Siemens WTX16.GSM User manual

CE1N2878en
14.07.2005
Building Technologies
HVAC Products
2878
Siemeca™ AMR
Network nodes
with gateway WTX16.GSM
WTX16.IP
WTX16.MOD
The WT…16… network nodes are used to receive and handle the data transmitted
by consumption meters of the Siemeca™ AMR system. They are equipped with a
gateway that can provide data of up to 2,000 meters for remote readout.
WTX16.IP can be read via Ethernet while WTX16.GSM and WTX16.MOD contain a
GSM modem. They are read via the telephone network.
Use
The WT…16… network node is a component of the Siemeca™ system.
It has been designed for use in buildings to create a radio network for receiving and
storing the data transmitted by the consumption meters installed in the building. Com-
munication between several network nodes is via radio also so that no wiring is re-
quired. All measured values acquired by the consumption meters are continuously
exchanged within the network, which means that every network node stores the current
consumption values, the values read out at the end of the month, and the set day val-
ues of all metering devices on the network. Owing to this operating principle, all net-
work data can be read out at any of the nodes, or a Siemeca™ gateway for remote
data transmission can be used with any of the nodes.
The field of use of the Siemeca™ AMR system is described in Data Sheet N2870.

2/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
Functions
•Reception and storage of the data transmitted by the Siemeca™ AMR consumption
meters
•Automatic creation of a network with up to 12 WT…16 (with a maximum of 500 con-
sumption meters)
•Passing on all relevant consumption values to all WT…16 on the network
•Communication via the Siemeca™ gateway
Type summary
The WT…16… network node is a component of the Siemeca™ system and has been
designed for exclusive use with that system.
The network node with integrated gateway is available in a number of versions for dif-
ferent applications:
Type code Application Integrated
M-Bus master Max. number of meters
WTX16.GSM Network node with gateway
remote readout via GSM
yes,
5 unit loads
2000
WTX16.IP Network node with gateway
remote readout via Ethernet
yes,
5 unit loads
2000
WTX16.MOD Network node with gateway
remote readout via GSM or GPRS*)
no 500**)
*) The use of the GPRS application requires certain provisions by the network operator. To use the GPRS
option the user has to conclude a special contract with the service provider.
**) WTX16.MOD has no M-Bus master. It cannot be used to interconnect different networks.
Equipment combinations
All network nodes with gateway can be used in any combination with other Siemeca™
network nodes as long as the maximum number of 12 nodes per network is not ex-
ceeded.
Network nodes with gateway and integrated M-Bus master (WTX16.GSM and
WTX16.IP) can read external M-Bus meters complying EN1434/3.

3/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
Technical design
The WT…16… consists of the following blocks:
transceiver for
Siemeca™ network
data memory
500 meters
M-Bus
(slave)
backup battery
mains power supply
M-Bus master
5 unit loads
data base
2000 meters
GSM
*)
TCP/IP
**)
RS232
*) WTX16.GSM only
**) WTX16.IP only
The transmitter and the receiver are
used to collect data from the consump-
tion meters and to forward theses data to
other nodes in the network the data
memory stores the consumption data. It
is protected against temporary mains
power failures by the backup battery.
The network nodes WTX16.GSM and
WTX16.IP are equipped with a gateway
to store data of up to 2000 meters and to
provide a possibility for remote readout
via GSM or Ethernet. The gateway has
an additional M-Bus master that can
drive up to 5 external M-Bus unit loads
(e.g. up to 5 M-Bus meters). Usually,
however, the M-Bus master is used to
connect nodes of different networks to
be able to read more meters using only
one gateway.
The gateway can be programmed using
an additional RS-232 interface.
trnaceiver for
Siemeca™ network
data memory
500 meters
M-Bus
(slave)
backup battery
Spannungsversorgung:
Netzteil
data base
500 meters
GSM/
GPRS
***)
RS232
***) user programmable
The network node WTX16.MOD is equipped
with a gateway for remote readout via GSM
or GPRS.
It has no M-Bus master, though. Therefore it
can read data from one network only (max.
500 meters).
The WT…16… consists of 2 major sections: The base and the housing with the elec-
tronics. It is thus possible to mount the base prior to commissioning, enabling the elec-
trical installer to connect the WTX16 to the mains network. At the time of commission-
ing, the electronics section is snapped on and the electrical connections are made.
The electronics section is identical for all types of network nodes. It contains control
elements of the network:
WTX16.GSM
WTX16.IP
WTX16.MOD
Basic design

4/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
RESET
MODE
DISPLAY
1 2 3 4
6
7
11
10
8
9
5
1 Connector for M-bus service connection
2 Connector for RS-232 module
3 Screw terminal for the fixed M-bus connection
4 Connector for power supply DC 3,6 V
5 Connector for backup battery
6 Operating mode button (MODE, red)
7 Button for switching the display (DISPLAY, blue)
8 Reset button (recessed)
9 Display
10 Connector (not for the user)
11 Firmware memory (covered up)
The wall-mounted section of WTX16.GSM and WTX16.IP contains these components:
7
4
2
10
3
5
6
8
1
11
The wall-mounted section of WTX16.MOD contains these components:
1
9
42
1
3
5
6
10
11
1 Mains connection L and N
2 Permanently installed cable (no flexible cable!)
3 Extra insulation (shrink sleeve)
4 Connector for power supply DC 3,6 V
5 Screw terminal for the fixed M-bus connection
6 Connector for M-bus service connection
7 M3 nut to fix the hinged protection lid (WTX16.GSM and WTX16.IP only)
8 Antenna (WTX16.GSM only)
9 SIM card holder (WTX16.MOD only)
10 Indication of mains supply
11 RS-232 interface for servicing
Electronics section
Wall-mounted section

5/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
The display of the WT…16… facilitates commissioning work and troubleshooting. In
addition to the standard display that shows the operating mode of the WT…16…, there
are 6 different display levels from “A“ to “H“ that can be selected by the user.
Display level
-
Current operating mode
A
WT…16… number (primary address) and net-
work number alternate
B
Number of WT…16… on the network
C
Number of consumption meters on the network
D
Remaining capacity of the WTT16’s main battery
in percent
E
Error code (3 groups)
H
Error code for WTX16.MOD (visible in different
types)
There is a total of 6 operating modes some of which can be selected by pressing the
button on the network node, some are selected automatically, or from a connected PC
via the ACT26 commissioning software. The selected operating mode appears on the
display:
Operating mode Display Explanation
Standard mode
This is the normal operating mode of the data
collectors: Telegrams from the metering de-
vices are received, stored and further handled
by the network.
Extended stan-
dard mode1)
M
The receiver is always active to ensure fast
communication. This mode is automatically
activated in the case of mains-powered opera-
tion (WTX16…). It can also be started manually
with the ACT26 service tool.
Installation
mode2)
In installation mode, the radio network will be
configured automatically. Metering devices that
transmit installation telegrams in this operating
mode are registered on the network.
Extended instal-
lation mode2)
M
Same as installation mode, except that in addi-
tion to installation telegrams, data telegrams
are accepted also. This mode is practical when
the network is installed at a later stage.
Search mode
Metering devices that have been lost are syn-
chronized again (this mode is activated
automatically).
Extended
search mode2)
M
Same as resynchronization mode. It must be
started manually with the ACT26 service tool
and searches for lost or manually entered me-
tering devices.
1) This mode will be turned off automatically after eight hours in battery powered network
nodes WTT16…
2) This mode will be turned off automatically after eight hours.
Display
Operating modes

6/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
State of the
system Display Explanation
Remote access
C
When, from a PC, the WT…16 is accessed with
a WTZ.RM radio module, symbol “ “ will appear
High-speed
mode
For example
M
When all WTT… have their receivers continu-
ously on so that all new data can immediately
be exchanged on the network, 2 dots will ap-
pear in the upper half of the display
Engineering notes
For detailed engineering instructions, refer to the Siemeca™ Engineering Manual
J2870.
Notes on Mounting and Commissioning
For mains-powered WTX16…. network nodes, the mains connections are to be made
first at the selected mounting positions (typically on every second floor, mounting height
≥2 m).
S
N L
R1 ... Rn
M1 M2
S switch
L, N AC 230 V mains supply
M1, M2 M-Bus output
R1…Rn optional interface(s)
CAUTION:
Connect the mains cable to
the power supply unit only!
1
23
1 Mains connection L and N
2 Permanently installed mains cable (no flexible power cable!)
3 Extra insulation (shrink sleeve)
Connect the AC 230 V power supply line to the power pack of the
WTX16… in the following order: Remove the upper housing section of
the WTX16… from the base. For that purpose, remove the 2 cable
connections (power supply (4) and M-Bus (6)) between gateway and
base. Then, use a suitable tool (screwdriver or similar) to slightly open
one of the two lateral fixing levers so that upper housing section and
base can be separated. Then, the top section of the WT…16 is to be
fitted using 2 dowels and screws (spacing of dowels is 184 mm with
the WTX16…).
Connection of the AC 230 V power line to the power pack of the WTX16… is to be
made as follows:
A 2-core mains cable (L and N) has to be preinstalled at the mounting site already. The
power pack must be connected by qualified staff. The cores must be sheathed with the
en-closed insulating sleeves to ensure compliance with safety class II. Then, the live (L)
and neutral (N) conductors must be connected to terminal “IN” of the power pack.
Connection diagram
Mains connection

7/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
Mains voltage must be in the range from AC 100 to 240 V (50 / 60 Hz). There is no
protective earth (PE) connection. Then, cable strain relief must be provided by fitting
cable ties.
Once the top section of the WTX16 is fitted, the housing with the electronics can be
snapped on. Then, the power supply connector can be plugged into the electronics
section and the WTT16 switched to installation mode by pressing the MODE button
(red) for a few seconds. Then, additional network nodes or consumption meters of the
Siemeca™ AMR system can automatically configure themselves to form a network.
After the complete installation of the network the gateway must do a search run to find
all meters of the network(s). One can start a search run either by restarting the
WTX16… by disconnecting it shortly from the mains power (switch S) or by triggering it
with a command sent by the commissioning software ACT21 from a PC attached to the
network node.
Screw tight the GSM antenna prior to commissioning
Network nodes WTX16.GSM require a SIM card. For that purpose,
remove the upper section of the WTX16.GSM from the base. Remove
the 2 cable connections (power supply and M-Bus) between gateway
and base. Then, use a suitable tool (screwdriver or similar) to open
one of the two lateral fixing levers so that upper housing section and
base can be separated.
Insert the SIM card in the slot at the bottom of the gateway.
12
Then, snap base and
upper housing section
together and
reestablish the
connections for M-Bus
and power supply.
1 SIM card
2 Card ejector
Search run
GSM antenna of
WTX16.GSM
SIM card of WTX16.GSM

8/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
Network nodes WTX16.GSM require a SIM card. The cardholder is easily accessible
1
1 SIM card holder
The WTX16.IP network node features an Ethernet interface, which connects to the
outside world via an RJ45 connector, where the net-work cable is to be connected.
The distance to the network conduit box may not exceed 2 meters.
The WTX16.GSM, WTX16.MOD and WTX16.IP network nodes are parameterized with
the ACT21 software. The scope of delivery of the software includes an RS-232 cable
for connecting the PC to the gateway.
On completion of commissioning, secure the network node with the seal provided. In-
sert the seal in the opening to the right of the network node.
After opening the housing, certain parts of the device / system that become accessible
carry dangerous voltage. Only qualified staff may interfere with such devices / systems.
•To ensure correct and safe operation, the pro-duct must be adequately shipped,
stored, installed, operated and maintained.
•Staff dealing with the product must be familiar with all potential hazards and mainte-
nance measures in accordance with the instructions given in this document.
Non-observance of these warning notes can lead to personal injury or damage to
property!
The power line to the WTX16… must include an easily accessible switch (contact gap ≥
3 mm) that allows the user to disconnect the device from the mains supply. The con-
nection cable has to be protected by an appropriate fuse. Whenever performing any
work on the WTX16…, disconnect the device from the mains supply.
The local regulations for electrical installations and wireless systems must be complied
with.
Pursuant to the "Verordnung über Allgemeine Bedingungen für die Elektrizitätsver-
sorgung von Tarifkunden (AVBEltV)" of the Ministry of Economics, electrical installa-
tions behind the house’s fused connection may only be erected, extended, changed
and maintained by electrical installers that are registered with an electric utility. They
must ensure that the general technical regulations and legal safety regulations are
complied with.
SIM card of WTX16.MOD
WTX16.IP
Parameter setting
Sealing
Safety guidelines
In Germany:

9/9
Building Technologies Network nodes with gateway WTX16… CE1N2878en
HVAC Products 14.07.2005
Each network node has a screw terminal for a permanently installed M-Bus connection.
A fitting plug is included.
RESET
MODE
permanently connected M-Bus
max. 5 unit loads
temporary
M-Bus connection
(WTX16.GSM, WTX16.IP:
connection to gateway)
Technical data
conformity to EMC directives
Protection degree IP 32 (WTX16.IP has IP21)
Safety class 2
Electromagnetic compatibility Immunity: EN 55 024/EN 301 489
Emissions: EN 55 022/EN 300 220-1
Operating voltage WTX16… AC 100…240 V 50/60 Hz
Rated frequency 868,3 MHz
Transmitter power < 14 dBm
Frequency of transmission <1 %
Permanent ambient temperature
Transport and storage
Operation
−20…+60 °C (< 30 °C recommended)
0…55 °C
Weight 0,3 kg
Dimensions
184
31,8
9,7
200
60
R
150
R
100
150
250
250
R
55
250
2,5
R
Dimensions in mm
M-Bus connection
The information provided in this Data Sheet only gives general descriptions and general technical features
which, in the case of specific applications, may not necessarily apply, or which may change due to further
development of the product. Technical features are binding only when expressly agreed upon at the time a
contract is concluded.
©2005 Siemens Building Technologies AG
Subject to alteration
