SIIG AC-PW1724-S1 Product information sheet

04-1057A
5-Port Smart USB Charger
plus Organizer Bundle
User Reference Guide
Introduction
The 5-Port Smart USB Charger plus Organizer
Bundle comes with 1 Quick Charge 3.0, 1 USB
Type-C and 3 standard USB charging ports to
satisfy a variety of power charging demands.
Package Contents
•5-Port Smart USB Charger plus Organizer
Bundle with QC3.0 & Type-C-Black/White
• Power cord
• Charging organizer
• User Reference Guide
LOT Number Sticker
Forfutureproductreturnorexchange,thisLOTnumber
is required. Please keep it for your reference.
LOT Number Part Number

2
Key Features and Benefits
• Simultaneously charge all your devices at
once with this 5-port USB charger, supports
iPads, iPhones, Android smartphones,
tablets and more
• Qualcomm Quick Charge 3.0 certified,
charges up to 4X faster than conventional
chargers and achieves up to 80% of battery
charge in as little as 35 minutes when
charging Quick Charge 3.0 enabled devices
• The three standard USB ports have built-in
smart charging IC to automatically detect
and deliver the optimal power output up to
2.4A per port
Specifications
Charging Ports
1 x Quick Charge 3.0 port
1 x USB Type-C charging port
3 x USB charging ports
Power Input AC 100~240V (50/60Hz)
Power Output
QC 3.0 port: 3.6V-6.5V/3A, 6.5V-9V/2A, 9V-12V/1.5A (Max)
Type-C port: 5V/3A (Max)
USB charging port: 5V/2.4A per port (Max)
Total power
output 45W
Dimensions 3.15" (W) x 1.10" (H) x 3.15" (D)
Weight 0.35 lbs

3
Layout
USB Charging
Ports (x3)
Quick Charge 3.0
USB Charging Port
•USB Type-C Charging Port: Connects to
Type-C equipped smartphones or tablets
for charging
•USB Charging Ports (x3): Connects to
smartphones, tablets or other USB-powered
devices for charging
•Quick Charge 3.0 USB Charging Port:
Connects to smartphones, tablets or other
USB-powered devices for charging
Figure 1: 5-Port Smart USB Charger plus Organizer Bundle
with QC3.0 & Type-C
USB Type-C Charging
Port

4
• 2-pin power connector: Connects to the
included power cord for power source
2-pin power connector
Instructions for Use
Note: 1. It is recommended to use your
USB device's original charging cable for
charging.
2. For Quick Charge 3.0, please make sure to
usethedevice's Sync &ChargeUSBcharging
cable for proper initialization.
1. Connect the Charger to a reliable power outlet
using the included power cord and verify the
power LED is lit.

5
2. Connect your USB device(s) to the USB
charging ports using USB charging cable(s).
Note: Plug your Quick Charge 3.0 enabled
device into the Quick Charge 3.0 USB
Charging Port for optimal charging
efficiency.
3. Optional: Use the included charging
organizer as needed.

6
Quick Charge 3.0
Please refer to the table for a list of Quick Charge
3.0 enable devices: (not complete list)
For an updated list of Quick Charge 3.0 enabled devices visit
thiswebsite:https://www.qualcomm.com/documents/quick-
charge-device-list
LG G5 LG V20 HTC 10 HTC One A9
ZTE Nubia Z11 ZTE Nubia Z11
Max
ZTE Nubia
Z11miniS ZTE Axon 7
ZTE Axon 7 Max ASUS ZenFone 3 ASUS ZenFone 3
Deluxe
ASUS ZenFone 3
Ultra
HP Elite x3 Sony Xperia XZ Vodafone Smart
platinum 7 Xiaomi Mi 5
Xiaomi Mi 5s Xiaomi Mi Max Xiaomi Mi Note 2 Xiaomi MIX
USB Type-C
Please refer to the table for a list of USB Type-C
enable devices: (not complete list)
Google Pixel Google Pixel XL Google Nexus 6P GoogleNexus 5X
Nokia Lumia 950 Nokia Lumia
950XL Meizu Pro 5 Lenovo ZUK Z1
LeTV One Max LeTV One Pro Huawei P9 CHUWI Hi10 Pro
HTC 10 LG G5 Nokia N1 OnePlus 2 & 3
Nextbit Robin ASUS Zenpad S
8.0 Asus Zenfone 3

Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks away. You
can also submit questions online and a technical support analyst will promptly respond.
SIIG offers a 1-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for one (1) year from the date of purchase of the product. This warranty is
not transferable and is available only to the original purchaser of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product having
similar features and functionality) the product if defective in materials or workmanship.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. Please see our web site for more warranty details.
If you encounter any problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the steps
below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT
to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
will be processed, if the product is determined to be defective, an RMA number will
be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included
• Include a copy of your original sales receipt inside the package with date of
purchase and place of purchase circled and clearly visible
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping carton
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer

8
