Sierra Designs FLASHLIGHT 1 Configuration guide

FLASHLIGHT 1 and 1 UL
FLASHLIGHT 2 and 2 UL
FLASHLIGHT 1 (STANDARD, UL & FL MODELS)
PITCHING INSTRUCTIONS
PACKAGE INCLUDES: Tent body with attached Rain Fly, 1 NR Joint Rear Pole, 2 Vertical Poles, Guy Cords, Stakes, 1 Pole/Stake Bag and Tent Stuff Sack.
NOTE: If you’re carrying trekking poles and want to
drop 6oz of weight, leave the vertical poles at home.
Simply insert the handle end of the pole into the
awning peak and put the trekking pole tip into the
grommet.
STEP 2: Assemble rear pole and insert in grommets.
Attach the two H-Clips on the tent to NR Joint on pole.
STEP 1: Find an even piece of ground; be sure area
is clear of debris. Layout your tent as shown. Stake
the 4 corners (circled).
STEP 3: Assemble vertical poles. Insert the rounded
end of the pole into the sleeve located under the
awning at the peak of the tent. Insert the bottom of
the pole into the grommet.
STEP 4: Now that the vertical pole is installed, stake
out the front awning (circled). Repeat steps 3 & 4 on
the other side of the tent.
STEP 5: Stake out the rear vent on tent (circled) and
your tent should be completely set up.
Congratulations on the purchase of you new Sierra Designs Tent! In order to familiarize yourself with
your new tent, we recommend you “test pitch” it before embarking on your wilderness adventure.
NR Joint with H-Clip
must face down.

Sierra Designs
Boulder, CO USA 800.635.0461
SierraDesigns.com
USING YOUR TENT
GUYING OUT YOUR TENT:
Your tent includes 3 guy
points, guylines and
stakes. It is good practice
to always guy out your
tent, but it is absolutely
necessary when it’s windy.
Tie the end of the guy line to the
reflective guy out loop on your tent.
Use the black LINE-LOK®to adjust
the length of the guy line.
Stake out the end of the guy line loop.
GEAR STORAGE: Your SD tent provides gear storage
out of the doorway of the tent with access from inside
and outside. You can choose to keep the door closed
for more protection, or clip it back to provide greater
ventilation/visibility.
Gear Closet panel can be clipped to
“open” position for greater ventilation
Clip the male end of SR Buckle to female end
on tent door for the most protection and storage.
LINELOCS®:All tent and awning stake-out points
feature LineLocs®. Lift up on the tab to decrease
tension. Pull on the knotted end to increase tension.
VENTILATION/VISIBILITY:
Because we have replaced
the vestibule with an awning
on both sides of the tent
you have the ability to
control the visibility and
ventilation during a
downpour. Simply zip up
or zip down the waterproof
panel on the door and rear
wall of the tent for the
coverage you desire. NOTE: For greatest ventilation and visibility toggle the gear closet in place and guy out as shown.
DOOR
REAR WALL
