SIRIUS 3R
Halbleiter-Motor-Steuergerät
AC Semiconductor Motor Controller
Contrôleur de moteur à semiconducteurs
3RW30/31
EN/IEC 60947-4-2
Montageanleitung/Assembly InstructionsBestell-Nr./Order No.: 3ZX1012-0RW30-1AA1
3RW301.
L1 L2 L3
A1/A2; NO/NC
3RW302.
3RW312.
L1 L2 L3
3RW303.
L1 L2 L3
3RW304..
L1 L2 L3
∅5 ... 6 mm / PZ2
0,8 ... 1,2 Nm
7 to 10.3 LB.IN
2 ... 2,5 Nm
18 to 22 LB.IN∅5 ... 6 mm / PZ2
3 ... 4,5 Nm
27 to 40 LB.IN
4 ... 6 Nm
35 to 53 LB.IN
2 x 0,5 ... 1,5 mm²
2 x 0,75 ... 2,5 mm²
2 x 1 ... 2,5 mm²
2 x 2,5 ... 6 mm²2 x 0,75 ... 16 mm²2 x 2,5 ... 16 mm²
2 x 0,5 ... 2,5 mm²2 x 1 ... 2,5 mm²
2 x 2,5 ... 6 mm²
2 x 0,75 ... 16 mm²
1 x 0,75 ... 25 mm²
2 x 2,5 ... 35 mm²
1 x 2,5 ... 50 mm²
------------2 x 0,75 ... 25 mm²
1 x 0,75 ... 35 mm²
2 x 10 ... 50 mm²
1 x 10 ... 70 mm²
AWG2 x 18 to 142 x 14 to 10AWG2 x 18 to 3
1 x 18 to 2AWG2 x 10 to 1/0 1 x 10 to 2/0
min
22
4
10 13 17
10 13 17
13 17
5
10
20s0
maxmin 5
10
20s0
1 L1 3 L2 5 L3
3RW
A1A2 1
13 14/23 24
2 T1 4 T2 6 T3
1.
2.
1.A1/A2:
supply voltage
tension d’aliment.
2.L1/L2/L3:
power
puissance
3RW30
tRon
uS
tR off
optional
3RW301.---
3RW302.
3RW312.3RW3926-8A
3RW303.
3RW304.3RW3936-8A
3RW31
tR1
uS
tR2
US
UN
U
tR on tR off t
Us
UN
U
t
tR1 tR2
3RW30
3RW31
2
1
RW-00556
5
10
20s
0
maxmin 5
10
20s
0
1 L1
2T1
3L2 5L3 IN1 A1
4T2 6 T3 A2
1.
2.
3RW301.3RW302.
3RW303./3RW304
.
tR on tR off t
WarnungWarning
Einschalthäufig-
keit:
Abkühlzeit be-
achten!
Frequency of
starting:
keep cooling
time in mind!
Attention
Fréq. de démar. :
respectez le
temps de refroi-
dissement !
ON 13/14
BYPASSED 23/24

DANGER
Hazardous voltage.
Will cause death, serious personal injury,
or property damage.
Always de-energize and ground the equipment
before maintenance. Read and understand this
manual before installing, operating, or main-
taining the equipment. Maintenance should be
performed only by qualified personnel. The use
of unauthorized parts in the repair of the
equipment or tampering by unqualified per-
sonnel may result in dangerous conditions
which may cause death or serious personal in-
jury, or equipment or property damage. Follow
all safety instructions contained herein.
Qualified Person
For the purposes of this manual and product labels a qualified
person is one who is familiar with the installation, construction,
operation, or maintenance of the equipment and the hazards in-
volved. In addition this person has the following qualifications:
ais trained and authorized to energize, de-energize, clear,
ground, and tag circuits and equipment in accordance with esta-
blished safety practices.
bis trained in the proper care and use of protective equip-
ment such as rubber gloves, hard hat, safety glasses or face
shields, flash clothing, etc., in accordance with established
safety practices.
cis trained in rendering first aid.
Important
These instructions do not purport to cover all details or variations in equipment, nor to provide for every possible contingency to be met in connec-
tion with installation, operation or maintenance. Should further information be desired or should particular problems arise which are not covered
sufficiently for the purchaser’s purposes, the matter should be referred to the local Siemens sales office. The contents of this instruction manual
shall not become part of or modify any prior or existing agreement, commitment or relationship. The sales contract contains the entire obligation
of Siemens. The warranty contained in the contract between the parties is the sole warranty of Siemens. Any statements contained herein do not
create new warranties or modify the existing warranty.
AchtungAttentionImportant :
Der Sanftstarter 3RW3...-1..1. wurde als Gerät
der Klasse A gebaut. Der Gebrauch dieses Pro-
dukts in Wohnbereichen könnte zu Funkstörun-
gen führen.
The Soft Starter 3RW3...-1..1. have been desi-
gned for class A equipment. Use of the product
in domestic environments can cause radio inter-
ference.
Le démarreur progressif 3RW3...-1..1. est conçu en
tant qu’appareil de classe A. L’utilisation de ce pro-
duit dans le domaine résidentiel pourrait entraîner
des perburbations radioélectriques.
Warnung!Warning!Attention !
Dieses Gerät wurde im Werk sorgfältig
geprüft und in Ordnung befunden. Auf dem
Transportweg zu Ihnen können
u. U. Beanspruchungen aufgetreten sein, auf
die wir keinen Einfluß haben.
Die Überbrückungsrelais im Hauptstromkreis
können sich in einem undefinierten Schaltzu-
stand befinden.
Im Interesse einer vollständigen Sicherheit
ist bei der Inbetriebsetzung oder nach einem
Austausch des SIRIUS Sanftstarters folgen-
des Vorgehen notwendig:
Legen Sie zuerstdie Versorgungsspannung
an, um die Überbrückungsrelais in einen
definierten Schaltzustand zu bringen.
Schalten Sie danachden Hauptstromkreis
ein.
Ansonsten kann der Motor unbeabsichtigt
eingeschaltet werden und Schäden an Per-
sonen oder Anlagenteilen hervorrufen.
This device has been thoroughly tested at
the factory and found to be in order. On its
way to you, the device may have been expo-
sed to stresses and strains for which we are
not responsible.
The bypass relays in the main circuit may be
in an undefined switching state.
In the interests of complete safety, the follo-
wing procedure is necessary during commis-
sioning or after replacement of the SIRIUS
soft starter:
Apply the supply voltage firstto set the
bypass relays to a defined switching state.
Only thenswitch on the main circuit.
Otherwise, the motor may be unintentionally
activated and may cause injury or damage to
persons or plant components.
Cet appareil a subi des essais minutieux et a
quitté l’usine en ordre de marche. Il a pu
subir en cours de transport des sollicitations
dont nous ne pouvant être portés respon-
sables.
Les relais de shuntage dans le circuit princi-
pal peuvent se trouver dans une position
indéfinie.
Dans l’intérêt d’une parfaite sécurité, la
démarche suivante est nécessaire lors de la
mise en service et après un remplacement
du démarreur progressif SIRIUS :
Appliquez d’abordla tension d’alimentation
pour mettre les relais de shuntage dans une
position définie.
Ensuite seulementfermer le circuit principal.
Sans cette précaution, le moteur peut
démarrer intempes-tivement et causer des
blessures aux personnes ou des dommages
matériels.
2

A2 A1 1
ON/OFF
A1
IN1
K1
A1
A2 1
ON
OFF
13 14/23 24
K1
K1
ON
OFF
M
3RW30
3RU/3RB10
3RT
3RW30
3RV
I >
A1 1
ON/OFF
A2
2
ON/OFF
Ramp 1
Ramp 2 A1A2 1
K1
2
K2
OFF
ON ON
K1
K1
K1K2
K2
K2
Ramp 1 Ramp 2
3RW303RW301.3RW302./3RW312./3RW303./
3RW304.
3RW31 - Dual Ramp
M
3 ~
. /.P
A2
N (L-) L1 (L+)
3 ~ M 3 ~
F1
F2
F3
F1
K1
3RU/3RB10
3RT
3RU/3RB10
3RT
N (L-)
L1 (L+)
L1 (L+)
L1(L+)N (L-)
N (L-)
N (L-)
L1 (L+)
K2
K1
F2 F3
Bestell-Nr./Order. No.:a b c d e fg h i j klmn
3RW301.97,5 45 93 95 66 51 -- 7,5 76 -- 86 -- 90 35
3RW302./3RW312.125 45 119 125 81 63 96 7 101 63 14 7 115 35
3RW303.160 55 143 141 95 63 1158119 77 18 7 150 30
3RW304
.
170 70 178 162 108 87 1568132 87
22,
5 7 160 60
k
j
i
b
a
l
m
n
5
c
h
5f
g
ed
3RW31
mm
3RW30..-1AA.2
3RW30
I>
I>
I>
3RV
M
1~
3RW30
M
1~
3RT
3RU/3RB10
K1
F1
1L1 3L2/N
2T1 4T2/N
1L1 3L2/N
2T1 4T2/N
3
