Source Four Mini LED
F-Drive
User Manual
Part Number: 7063M2130 Rev C
Released: 2023-12

To view a list of ETCtrademarks and patents, go to etccon-
nect.com/ip. All other trademarks, both marked and not marked,
are the property of their respective owners.
For a complete list of all third-party licenses that are fully incor-
porated herein to the extent required by each third-party license
terms and conditions, please visit etcconnect.com/licenses.
ETC intends this document, whether printed or electronic, to be
provided in its entirety.

Table of Contents
Source Four Mini LED (F-Drive) User Manual i
Overview 1
Safety 2
Canopy Luminaire 3
Installation 4
Install a Lens Tube 4
Luminaire Wiring 4
Install Canopy Luminaire 6
Connect Portable Luminaire 8
Power Up Procedure 8
Identify 8
Focus and Setup 9
Adjust the Tilt 9
Focus the Beam 9
Shape the Beam 9
Use the Color Frame Holder 10

Cleaning 11
Specifications and Reference 12
FCC Compliance 12
ii Source Four Mini LED (F-Drive) User Manual

Source Four Mini LED (F-Drive) User Manual 1
Overview
This guide provides installation instructions for Source Four Mini LED lumin-
aires. They are intended for use with the ETC F-Drive family of drivers and
accessories (including R12, W1, and B-Box) or other Class 2 or Low Voltage
Limited Energy (LVLE) power supplies (48 VDC maximum). Consult the spe-
cifications and installation manual for your driver to ensure compatibility.
This release of the Source Four Mini LED luminaire is compatible with the
R12 CC-150 output card or the W1 CC driver. Set the output channel for
the luminaire to 350 mA.
Canopy Portable
Note: For the portable luminaire, use an M10 bolt to secure a
clamp (provided separately) to the luminaire.
For more information about compatible products, see the resources below,
which are available for download at etcconnect.com/Products/Power-Con-
trols/LED-Drivers/F-Drive/Documentation.aspx:
• F-Drive Series R12 Installation Manual
• F-Drive Series W1 Installation Manual
• F-Drive R12 and W1 Wiring Reference Guide
• F-Drive B-Box4 Installation Guide
The F-Drive System Design Tool is available at etccon-
nect.com/FDriveSysDesignTool.
You must install a lens tube before you use the Source Four Mini LED. There
are four lens tube sizes available: 19°, 26°, 36°, and 50°.
There are also canopy, track, and portable versions of the luminaire that are
not compatible with the F-Drive family of drivers and accessories. See the
luminaire datasheets at etcconnect.com for more information on Source
Four product options.

2 Source Four Mini LED (F-Drive) User Manual
Yoke
Pattern
holder slot
Shutter
barrel
Lens tube
Color frame
retainer clip
Color
frame
Safety cable
attachment point
Shutters x4
Beam
focus knob
Safety
WARNING: Note the following safety warnings before use:
• Use the luminaire in dry locations only, where humidity
does not exceed 90 percent (non-condensing).
• Do not mount the luminaire on or near a flammable
surface.
• Check that the accessory holder is locked before
mounting the luminaire.
• Do not operate the luminaire without a lens installed.
• Do not use this luminaire if a lens is deeply scratched or
cracked. You must replace a lens when it is damaged.
AVERTISSEMENT : Prendre connaissance des avertissements
de sécurité suivants avant toute utilisation :
• Ne pas installer le projecteur sur ou à côté d’une surface
inflammable.
• Vérifiez que le porte-accessoires est verrouillé avant de
monter le projecteur.
• N’utilisez pas le projecteur sans que la lentille soit
installée.

Source Four Mini LED (F-Drive) User Manual 3
IMPORTANT SAFEGUARDS
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS
• Keep lamp away from materials that may burn.
• Do not touch hot lens, guard, or enclosure.
• Do not remain in light if skin feels warm.
• Do not look directly at lighted lamp.
• External temperature after 5 minutes of full-brightness operation:
50°C (122°F).
• External temperature when steady state is achieved: 67°C
(152.6°F).
SAVE THESE INSTRUCTIONS
Canopy Luminaire
WARNING: RISK OF ELECTRIC SHOCK! Power must be off
when you perform this procedure.
The luminaire must be installed by a qualified electrician in
accordance with all national and local electrical and con-
struction codes and regulations.
AVERTISSEMENT : RISQUE DE DÉCHARGE ÉLÉCTRIQUE!
L'alimentation doit étre éteinte avant d'exécuter cette procé-
dure.
The luminaire must be installed at
least 0.1m (4.0in) away from all
lighted objects.
Le luminaire doit être installé à au
moins 0,1m (4,0po) de tout objet
éclairé.
General warning Avertissement général
This product should not be
discarded as unsorted waste but
must be sent to separate collection
facilities for recovery and recycling.
Ce produit ne doit pas être jeté avec
les déchets ménagers mais doit être
déposé dans une collecte de déchets
électroniques ou dans un point de
collecte.
This product meets the safety
requirements specified for Class III
according to IEC 60536.
Produit à Protection Classe III Très
basse tension conforme à la norme
IEC 60536.
The product input or output is
suitable for direct current only.
L’entrée et la sortie de ce produit
convient uniquement au courant
continu.

4 Source Four Mini LED (F-Drive) User Manual
Installation
Install a Lens Tube
You must install a lens tube before you use the Source Four Mini LED. There
are four lens tube sizes available: 19°, 26°, 36°, and 50°.
Lens Tube Description
4M19LT (-1, -5) 19° Source Four Mini Lens Tube Only Black (White, Silver)
4M26LT (-1, -5) 26° Source Four Mini Lens Tube Only Black (White, Silver)
4M36LT (-1, -5) 36° Source Four Mini Lens Tube Only Black (White, Silver)
4M50LT (-1, -5) 50° Source Four Mini Lens Tube Only Black (White, Silver)
1. Unscrew the beam focus knob from the loose lens tube.
2. Slide the lens tube into the shutter barrel.
3. Install the beam focus knob.
Beam focus knob
Luminaire Wiring
Luminaire power and data in and out cables terminate to RJ45 connectors.
Please note the following requirements for wiring:
• Use 0.25 mm2(23 AWG) or larger gauge conductors in Category-type
cable terminated to the T568B standard. Not all Cat5 or Cat6 cables
meet this gauge requirement.
• You can connect up to four luminaires along one run of cable when
using RJ45 output from a compatible output card or driver. The total
cable distance for each wiring run should not exceed 100 m (328 ft).
See the F-Drive R12 and W1 Wiring Reference Guide for more details.

Source Four Mini LED (F-Drive) User Manual 5
Select the Driver
CAUTION: F-Drive channels are not configured to the
proper current for this luminaire by default. You must con-
figure the channel on the driver to 350 mA. Connecting the
luminaire to a channel that is configured for more than 350
mA will shorten the life of the luminaire LEDs and may void
the luminaire warranty.
This release of the Source Four Mini LED luminaire is compatible with the
R12 CC-150 output card or the W1 CC driver. Set the output channel for
the luminaire to 350 mA.
For more information about compatible products, see the resources below,
which are available for download at etcconnect.com/Products/Power-Con-
trols/LED-Drivers/F-Drive/Documentation.aspx:
• F-Drive Series R12 Installation Manual
• F-Drive Series W1 Installation Manual
• F-Drive R12 and W1 Wiring Reference Guide
• F-Drive B-Box4 Installation Guide
The F-Drive System Design Tool is available at etccon-
nect.com/FDriveSysDesignTool.
RJ45 Pinout Information
In Port
Pin Description
1 - *
2,6 THRU 1**
3,7 THRU 2**
4,8 THRU 3**
5 + *
*Pins 1 and 5 receive power from the source or the previous luminaire in line.
**These pins pass through power to the next luminaires in line.
Out Port
Pin Description
1,5 THRU 1
2,6 THRU 2
3,7 THRU 3
4,8 No Connection

6 Source Four Mini LED (F-Drive) User Manual
Use of Third-Party Drivers with Daisy-Chained
Luminaires
Source Four Mini LED luminaires can be controlled by third-party Class 2 or
Low Voltage Limited Energy (LVLE) drivers that provide a maximum of
48VDC. To daisy-chain luminaires and still have independent channel func-
tionality, you must wire the first luminaire in the chain as described below.
(The RJ45 outputs on F-Drive natively support this wiring configuration.)
Configure the third-party drivers to a maximum of 350 mA.
Channel Input Pins for First Luminaire in
Daisy-Chain Description
1
(First luminaire)
1 Channel 1 -
5 Channel 1 +
2
(Second luminaire)
2 Channel 2 -
6 Channel 2 +
3
(Third luminaire)
3 Channel 3 -
7 Channel 3 +
4
(Fourth luminaire)
4 Channel 4 -
8 Channel 4 +
Install Canopy Luminaire
Note: The canopy luminaire can be installed directly on 4in and
4-11/16in back boxes, or on back boxes with round cover plates.
The canopy luminaire cannot be installed on 1-gang back boxes or
trim rings.
Mounting
plate
Mounting
plate bolt
Safety
braid
Canopy
bolts
Mounting
plate bolts

Source Four Mini LED (F-Drive) User Manual 7
1. Remove the mounting plate from the luminaire by removing the two
canopy bolts.
2. Using two of the mounting plate bolts, secure the mounting plate to
the installed back box (not included).
1
1
2
2
Canopy
bolt hole
3
3
Canopy
bolt hole
Mounting plate
installation detail
Install the mounting plate
screws in one of the three
position-pairings shown.
3. Place the copper safety braid loop over the third mounting plate bolt,
and then attach the mounting plate bolt to the back box to help
secure the fixture during installation.
4. Connect a power and data in cable from the driver or ETC breakout
box to the "IN" port on the luminaire. If you are daisy-chaining
luminaires, be careful to connect the cables to the correct "IN" and
"OUT" ports. (The cable from the "OUT" port on one luminaire
connects to the "IN" port of the next luminaire.) Incorrect
connections will result in improper operation of the luminaires.
5. Use the canopy bolts to secure the luminaire to the mounting plate.
6. Open all four shutter blades by sliding them outward until they stop.
7. Focus the luminaire as needed. See Focus and Setup on page9 .

8 Source Four Mini LED (F-Drive) User Manual
Connect Portable Luminaire
Note: For the portable luminaire, use an M10 bolt to secure a
clamp (provided separately) to the luminaire.
1. Connect a power and data in cable from the driver or ETC breakout
box to the "IN" port on the luminaire. If you are daisy-chaining
luminaires, be careful to connect the cables to the correct "IN" and
"THRU" ports. (The cable from the "THRU" port on one luminaire
connects to the "IN" port of the next luminaire.) Incorrect
connections will result in improper operation of the luminaires.
2. Open all four shutter blades by sliding them outward until they stop.
3. Focus the luminaire as needed. See Focus and Setup on the facing
page .
Power Up Procedure
1. Verify that each luminaire is connected to a Constant Current
(CC)driver or output card before you power up the luminaires. See
the installation manual for your F-Drive for more compatibility
information.
2. Use Concert to verify that each CC channel is set to output 350 mA.
3. Refer to the installation manual for your F-Drive for information about
the power up procedure for the driver.
Identify
You can send an identify command to individual channels of an R12 output
card or W1 driver using ETC Concert or a third-party RDM controller. Lumin-
aires connected to an F-Drive will respond to an RDMidentify command by
blinking on and off:500 ms on, 500 ms off, until the identify command is
ended. See the F-Drive Device Package Help in Concert or the installation
manual for your F-Drive for information about this RDM command.

Source Four Mini LED (F-Drive) User Manual 9
Focus and Setup
Yoke locking
knob
Adjust the Tilt
Image shows the yoke from the canopy
version of the fixture.
1. Loosen, but do not remove the
yoke locking knob.
2. Tilt the luminaire as needed.
3. Tighten the yoke locking knob.
Beam focus knob
Focus the Beam
Image shows the yoke from the canopy ver-
sion of the fixture.
Loosen the beam focus knob, adjust the
lens tube position as needed, and then
tighten the knob.
Shape the Beam
You can shape the beam using the four shutters or with a pattern.
Shape the Beam with
Shutters
The luminaire has four shutters: left,
right, top, and bottom. Each shutter can
be pulled out or pushed in to create the
desired beam shape.

10 Source Four Mini LED (F-Drive) User Manual
Shape the Beam with a Pattern
25.4 mm
(1 in)
Diameter
The luminaire has a pattern-holder slot on the top side of
the shutter barrel, in front of the shutter. It accommodates
a glass or stainless steel E-size (37.5mm with a 25.4mm
image area) pattern. The maximum pattern thickness that
can be accommodated is 1.1mm (0.04in).
Use an optional donut in the color frame holder to enhance
pattern projection.
When the slot is not in use, a small sheet metal cover
secured with a Phillips screw prevents light leakage.
1. Use a Phillips screwdriver to loosen the screw on the slot cover. Do not
remove the screw.
2. Slide the cover knob on the luminaire completely to the side to expose
the slot.
3. Insert the pattern holder.
4. Slide the slot cover back toward the shutters until it meets the pattern
handle. Leave enough space to move the handle.
5. Secure the slot cover by tightening the screw.
Use the Color Frame Holder
The Source Four Mini LED (F-Drive) comes equipped with a color frame
(either 70mm or 2 3/4in), which is a metal frame used to hold color media
(often referred to as gel) in front of the lens. The color frame holder is
equipped with a retaining clip that prevents the color frame from falling
out.
Additional accessories are available that also fit into the color frame holder:
top hat, short top hat, half hat, short half hat, and donut. When you use an
accessory, install the color frame in the rear slot of the holder.
WARNING: Check that the accessory holder is locked before
mounting the luminaire.
AVERTISSEMENT : Vérifiez que le porte-accessoires est ver-
rouillé avant de monter le projecteur.
Note: The color frame should be inserted with the open side down.
1.
Retaining clip
Color frame
holder
Release the retaining clip by gently
pushing it up.
2. Insert the color frame.
3. Lock the retaining clip by gently pushing
it down.

Source Four Mini LED (F-Drive) User Manual 11
Cleaning
WARNING: Do not use ammonia-based cleaners or other
harsh commercial cleaners. Clean lens only as directed.
Commercially available glass cleaning agents should be
avoided as they may contain ammonia, other harsh chemical
detergents, or abrasive agents. These cleaners may damage
the lens surface. Do not immerse or soak the lens in any
cleaning solution.
1. Remove the beam focus knob from the shutter barrel.
2. Remove the lens tube from the shutter barrel.
3. Remove dust with a blast of oil-free air or wipe with a clean, lint-free
cloth.
4. Slide the lens tube back into the shutter barrel with the color frame
retainer clip on the top.
5. Reinstall the beam focus knob.

12 Source Four Mini LED (F-Drive) User Manual
Specifications and Reference
For current and complete compliance and specifications, see the Source
Four Mini LED (F-Drive) datasheet at etcconnect.com.
FCC Compliance
Source Four Mini LED (F-Drive)
(For any FCC matters):
Electronic Theatre Controls, Inc.
3031 Pleasant View Road
Middleton, WI 53562
[phone]
etcconnect.com
This device complies with Part 15 of the FCCRules. Operation is subject to
the following two conditions:(1) this device may not cause harmful inter-
ference, and (2)this device must accept any interference received; including
interference that may cause undesired operation. Visit etccon-
nect.com/products for current and complete compliance information includ-
ing FCC compliance.
Note: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. Any modifications or changes to this product
not expressly approved by Electronic Theatre Controls, Inc. could
void the user’s authority to operate the product. Operation of this
equipment in a residential area is likely to cause harmful inter-
ference, in which case the user will be required to correct the inter-
ference at their own expense.

Source Four Mini LED (F-Drive) User Manual 13

14 Source Four Mini LED (F-Drive) User Manual

Source Four Mini LED (F-Drive) User Manual 15

Corporate Headquarters nMiddleton, WI, USA|[phone]
Global Offices nLondon|Rome|Holzkirchen|Paris|Hong Kong|Dubai|Singapore
New York|Orlando|Los Angeles|Austin|©2023 Electronic Theatre Controls, Inc.
Web etcconnect.com |Support support.etcconnect.com
Contact etcconnect.com/contactETC |Trademark and patent info:etcconnect.com/ip
Third-party license agreement info:etcconnect.com/licenses |Product information and spe-
cifications subject to change.ETCintends this document to be provided in its entirety.
7063M2130RevCReleased2023-12
