Shuttle K21 Series User manual
Kiosk K21 Series
Quick Start Guide
Copyright © 2021, Shuttle Corporation. All Rights Reserved
K21RK01 / K21WL01 (x1)
For safety reasons, please ensure that the power cord is disconnected before opening the
case. Do not attempt to open the system unless by authorized qualified personnel.
!
1. Insert the key into the lockhole at the rear case and turn it clockwise to open the front panel.
1. Power switch
2. Rear case
3. Cable hole
4. Connector for wifi antennas
5. Thermal vent
6. Webcam
7. 21” Touch display
8. Release button
9. Receipt printer
10. NFC RFID reader
11. Speakers
12. Barcode scanner
13. Front panel’s lockhole
14. IC card reader
15. Counter mount (optional)
2. Close the front panel in reverse
order and remove the key.
a
b
c
Unlock
Clockwise
b c
Lock
Counter-
clockwise
d
Do not touch the print head thermal elements. The print head becomes very hot just after
printing and is very dangerous. Be sure to allow the print head to cool down (after printing)
before cleaning it. Also, be sure to turn off the rinter power before cleaning the print head.
!
1. As shown, use the key to push the release button to open the printer cover.
2. Remove the used paper roll from the paper tray and load the new paper roll.
Make sure that a few inches of the paper is extended over the cover edge.
3. Close the printer cover. Tear the excess paper across the tear bar.
The product’s colour and specifications may vary from the actually shipping product.
Should any accessories be required, please contact Shuttle or your relevant supplier.
i
Roll Paper Partition (x1)
Magnetic Keychain (x1)
The key to the case rear door. (x2)
The key to the printer cover. (x3)
58mm thermal paper partition installation.
Paper roll width 80mm / 58mm selectable.
58mm paper roll only
Make sure the paper roll
is loaded in the direction.
b
Release button
a
c
d
5
7
6
8
9
13
11
14
10
12
11
24
3
5
1
15
Front panel
d
Lockhole
Rear case
a
Lockhole
Front panel
e
Cut the paper neatly.
3
Incorrectly replacing the battery may damage this computer. Replace only with the same or equivalent as recommended by Shuttle. Dispose of used batteries according to the manufacturer’s instructions.
!
The unit can be operated at an ambient temperature of max. 35°C (95°F).
Do not expose it to temperature below 5°C (41°F) or above 35°C (95°F).
2. Install the two handles on the both
sides of rear case and secure with
the four screws.
3. Gently push the four rubber cover into the four screw holes until it properly sits in place.
- Arrange the wires and cables connected to the product to prevent tripping, pulling or entanglement.
- Make sure the product does not hang over the edge of the supporting furniture.
- Do not place the product on supporting furniture higher than 1 meter.
Take the antennas out of the accessory box.
Screw the included antennas on the appropriate
connector at the rear case.
Make sure it is aligned vertically or horizontally
to achieve the best possible signal reception.
1. Connect the power cable to a wall outlet.
2. Place the magnetic keychain against the
power switch for 1 seconds and remove it,
then the power status LED will start to blink
for 2 seconds and turn on the system.
Repeat the steps above to turn off the system.
1
AC 100-240 V,
50-60 Hz, 1.5 A max
2
1. As shown, install the counter mount and secure with the four screws.
Counter Mount 100 x 100 mm
Screws 6M x 12L * 4pcs
2
1
2
The touch of your finger replaces the input devices
and is all you need to operate the Kiosk.
system and disconnect all cables.
Use a cleaning cloth which is soft,
lint-free and a little damp to gently
wipe the screen surface. Do not
spray liquids directly onto the device.
!
Connector for wifi antennas
1
The standard VESA openings show where an arm / wall
mount kit which is available separately can be attached.
The K21 series can be wall-mounted
using a VESA compatible 100 x 100 mm
wall / arm bracket.
The maximum load capacity is 25 kg
Le Série K21 peut être fixé au mur ou à un
bras à l’aide d’un support VESA 100 x 100 mm.
Le support doit être conçu pour une charge
d’au moins 25 kg et ne doit pas être situé à
plus de 2 m de hauteur.
!
Screws 6M x 12L * 4pcs
This manual suits for next models
2
