Model S-40S
Headset Instructions
The S-40S series headsets are adjusted at the factory for immediate use with all
current standard radio systems in general aviation aircraft. Headsets equipped
with two plugs are the standard conguration. The headphone plug is the larger
diameter plug and should be inserted into the headphone jack (.250” standard
monaural jack). The mic plug is the smaller diameter plug and should be inserted
into the microphone jack (.206” standard microphone jack).
The headband is adjustable through a full range of motion, or the locking nuts
may be tightened to allow you to custom t the headset. Place the headset over
your head, adjust the slides up until minimum pressure is felt on the top of your
head. The headset is now properly adjusted. For maximum noise attenuation, the
clamping pressure has been set at the factory. Releasing the clamping pressure
by bending the headband is not advised, because loss of attenuation will result.
Note: If especially small (children) or large headbands are needed, they may be
ordered from Sigtronics.
The microphone boom is fully adjustable and will rotate 360 degrees for use on
the left or right side of the head. The locking screw that secures the boom to the
ear cup is factory set to insure the correct tension. Turning it will not change the
tension, because the nut on the inside of the cup will turn as well. Microphone
placement should be at the corner of the mouth, approximately ¼” from the
lips. The exclusive thumbscrew on the mic boom may be used to assure proper
adjustment.
When you rst connect the headset, turn the volume controls on the headset to
maximum ( full clockwise on mic side, counterclockwise on pot side ), then adjust
the listening volume with the audio control of either your radio or intercom as
appropriate. Passengers should also turn their individual headset volumes up fully.
Doing this allows for a full range of adjustment for each passenger, since those
with the most acute hearing can turn their headset volume down, if necessary.
continued on back…
The headset is equipped with a stereo / monaural switch on the non-mic side ear
cup. For monaural sound or aircraft with only monaural jacks, move the switch to
the monaural position. In aircraft equipped for stereo audio, move the switch to
the stereo position.
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in water
or any other liquid. Be especially careful not to allow the microphone to become
wet! Exposure to moisture may cause internal corrosion and failure and will void
your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thor-
oughly and make sure it is completely dry before putting it back on.
To remove the windscreen, take out the screw that holds the microphone on the
boom and grasp the windscreen lightly along its entire length and slip it o.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited three-year parts and labor warranty. Please
see the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.

SIGTRONICS S-40S HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1800145 HEADBAND, WITH CUSHION, S-40 17 100083 RECEIVER, 300 OHM, STEREO 33 800012 CABLE, HEADSET, STEREO
2100383 HEADBAND, METAL, STANDARD 18 100423 RECEIVER MOUNT, HEADSET, STEREO 34 800039 CABLE, MICROPHONE BOOM, 12 INCH
3100367 YOKE, EAR CUP MOUNT, METAL 19 100939 EAR CUP, PRINTED AND DRILLED, MICROPHONE SIDE 35 100162 WIRE, 3 CONDUCTOR, #24, BLACK, 28.5 INCHES
4100384 BRACKET, YOKE SUPPORT WITH TANG 20 100940 EAR CUP, PRINTED AND DRILLED, VOLUME CONTROL SIDE 36 100935 WIRE, #22, JUMPER, HEADSET, 4 INCH
5100373 SLIDE, YOKE BRACKET, LONG, NYLON 21 100049 GROMMET, 5/16 INCH, RUBBER 37 100569 STRAIN RELIEF, CABLE
6100258 CLIP, HEADBAND GUIDE, PLASTIC 22 800078 MICROPHONE, ELECTRET, M-90 38 100579 CLIP, CLOTHING, HEADSET CABLE
7100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC 23 900084 WINDSCREEN, MICROPHONE 39 100371 MICROPHONE CABLE CLIP
8100362 CLIP, CROSS-OVER, WIRE, PLASTIC 24 100249 BOOM, ELECTRET MICROPHONE SUPPORT, SWIVEL 40 100360 KNOB, BLACK, VOLUME
9100363 SCREW, 8-32 X 1/2, PHILLIPS HEAD 25 100156 SCREW, THUMB, MICROPHONE BOOM, 2-56 X 1 41 100365 POTENTIOMETER, 2K
10 100364 SCREW, 8-32 X 3/8, PHILLIPS HEAD 26 100368 KNOB, MICROPHONE BOOM ADAPTER, PLASTIC 42 100509 SWITCH, STEREO / MONO
11 100377 SCREW, 8-32 X 5/8, PHILLIPS HEAD 27 100408 WASHER, GROOVED BOOM 43 100508 WASHER
12 100108 SCREW, 4-40 X 1/4, THREAD FORMING 28 100385 WASHER, SPRING, BOOM ADAPTER 44 100507 NUT, STEREO / MONO SWITCH
13 100251 E-RING, EAR CUP TO YOKE RETAINER 29 100369 EAR SEAL, FOAM FILLED 45 100257 OPTIONAL – HEADBAND, METAL, LARGE
14 100252 NUT, HEX, 8-32, LOCKING 30 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 46 100618 OPTIONAL – HEADBAND, METAL, YOUTH
15 100135 WASHER 31 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH 47 100402 OPTIONAL – EAR SEAL, GEL FILLED
16 100130 TERMINAL, SOLDER 32 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH
SIGTRONICS S-40S HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
116 31
217 32
318 33
419 34
520 35
621 36
722 37
823 38
9100615 EAR CUP, PRINTED AND DRILLED, MIC & NON MIC SIDE 24 39
10 25 40
11 26 41
12 27 42
13 28 43
14 29 44
15 30 45






 










































 


10-14-2021
P/N 700072
