Shuttle K11 Series User manual
Kiosk K11 Series
Quick Start Guide
Copyright © 2021, Shuttle Corporation. All Rights Reserved
Package Contents
Opening / Closing the Kiosk
For safety reasons, please ensure that the power cord is disconnected before opening the
case. Do not attempt to open the system unless by authorized qualified personnel.
!
1. Insert the key into the lockhole at the rear case and turn it clockwise to open the front panel.
1. Power switch
2. Handle
3. Rear case
4. Cable hole
5. Connector for wifi antennas
11. IC card reader
12. NFC RFID reader
13. Front panel’s lockhole
14. Counter mount (optional)
6. Thermal vent
7. Webcam
8. 11” Touch display
9. Barcode scanner
10. Speakers
2. Close the front panel in reverse order avnd remove the key.
a
d
b
c
Unlock
Lockhole
Rear case
Clockwise
a
Lockhole
Front panel
b
c
Lock
Counter-
clockwise
d
6
8
7
9
12
11
13
10
14
Product Overview
3
4
5
13
6
1
2
2
10
The product’s colour and specifications may vary from the actually shipping product.
Should any accessories be required, please contact Shuttle or your relevant supplier.
i
Kiosk K11WL02/K11RK02 (x1)
Magnetic Keychain (x1)
The key to the case rear door. (x2)
Counter mount Installation (optional)
Counter Mount 100 x 100 mm
Screws M6 x 12L * 4pcs
As shown, install the counter mount and secure with the four screws.
1. Install the handle and secure with the two screws.
2. Gently push the two rubber cover into the two screw holes until it properly sits in place.
Handle
1
2
Pole mount (optional)
Thermometer (optional)
If you want to move the Kiosk,
please use the handle (a, b) to
assist in the operation. Do not pull the
white front frame parts to avoid structural
damage caused by uneven force on the
left and right sides of the Kiosk.
!
a
b
Powering on the system
1. Connect the two power cords to a wall outlet.
2. Place the magnetic keychain against the power switch for 1 seconds and remove it,
then the power status LED will start to blink for 2 seconds and turn on the system.
Repeat the steps above to turn off the system.
VESA mounting to the wall (optional)
The standard VESA openings show where an arm / wall mount kit which is available
separately can be attached.
Screws M6 x 12L * 4pcs
Cleaning the screen: Turn off the system and disconnect all cables. Use a cleaning cloth
which is soft, lint-free and a little damp to gently wipe the screen surface. Do not spray
liquids directly onto the device.
!
The K11 series can be wall-mounted using a VESA compatible 100 mm x 100 mm wall / arm
Le Série K11 peut être fixé au mur ou à un bras à l'aide d'un support VESA 100x100 mm.
Le support doit être conçu pour une charge d'au moins 25 kg et ne doit pas être situé à plus
de 2 m de hauteur.
!
The touch of your finger replaces the input devices and is all you need to operate the Kiosk.
Incorrectly replacing the battery may damage this computer. Replace only with the same or equivalent as recommended by Shuttle. Dispose of used batteries according to the manufacturer’s instructions.
Warning: This is Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
!
The unit can be operated at an ambient temperature of max. 35°C (95°F).
Do not expose it to temperature below 5°C (41°F) or above 35°C (95°F).
- Arrange the wires and cables connected to the product to prevent tripping, pulling or entanglement.
Kiosk is recommended to be used in an indoor environment to avoid exposure to a humid environment. If it is not used for a long time, it is recommended to be moisture-proof to avoid affecting the life of the appliance;
if it is in a humid environment, it is normal to produce a little fog in front of the screen. It can be automatically eliminated after a period of normal use.
1
2
100-240V, 50-60Hz, 1.5A for System
Wifi Antennas Installation (optional)
Take the antennas out of the accessory box. Screw the included antennas on the appropriate
connector at the rear case. Make sure it is aligned vertically or horizontally to achieve the best
possible signal reception.
1Connector for wifi antennas
2
