ShowPro HEX36 User manual

HEX36
1
User Manual
www.showtech.com.au

HEX36
2
Table of Contents
1. Safety instructions…………………………………………………………3
1.1 Power Connection ………………………………….……………….4
1.2 Overhead Rigging …………………………………………………...4
1.3 DMX Connection ……………………………………………………..6
1.4 Cleaning and Maintenance ………………………………………6
2. Menu Navigation .…………………………………………………………7
3. DMX Allocation….………………………………………………………….9
4. Technical Specifications ……………………….……………………….12

HEX36
3
1. Safety Instructions
FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature.
Avoid exposing it to direct to rays of sun.
Operate only between 41°F/5°C and 95°F/35°C.
Keep away from humidity, water and dust.
Do not place the use in a location with high humidity or lots of dust.
It is ideal to use the Hercules away from such equipment:
Transformer motor, tuner, TV set and amplifier.
Avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a dry cloth to wipe off dust, or a wet soft cloth for stubborn dirt.
NO USER SERVICABLE PARTS INSIDE.
If unit is out of service, please contact your point of purchase.
If any troubles arise, remove the power plug and contact your ShowPro
representative for repair. Do not open the machine by yourself, it might result a
danger of electric shock.
Take care with the power cable. Never pull the power cable to remove the plug from
the receptacle, be sure to hold the plug.
When not using the unit for an extended period of time be sure to disconnect the
plug form the receptacle.

HEX36
4
1.1 Power Connection
AC Power This product has an auto-ranging power supply that can work with an
input voltage range of 100–240 VAC
AC Plug
1.2 Overhead Rigging
This item must be built in a way that it can hold 10 times more of its weight for 1
hour without causing any damage. The installation must be secured with a secondary
safety attachment. The Safety attachment has to be constructed in a way that no
part of the installation can fall. When rigging, de-rigging or servicing the fixture
ensure that the area below is secure. Before putting the device into operation, the
installation must be approved by an expert. The operator has to make sure that
safety-relating and machine-technical installations are approved by a skilled person
once a year.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE.
Including (but not limited to) calculating working load limits, installation material
being used, and periodic safety inspection of all installation material and the
projector. If you lack these qualifications, do not attempt the installations yourself,
but instead use a professional structural rigger. Improper installation can result in
bodily injury and/or damage to property.
Use only professional trussing system if the item is to be lowered from the ceiling or
high joists. Never let the device swing freely in a room.
Connection
Wire
AC Live
Brown
AC Neutral
Blue
AC Ground
Green/Yellow

HEX36
5
CAUTION: Overhead Items may cause serious injuries when not installed correctly!! If
there is concern about the safety DO NOT INSTALL the device.
DANGER OF FIRE!
When installing the device, make sure there is no highly-flammable material
(decoration articles, etc.) within a distance of min. 0.5m.
Mount the projector with the mounting bracket to your trussing system using an
appropriate clamp.
For overhead use, always install a rated safety - wire that can hold at least 10 times
the weight of the fixture. You must only use rated safety –wire with quick links with
screw cap. Pull the rated safety - wire through the hole in the mounting bracket and
over the trussing system or a safe fixation spot. Insert the end in the quick link and
tighten the safety screw. The maximum drop distance must never exceed 20cm
A safety - wire which has already held the strain of a fall or which is defective must
not be used again.
IMPORTANT!
Before taking into operation for the first time, the installation has to be approved by
an expert.

HEX36
6
1.3 DMX Connection
DMX Linking the HEX36 will work with a DMX controller using a 5-pin DMX serial connection.
DMX Connection the HEX36 uses IP Rated 5-pin DMX data connections for its DMX
personalities:
6 Ch, 8 Ch, 12Ch. See the User Manual for information about connecting and configuring the
product for DMX operation.
1.4 Cleaning and Maintenance
Please make sure that safety-relating and machine-technical installations are inspected by a
skilled person once a year.
1. Make sure before installing that all screws are tightly connected and not corroded.
2. There must be no deformations on the housings, fixations and installations spots
3. Any defects on the electronics, power cables or housing must be repaired for safe
use.
If the exterior of the unit is going to be cleaned, please use moist, lint free cloths. Never use
alcohol or solvents.
The Cooling fan must be cleaned monthly and check to ensure it is free of obstructions.
To clean the interior of the device please use a vacuum cleaner or an air jet, however we
recommend cleaning the lenses weekly to ensure the best output from your unit.

HEX36
7
2.0 Menu Navigation
Menu
1
6 - Channel
d1
（Default 12CH，d 1）
d512
2
8 - Channel
d1
d512
3
12 - Channel
d1
d512
4
C --
C1
Default：C63
C2
C3
C4
C5
****
****
C60
C61
C62
C63
5
P --
P1
（Default：P1）
P2
P3
P4
P5
6
S --
S--1
（Default：S100）
S100
1
7
U --
RED
0
（Default：RGBAWP=255）
255

HEX36
8
GREEN
0
255
BLUE
0
255
AMBER
0
255
WHITE
0
255
UV
0
255
8
Dimmer
OFF
Dimmer speed OFF: （Default：OFF）
DIM1
Dimmer speed Mode1(Fast)
DIM2
Dimmer speed Mode1(Middle)
DIM3
Dimmer speed Mode1(Slow)
9
Temperature
32
10
Password
ON
（Default：ON）
OFF
If setting pass word to “On”，need to press “UP，DOWN，UP，DOWN，ENTER” to
release;
if press wrong, pls press enter to input again.

HEX36
9
3.0 DMX Allocation
6-CH
Function
Value
Setting
1
Red
000-255
0~100%
2
Green
000-255
0~100%
3
Blue
000-255
0~100%
4
Amber
000-255
0~100%
5
White
000-255
0~100%
6
UV
000-255
0~100%
8-CH
Function
Value
Setting
1
Dimmer
000-255
0~100%
2
Red
000-255
0~100%
3
Green
000-255
0~100%
4
Blue
000-255
0~100%
5
Amber
000-255
0~100%
6
White
000-255
0~100%
7
UV
000-255
0~100%
8
Strobe
000-010
NO Function
011-255
Strobe slow to fast
12CH
Function
Value
Setting
1
Dimmer
000-255
0~100%
2
Red
000-255
0~100%
3
Green
000-255
0~100%
4
Blue
000-255
0~100%
5
Amber
000-255
0~100%
6
White
000-255
0~100%
7
UV
000-255
0~100%
8
Strobe
000-010
NO Function

HEX36
10
011-255
Strobe slow to fast
9
Manual Colour + Colour Temperature
000-010
No Function
011-030
R 100%, G 0~100%, B 0%
031-050
R 100%~0%, G 100%, B 0%
051-070
R 0%, G 100%, B 0~100%
071-090
R 0% G 100%~0% B 100%
091-110
R 0%~100% G 0% B 100%
111-130
R 100% G 0% B 100%~0%
131-150
R 100% G 0%~100% B 0%~100%
151-170
R 100%~0% G 100%~0% B 100%
171-200
R 100% G 100% B 100% A100%
201-205
Colour temperature1
206-210
Colour temperature2
211-215
Colour temperature3
216-220
Colour temperature4
221-225
Colour temperature5
226-230
Colour temperature6
231-235
Colour temperature7
236-240
Colour temperature8
241-245
Colour temperature9
246-250
Colour temperature10
251-255
Colour temperature11
10
Function
Value
Setting
Auto
Sound Programs
000-051
No Function
052-101
Auto Program 1
102-152
Auto Program 2
153-203
Auto Program 3
204-254
Auto Program 4
255
Auto Program 0 (Auto1-5)

HEX36
11
11
Function
Value
Setting
Auto Speed
000-255
Speed Slow to Fast
12
Function
Value
Setting
Dim Mode
000-051
Preset dimmer speed from display menu
052-101
Dimmer speed mode off
102-152
Dimmer speed mode1 (fast speed)
153-203
Dimmer speed mode2 (middle speed)
204-255
Dimmer speed mode3 (slow speed)

HEX36
12
4.0 Technical Specifications
OPTICS
LED Specification
12W RGBWAUV 6 in 1 LEDs
LED quantity
36
Field Angle
22°
Beam Angle
35 °
Output
1699 lux @ 5 meters
Control
Control method
DMX
WDMX Compatibility
N/A
DMX Channels
6,8 and 12
Dimming Curves
4 Modes
Dimming Resolution
16 bit
Data Connections
5 Pin IP Rated connectors
Menu
Touch Screen
Electrical
Power
240V IP Rated connectors
Battery Specifications
N/A
Working Hours
N/A
Charging hours
N/A
Charging
N/A
Charging during use
N/A
Input Voltage AC
110V-240V AC 50/60 Hz auto-ranging
Power Consumption
450W
Fuse
N/A

HEX36
13
Physical
Weight
14.3Kg
Size
593x303x212
Cooling System
Fan-free convection cooled
IP Rating
IP64
