Sicunet NEPTUNE User manual

Access Control Systems
Intercom Integrated
SDOC-5011

NEPTUNE P A G E 2
Notices
All rights strictly reserved. No part of this document may be reproduced, copied, adapted, or
transmitted in any form or by any means without written permission from Sicunet.
Standards Approvals
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment a residential area is likely to cause harmful
interference in which case the user willbe required to correct the interference athis own expense.
This access control system is compliant with Level I UL 294 listed devices and must be installed
in controlled locations.
Corporate Office
USA
3001 Red HillAve. Suite 2-205, Costa Mesa, CA 9262 6
Tel. [phone] Fax. [phone]
China
E1608 Bldg-East, Nanshan Digital Technology & Cultural Industry Park, Nanshan, Shenzhen,
China 518052
Tel. [phone]
Korea
Samsung-Dong, 8-1 Gunsul B/D Suite 301, Gangnam-Gu, Seoul, Korea 06097
Tel. [phone] Fax. [phone]
www.sicunet.com
Technical Support
Tel.: [phone]

NEPTUNE P A G E 3
E-mail: [email protected]
Notice
It is important that this instruction manual be read and understood completely before installation
or operation is attempted. It is intended that the installation of this unit will be performed only by
persons trained and qualified in the installation of access control equipment. The important
safeguards and instructions in this manual cannot cover all possible conditions and situations
which may occur during installation and use. It must be understood that common sense and
caution must be exercised by the person(s) installing, maintaining and operating the equipment.

NEPTUNE P A G E 4
History
Update
Description
Ver
04-05-2019
initial version
1.0

NEPTUNE P A G E 5
1.0 INTRODUCTION.............................................6
2.0 INTERCOM.....................................................6
2.1 Http Event Setup 7
2.2 Call Button Setup 8
2.3 Controller Setting 9
3.0 NEPTUNE.....................................................10
3.1 Event Action Setting 10

NEPTUNE P A G E 6
1.0 Introduction
This manual contains Information regarding the basic Intercom Integrated configuration of the
Neptune Access Control
2.0 Intercom
Intercom products integrated with NEPTUNE are described based on the DS05M Model of
“Beward”.
* Refer to the figure below for the connection between NEPTUNE and Intercom.
NEPTUNE
NC102P
(Intercom)
Alarm
Aux Input

NEPTUNE P A G E 7
2.1 Http Event Setup
❒Enable
Select whether to use Http Event to link with Neptune Server. Basically, it must be checked to use.
❒Protocol
Protocol for interworking with Neptune Server should be selected as HTTP by default.
❒Hostname
Enter the IP address and port of the Neptune Server.
IPAddress means the IP address of the Neptune Server already installed.
Port is using port number 8082 assigned to the Neptune Server.
* Example : 192.168.0.250:8082

NEPTUNE P A G E 8
❒Request
In order to recognize Intercom on Neptune Server, you must enter “/ beward”.
* Example : /beward
❒Method
The method to send to the Neptune Server is selected as “GET”.
2.2 Call Button Setup
❒Turn on
It activates the event alarm to the Neptune Server when an Intercom Call Button Event occurs.
❒Time 1
Select the time to use Event Alarm to the Neptune Server when a Call Button Event occurs in
Intercom. Basically, to use continuously, set the time as the default. The default time is 00:00 –
23:59.
❒HTTP event
Enter the door information to be delivered to the Neptune Server when a Call Button Event occurs
in Intercom. All entered English characters can be used in lower case.

NEPTUNE P A G E 9
m : method name ( Default fixed “call”)
door : Neptune Server Door List No.
* Example : m=call&door=15
2.3 Controller Setting
Controller type information may differ for each product of “BEWARD”.
The product described in this manual is based on the “NC102P” product.
❒Controller Type
Selected as Intercom's Channel 1
❒Status
Check Box Check.

NEPTUNE P A G E 10
❒Duration
Default Duration Used.
3.0 NEPTUNE
3.1 Event Action Setting
❒Adding an Event Action
Click New and enter a name and description.
In the Basic Section, name the event, fill in a Description, and select a Schedule for the time the
Event Action will be active.
❒Event
In the Event section. click Insert to add a new event
Choose the type is Aux Input (fixing)

NEPTUNE P A G E 11
Select “Aux Input” in the Event category.
Storage
❒Action
Select “Door” for Action Source Type.
Select the door to open when a door open trigger occurs in Intercom.
NEPTUNE Dash Board Log of Intercom Trigger Event
