Documentation
HiPath 500, HiPath 2000, HiPath 3000, HiPath 5000
HiPath 4000, HiPath OpenOffice ME
OpenStage 60/80
OpenStage 60/80 T
Quick Reference Guide
oi.book Seite 1 Mittwoch, 10. August 2011 1:27 13

Using Your Telephone
2
Using Your Telephone
Function Keys and Audio Keys
Mode keys and TouchSlider
Shining blue: mode is active
Shining white:
for call lists: new entry in call list
for voicemails: new voicemail
TouchGuide
Programmable sensor keys on the display
qStart voice dialing
rActivate/deactivate forwarding
sEnd (disconnect) call
pTurn microphone on/off
oTurn headset on/off
nTurn speaker on/off
tTelephony interface
uPhonebooks
wCall lists
xVoicemails
vService/Applications menu
yHelp function
Run finger over TouchSlider:
Depending on situation, set
volumes for ringer or
speaker
X
Press mkey:
- Scroll upwards
Hold down:
- Scroll to beginning of list
Press lkey:
- Scroll downwards
Hold down:
- Scroll to end of list
Press gkey:
- Call up the context menu
- Go down a level
Press hkey:
- Cancel function
- Delete character
left of cursor
- Go up a level
Press ikey:
- Confirm input
- Perform action
Run finger over inner edge of ring W:
- Scroll through lists and menus
- Adjust volume
Keys
Label
S inactive
R lit
T flashing
oi.book Seite 2 Mittwoch, 10. August 2011 1:27 13

Entering Phone Numbers and Text Using Your Telephone
3
Entering Phone Numbers and Text
Keypad
In situations where text entry is possible, you can use the dial keys to enter text, punctua-
tion and special characters. To do this, press the numerical keys repeatedly.
Extra asterisk and pound key functions:
Display keyboard
Depending on the context, the display keyboard is displayed with different elements.
Using the display keyboard:
WShift focus to another element
gShift focus to "OK"
iSelect element
Display
Components
Key Function during text input Function when held down
*Write special characters Deactivate the ring tone.
#Switch between upper/lower case and digit entry. Activate telephone lock.
Element in focus
Letters, digits, punctuation or special characters
Changes
Switch to number input
Switch to upper/lower case
Insert clipboard contents at cursor position
Move cursor left/right
Switch to punctuation and special characters
Copy content of active field to the clipboard
Status bar
Ta b ( a c t ive )
Selected entry
(e.g. call lists)
Context menu
Selected entry
in context menu
Missed Dialed
10:23 Mon 10/23/06 54321
Dial
Details
Delete
List options
Marie Curie
Einstein, A
Joseph von Fr.
oi.book Seite 3 Mittwoch, 10. August 2011 1:27 13

Using Your Telephone Display
4
Symbols
Application tab
Telephony interface
Phonebooks
Call lists
Messages
Menu
Help function
Status bar
The ring tone is deactivated
The "Do not disturb" function is activated
The phone lock is activated
The Bluetooth function is activated
A mobile user is logged on to the telephone[1]
[1] This function is not yet available.
Message icons
You have received one or more new messages
One or more new entries have been added to the call lists
Call forwarding is active
Frequent call states
The call is active
The call has been disconnected
You have placed the call on hold (e.g. consultation hold)
Your call partner has placed the call on hold
You are conducting a call via a secure connection
You are conducting a call via an unsecured connection
Phonebook icons
Primary business number
Secondary business number
Mobile phone number
Private phone number
oi.book Seite 4 Mittwoch, 10. August 2011 1:27 13

HiPath 4000 Important Operating Procedures
5
Important Operating Procedures
HiPath 4000
In Idle State
Answering a call with the handset
Z^
Answering a call in speakerphone mode
Zn
Dialing from the caller list
w("Missed" tab, press repeatedly for "Dialed", "Received") f desired entry i
Activating callback
j destination phone number iif no answer or busy: f"Callback" i
Saving a phone number to a key
SHold down programmable key "Assign function" i"Change?" i"Selected
dialing?" i"Save?" i"Service menu" i"Destinations?" i
f"Selected dialing?" iSpress programmable key j phone number
"Completed?" i"Use Destination Number?" i"Save?" i
Dialing a saved number
Ssaved phone number ^
^Lift handset jEnter text or number
\Replace handset fSelect entry
[Conduct call gOpen context menu
ZRing tone/call waiting tone Next step in procedure
oi.book Seite 5 Mittwoch, 10. August 2011 1:27 13

Important Operating Procedures HiPath 4000
6
Saving a function to a key
SHold down programmable key "Assign function" i"Change?" i
fselect function i"Save?" i
Redialing a number
^or nf"Last number redial?" i^
Programming call forwarding
rf"Edit call forwarding" ifselect desired forwarding type (all calls, busy, no
reply, fixed, internal calls, external calls, busy/no reply) i
fselected forwarding, e.g. "all calls" if"On" if"Destination" i
jphone number if"Save & exit" i
Turning fixed call forwarding on/off for all calls
r
oi.book Seite 6 Mittwoch, 10. August 2011 1:27 13

HiPath 4000 Important Operating Procedures
7
During Calls with a Party A
Switching to speakerphone mode
Hold down n\(US only: n\)
Consultation
g"Consultation?" i j phone number for party B i[party B g
"Release and return?" i[party A
Accepting call waiting
Zcall waiting tone f"Answer camp-on?" i[party B fparty B g
f"Release and return?" i[party A
Start conference
g"Consultation" i j phone number for party B i[party B g
f"Conference?" i[party A and B
Start conference on call waiting
Zcall waiting tone f"Answer camp-on?" i[party B g
f"Conference?" i[party A and B
Blind transfer
gf"Consultation?" ijdestination phone number \
Transfer after consultation
g"Consultation?" i j phone number for party B [party B \
oi.book Seite 7 Mittwoch, 10. August 2011 1:27 13

Important Operating Procedures HiPath 500/2000/3000/5000, HiPath OpenOffice ME
8
HiPath 500/2000/3000/5000, HiPath OpenOffice ME
In Idle State
Answering a call with the handset
Z^
Answering a call in speakerphone mode
Zn
Rejecting a call
Zf"Reject call" i
Dialing from the caller list
w("Missed" tab, press repeatedly for "Dialed" and "Received") f desired entry i
Activating callback
j destination phone number iif no answer or busy: f"Callback" i
Saving a phone number to a key
SHold down programmable key f"Assign function" if"Change key" i
f"Destinations" if"Station no." ijphone number i
"Save" i"Exit" i
Dialing a saved number
Ssaved phone number ^
Saving a function to a key
SHold down programmable key f"Assign function" if"Change" i
fselect function if"Exit" i
Programming call forwarding
rf"Edit call forwarding" i
fselecting forwarding type (all calls, internal calls, external calls) i
f"Destination" ijphone number ifselected forwarding, e.g. "all calls" i
gf"On" if"Save & exit“ i
Turning call forwarding on/off for all calls
r
oi.book Seite 8 Mittwoch, 10. August 2011 1:27 13

HiPath 500/2000/3000/5000, HiPath OpenOffice ME Important Operating Procedures
9
During Calls with a Party A
Consultation
g"Consultation" i j phone number for party B i[party B fparty B
g"Release and return" i[party A
Start conference
g"Start conference" i j phone number for party B i[party B g
f"Conference" i[party A and B
Blind transfer
gf"Consultation?" ijdestination phone number \
Transfer after consultation
g"Consultation?" i j phone number for party B [party B \
oi.book Seite 9 Mittwoch, 10. August 2011 1:27 13
