SIIG JU-H30612-S1 Product information sheet

1
USB 3.1 Type-C Hub with HDMI
& PD charging Adapter - 4K
04-1025A
Introduction
The USB 3.1 Type-C Hub with HDMI & PD charging
Adapter -4K ready easily adds three USB ports, an
HDMIoutputandaUSBPD(USBPowerDelivery)
port to USB Type-C enabled computers.
Key Features and Benefits
• Adds one HDMI port, one USB Type-C
charging port (PD) and triple USB 3.1 Gen 1
port instantly through USB Type-C
connection
• Compatible with USB Type-C port with
DisplayPort signal and power deliver (PD)
protocol enabled such as new MacBook and
GoogleChromebookPixel
• Multi-Function pocket size unit with no
external power adapter required provides
greaterportability
User Reference Guide

2
• Delivers HDMI video/audio signal with
maximum display resolution up to
4Kx2K@30Hz
• USB 3.1 Gen 1 ports support data transfer
rates up to 5Gbps for fast data delivery
• Plug-n-Play, no software installation
required
Specifications
Number of Connectors 5
Connectors
Input: 1x USB Type-C, Male
Output: 1x 19-pin HDMI, Female
3x 9-pin USB 3.1 Gen 1 Type-A, Female
1x USB Type-C (charging) , Female
Video Type HDMI
Resolution Up to 4Kx2K
Audio Yes
Data Transfer Rate Up to 5Gb/s (USB 3.1 Gen 1)
Power USB Bus-powered
Housing Material Metal (Aluminum)
Built-in Cable Length 5.91" (15cm)
Color Silver
Dimensions 3.11" (W) x 0.63" (H) x 1.85" (D)
Weight 0.15 lbs

3
Package Contents
•USB3.1Type-CHubwithHDMI& PDcharging
Adapter - 4K ready
• UserReference Guide
System Requirements
• Computer with USB Type-C port
• USBPowerDelivery Specification (USB PD)
overUSBType-C
• DisplayPort over USB Type-C
Layout
Figure1:USB3.1Type-CHubwithHDMI& PDchargingAdapter -4K
USB Type-A
HDMI
USB Type-A USB Type-C
•USB Type-C: Connects to USB Type-C port
ofthe computer
USB Type-A
USB PD
Type-C

4
•USB Type-A (x3): Connects to USB
peripherals such as mice, pen drives, or
printers
•HDMI: Connects to an HDMI display by
HDMI cable (cable not included)
•USB PD Type-C: Connectsto a USB Type-C
powersourceforpoweringor charging your
laptop

5
Application
USB 3.1 Type-C Hub with HDMI & PD charging
Adapter -4K ready provides HDMI, USB data and
USB PD charging connection simultaneously in
one ultra-slim unit.
Figure2: Application
Note: It's not recommended to connect
power-hungry USB devices simultaneously

6
Blank Page

7
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com andclick Support. Our online support database is updated dailywith new
driversand solutions. Answers to your questions could bejust a few clicks away. You can
also submit questions online and a technical support analyst will promptly respond.
SIIG offers a 2-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for two (2) years from the date of purchase of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product having
similar features and functionality) the product if defective in materials or workmanship.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. Please see our web site for more warranty details.
Ifyou encounter any problems with this product, please follow the procedures below.
A)Ifit is within the store's returnpolicy period, please return the producttothe store where
youpurchased from.
B)Ifyourpurchasehas passed the store's return policy period, please follow thestepsbelow
to have the product repaired or replaced.
Step 1: Submit your RMA request.
Gotowww.siig.com, click Support,thenREQUEST A PRODUCT REPLACEMENT
tosubmit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
willbe processed, if the product is determined to be defective, an RMAnumber will
beissued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will
refuseto accept any shipping package, andwill not be responsible for aproduct
returnedwithoutan RMA number posted on the outsideoftheshipping carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the
followingaddress:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer.
