Siemens QAX913 Guide

Edition 1.0
QAX9x3 Series A
CE1C2740en
13.12.2010 Building Technologies
s
Synco™ living
Mounting and commissioning

3 / 134
Siemens Synco™ living CE1C2740en
Building Technologies 13.12.2010
Congratulations …
… on choosing the Siemens Synco™ living system and thank you for pur-
chasing the central apartment unit!
The present document describes how to mount and commission the central
apartment unit and the other system components.
First, please familiarize yourself with the operating philosophy of the central
apartment unit. Operation itself is covered by the operating instructions
(CE1B2740en).
Symbols used
The symbols used on the central apartment unit are explained in Section "Dis-
play symbols" in the operating instructions. The following symbols are used in
this document:
This symbol draws your attention to important information you must ob-
serve to ensure safe operation of the plant.
The info symbol refers to additional information, notes and practical tips
on settings and operation of the various units and the system.
This symbol refers to disposal issues.
Setting values and predefined settings
When commissioning the system, the activated parameters are loaded as
predefined settings. The documentation differentiates between guide values
and factory settings.
Guide value Setting recommended for most types of plant.
Factory setting Setting that can be changed to meet user- or plant-
specific requirements.
Siemens Switzerland Ltd
Industry Sector
Building Technologies Division
Gubelstrasse 22
6301 Zug
Switzerland
Tel. [phone]
www.siemens.com/sbt
© 2006-2010 Siemens Switzerland Ltd
Subject to change

4 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Table of contents
Safety notes................................................................................................... 11
Mounting and installation............................................................................. 12
Mount the central apartment unit .............................................................. 12
Mounting rules.................................................................................... 12
Mounting location ............................................................................... 12
Central apartment unit QAX913 dimensions ...................................... 13
Dimensions of the base......................................................................13
Mounting procedure ........................................................................... 14
Mounting method / knockout holes .............................................. 14
Holes............................................................................................ 14
Remove the electronics section from the base ............................ 14
Fit the base .................................................................................. 15
Wiring...........................................................................................15
Replace the electronics section ................................................... 15
Electrical installation of the central apartment unit ................................... 16
Installation rules ................................................................................. 16
Connection terminals/wiring ............................................................... 16
Commissioning the system ......................................................................... 18
Prerequisites............................................................................................. 18
Procedure .................................................................................................18
Basic configuration of the central apartment unit ..................................... 18
Switch on the central apartment unit .................................................. 18
Change to the expert level ................................................................. 19
Select the Commissioning menu........................................................ 20
Configure rooms.................................................................................20
Configure room groups....................................................................... 22
Room group name ....................................................................... 22
Function ....................................................................................... 22
Room group pumps .....................................................................23
Return temperature limitation....................................................... 24
Configure domestic hot water (QAX913 only) .................................... 25
DHW sensor................................................................................. 26
DHW charging pump/diverting valve............................................ 26
Electric immersion heater ............................................................ 27
Operation of external DHW heating ............................................. 27
Configure ventilation........................................................................... 28
Function ....................................................................................... 28
Configure switching groups (QAX913 only) ....................................... 29
Switching group relay................................................................... 30
Configure doors (QAX913 only) .........................................................31
Configure meter.................................................................................. 31
Synergyr....................................................................................... 31
Allocation ..................................................................................... 32
Source.......................................................................................... 32
Configure heat/cooling energy meter........................................... 32
Configure hot water meter ...........................................................33

5 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Configure cold water meter.......................................................... 33
Configure electricity meter ........................................................... 34
Configure gas meter .................................................................... 34
Configure other meters ................................................................ 34
Configure light state display (QAX913 only) ...................................... 35
Temperature display (QAX913 only).................................................. 36
Display fault status message bus....................................................... 36
Configure fault input/output (QAX913 only) ....................................... 37
Fault inputs 1 – 8 ......................................................................... 37
Fault outputs 1 and 2 ................................................................... 37
Supervision (QAX913 only)................................................................ 38
Supervision contact ..................................................................... 38
Supervision state ......................................................................... 38
Water shutoff valve ...................................................................... 39
Gas shutoff valve ......................................................................... 39
Status output 1 – 4....................................................................... 40
Handheld control (QAX913 only) ....................................................... 40
Configure inputs ................................................................................. 40
Operating mode contact .............................................................. 41
Summer operation ....................................................................... 41
Cooling enable............................................................................. 42
Heating/cooling changeover ........................................................ 42
Dew point..................................................................................... 43
Absence....................................................................................... 43
Twilight (QAX913 only) ................................................................ 44
Configure outputs............................................................................... 44
Heat demand relay ...................................................................... 45
Heat demand DC 0..10 V............................................................. 45
Refrigeration demand relay ......................................................... 45
Refrigeration demand DC 0..10 V................................................ 46
Summer operation ....................................................................... 46
Cooling enable............................................................................. 47
Window/door state ....................................................................... 47
Exhaust hood............................................................................... 47
Configure RF repeater ....................................................................... 48
Configure info pages .......................................................................... 48
Windows/doors ............................................................................ 48
Business card .............................................................................. 48
Progression of outside temperature............................................. 49
Progression of air pressure.......................................................... 49
Consumption data........................................................................ 49
Configure cooling mode ..................................................................... 49
2-pipe heating/cooling system ..................................................... 49
Extra configuration.................................................................................... 50
Rooms................................................................................................ 50
Assign rooms to room groups...................................................... 50
Cooling release output................................................................. 50
Configure ventilation .......................................................................... 51
Step selector................................................................................ 51
Humidity sensor ........................................................................... 51
Indoor air quality sensor .............................................................. 52

6 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Fireplace mode ............................................................................ 52
Ventilation contacts 1 and 2.........................................................53
HR bypass ................................................................................... 53
Meters ................................................................................................53
Due date ...................................................................................... 54
Synergyr apartment ..................................................................... 54
Identification number.................................................................... 54
Impulse sensor type.....................................................................54
Unit factor..................................................................................... 55
Pulse valency numerator and denominator ................................. 56
Start value....................................................................................57
Calibrate date and year................................................................ 57
Synergyr meter number ............................................................... 57
Faults (QAX913 only) ......................................................................... 58
Fault input source ........................................................................58
Fault input normal position...........................................................59
Connect RF components .......................................................................... 59
Notes .................................................................................................. 59
Connect RF room devices.................................................................. 59
Connect room unit QAW910 ........................................................ 60
Connect room temperature sensor QAA910................................ 61
Connect SSA955 radiator control actuators................................. 61
Connect RRV912 and RRV918 heating circuit controllers........... 62
Connect window contacts ............................................................ 64
Connect smoke detector (QAX913 only)............................................ 64
Connect RRV934 multi-controller.......................................................65
Connect cooling release outputs ........................................................ 66
Connect room group devices ............................................................. 67
Connect output for the mixing valve............................................. 67
Connect input for flow sensor / return sensor .............................. 67
Connect output for room group pump .......................................... 68
Connect ventilation components ........................................................ 68
Connect input for the humidity sensor/indoor air quality sensor .. 68
Connect input for open fireplace mode ........................................ 68
Connect input for ventilation contacts 1 and 2............................. 69
Connect outputs for the step selector .......................................... 69
Connect outputs for the HR bypass ............................................. 70
Connect DHW components (QAX913 only) ....................................... 70
Connect the input for the DHW sensor ........................................ 70
Connect the output for the DHW pump/valve .............................. 70
Connect the output for the electric immersion heater .................. 71
Connect meteo sensor ....................................................................... 71
Connect lighting and blinds control (QAX913 only)............................ 72
Connect RF adapter plugs KRF960 and KRF961........................ 72
Connect GAMMA wave actuator (QAX913 only)......................... 72
Connect switching group relay (QAX913 only)................................... 72
Connect meter.................................................................................... 73
Connect WRI982 consumption data interface ............................. 73
Connect door contacts (QAX913 only)...............................................74
Connect temperature sensor (QAX913 only) .....................................74
Connect fault inputs 1 – 8 (QAX913 only) .......................................... 74

7 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Connect water detector QFP910 (QAX913 only) ........................ 75
Connect fault outputs 1 – 2 (QAX913 only) ....................................... 75
Connect supervision components (QAX913 only) ............................. 76
Connect supervision contact........................................................ 76
Connect supervision state ........................................................... 76
Connect water shutoff valve ........................................................ 76
Connect gas shutoff valve ........................................................... 77
Connect status outputs 1 – 4 ....................................................... 77
Connect handheld control .................................................................. 77
Connect inputs ................................................................................... 78
Connect inputs for operating mode contact................................. 78
Connect input for summer operation ........................................... 78
Connect input for cooling enable ................................................. 78
Connect input for heating/cooling changeover ............................ 78
Connect input for dew point ......................................................... 79
Connect input for absence........................................................... 79
Connect input for twilight (QAX913 only)..................................... 79
Connect outputs ................................................................................. 79
Connect output for heat demand DC 0..10 V............................... 79
Connect heat demand relay......................................................... 80
Connect output for refrigeration demand DC 0..10 V .................. 80
Connect output for refrigeration demand relay ............................ 80
Connect output for summer operation ......................................... 80
Connect output for cooling enable ............................................... 81
Connect the window/door state output ........................................ 81
Connect Hager tebis devices (QAX913 only) .................................... 81
Numbering inputs......................................................................... 81
Connect RF repeaters........................................................................ 82
Assign devices to RF repeaters................................................... 83
Connect RF adapter plugs KRF960 and KRF961 (QAX913 only) . 83
Connect GAMMA wave actuator (QAX913 only)......................... 83
Test radio connections ............................................................................. 84
Wiring test................................................................................................. 84
Disconnect devices................................................................................... 86
Replace devices ....................................................................................... 87
Replace meter on pulse input ............................................................ 87
Replace M-bus meter......................................................................... 88
Display the device list by function ............................................................ 88
Display the device list for all devices........................................................ 89
Delete devices from the device list..................................................... 90
Bus communication .................................................................................. 90
Device address KNX TP1 .................................................................. 90
Bus power supply............................................................................... 90
Programming mode............................................................................ 91
Clock time operation .......................................................................... 91
Remote setting clock slave ................................................................ 91
Calendar zone (holidays and special days) ....................................... 92
DHW zone.......................................................................................... 92
Set distribution zone........................................................................... 93
Exit the "Commissioning" menu ............................................................... 94

8 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Function settings .......................................................................................... 95
General ..................................................................................................... 95
Buzzer volume.................................................................................... 95
Password expert level ........................................................................ 95
Apartment .................................................................................................95
Enable setpoint limitation ................................................................... 95
Heating setpoint limitation .................................................................. 96
Cooling setpoint limitation .................................................................. 96
Pump overrun time ............................................................................. 96
Valve override .................................................................................... 96
Economy increase.............................................................................. 96
Rooms ......................................................................................................97
Room temperature increase...............................................................97
Proportion of room unit....................................................................... 97
Valve position cooling mode / summer operation .............................. 98
Minimum valve position Comfort ........................................................98
H/C changeover locking time ............................................................. 98
Room controller settings ........................................................................... 99
P-band Xp .......................................................................................... 99
Integral action time Tn........................................................................99
Derivative action time Tv .................................................................. 100
Neutral zone ..................................................................................... 100
Switching differential 2-position........................................................ 100
Actuator runtime ............................................................................... 101
Switching differential for cooling....................................................... 101
Room groups .......................................................................................... 101
Flow temperature limitation room heating ........................................ 101
Minimum limitation ..................................................................... 101
Maximum limitation .................................................................... 103
Return temperature limitation ........................................................... 103
Cooling curve ................................................................................... 104
Setpoint increase mixing valve......................................................... 105
Setpoint decrease mixing valve........................................................ 105
Temperature request winter operation ............................................. 105
Valve position temperature request On/Off ...................................... 106
Actuator runtime ............................................................................... 106
P-band Xp ........................................................................................ 106
Integral action time Tn......................................................................107
Ventilation ............................................................................................... 107
Indoor air quality control ................................................................... 107
Indoor air quality at 0 V/10 V ............................................................ 107
P-band Xp indoor air quality ............................................................. 107
Humidity limitation ............................................................................ 108
Switching differential of humidity limitation....................................... 108
Running time humidity limitation....................................................... 108
Pause time humidity limitation.......................................................... 109
Air humidity at 0 V/10 V....................................................................109
Minimum operating time night cooling.............................................. 109
Reference room night cooling .......................................................... 109
Outside temperature limit value night cooling .................................. 110
Room outside temperature delta night cooling................................. 110

9 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Startup delay .................................................................................... 110
Locking time ..................................................................................... 110
Rundown time .................................................................................. 110
DHW (QAX913 only) .............................................................................. 111
Frost protection setpoint................................................................... 111
Legionella setpoint ........................................................................... 111
Legionella protection frequency ....................................................... 111
Legionella protection time ................................................................ 111
Legionella protection period ............................................................. 111
DHW priority..................................................................................... 112
Switching differential ........................................................................ 112
Charging time max ........................................................................... 112
Forced charging ............................................................................... 113
Setpoint boost DHW charging.......................................................... 113
System pump required ..................................................................... 114
Summer operation electric immersion heater .................................. 114
Switching groups (QAX913 only)............................................................ 115
Scene number.................................................................................. 115
Consumption data .................................................................................. 115
Operating hours ............................................................................... 116
ID number ........................................................................................ 116
Metering medium ............................................................................. 116
Allocation.......................................................................................... 116
Meter replacement ........................................................................... 116
Time of day/date..................................................................................... 116
Start/end of daylight saving time...................................................... 116
Faults...................................................................................................... 117
Fault history...................................................................................... 117
Delete faults ..................................................................................... 117
Inputs/Outputs ........................................................................................ 117
Simulate outside temperature .......................................................... 117
Texts....................................................................................................... 118
File name ......................................................................................... 118
Room group names 1 - 2 ................................................................. 118
Business card title and lines 1 – 4.................................................... 118
Meter names .................................................................................... 118
Heat request 0..10 V............................................................................... 119
Refrigeration request 0..10 V ................................................................. 120
Exhaust hood.......................................................................................... 121
Impact of window switches............................................................... 121
Handheld control (QAX913 only)............................................................ 121
Function test water detector ................................................................... 121
Device information.................................................................................. 121
VVS-ID ............................................................................................. 121
Device list repeater .......................................................................... 122
Data backup ........................................................................................... 122
System limits............................................................................................... 123
System limitations (TP1 bus) ..................................................... 123
Limitations per central apartment unit........................................ 123
Limitations per room .................................................................. 123

10 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Table of contents 13.12.2010
Communication ........................................................................................... 124
Protocol...................................................................................... 124
Maintenance/service ................................................................................... 124
Peripheral devices .................................................................................. 124
Restore factory settings.................................................................... 124
Manual control of the radiator control actuator.................................124
Disposal .......................................................................................................125
Index.............................................................................................................126

11 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Safety notes 13.12.2010
Safety notes
Product liability
•Use these products only in building services plant and only for the
applications described.
•Comply with all local safety regulations (installation, etc.).
•Do not open the devices. Opening the devices will void warranty by
Siemens.
•If a device is defective or damaged, disconnect it from power imme-
diately and replace it.
•Application-related technical data are only guaranteed in connection
with the Siemens Synco™ living system. When using together with
third-party products not specified by Siemens, user must ensure
functionality. In that case, Siemens does not provide any services or
warranty.

12 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
Mounting and installation
Mount the central apartment unit
Mounting rules
•The central apartment unit is designed in compliance with safety class II
and must be mounted accordingly.
•Power may be applied to the unit only when completely mounted. Other-
wise, there is a risk of electric shock by the connection terminals.
•Do not expose the unit to dripping water.
•Adhere to the permissible ambient conditions as stated in the technical data
(see data sheets N2740en (QAX913) or N2741en (QAX903)).
•Sufficient space must be provided for fitting/removing the unit cover and for
connecting the service tool (>70 mm below and >10 mm above the unit).
Mounting location
The central apartment unit consists of electronics section and base.
The base is designed for wall mounting (on an interior wall of the apartment).
We recommend mounting the unit in an easily accessible space (e.g. in the
living room or the lobby). For convenient operation, the recommended mount-
ing height is 1.5 m above the floor.
2707Z31
> 70 mm > 10 mm
1.5 m
The central apartment unit communicates with most system components via
radio. To ensure optimum radio coverage, the following points should be ob-
served:
•The distance to devices with electromagnetic emissions, such as wireless
telephones, TV sets, PCs, microwave appliances, etc., should be at least
1 m.
•Larger items made of steel or construction elements with metal meshes
(e.g. special glass or concrete), or metal foils in thermal insulation materials,
mirrors or metal-coated heat absorbing glass, can have an impact on the
range.
•The typical range between transmitter and receiver in residential buildings is
30 m, or across 2 floors, or 2 concrete ceilings. But depending on the type

13 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
of house or building and the materials used, the effective range can be con-
siderably greater or smaller.
If greater distances are to be covered, RF repeaters should be used.
Central apartment unit QAX913 dimensions
Dimensions in mm
Dimensions of the base
Dimensions in mm

14 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
Mounting procedure
Mounting method / knockout holes
The base of the central apartment unit can be mounted directly on the wall or
on a recessed conduit box. It has an opening at the rear and 2 knockout holes
(one at the top and one at the bottom). If required, the hole(s) must be
knocked out before securing the base to the wall.
Holes
Secure the base to the wall with at least 3 screws. To determine the positions
of the holes in the wall, hold the base horizontally against the wall and mark
the required positions.
Remove the electronics section from the base
Insert a screwdriver (size 3)
in the first and then in the
second slot at the bottom of
the unit, slightly push it and
then turn to unlock.

15 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
Swing the electronics sec-
tion 45° upward and pull it
towards you to remove it.
Fit the base
Secure the base to the wall
using at least 3 fixing screws.
Wiring
Wiring is described under “Connection terminals/wiring“ (see page 16).
Replace the electronics section
Insert the electronics section
at an angle of about 45° in the
base (left and right). Then,
swing it downward until it en-
gages.
The central apartment unit is
now ready for commissioning.

16 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
Electrical installation of the
central apartment unit
Installation rules
•Comply with all local safety regulations (installation, etc.).
•Only qualified staff may carry out electrical installations.
•Prior to installation, disconnect the central apartment unit from power!
•The connection terminals for low-voltage and mains voltage are arranged
on different sides of the unit.
•When wiring the unit, satisfy requirements of safety class II.
•Provide cable strain relief.
Connection terminals/wiring
The connection terminals can be accessed from the front of the base.
Connect the low-voltage and mains voltage cables to the respective terminals
on the base.
Run the cables under the straps provided and – after connection – ensure
strain relief with the help of cable ties.

F

17 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Mounting and installation 13.12.2010
Detail view
Q13 Q14
N L
CE- CE+
M
B
2707Z24
KNX
230 V

Key
Mains voltage or protective extra low-voltage
Q13, Q14 Potential-free, universal relay output
Mains voltage
N Operating voltage, neutral conductor AC 230 V
L Operating voltage, live conductor AC 230 V
Protection by extra-low voltage
CE-, CE+ Connection data bus KNX TP1- and KNX TP1+
M Ground for universal input
B Universal input
F Strap for cable ties

18 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Commissioning the system 13.12.2010
Commissioning the system
Prerequisites
Prior to commissioning the system, check to ensure that the following prereq-
uisites are met:
•You are familiar with the different operating elements and operating levels
of the central apartment unit.
•All system components are correctly installed.
•Mains-powered components are connected to power.
•New batteries are ready to be inserted in the battery-powered devices *.
•Wired devices are connected to the KNX TP1 data bus.
•Meters are integrated correctly and connected to the consumption data in-
terface WRI982.
* To extend battery life, insert the batteries only prior to connecting the
device to the central apartment unit (for procedures, see the mount-
ing instructions of the associated device).
Procedure
Commission the system in steps:
1. Commission the meters (if available):
2. Enter the basic configuration for the central apartment unit.
3. Enter extra configurations for the central apartment unit.
4. Switch on and connect the devices communicating via radio (KNX RF).
5. Test the wiring.
6. Configure the wired bus communication (KNX TP1).
7. Set the central apartment unit parameters.
Basic configuration of the central apartment
unit
You must first enter the basic configuration at the central apartment unit to
connect devices.
Switch on the central apartment unit
The central apartment unit must be switched on to enter the basic configura-
tion.

19 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Commissioning the system 13.12.2010
The unit switches on as soon as
power is supplied. A brief function test
is carried out while the hourglass is
displayed.
When you first commission the central apartment unit, you must select
the language, time of day, year, and date.
The display then changes to the default picture.
You can also select both language and time format during operation.
See the operating instructions for a description.
Tuesday 01:32 16.11.2010
If the central apartment unit was oper-
ated previously (e.g. after a power fail-
ure), the default picture appears after
the function test.
Change to the expert level
You must be at the expert level to enter the basic configuration.
Simultaneously press the Esc and Menu/ok button to
go from the default picture to the expert level. The
”Access levels“ window opens.
Access levels
User
Service
Expert
Use the arrow buttons to select the
expert level and confirm your selection
by pressing the Menu/ok button.
Enter
p
assword
0
To change to the expert level, you
must enter a password (factory setting
= 9). Confirm the password by pressing
the Menu/ok button.
If no button is pressed on the expert level for a certain period of time,
the central apartment unit automatically returns to the user level.
20°C
5°C
1013 hPa

20 / 134
Siemens Synco™ living CE1C2740en
Building Technologies Commissioning the system 13.12.2010
Select the Commissioning menu
From the “Main menu“ of the central apartment unit, select submenu “Com-
missioning“ and confirm the selection by pressing the Menu/ok button.
Caution!
Plant stops
You are notified that the plant is being
stopped. Confirm by pressing the
Menu/ok button to shut down the plant
and go to the ”Commissioning“ menu.
Commissioning
Basic configuration…
RF connections…
Device list…
Bus communication…
You are now in the “Commissioning “
menu – the plant has been stopped.
It is switched on again only when you
manually exit the ”Commissioning ”
menu by pressing the Esc button (no
timeout).
Configure rooms
Activate the required rooms by selecting a heating/cooling type other than “---“
or by activating function ”Supervision only“.
Main menu > Commissioning > Basic configuration
> Rooms > Room X > Heating type:
--- Inactive – all relevant room heating informa-
tion and all operating lines are hidden.
(Factory setting)
Radiator heating slow Radiator heating in buildings with massive
walls, heavy construction.
Radiator heating fast Radiator heating in buildings with light
walls, light construction.
Floor heating slow Floor heating in buildings with massive
walls, heavy construction and massive floor
construction.
Floor heating fast Floor heating in buildings with light walls,
light construction and light floor construction.
Rad/floor user-defined Control parameters can be manually set.
Air conditioner (S-mode) For rooms with an air conditioner used for
heating.
Usually, the standard heating types are enough. Customize settings
only in plants with greatly differing control behavior (see page 99).
