Shuttle XPC SN26P User manual

XPCUserGuide
Forthe:SN26P

StatementofShuttleMainboardviatheEMITest
Shuttlemainboardshavebeen viathe EMItestintermsofseriesofregulations:EN55022/
CISPR22/AS/NZS3548 Class B,EN55024 (1998/AS/NZS),EN4252.1(1994),EN61000,ANSI
C63.4(1992),CFR47 Part15 SubpartB,and CNS13438 (1997).The itemstested areillus-
trated asfollows:
(A)Voltage:AC110V/60HZ&AC230V/50HZ
(B)Tested ProductInformation:
ProductName:PCMainboard
Status:Sample
ModelName:SN26P
S/N:N/A
CPU:
ExternalFrequency:200 MHz
AMDAthlonTM64 :2800+,3200+,3400+,3800+,4000+
SerialPort: one portwith9pins
ClearCMOSbutton:one port
KeyboardPort: one portwith6pins
MousePort: one portwith6pins
USB 2.0Port: sixportswith4pinsrespectively
1394 Port: twoportwith6pinsrespectively
LANPort: one portwith8pins(10Mbps/100Mbps/1000Mbps)
Mic-In&Line-In&Earphone Ports:one portforeach
Center/Bass-OutPort: one port
Surround-OutPort: one port
Surround-Back Port: one port
Front-OutPort: one port
SPDIF-Out(Coaxial)Port: one port
SPDIF-Out(Optical)Port: one port
SPDIF-In(Optical)Port: one port
DIMMMemory(optional):DDR400 256 MB*2
PowerCable:Detachableand Shielded (withaGND pin)
Monitor:CRT
MaximumResolution:1280 X1024 V:60Hz
All CPUshavecompletelybeen tested,and valuesoffered bythe worstEMIcombination of
CPUexternalfrequency arelisted asfollows:
TestMode ExternalFrequency CPU CPUOpen/Close
1 200MHzAMDAthlonTM64 4000+Close
2 200MHzAMDAthlonTM64 4000+Open

(C)Remedyforthe Tested Product&ItsEMIInterference:
Remedy:N/A
EMIInterference:
Crystal:32.768KHz(X8)/25MHz(X7)/22.5MHz(X9)/24.576MHz(X10)/24.576MHz(X6)
(D)Supported HostPeripherals:
HostPeripheralProductNameModelName
#1CaseSN26P
#2PowerSupplyPC43I3503
#3SerialATAII HITACHIS2VT9K9M
#4SerialATAII HITACHIS2VT9K9M
#5CardReaderW4604B007001
#6DVDDualPlayerP10437007994
#7WINFASTPX6800GTW1100892
#8WINFASTPX6800GTW1100892
(E)NoticesforAssembling Computers:
1.Casesshouldbe made ofiron orothermetalthathasgood electricconductivity.
2.Cylindersinacaseshouldbe made ofmetal,and ashaving amainboardmounted
inacase,makesurescrewsareall utilized and fastened on amainboard.
3.AnI/Oshielding shouldbe contacted withI/Ometallicpartsofamainboard.
4.Cablesshouldappropriatelybe arranged and fixed inacase.Followinstructions:
Ø LeaveIDEcablesnotcrossed upon CPUand SDRAM;
Ø Leavepowercablesminimuminlength,and notcrossed upon amainboard;
Ø LeaveCPUfan cablesminimuminlength,and notnearCPU;
Ø Leavecableson panelsand othersparecablestied inacomputercase.
5.Makesurean EMIshielding attached toacasehasproperlybeen installed.
6.Makesurea5.25"or3.5"FDD and screwsarefastenedtoan EMIshielding.
7.MakesureacaseiscloselyincontactwithEMIconnected points.
8.Makesurethereisno cleft inacasewhichisnotdeformed.
9.MakesureaPCIorAGPdoorisbound toacase.
10.Makesurecablesofotherdevices(fansorsomeothers)arefixed inacase.

Shuttle®
XPCInstallation Guide
Copyright
Copyright©2005 byShuttle®Inc.All RightsReserved.
Nopartofthispublication maybereproduced,transcribed,storedinaretrievalsystem,
translatedintoanylanguage,ortransmittedinanyformorbyanymeans,electronic,
mechanical, magnetic,optical, chemical, photocopying,manual, orotherwise,withoutprior
writtenpermission fromShuttle®Inc.
Disclaimer
Shuttle®Inc.shall notbeliableforanyincidentalorconsequentialdamagesresultingfrom
theperformanceoruseofthisproduct.
Thiscompanymakesno representationsorwarrantiesregardingthecontentsofthisma-
nual. Information inthismanualhasbeencarefullycheckedforreliability;however,no
guarantee isgivenastothecorrectness ofthecontents.Intheinterestofcontinuedproduct
improvement, thiscompanyreservestherighttorevisethemanualorincludechangesin
thespecificationsoftheproductdescribedwithinit atanytimewithoutnoticeand without
obligation tonotifyanyperson ofsuchrevision orchanges.Theinformation containedin
thismanualisprovidedforgeneralusebycustomers.
ThisdevicecomplieswithPart15 oftheFCC Rules,Operation issubjecttothefollowing
twoconditions:
1.Thisdevicemaynotcauseharmfulinterference.
2.Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
Trademarks
ShuttleisaregisteredtrademarkofShuttleInc.
Inteland PentiumareregisteredtrademarksofIntelCorporation.
PS/2isaregisteredtrademarkofIBMCorporation.
AWARDisaregisteredtrademarkofAwardSoftwareInc.
Microsoft and WindowsareregisteredtrademarksofMicrosoft Corporation.
GeneralNotice
Otherbrand and productnamesusedhereinareforidentification purposesonlyand may
betrademarksoftheirrespective owners.
9M0-A87SN0-26P0

Installation Notices
Donotplace thisdevice underneath
heavy loadsorinanunstableposition.
Donotexpose thisdevice tohigh
levelsofdirectsunlight,high-humidity
orwetconditions.
Donotuse orexpose thisdevice
around magneticfieldsas magnetic
interference may affectthe
performance ofthedevice.
Donotblock theairventstothis
device orimpedetheairflowin
anyway.
CAUTION
Incorrectlyreplacingthebatterymaydamage thiscomputer.Replaceonlywith
the sameorequivalentasrecommendedbyShuttle.Disposeofusedbatteries
accordingtothemanufacturer'sinstructions.
SafetyInformation
ReadthefollowingprecautionsbeforesettingupaShuttleXPC.

TABLEOFCONTENTS
1Function Introduction .......................................................................................... 1
1.1XPCIntroduction ........................................................................................... 1
1.2ModelSpecifications..................................................................................... 2
1.3XPCExteriorDissection................................................................................ 3
1.3.1XPCFront ............................................................................................. 3
1.3.2XPCBack ............................................................................................. 4
1.4Accessories .................................................................................................... 5
1.5XPCMainboard.............................................................................................. 6
1.5.1SN26Pmainboardillustration ................................................................ 6
1.5.2JumperSettings.................................................................................... 7
FrontPanelConnector(JP12)............................................................... 7
FrontPanelAUDIO/USB/1394 Connector(JP6/JP16)........................... 8
FanConnectors(FAN1/FAN2/FAN3/FAN4)........................................... 9
LINE-IN(CN8)(Blue),CD-IN(CN7)(Black),miniCD-IN(CN6)(White)
Connectors........................................................................................... 9
WirelessKeyboardandMouseConnectors(JP2)............................... 10
IRHeader(JP5).................................................................................. 10
USB Header(USB3)............................................................................11
ParallelPortHeader-EXT.PrinterPort(J1)..........................................11
2XPCInstallation Guide........................................................................................ 12
2.1Installation.................................................................................................... 12
2.1.1Removethe Cover............................................................................... 12
2.1.2Removethe Rack ................................................................................ 13
2.2CPU,DDR and ICEInstallation ................................................................... 14
2.2.1Removethe ICEModule...................................................................... 14
2.2.2InstalltheCPU..................................................................................... 15
2.2.3DDRInstallation ................................................................................... 17
2.2.4InstalltheICEModule........................................................................... 19

2.3PeripheralInstallation ................................................................................ 20
2.3.1InstalltheserialATAHDD..................................................................... 20
2.3.2OpticalDriveRackMounting ................................................................ 20
2.3.3Install theRackPeripherals................................................................. 21
2.3.4Install moreSerialATAHDDs............................................................... 24
2.4Accessories Installation .............................................................................. 26
2.4.1Install PCIExpressx16 Card................................................................ 26
2.4.2InstallSLIbridge card.......................................................................... 28
2.5FinalTouches .............................................................................................. 29
2.5.1Closethe ChassisCover..................................................................... 29
2.5.2InstallFrontFeet .................................................................................. 29
2.5.3Complete............................................................................................ 30
2.6XPCAccessories ......................................................................................... 30
2.7TechSupport............................................................................................... 30
2.8TechnicalNotes ........................................................................................... 31
2.8.1ClearCMOSButton............................................................................. 31
3Driverand SoftwareInstallation......................................................................... 32
3.1MainboardDriverCD................................................................................... 32
3.1.1InstallMainboardSoftware................................................................... 33
Appendix................................................................................................................ 34
EntertheBIOS................................................................................................... 34
THEMAINMENU ............................................................................................... 35
StandardCMOSFeatures............................................................................ 37
AdvancedBIOSFeatures............................................................................. 40
AdvancedChipsetFeatures......................................................................... 44
IntegratedPeripherals.................................................................................. 47
PowerManagementSetup ........................................................................... 50

PnP/PCIConfigurations............................................................................... 53
PCHealthStatus.......................................................................................... 55
Ratio/VoltageControl................................................................................... 57
LoadFail-SafeDefaults................................................................................ 58
LoadOptimizedDefaults.............................................................................. 58
SetSupervisor/UserPassword..................................................................... 58
Save&ExitSetup ........................................................................................ 59
ExitWithoutSaving ...................................................................................... 59

1
English
<1.1XPCIntroduction
TheShuttleXPCistheoriginalhigh-performanceSmall FormFactor(SFF)computer.
Sincethefirstmodelwasintroducedin2001,theXPChasbecometheworld’sbest-
sellingSFF computerbrand.
EachShuttleXPCissoldasa”barebone” computer~chassis,powersupplyand
motherboard.Theusermustadd hisownprocessor,memory,drivesand,asapplicable,
expansion cards.TheXPChasbeendesignedtobeeasilyassembledand configured
directlybytheend user.Consumerscanchoosetobuypreconfigured,ready-to-run
XPC’saswell~alistofShuttle-authorizedvalue-addedresellerscanbefound atwww.
shuttle.com.
TheShuttleXPCowesitspopularitytoitsuniquecombination ofsmall-size,high-
performanceand nearuniversalcomponentcompatibility.However,unlike ordinary
desktop computers,ShuttleXPC’shave beenengineeredascompletesystems.
TheXPCconceptcanbesummarizedas:
Useofhigh-performance,industry-standardcomponents;Minimumsize possible,while
preservingcomponentcompatibilityand systemexpansion;Focuson quality~acom-
mitmenttoqualityconstruction,materialsand industrialdesign.
To meettheabove requirements,Shuttlehascreatedand patenteddozensofnew
technologies,includingtheIntegratedCoolingEngine(ICE), whichextend and en-
hancethepersonalcomputingexperiencewhilereducingheat, noiseand space
requirements.
Thankyou forchoosingtheShuttleXPC!
1Function Introduction

2
English
<1.2ModelSpecifications
FormFactor
ShuttleSmall FormFactor
Processor
AMD939 pinpackage with200MHzx5FSB
Chipset
nVIDIAnForce 4SLI
Memory
184 pins333/400 DDRSDRAMDIMM X2withDual-ChannelModeconfiguration
Supports256Mb,512Mb,and 1GbtechnologiesforX8and X16 devices
Audio
H/W AudioEnvy24 (7.1-CHANNEL)
Ethernet
Mravell 88E1111 PCI-ELanController,supportsWake-on-Lan(WOL)function
10/100/1000 Mb/sLANoperation
IEEE 1394a
VIAVT6307,1394 OHCIv1.0compliant,Upto400Mb/sdatatransferrate
SerialATA
nVIDIAintegratedSATA,DualChannelUDMA300MB/sS-ATA
SupportRAID0,1,0+1&5
Onboardheaders &connectors
(4)Fanconnectors (1)Line_inheader(1)AUX_INheader
(1)miniCD_inheader(1)Power&resetheader(1)IRheader
(2)1x5pinUSB2.0headers (4)USB2.0connectors (4)SATAconnectors
(1)Printerportheader(2)Powerconnector(2)PCI-EX16 slots
(1)PS2Keyboard/MouseHeader(1)Floppyconnector(1)IDEconnector
PSU
Output:350 Watt,Input:100/240VAC,Active PFC,FCC,CE,BSMI,UL,TUV,
CBcertificated
Chassis
P,Dimension:325 (L)x220 (W) x210 (H)
Bay:(1)3.5"bay (1)3.5"bays(internal) (1)5.25"bay

3
English
<1.3.1XPCFront
1.CardR/W(MS,MSPro,MMC,SD,SM)
2.CardR/W(CFTypeI/II, MD)
3.Ejectbutton
4.5.25"Bay
5.HDD LED
6.Powerswitch&LED
7.Reset
8.Mic
9.Headphone
10.USBports
11.FireWire® 400 miniport
<1.3XPCExteriorDissection
Note:Shuttleoffers avarietyofdifferentXPCmodelsloadedwithvarious
options.Theillustration belowwill helpfamilarize you withtheincluded
featuresinyournewXPC.
8
11
10
7
6
5
4
3
12
9

4
English
<1.3.2XPCBack
1.AC powerswitch
2.AC powersocket
3.COMport
4.ClearCMOS
button
5.PS/2Mouse
6.PS/2Keyboard
7.LANport8.USBports
9.FireWire®400 port10.SPDIFOUT(Coaxial)
11.SPDIFOUT(Optical) 12.Central/Bass
13.SideSurr (R/L)14.SPDIFIN(Optical)
15.FrontOUT(R/L)16.Surround back(R/L)
17.LineINport
A.Wireless LANperforation
1
2
3
46
5 7
11
10
14
12
A
15
13
16
17
9
8
Clear
CMOS
1394

5
English
<1.4Accessories
1.ICEHeat-Pipe(1)
2.Opticaldrive mountingbrackets(2)
3.Cabletie(2)
4.HDD screws(6)
5.Frontfeet(2)
6.Powercord(1)
7.Cableclip(1)
8.Adhesive (1)
9.ShuttleExtrasCD(1)
10.MotherboardCDDriver(1)
11.SLIbridge card(1)
12.Heatsinkcompound (1)
13.RAIDDriverFloppyDisk(1)
14.XPCuserguide(1)
15.RAIDmanual(1)
Note:BundledAccessoriesmay differfromspecified.If thereareitems
missing,pleasecontactyourlocalauthorizedShuttledealer.
1
2
3
4
5
6
8
7
911
15
14
10
12
13

6
English
<1.5XPCMainboard
<1.5.1SN26Pmainboardillustration
H/W Audio on/off Jumper
VT6307
VT6307
F
ORCE
4
SLI
n
PS/2 Keyboard/Mouse s
Port
COM Port & Clear CMOS Button
SPDIF-IN Optical/
Front-Out/
Surround-Back/ Line-In Ports
Surround-Out/
Center/Bass/
Giga LAN (GbE) & USB 2.0 s
Port
CPU Power Connector
- CN5
CD-IN- CN7
Four Serial ATA Connectors
Two PCI Express x16 Slot
FAN Connector- FAN2
Front Panel Connector- JP6
Front Panel Connector- JP16
SOCKET 939
TWO 184-pin DDR
SDRAM DIMM Sockets
One IDE Connector-IDE1
SPDIF-OUT Coaxial/Optical Ports
USB Header- USB3
Wireless KB/MS Header- JP2
nVIDIA nForce 4 SLI Chip
FAN Connector- FAN1
FAN Connector- FAN4
IR Header- JP5
FAN Connector- FAN3
Clear CMOS- JP17
Line-IN- CN8
Front Panel Connector
- JP12
One Floppy Connector
EXT. Print Port- J1
1394 & USB 2.0 sPort
ATX Power Connector- ATX3

7
English
<1.5.2JumperSettings
PinAssignments(JP12):
1=HDLED_PU2=GLEDA
3=HDLED4=GLEDB
5=Reset_SW6=Power_SW
7=GND 8=GND
9=NC10=KEY
@FrontPanelConnector(JP12)
HeaderJP12 canbeusedtoprovideoperation statussignalstothefrontdaughterboard.
Notethatthisisanalternative headertothe50pinstreamlineheaderthatalsocon-
nectsthemotherboardtothefrontdaughterboard.
9
7
5
3
1
10
8
6
4
2
JP12
Severalhardwareadjustmentsaremadebysettingjumperson themainboard.To
successfullychange jumpersettings,you will needtolocatepin#1.Inthismanual,
pin#1 isrepresentedbyawhitesquare,otherpinsarerepresentedbyacircles.An
illustration isshownbelowforyourreference:
Caution!
1.Donotremove themainboardfromitscase.
2.Donottouchthecomponentson themainboard.Wheninstallingcom-
ponents,pay specialattention nottomanhandlesensative components
on themainboard.
3. Wearanantistaticwriststraportake othersuitablemeasurestoprevent
electrostaticdischarge (ESD)wheneverhandlingthisequipmentorinsta-
llingcomponents.
JumperswithtwopinsareshownasforClosed[On]orforOpen
[Off]. To Shortjumperpins,simplyplaceaplasticjumpercapoverthedesiredpair
ofpins.

8
English
@FrontPanelAUDIO/USB/1394 Connector(JP6/JP16)
HeadersJP6 and JP16 areusedtoconnectcablestofrontpanelconnectorsmounted
on front-panelorback-panel. Thefrontpaneliswheretheharddrive activitylights,
resetbutton,on/off button,computerpoweron light, USBconnectors,1394 connectors,
and audioheaders,arelocated.
PinAssignments(JP6):
1=N/C21=AC97_CLK
2=N/C22=KEY
3=N/C23=-AC_RST
4=N/C24=GPIO
5=N/C25=AC_SUMCPinAssignments(JP16):
6=N/C26=AC_SDIN1=USBPWR16=USB4+
7=N/C27=AC_SDOUT2=USBPWR17=USBGD
8=N/C28=AC_BITCLK3=USBPWR18=USBGD
9=N/C29=KEY4=USBPWR19=USB5-
10=GND 30=AUDIOGND 5=USBGD 20=USBGD
11=N/C31=AUDIOGND 6=USBGD 21=USB5+
12=RST_SW32=FRONT_R7=USB1-22=KEY
13=FPGND 33=FRONT_OUT_R8=USB2-23=1394GND
14=HDLED34=FRONT_L9=USB1+24=1394GND
15=PW_SW35=FRONT_OUT_L10=USS2+25=TPA+
16=HDPU36=AUDIOGND 11=USBGD 26=TPB+
17=GLEDB37=NC12=USBGD 27=TPA-
18=VCC3 38=AUDIOGND 13=USB3-28=TPB-
19=GLEDA 39=NC14=USB4-29=1394PWR
20=+12V40=MIC15=USB3+30=1394GD
39373533312927252321191715131197531
403836343230282624222018161412 108642
30282624222018161412 108642
2927252321191715131197531
JP6
JP16

9
English
PinAssignments(CN8): PinAssignments(CN7): PinAssignments(CN6):
1=Line-IN-Left 1=CD-IN-Left 1=Ground
2=Ground 2=Ground 2=CD-IN-Right
3=Ground 3=Ground 3=Ground
4=Line-IN-Right4=CD-IN-Right4=CD-IN-Left
@LINE-IN(CN8)(Blue), CD-IN(CN7)(Black), miniCD-IN(CN6)(White)
Connectors
PortCN8(Blue), CN7(Black)and CN6(White)areusedtoconnectstereoaudio
inputsfromaCD-ROM.
@FanConnectors (FAN1/FAN2/FAN3/FAN4)
Themainboardprovidesfouronboard12Vcoolingfanpowerconnectorstosupport
CPU_In(FAN1), CPU_Out(FAN2), chipset(FAN3), Reserved(FAN4)fans.
Note:Bothcablewiringand typeofplugmay varydependingon thefan
maker.
1
PWM_CTRL
SPEED_SENSE
+12V
GNDt
1
SPEED_SENSE
+12V
GND

10
English
@IRHeader(JP5)
If you have anInfrareddevice,thismainboardcanimplementIRtransferfunction.
To enabletheIRtransferfunction,followthesesteps:
PinAssignments(JP5):
1=NC
2=KEY
3=VCC
4=GND
5=IrTx
6=IrRx
@Wireless Keyboardand MouseConnectors (JP2)
JP2 headerprovidessupportforawireless keyboardand mouse.ThefourminiJump-
ersmustbeseton the5-6,7-8,9-10 pinsand 11-12 pinswhenthisheaderisnotinuse.
PinAssignments(JP2):
1=VCC 2=VCC
3=GND 4=KEY
5=MSCLK6=MS_CK
7=MSDATA8=MS_DK
9=KBCLK10=KB_CK
11=KBDATA12=KB_DK
1197531
12108642

11
English
@USBHeader(USB3)
TheheaderisusedtoconnectauxillaryUSBdevicestothemainboard.Theheaderis
directionaland will onlyallowUSBcablestobeconnectedinonedirection.
PinAssignments(USB3):
1=GND
2=GND
3=USB+
4=USB-
5=5VSB
@ParallelPortHeader-EXT.PrinterPort(J1)
ADB25 maleparallelportheaderislocatedneartherearpanelofthemainboard.The
headerisusedtoconnectaparallelportsocket(PC15)tothemainboard.Theparallel
printerportcanbepurchasedfromShuttleasanoptionalaccessory.
PinAssignments(J1):
1=PSTB2=PD0 3=PD1
4=PD2 5=PD3 6=PD4
7=PD5 8=PD6 9=PD7
10=P_-ACK11=P_BUSY12=P_PE
13=P_SLCT 14=PAUTOFD15=P_-ERR
16=PINIT 17=PSLCTIN18=GND
19=GND 20=GND 21=GND
22=GND 23=GND 24=GND
25=GND 26=KEY
13
12
11
10
9
8
7
6
5
4
3
2
1
26
25
24
23
22
21
20
19
18
17
16
15
14

12
English
2XPCInstallation Guide
<2.1Installation
Note:Forsafetyreasons,pleaseensurethatthepowercordisdisconnected
beforeopeningthecase.
<2.1.1Remove theCover
1.Unscrewthefourthumbscrews.
2.Slidethecoverbackwardsand upwards.
2
1
