 Q4-12. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
8

Ordercode: 42466
LED Par 64 Q4-12
Color frame retaining clip
01) Press and hold down the color frame retaining clip.
02) Insert the color frame into the bracket.
03) Release the color frame retaining clip in order to secure the color frame in position.
Fig. 03
Control Modes
There are 5 modes:
•Built-in programs
•Auto
•Sound-controlled
•Master/Slave
•DMX-512 (4CH, 5CH, 8CH)
One Par (Built-in pograms and Auto)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Par is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 15-16 for more information about the Built-in programs and Auto Mode.
One Par (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Par will react to the beat of the
music. Please see page 17 for more information about the sound-control options.
9

Ordercode: 42466
LED Par 64 Q4-12
Multiple Pars (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Par.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 15-17 (Built-in
programs, Auto or Sound-controlled mode). This means that you can set your desired operation
mode on the master device and all slave devices will react the same as the master device.
Multiple Pars (Master/Slave control)
Fig. 04
10

Ordercode: 42466
LED Par 64 Q4-12
Multiple Pars (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Pars and other devices.
04) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Pars DMX Set Up
Fig. 05
Note : Link all cables before connecting electric power
11

Ordercode: 42466
LED Par 64 Q4-12
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio Certified DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3 p. > XLR/F 3 p.
Ordercode FL01150 (1,5m.), FL013 (3m.), FL016 (6m.), FL0110 (10m.), FL0115 (15m.), FL0120 (20m.).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5m.), FL713 (3m.), FL716 (6m.), FL7110 (10m.).
12

Ordercode: 42466
LED Par 64 Q4-12
The LED Par 64 Q4-12 can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) 4-digit LED display
B) MODE button
C) SETUP button
D) UP button
E) DOWN button
Fig. 06
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Par will respond to the controller.
Please note, when you use the controller, the unit has 8channels.
When using multiple Pars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Par should be 1(001); the DMX address of the second Par should
be 1+8=9 (009); the DMX address of the third Par should be 9+8=17 (017), etc. Please, be sure that you do
not have any overlapping channels in order to control each Par correctly. If two or more Pars are
addressed similarly, they will work similarly.
Controlling:
After having addressed all Par fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Par will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Par.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 15 seconds
When no button is pressed for 15 seconds, the display will turn off.
To light up the display, you have to press the MENU, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.
13

Ordercode: 42466
LED Par 64 Q4-12
Menu Overview
14

Ordercode: 42466
LED Par 64 Q4-12
Main Menu Options
Built-in programs
Auto Mode
DMX-512 Mode
Master/Slave Mode
(Manual Mode) Red
1. Built-in programs
With this mode, you can set the built-in programs.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to toggle between the 11 available built-in programs.
03) When the display shows , press the SETUP button to open the menu.
04) Press the UP/DOWN buttons to toggle between the following 15 color presets:
1. Red
2. Red, Green
3. Green
4. Green, Blue
5. Blue
6. Red, Blue
7. Red, Green, Blue
8. White
9. Red, Green, Blue, White
10. Red, White
11. Green, White
12. Blue, White
13. Yellow, White
14. Purple
15. OFF
15

Ordercode: 42466
LED Par 64 Q4-12
05) Press the SETUP button to activate the desired color preset.
06) Repeatedly press the SETUP button to toggle between the current preset’s constituent colors.
07) Press the UP/DOWN buttons to increase/decrease the intensity of the colors. The adjustment range of
each color is between 000-255, from OFF to FULL ON.
08) Press the SETUP button again to proceed to the strobe frequency settings.
09) Press the UP/DOWN buttons to increase/decrease the strobe frequency. The adjustment range is
between , from OFF to high frequency.
10) Return to step 2 and press the UP/DOWN buttons to choose one of the remaining built-in programs:
. Press the SETUP button to activate the desired built-in program.
11) Press the SETUP button to toggle between the 2 available options:
Program speed
Strobe frequency
12) When the display shows , press the UP/DOWN buttons to
increase/decrease the program speed. The adjustment range is between 01-99 (from slow to fast)
and FL (full speed).
13) When the display shows , press the UP/DOWN buttons to increase/decrease the
strobe frequency. The adjustment range is between 00-99, from OFF to high frequency.
2. Auto Mode
The device will run the built-in programs in a sequence.
01) Press the MODE button until the display shows .
02) The device will now run the built-in programs in a sequence.
3. DMX-512 Mode
With this menu you can set the DMX address and set the desired channel mode.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN button to set the desired DMX address. The address range is between 001-512.
03) Press the SETUP button to proceed to the channel mode choice menu.
04) Press the UP/DOWN buttons to choose one of the 3 following channel modes:
4-channel mode
5-channel mode
8-channel mode
05) When the display shows , press the SETUP button to open the menu.
06) Press the UP/DOWN buttons to set the ID number of each device. The adjustment range is between
. In this way, you can control up to 66 devices, instead of 30.
4. Master/Slave Mode
With this menu you can set the device as a slave.
01) Press the MODE button until the display shows .
02) The device is now operating as a slave and will react the same as the master device.
16

Ordercode: 42466
LED Par 64 Q4-12
5. Sound-controlled Mode
With this menu, you can set the device’s sound sensitivity.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN button to increase/decrease the sound sensitivity. The adjustment range is
between 00-31, from OFF to high sensitivity.
03) The device will now react to the beat of the background music.
DMX Channels
4 channel
Channel 1 – Red
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 – Green
0-255
Gradual adjustment Green, from dark to brightest
Channel 3 – Blue
0-255
Gradual adjustment Blue, from dark to brightest
Channel 4 – White
0-255
Gradual adjustment White, from dark to brightest
5 channels
Channel 1 – Dimmer
0-255
Gradual dimmer adjustment 0-100%, from dark to brightest
Channel 2 – Red Dimmer must be open
0-255
Gradual adjustment Red, from dark to brightest
Channel 3 – Green Dimmer must be open
0-255
Gradual adjustment Green, from dark to brightest
Channel 4 – Blue Dimmer must be open
0-255
Gradual adjustment Blue, from dark to brightest
Channel 5 – White Dimmer must be open
0-255
Gradual adjustment White, from dark to brightest
17

Ordercode: 42466
LED Par 64 Q4-12
8 channels
Channel 1 – Dimmer
0-255
Gradual dimmer adjustment 0-100%, from dark to brightest
Channel 2 – Red Dimmer must be open and CH7 must be set between 0-1
0-255
Gradual adjustment Red, from dark to brightest
Channel 2 – Color Presets Dimmer must be open and CH7 must be set between 2-22
0-5
Color 1
6-11
Color 2
12-17
Color 3
18-23
Color 4
24-29
Color 5
30-35
Color 6
36-41
Color 7
42-47
Color 8
48-53
Color 9
54-59
Color 10
60-65
Color 11
66-71
Color 12
72-77
Color 13
78-83
Color 14
84-89
Color 15
90-95
Color 16
96-101
Color 17
102-107
Color 18
108-113
Color 19
114-119
Color 20
120-125
Color 21
126-131
Color 22
132-137
Color 23
138-143
Color 24
144-149
Color 25
150-155
Color 26
156-161
Color 27
162-167
Color 28
168-173
Color 29
174-179
Color 30
180-185
Color 31
186-191
Color 32
192-197
Color 33
198-203
Color 34
204-209
Color 35
210-215
Color 36
216-221
Color 37
222-227
Color 38
228-233
Color 39
234-239
Color 40
240-245
Color 41
246-251
Color 42
252-255
Color 43
Channel 2 – Program Speed Dimmer must be open and CH7 must be set between 23-252
0-255
Program speed adjustment, from slow to fast
18

Ordercode: 42466
LED Par 64 Q4-12
Channel 2 – Sound Sensitivity Dimmer must be open and CH7 must be set between 253-255
0-255
Sound sensitivity adjustment, from low to high
Channel 3 – Green Dimmer must be open and CH7 must be set between 0-1
0-255
Gradual adjustment Green, from dark to brightest
Channel 4 – Blue Dimmer must be open and CH7 must be set between 0-1
0-255
Gradual adjustment Blue, from dark to brightest
Channel 5 – White Dimmer must be open and CH7 must be set between 0-1
0-255
Gradual adjustment White, from dark to brightest
Channel 6 – Strobe Dimmer must be open
0-9
Not functional
10-255
Strobe frequency adjustment, from low to high frequency
Channel 7 – Control Modes Dimmer must be open
0-1
Not functional
2-22
Program 1 (Static Color Mode)
23-45
Program 2
46-68
Program 3
69-91
Program 4
92-114
Program 5
115-137
Program 6
138-160
Program 7
161-183
Program 8
184-206
Program 9
207-229
Program 10
230-252
Program 11
253-255
Sound-controlled Mode
Channel 8 – ID Address
0-9
ID.01-ID.66
10-19
ID.01
20-29
ID.02
30-39
ID.03
40-49
ID.04
50-59
ID.05
60-69
ID.06
70-79
ID.07
80-89
ID.08
90-99
ID.09
100-109
ID.10
110-119
ID.11
120-129
ID.12
130-139
ID.13
140-149
ID.14
150-159
ID.15
160-169
ID.16
170-179
ID.17
180-195
ID.18
196-199
ID.19
200-209
ID.20
210
ID.21
211
ID.22
19
