Siemens SRC-8 User manual

P/N 315-092968-10
Installation Instructions
Model SRC-8
Addressable 8-Output Relay Module
OPERATION
The Model SRC-8 module from Siemens
Industry, Inc., used with the SXL-EX System is
an 8-Output Programmable Relay Module that
provides eight Form C relays. Terminal Block 9
(See Figure 1 below) provides a connection to
TB3 on the Main Board for a 24V regulated and
filtered power supply. Terminal blocks 1-8
provide the eight Form C relays.
If the green LED (labeled DS1) on the right-
hand side of the module is on, it indicates that
the module is active.
The SRC-8 causes a trouble on the display
panel when any of the following three conditions
occurs:
1. There is a short on the data line.
2. No SRC-8 module is connected to the
System, though there is an address for the
module in the System.
3. An SRC-8 module is connected to the
system, but there is no address for it in the
System.
INSTALLATION
Remove all System power before
installation, first battery and then AC.
(To power up, connect the AC first
and then the battery.)
In a New SXL-EX System
(Refer to Figure 2):
Install the SRC-8 in the upper right-hand
portion of the EN-SX enclosure by following the
steps listed below.
1. Insert the four 6-32 x 1/2standoffs over the
four studs in the upper right-hand corner of
the SXL-EX enclosure as shown in Figure 2.
2. Place the SRC-8 board over the four
standoffs in the upper right-hand portion of
the EN-SX enclosure. Using the four 6-32
screws provided, fasten the SRC-8 board to
the standoffs.
C
POLL
SRC-8
CCCCCCCC
N
C
CCCCCCC
-V
ER
N
ON
ON
ON ON
ON
ON ON
O
N
CN CN
CN CN
CN
CN C
RELAY 1 RELAY 2 RELAY 3 RELAY 4 RELAY 5 RELAY 6 RELAY 7 RELAY 8
DS1
TB9
TB1 TB2 TB3 TB4 TB5 TB6 TB7 TB8
+
24V
Data
Figure 1
SRC-8 Module
Siemens Industry, Inc.
Building Technologies Division
Florham Park, NJ
Siemens Building Technologies, Ltd.
Fire Safety & Security Products
2 Kenview Boulevard
Brampton, Ontario
L6T 5E4 Canada
Figure 2
Installing an SRC-8
4X
4X

2
6. Fasten the two short standoffs remaining to
the bottom two corners of the SRC-8 board
(They are supports for the Display Board).
7. Once the SRC-8 is in place, re-install the
Display Board by reversing Steps 1-3 above.
PROGRAMMING
Use Program Level 9 to program the System to
supervise the SRC-8 module; and refer to the
SXL-EX Manual, P/N 315-095997, Program
Level 5, for programming the relay output
control matrix.
1. To enter the System:
a. Press the RESET and DRILL keys at
the same time.
b. Enter your password (Refer to Enter
Password under PROGRAM MODE in
the Manual).
c. Press the SILENCE key to confirm the
information for the system.
d. An A should display in the 7-segment
display.
e. If an F appears, repeat the process until
an A appears.
2. To enter the Program Mode:
a. Press the ACK key once.
b. Note that a P displays in the 7-segment
display.
c. Be sure the PROGRAM/TEST LED is lit.
3. To select the desired Program Mode level:
a. To select Program Level 9, press the
RESET button 9 times.
b. Press SILENCE.
4. To program the SRC-8:
a. Note the top zone status LEDs on the
display board.
• If the top red LED is on, the SRC-8 is
activated and sublevel -1 appears in
the display.
• If the top red LED is off, the SRC-8 is
not activated.
b. Press the DRILL key to toggle between
ON (activated) and OFF (de-activated)
as desired.
5. To exit the system:
a. Press the ACK key until an L appears
on the display.
b. Press SILENCE to exit the program.
In an Existing SXL®System
(Refer to Figure 3):
To place the SRC-8 on the Main Board of an
existing system, first remove the existing Display
Board and its cover by following the steps below.
1. Remove the Display Cover from the Display
Board as shown in Figure 3. Discard its top
two standoffs.
2. Unplug the ribbon cable from the Display
Board at jumper JP4 on the Main Board.
3. Remove the Display Board from the SXL®
Main Board by unscrewing the four 6-32
screws and setting them to one side.
4. Remove and discard the two standoffs that
were supporting the two upper corners of
the Display Board.
5. Next, install the SRC-8 by using the four 6-
32 x 1-7/8standoffs, the 6-32 screw, and the
two 15/16 standoffs provided as follows:
• Fasten the 1-7/8 nylon standoff provided to
the back of the upper left-hand corner of
the SRC-8 with the screw provided.
• Remove the screw from the upper right-
hand corner of the Main board.
• Screw another long standoff to the upper
right-hand corner of the Main board.
• Screw the last two long standoffs provided
to the Main board as shown in Figure 3.
• Place the SRC-8 module on the standoffs.
• Use the screw removed from the Main
board to secure the upper right-hand
corner of the SRC-8 board to the Main
board.
SRC-8
Figure 3
Installation in an Existing System

3
Figure 4
Wiring the SRC-8
WIRING
(Refer to Figure 4)
Refer to Figure 4 below to wire the SRC-8 into
the SXL-EX System.
The wiring for the Form C relay circuits from
terminal blocks 1-8 is also shown in Figure 4.
For information on programming the relays on
the SRC-8, refer to the SXL-EX Manual, P/N
315-095997.
BATTERY CALCULATIONS
Battery backup is required for the SRC-8. To
determine the size battery you need, use the
battery calculation table in the SXL-EX Manual,
P/N 315-095997.
Notes:
1. The SXL-EX Control Panel meets NFPA 72 Local System requirements.
2. All wiring must be in accordance with NFPA 70.
3. Form C relay contacts are shown de-energized . They are suitable for resistive load only.
4. Refer to the Battery Calculations in the manual to determine battery needs.
5. Minimum 18AWG wire to all field connections.
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
CC
N
C
N
O
RELAY
TB1
RELAY
TB2
RELAY
TB3
RELAY
TB4
RELAY
TB5
RELAY
TB6
RELAY
TB7
RELAY
TB8
FORM C
RELAY 1
FORM C
RELAY 2
FORM C
RELAY 3
FORM C
RELAY 4
FORM C
RELAY 5
FORM C
RELAY 6
FORM C
RELAY 7
FORM C
RELAY 8
TO SXL-EX
MAIN BOARD
TB-3
STYLE 4
SUPERVISED
-V
+24V
DATA
EARTH
+24V
DATA
-V
ER
TB9
SRC-8
DS1
POLL
PROGRAMMABLE
POSITIVE AND NEGATIVE
GROUND FAULT DETECTED
AT <20K FOR TERMINALS ON TB9
Electrical Characteristics
Supervisory: 18 mA
Alarm: 26mA per relay
Electrical Characteristics
of Form C Relays
2A at 30 VDC and 120 VAC resistive only

P/N 315-092968-10
Siemens Industry, Inc.
Building Technologies Division
Florham Park, NJ
Siemens Building Technologies, Ltd.
Fire Safety & Security Products
2 Kenview Boulevard
Brampton, Ontario
L6T 5E4 Canada
