SILENT KNIGHT 5700 User manual

Installation and
Operations Manual
Addressable Fire Alarm Control Panel
Document: 151295
Rev: T
P/N 151295:T ECN: 15- 0644
INTELLIKNIGHT
®
MODEL 5700

2
Fire Alarm & Emergency Communication System Limitations
While a life safety system may lower insurance rates, it is not a substitute for life and property insurance!
An automatic fire alarm system—typically made up of smoke
detectors, heat detectors, manual pull stations, audible warning
devices, and a fire alarm control panel (FACP) with remote notifi-
cation capability—can provide early warning of a developing fire.
Such a system, however, does not assure protection against
property damage or loss of life resulting from a fire.
An emergency communication system—typically made up of
an automatic fire alarm system (as described above) and a life
safety communication system that may include an autonomous
control unit (ACU), local operating console (LOC), voice commu-
nication, and other various inter-operable communication meth-
ods—can broadcast a mass notification message. Such a system,
however, does not assure protection against property damage or
loss of life resulting from a fire or life safety event.
The Manufacturer recommends that smoke and/or heat detectors
be located throughout a protected premises following the
recommendations of the current edition of the National Fire
Protection Association Standard 72 (NFPA 72), manufacturer's
recommendations, State and local codes, and the
recommendations contained in the Guide for Proper Use of
System Smoke Detectors, which is made available at no charge
to all installing dealers. This document can be found at http://
www.systemsensor.com/appguides/. A study by the Federal
Emergency Management Agency (an agency of the United States
government) indicated that smoke detectors may not go off in as
many as 35% of all fires. While fire alarm systems are designed to
provide early warning against fire, they do not guarantee warning
or protection against fire. A fire alarm system may not provide
timely or adequate warning, or simply may not function, for a
variety of reasons:
Smoke detectors may not sense fire where smoke cannot reach
the detectors such as in chimneys, in or behind walls, on roofs, or
on the other side of closed doors. Smoke detectors also may not
sense a fire on another level or floor of a building. A second-floor
detector, for example, may not sense a first-floor or basement fire.
Particles of combustion or “smoke” from a developing fire may
not reach the sensing chambers of smoke detectors because:
• Barriers such as closed or partially closed doors, walls, chim-
neys, even wet or humid areas may inhibit particle or smoke
flow.
• Smoke particles may become “cold,” stratify, and notreach the
ceiling or upper walls where detectors are located.
• Smoke particles may be blown away from detectors by air out-
lets, such as air conditioning vents.
• Smoke particles may be drawn into air returns before reaching
the detector.
The amount of “smoke” present may be insufficient to alarm
smoke detectors. Smoke detectors are designed to alarm at vari-
ous levels of smoke density. If such density levels are not created
by a developing fire at the location of detectors, the detectors will
not go into alarm.
Smoke detectors, even when working properly, have sensing lim-
itations. Detectors that have photoelectronic sensing chambers
tend to detect smoldering fires better than flaming fires, which
have little visible smoke. Detectors that have ionizing-type sens-
ing chambers tend to detect fast-flaming fires better than smolder-
ing fires. Because fires develop in different ways and are often
unpredictable in their growth, neither type of detector is necessar-
ily best and a given type of detector may not provide adequate
warning of a fire.
Smoke detectors cannot be expected to provide adequate warn-
ing of fires caused by arson, children playing with matches (espe-
cially in bedrooms), smoking in bed, and violent explosions
(caused by escaping gas, improper storage of flammable materi-
als, etc.).
Heat detectors do not sense particles of combustion and alarm
only when heat on their sensors increases at a predetermined
rate or reaches a predetermined level. Rate-of-rise heat detectors
may be subject to reduced sensitivity over time. For this reason,
the rate-of-rise feature of each detector should be tested at least
once per year by a qualified fire protection specialist. Heat detec-
tors are designed to protect property, not life.
IMPORTANT! Smoke detectors must be installed in the same
room as the control panel and in rooms used by the system for
the connection of alarm transmission wiring, communications, sig-
naling, and/or power. If detectors are not so located, a developing
fire may damage the alarm system, compromising its ability to
report a fire.
Audible warning devices such as bells, horns, strobes,
speakers and displays may not alert people if these devices are
located on the other side of closed or partly open doors or are
located on another floor of a building. Any warning device may fail
to alert people with a disability or those who have recently con-
sumed drugs, alcohol, or medication. Please note that:
• An emergency communication system may take priority over a
fire alarm system in the event of a life safety emergency.
• Voice messaging systems must be designed to meet intelligi-
bility requirements as defined by NFPA, local codes, and
Authorities Having Jurisdiction (AHJ).
• Language and instructional requirements must be clearly dis-
seminated on any local displays.
• Strobes can, under certain circumstances, cause seizures in
people with conditions such as epilepsy.
• Studies have shown that certain people, even when they hear
a fire alarm signal, do not respond to or comprehend the
meaning of the signal. Audible devices, such as horns and
bells, can have different tonal patterns and frequencies. It is
the property owner's responsibility to conduct fire drills and
other training exercises to make people aware of fire alarm
signals and instruct them on the proper reaction to alarm sig-
nals.
• In rare instances, the sounding of a warning device can cause
temporary or permanent hearing loss.
A life safety system will not operate without any electrical power.
If AC power fails, the system will operate from standby batteries
only for a specified time and only if the batteries have been prop-
erly maintained and replaced regularly.
Equipment used in the system may not be technically compati-
ble with the control panel. It is essential to use only equipment
listed for service with your control panel.
Telephone lines needed to transmit alarm signals from a prem-
ises to a central monitoring station may be out of service or tem-
porarily disabled. For added protection against telephone line
failure, backup radio transmission systems are recommended.
The most common cause of life safety system malfunction is
inadequate maintenance. To keep the entire life safety system in
excellent working order, ongoing maintenance is required per the
manufacturer's recommendations, and UL and NFPA standards.
At a minimum, the requirements of NFPA 72 shall be followed.
Environments with large amounts of dust, dirt, or high air velocity
require more frequent maintenance. A maintenance agreement
should be arranged through the local manufacturer's representa-
tive. Maintenance should be scheduled monthly or as required by
National and/or local fire codes and should be performed by
authorized professional life safety system installers only. Ade-
quate written records of all inspections should be kept. Limit-D-1-2013

3
Installation Precautions
Adherence to the following will aid in problem-free installation with long-term reliability:
WARNING - Several different sources of power can be
connected to the fire alarm control panel. Disconnect all
sources of power before servicing. Control unit andassociated
equipment may be damaged by removing and/or inserting
cards, modules, or interconnecting cables while the unit is
energized. Do not attempt to install, service, or operate this
unit until manuals are read and understood.
CAUTION - System Re-acceptance Test after Software
Changes: To ensure proper system operation, this product
must be tested in accordance with NFPA 72 after any pro-
gramming operation or change in site-specific software. Re-
acceptance testing is required after any change, addition or
deletion of system components, or after any modification,
repair or adjustment to system hardware or wiring. All compo-
nents, circuits, system operations, or software functions
known to be affected by a change must be 100% tested. In
addition, to ensure that other operations are not inadvertently
affected, at least 10% of initiating devices that are not directly
affected by the change, up to a maximum of 50 devices, must
also be tested and proper system operation verified.
This system meets NFPA requirements for operation at 0-49º
C/32-120º F and at a relative humidity. However, the useful
life of the system's standby batteries and the electronic com-
ponents may be adversely affected by extreme temperature
ranges and humidity. Therefore, it is recommended that this
system and its peripherals be installed in an environment with
a normal room temperature of 15-27º C/60-80º F.
Verify that wire sizes are adequate for all initiating and indi-
cating device loops. Most devices cannot tolerate more than a
10% I.R. drop from the specified device voltage.
Like all solid state electronic devices, this system may
operate erratically or can be damaged when subjected to light-
ning induced transients. Although no system is completely
immune from lightning transients and interference, proper
grounding will reduce susceptibility. Overhead or outside
aerial wiring is not recommended, due to an increased sus-
ceptibility to nearby lightning strikes. Consult with the Techni-
cal Services Department if any problems are anticipated or
encountered.
Disconnect AC power and batteries prior to removing or
inserting circuit boards. Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing,
reaming, or punching of the enclosure. When possible, make
all cable entries from the sides or rear. Before making modifi-
cations, verify that they will not interfere with battery, trans-
former, or printed circuit board location.
Do not tighten screw terminals more than 9 in-lbs. Over-
tightening may damage threads, resulting in reduced terminal
contact pressure and difficulty with screw terminal removal.
This system contains static-sensitive components. Always
ground yourself with a proper wrist strap before handling any
circuits so that static charges are removed from the body. Use
static suppressive packaging to protect electronic assemblies
removed from the unit.
Follow the instructions in the installation, operating, and
programming manuals. These instructions must be followedto
avoid damage to the control panel and associated equipment.
FACP operation and reliability depend upon proper installa-
tion.
Precau-D1-9-2005

4
Documentation Feedback
Your feedback helps us keep our documentation up-to-date and accurate. If you have a question or encounter a problem not
covered in this manual, contact Silent Knight Technical Support at 800-446-6444.
Please give the following information:
•Product name and version number (if applicable)
•Printed manual
•Topic Title
•Page number (for printed manual)
•Brief description of content you think should be improved or corrected
•Your suggestion for how to correct/improve documentation
To order parts, contact Silent Knight Sales at 800-328-0103.

Contents
1
Contents
Section 1
Introduction .............................................................................................................................................. 1-1
1.1 Overview of Basic System ........................................................................................................1-1
1.1.1 Hardware Features ............................................................................................................1-1
1.1.2 Software Features ..............................................................................................................1-2
1.2 About this Manual .....................................................................................................................1-2
1.2.1 Terms Used in this Manual ................................................................................................1-2
1.3 Compatible Products ................................................................................................................1-3
Section 2
Agency Listings, Approvals, and Requirements ................................... 2-1
2.1 Federal Communications Commission (FCC) ..........................................................................2-1
2.2 Underwriters Laboratories (UL) ................................................................................................2-2
2.2.1 Requirements for All Installations ......................................................................................2-2
2.2.2 Requirements for Central Station Fire Alarm Systems ......................................................2-3
2.2.3 Requirements for Local Protected Fire Alarm Systems .....................................................2-3
2.2.4 Requirements for Remote Station Protected Fire Alarm Systems .....................................2-3
Section 3
Before You Begin Installing ............................................................................................... 3-1
3.1 What’s in the Box? ...................................................................................................................3-1
3.2 Environmental Specifications ...................................................................................................3-1
3.3 Electrical Specifications ............................................................................................................3-2
3.4 Wiring Specifications ................................................................................................................3-3
3.5 Board Assembly Diagram .........................................................................................................3-4
3.6 Calculating Current Draw and Standby Battery ........................................................................3-5
3.6.1 Current Draw Worksheet Requirements ............................................................................3-5
3.6.2 Current Draw Worksheet for SK SLC Devices ...................................................................3-6
3.6.3 Current Draw Worksheet for SD SLC Devices ..................................................................3-8
3.6.4 Maximum Battery Standby Load ......................................................................................3-10
3.7 Installation Tasks Overview ....................................................................................................3-11
Section 4
Control Panel Installation ...................................................................................................... 4-1
4.1 Mounting the Control Panel Cabinet ........................................................................................4-1
4.1.1 Preventing Water Damage .................................................................................................4-1
4.1.2 Removing the 5700 Assembly from the Housing ...............................................................4-1
4.1.3 Dead Front Installation and removal ..................................................................................4-1
4.1.3.1 Installing the Dead Front ..........................................................................................4-2
4.1.3.2 Dead Front Removal ................................................................................................4-2

Contents
2
4.2 AC Connection .........................................................................................................................4-3
4.3 Battery Connection ...................................................................................................................4-4
4.3.1 RBB Accessory Cabinet .....................................................................................................4-5
4.3.1.1 Installing the RBB Accessory Cabinet and Batteries ...............................................4-5
4.4 SBUS Wiring ............................................................................................................................4-7
4.4.1 Calculating Wiring distance for SBUS modules .................................................................4-7
4.4.2 Wiring Configurations .........................................................................................................4-9
4.4.2.1 How to Power SBUS Devices From Auxiliary Power Supply ...................................4-9
4.5 5860emote Annunciator Installation .......................................................................................4-10
4.5.1 Mounting the 5860 ...........................................................................................................4-11
4.5.1.1 Flush Mounting .......................................................................................................4-13
4.5.1.2 Surface Mounting ...................................................................................................4-14
4.5.2 Model 5860 Connection to the Panel ...............................................................................4-14
4.6 5824 Serial/Parallel Printer Interface
Module Installation .................................................................................................................4-15
4.6.1 Selecting 5824 Options ....................................................................................................4-16
4.7 5880 LED Driver Module ........................................................................................................4-17
4.7.1 5880 Board Layout ...........................................................................................................4-17
4.7.2 FACP Connection ............................................................................................................4-18
4.7.3 LED Wiring .......................................................................................................................4-19
4.7.4 Dry Contact Wiring ...........................................................................................................4-19
4.8 5865-3 / 5865-4 LED Annunciator Installation ........................................................................4-20
4.8.1 FACP Connection ............................................................................................................4-21
4.8.2 5865 Mounting .................................................................................................................4-21
4.9 Configuring Modules ..............................................................................................................4-22
4.9.1 Assigning Module IDs ......................................................................................................4-22
4.10 Telephone Connection ...........................................................................................................4-23
4.11 Notification Appliance/Auxiliary Power Circuits ......................................................................4-23
4.11.1 Conventional Notification Appliance ...............................................................................4-23
4.11.1.1 Class B Notification Wiring ....................................................................................4-24
4.11.1.2 Class A Notification Wiring ....................................................................................4-25
4.11.2 Auxiliary Power Installation .............................................................................................4-26
4.11.2.1 Door Holder Power ................................................................................................4-26
4.11.2.2 Constant Power .....................................................................................................4-27
4.11.2.3 Resettable Power ..................................................................................................4-27
4.11.2.4 Sounder Sync Power ............................................................................................4-27
4.12 On-Board Relays (Conventional) ...........................................................................................4-27
4.12.1 Common Trouble Relay ..................................................................................................4-27
4.12.2 Programmable Relays ....................................................................................................4-27
4.13 Remote Station Applications ..................................................................................................4-28
4.13.1 Keltron Model 3158 Installation ......................................................................................4-28
4.13.2 City Box Connection Using the 5220 Module .................................................................4-29
4.13.3 NFPA 72 Polarity Reversal .............................................................................................4-30
4.13.3.1 Using the 5220 Module .........................................................................................4-30
4.13.3.2 Using the 7644-L8 Module ....................................................................................4-31
4.13.4 Using the SD500-ARM Addressable Relay Module .......................................................4-31
4.13.5 Using a MR-201/T Control Relay From Air Products ......................................................4-33
4.13.6 Transmitter Activated by Dry Contacts ...........................................................................4-34

Contents
3
Section 5
SK and SD SLC Device Installation .......................................................................... 5-1
5.1 List of SK SLC Devices ............................................................................................................5-1
5.2 List of SD SLC Devices ............................................................................................................5-2
5.3 Maximum Number of Devices ..................................................................................................5-3
5.4 Wiring Requirements for SLC Devices .....................................................................................5-3
5.4.1 Wiring SLC in Style 4 (Class B) Configuration ...................................................................5-3
5.4.2 Wiring SLC Devices in Style 6 & 7 (Class A)
Configuration 5-5
5.5 SK Detector Installation ............................................................................................................5-6
5.5.1 Wiring SK Detectors ...........................................................................................................5-6
5.6 Addressing SK SLC Devices ....................................................................................................5-7
5.7 SD Detector Installation ............................................................................................................5-8
5.7.1 Wiring SD Detectors ..........................................................................................................5-8
5.8 Addressing SD SLC Devices ....................................................................................................5-9
5.8.1 SD505-PHOTO or SD505-HEAT .......................................................................................5-9
5.8.2 SLC Devices with DIP Switches ......................................................................................5-10
Section 6
Programming Overview ........................................................................................................... 6-1
6.1 JumpStart Autoprogramming ...................................................................................................6-1
6.1.1 Input Points ........................................................................................................................6-1
6.1.2 Output Points .....................................................................................................................6-1
6.1.3 Running JumpStart ............................................................................................................6-2
6.2 Mapping Overview ....................................................................................................................6-3
6.2.1 Input Point Mapping ...........................................................................................................6-4
6.2.2 Output Circuit Mapping ......................................................................................................6-5
6.2.3 Zone Event Mapping ..........................................................................................................6-6
6.2.4 Mapping LED Points ..........................................................................................................6-8
6.3 Programming Using the 5660 Silent Knight Software Suite .....................................................6-9
6.4 Programming Using an Annunciator ........................................................................................6-9
6.4.1 Entering / Exiting the Program Menu .................................................................................6-9
6.4.2 Moving through the Menus ..............................................................................................6-10
6.4.3 Selecting Options and Entering Data ...............................................................................6-10
6.4.4 Editing Keys .....................................................................................................................6-11
6.5 Programming Menu Quick Reference ....................................................................................6-12
Section 7
Programming ......................................................................................................................................... 7-1
7.1 UL 864 Programming Requirements ........................................................................................7-1
7.2 Modules ....................................................................................................................................7-2
7.2.1 Edit Modules ......................................................................................................................7-2
7.2.1.1 Naming Modules ......................................................................................................7-2
7.2.1.2 Module, Wiring Class ...............................................................................................7-2
7.2.2 Adding a Module ................................................................................................................7-2
7.2.3 Deleting a Module ..............................................................................................................7-3
7.2.4 View Module List ................................................................................................................7-3

Model 5700 Installation Manual
4
7.3 Zone .........................................................................................................................................7-3
7.3.1 Edit Zone ............................................................................................................................7-3
7.3.1.1 Edit Zone Name .......................................................................................................7-4
7.3.1.2 Edit Zone Properties ................................................................................................7-4
7.3.1.3 Zone Outputs ...........................................................................................................7-6
7.3.1.4 Cadence Patterns ....................................................................................................7-8
7.3.1.5 Zone Accessory Options ..........................................................................................7-9
7.3.2 Add Zone ...........................................................................................................................7-9
7.3.3 Delete Zone .......................................................................................................................7-9
7.3.4 View Zone Points ...............................................................................................................7-9
7.4 Group .....................................................................................................................................7-10
7.4.1 Edit Group ........................................................................................................................7-10
7.4.1.1 Edit Group Name ...................................................................................................7-10
7.4.1.2 Edit Group Properties .............................................................................................7-11
7.4.2 Add Group ........................................................................................................................7-13
7.4.3 Delete Group ....................................................................................................................7-13
7.4.4 View Group Points ...........................................................................................................7-13
7.4.5 Edit Output Group Templates ..........................................................................................7-14
7.5 Point .......................................................................................................................................7-15
7.5.1 Point Programming For SLC ............................................................................................7-15
7.5.2 Point Programming For Internal or External Power Module ............................................7-18
7.5.3 Point Programming For 5880 and 5865 Modules ............................................................7-20
7.5.4 Assigning a Name to a Points ..........................................................................................7-20
7.6 System Options ......................................................................................................................7-21
7.6.1 Reporting Account ...........................................................................................................7-21
7.6.1.1 Edit Accounts .........................................................................................................7-21
7.6.1.2 Auto Test Time .......................................................................................................7-24
7.6.2 Phone Lines .....................................................................................................................7-24
7.6.2.1 Dialing Prefix ..........................................................................................................7-25
7.6.2.2 Number of Answer Rings .......................................................................................7-25
7.6.2.3 Dial Option (TouchTone or Pulse) ..........................................................................7-25
7.6.2.4 Rotary Format ........................................................................................................7-25
7.6.2.5 Line Monitor ...........................................................................................................7-25
7.6.2.6 Answering Machine Bypass ...................................................................................7-26
7.6.3 Sys. Event Outputs ..........................................................................................................7-26
7.6.3.1 Trouble Events .......................................................................................................7-26
7.6.3.2 System Alarm Cadence .........................................................................................7-27
7.6.4 Time Options ....................................................................................................................7-27
7.6.4.1 Water Flow Delay ...................................................................................................7-28
7.6.4.2 Alarm Verification Time ..........................................................................................7-28
7.6.4.3 Low AC Report Delay .............................................................................................7-28
7.6.4.4 Clock Display Format (AM/PM or Military) .............................................................7-28
7.6.4.5 Change AC Line Frequency ...................................................................................7-29
7.6.5 Miscellaneous Options .....................................................................................................7-29
7.6.5.1 Synchronize Strobes Active During Silence ...........................................................7-29
7.6.5.2 Auto Display Oldest Event .....................................................................................7-29
7.6.5.3 Report by Zone or by Point ....................................................................................7-29
7.6.5.4 Single Key Acknowledge .......................................................................................7-30
7.6.6 Daylight Savings ..............................................................................................................7-30
7.6.6.1 Automatic Daylight Savings Adjustment ................................................................7-30
7.6.6.2 Daylight Saving Time Start and End ......................................................................7-30
7.6.7 Edit Banner ......................................................................................................................7-30
7.6.8 SLC Family ......................................................................................................................7-31
7.7 JumpStart Autoprogramming .................................................................................................7-32

Contents
5
7.8 Computer Account ..................................................................................................................7-32
7.9 Access Codes ........................................................................................................................7-33
7.9.1 Profile Edit Menu ..............................................................................................................7-34
7.9.1.1 Edit Name ..............................................................................................................7-34
7.9.1.2 Edit Access Code ...................................................................................................7-34
7.9.1.3 Panel Functions .....................................................................................................7-34
Section 8
System Operation ............................................................................................................................ 8-1
8.1 Default Codes: ..........................................................................................................................8-1
8.2 Annunciator Description ...........................................................................................................8-1
8.2.1 LCD Displays .....................................................................................................................8-1
8.2.2 Banner ...............................................................................................................................8-1
8.3 Menu System ...........................................................................................................................8-2
8.3.1 Main Menu Overview .........................................................................................................8-2
8.3.2 Using the Menus ................................................................................................................8-3
8.4 Basic Operation ........................................................................................................................8-3
8.4.1 Setting Time and Date .......................................................................................................8-3
8.4.2 Disable / Enable NACs by Group .......................................................................................8-3
8.4.3 Disable / Enable a Template ..............................................................................................8-3
8.4.4 Disable / Enable a Zone .....................................................................................................8-3
8.4.5 Disable / Enable a Point .....................................................................................................8-3
8.4.6 View Event History .............................................................................................................8-4
8.4.6.1 To clear the event history .........................................................................................8-4
8.4.7 Conduct a Fire Drill ............................................................................................................8-4
8.4.8 Conduct an Indicator Test ..................................................................................................8-4
8.4.9 Conduct a Walk Test ..........................................................................................................8-5
8.4.10 Conduct a Dialer Test .......................................................................................................8-5
8.4.11 Silence alarms or troubles ................................................................................................8-5
8.4.12 Reset alarms ....................................................................................................................8-5
8.4.13 Check Detector Sensitivity Through Point Status .............................................................8-5
8.4.14 View Status of a Point ......................................................................................................8-6
8.4.15 View Alarms, Supervisories or Troubles ...........................................................................8-7
8.4.16 View System Information ..................................................................................................8-7
8.4.17 Reset dialer ......................................................................................................................8-7
8.4.18 Communicating with a Remote Computer ........................................................................8-7
8.4.19 Working with a Printer ......................................................................................................8-8
8.5 Operation Mode Behavior ........................................................................................................8-9
8.6 Releasing Operations .............................................................................................................8-12
8.6.1 Single Interlock Zone Releasing ......................................................................................8-13
8.6.2 Double Interlock Zone Releasing .....................................................................................8-14
8.7 Smoke Alarm Verification .......................................................................................................8-16
Section 9
Reporting ..................................................................................................................................................... 9-1
9.1 Receivers Compatible with the Control Panel ..........................................................................9-1
9.2 Reporting Formats Table ..........................................................................................................9-1

Model 5700 Installation Manual
6
Section 10
Testing and Troubleshooting ......................................................................................... 10-1
10.1 Troubleshooting ......................................................................................................................10-1
10.2 Common Problems .................................................................................................................10-1
10.2.1 Periodic Testing And Maintenance .................................................................................10-2
10.2.2 Event History ..................................................................................................................10-2
10.3 Built-in Troubleshooting and Testing Tools ............................................................................10-3
10.3.1 SLC Device Locator ........................................................................................................10-3
10.3.2 SLC Multi Locator ...........................................................................................................10-3
10.3.3 I/O Point Control .............................................................................................................10-4
10.4 Earth Fault Resistance ...........................................................................................................10-4
Section 11
Installation Records .................................................................................................................... 11-1
11.1 Detector and Module Point Record ........................................................................................11-1
Appendix A
Compatible Devices ..................................................................................................................... A-1
Appendix B
Special Characters Lists .........................................................................................................B-1
Silent Knight Fire Product Warranty and Return Policy
Manufacturer Warranties and Limitation of Liability
Model 5700 Basic Operating Instructions

151295
1-1
Section 1
Introduction
The 5700 Fire Alarm Control / Communicator is an addressable fire control system that meets the requirements
of UL 864.
1.1 Overview of Basic System
1.1.1 Hardware Features
• The 5700 has one signaling line circuit (SLC) that supports 50 SK detectors and 50 SK modules or 50 SD
protocol devices.
• 2.5A of output power is available through 2 sets of terminals for notification appliance circuits or auxiliary
applications. Each circuit is power limited per UL 864 and can source up to 2.5A (total output power for
both circuits must not exceed 2.5A).
• Built-in dual phone line, digital alarm communicator/transmitter (DACT).
• Reports events to central station by point or by zone.
• UL Listed for pre-action and deluge releasing systems.
• Two general purpose Form C programmable relays.
• One Form C Trouble Relay.
• Basic system operation can be performed from the on-board, or any remote annunciator.
• Up to 20 user profiles can be programmed, each having custom access code, and main menu items.
• Can be used with up to 8 Model 5860 Remote Annunciators (sold separately).
• Can be used with Model 5865-3, 5865-4, and 5880 in any combination for a total of eight devices on one
control panel. See Sections 4.7 and 4.8 for additional information on these models.
• Printing of detector status, event history, and real time event log available through the Model 5824 Serial /
Parallel Interface (sold separately).
• 125 software zones, 125 output groups.
• Add 6 Flexput™ circuits with each 5895XL Intelligent Power Module (up to eight 5895XLs per system).
See note below.
• Add four Notification/Auxiliary power circuits with each 5496 Intelligent Power Module (up to eight 5496s
per system). See note below.
Note: The system can support a maximum of eight intelligent power modules, either the 5895XL or 5496, in any
combination.

Introduction 151295
1-2
1.1.2 Software Features
• Advanced smoke detector features:
–Automatic drift compensation
–Maintenance alert region
–Point status meets calibrated smoke test requirements for NFPA 72
• “JumpStart” feature for easy programming
• Non-volatile event history stores 1000 events
• A choice of output patterns available for notification outputs, including ANSI 3.41 temporal signal
• Built-in synchronization appliance support for Faraday, Gentex®, Wheelock®, or System Sensor ®
1.2 About this Manual
This manual is intended to be a complete reference for all installation and operation tasks for the 5700. Please let
us know if the manual does not meet your needs in any way. We value your feedback!
1.2.1 Terms Used in this Manual
The following terminology is used with the 5700 system:
Table 1-1 Manual Terminology
Term Description
SLC Signaling Line Circuit
Module The term module is used for all hardware devices except for SLC
addressable devices and notification appliances. This includes
the 5700 panel itself.
Input Point An addressable sensing device, such as a smoke or heat
detector or a contact monitor device.
Input Zone A protected area made up of input points.
Output Point
(or Output Circuit) A notification point or circuit for notification appliances. Relay circuits and auxiliary power circuits are also considered output
points.
Group (or “Output Group”) A group of output points. Operating characteristics are common
to all output points in the group.
Output (or “Cadence”) Pattern The pattern that the output will use, for example, Constant,
March Code, ANSI 3.41. Applies to zones and special system
events. See Section 7.6.3.2 for additional information.
Mapping Mapping is the process of specifying which outputs are activated
when certain events occur in the system. Section 6.2 explains
mapping in detail.

Model 5700 Installation and Operation Manual
1-3
1.3 Compatible Products
The chart below lists the products available from Silent Knight for use with the 5700.
Note: 5865-3, 5865-4, and 5880 can be used in any combination, up to a total of eight devices on one panel.
Table 1-2 5700 Compatible Products
Type of
Device Model Description
SK
Addressable
SLC Devices
See Section 5.1 for a list of compatible devices.
SD
Addressable
SLC Devices
See Section 5.2 for a list of compatible devices.
Other
Modules
5824 Serial/Parallel Printer
Interface Module Allows a printer to be attached for the system for on-site event logging, detector status and event history reports. Two maximum per system.
5895XL Provides additional power, six Flexput circuits, and two Form C relays. Max 8 per
system. See 5895XL Installation Manual (PN 151142) for more information.
5496 Intelligent Power
Module Provides 4 additional Notification Appliance Circuits/Auxiliary power. (Up to 8 per 5700 system.)
5860TG and 5860TR Trim
Ring Trim ring kits for surface mounting the 5860/5860R annunciator. 5860TG is gray; 5860TR is red.
5865-3 and 5865-4 LED
Annunciator LED annunciator can display up to 30 LEDs (15 red and 15 yellow). 5865-4 has key switches for silence and reset, and a system trouble LED.
5880 LED Driver Module Driver for up to 40 LEDs. Interfaces with customized annunciator boards. In addition the
5880 has eight generic switch input points.
5883 General Purpose
Relay Module Provides 10 Form C relays. Designed to be driven by the 5880. Up to four, 5883s can be used with each 5880 module.
Software
5660 Silent Knight
Software Suite (SKSS) For communication and panel programming with a Windows-based computer and modem (not sold by Silent Knight, see Table 1-3 for compatible modems). Enables
remote viewing of detector status and event history.
5670 SKSS Facility
Management Software For remote viewing of detector status and event history. Requires a modem (not sold by Silent Knight).
Misc.
7860 Telephone Cord RJ31X cord for connecting phone line to the 5700.
7628 UL Listed End-of-line resistor.
DF-50 Dead Front insert.

Introduction 151295
1-4
The following modems have been tested by Silent Knight for compatibility with the 5700 and the Silent Knight
Software Suite software packages:
Table 1-3: Compatible Modems
Manufacturer Model
US Robotics 28.8
Motorola
Lifestyle
28.8, 3400 series
Premier 33.6
Multi-Tech MT19321ZDX

Agency Listings, Approvals, and Requirements 151295
2-1
Section 2
Agency Listings, Approvals, and Requirements
Install and maintain in accordance with NFPA 72. Detector spacing shall be in accordance to NFPA 72. End-of -
line relays and resistors shall be placed within the electrical box located and the end of the initiating circuit.
Testing and maintenance should be performed according to NFPA 72.
2.1 Federal Communications Commission (FCC)
The following information must be provided to the telephone company before the 5700 can be connected to the
phone lines:
1. This device may not be directly connected to coin telephone or party line services.
2. This device cannot be adjusted or repaired in the field. In case of trouble with the device, notify the installing
company or return to:
Silent Knight
12 Clintonville Road
Northford, CT 06472-1610
[phone]
3. If the 5700 causes harm to the telephone network, the telephone company will notify the user in advance that
temporary discontinuance of service may be required. If advance notice is not practical, the telephone com-
pany will notify the user as soon as possible. Users have the right to file complaints, if necessary, with the
Federal Communications Commission.
4. The telephone company may make changes in its facilities, equipment, operations, or procedures that could
affect the operation of the equipment. If this happens, the telephone company will provide advance notice to
allow you to make the necessary modifications to maintain uninterrupted service.
a) This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the
wiring diagram of this equipment is a label that contains, among other information, a product identifier in
the format US: AC6AL05B-205700. If requested, this number must be provided to the telephone company.
b) See Section 4.10 for phone jack information.
c) A plug and jack used to connect this equipment to the premises wiring and telephone network must comply
with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord
and modular plug is provided with this product. It is designed to be connected to a compatible modular jack
A Manufacturer: Silent Knight by Honeywell
B Model Number: 5700
C FCC registration number: US: AC6AL05B205700
Ringer equivalence: 0.5B
D Type of jack: RJ31X
E Facility Interface Codes: Loop Start: 02LS2
F Service Order Code: 9.0F
Warning
This device has been verified to comply with FCC Rules Part 15. Operation is subject to the following conditions: (1)
This device may not cause radio interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation.

Agency Listings, Approvals, and Requirements 151295
2-2
that is also compliant. See installation instructions for details.
d) The REN is used to determine the number of devices that may be connected to a telephone line. Excessive
RENs on a telephone line may result in the devices not ringing in response to an incoming call. In most but
not all areas, the sum of RENs should not exceed five (5.0). To be certain of the number of devices that may
be connected to a line, as determined by the total RENs, contact the local telephone company. For products
approved after July 23, 2002, the REN for this product is part of the product identifier that has the format
US: AC6AL05B-205700. The digits represented by ## are the REN without a decimal point (e.g., 03 is a
REN of 0.3). For earlier products, the REN is separately shown on the label.
e) If this equipment 5700 causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice isn't practical, the
telephone company will notify the customer as soon as possible. Also, you will be advised of your right to
file a complaint with the FCC if you believe it is necessary.
f) The telephone company may make changes in its facilities, equipment, operations or procedures that could
affect the operation of the equipment. If this happens the telephone company will provide advance notice in
order for you to make necessary modifications to maintain uninterrupted service.
g) If trouble is experienced with this equipment 5700, for repair or warranty information, please contact Silent
Knight. If the equipment is causing harm to the telephone network, the telephone company may request that
you disconnect the equipment until the problem is resolved.
h) See warranty in back of this manual for repair and replacement information.
i) Connection to party line service is subject to state tariffs. Contact the state public utility commission, public
service commission or corporation commission for information.
j) If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of
this 5700 does not disable your alarm equipment. If you have questions about what will disable alarm
equipment, consult your telephone company or qualified installer.
Electrical Safety Advisory:
Parties responsible for equipment requiring AC power should consider including an advisory notice in their
customer information suggesting the customer use a surge arrestor. Telephone companies report that electrical
surges, typically lightning transients, are very destructive to customer terminal equipment connected to AC
power sources. This has been identified as a major nationwide problem.
2.2 Underwriters Laboratories (UL)
2.2.1 Requirements for All Installations
General requirements are described in this section. When installing an individual device, refer to the specific
section of the manual for additional requirements. The following subsections list specific requirements for each
type of installation (for example, Central Station Fire Alarm systems, Local Protected Fire Alarm systems, and
so on). See Section 8.6 for information on releasing operation.
1. All field wiring must be installed in accordance with NFPA 70 National Electric Code.
2. Use the addressable smoke detectors specified in Section 5.2 of this manual.
3. Use UL listed notification appliances compatible with the 5700 from those specified in the Appendix at the
back of this manual.
4. A full system checkout must be performed any time the panel is programmed.
Restricted Options:
• The loss of AC signal is defaulted to 3 hours however the system allows settings from 0 - 30 hours. For UL
certified installations this number must be set from 1 to 3 hours.
• The system allows the use of non-latching spot type smoke detectors. This feature may not be used in
commercial applications whereby a general alarm is sounded. It is intended for elevator recall, door holding

Model 5700 Installation Manual
2-3
applications, and hotel/motel room applications.
• The system allows the Alarm Verification time to be set from 1 to 255 seconds. For UL certified installations
the setting must be a maximum of 60 seconds.
• Call forwarding shall not be used.
• When two count is used detector spacing shall be cut in half, you shall not use the alarm verification feature,
and no delay shall be used.
• P.A.S (positive alarm sequence) feature shall be used only with automatic detectors.
2.2.2 Requirements for Central Station Fire Alarm Systems
1. Use both phone lines. Enable phone line monitors for both lines.
2. You must program a phone number and a test time so that the 5700 sends an automatic daily test to the cen-
tral station.
3. The AC Loss Hours option must be set from 6-12 hours.
4. The Attempts to Report option must be set for 5.
2.2.3 Requirements for Local Protected Fire Alarm Systems
At least one UL listed supervised notification appliance must be used.
2.2.4 Requirements for Remote Station Protected Fire Alarm
Systems
1. Do not exceed the current load restrictions shown in Section 3.6.
2. The AC Loss Hours option must be set from 1-3 hours.

Before You Begin Installing 151295
3-1
Section 3
Before You Begin Installing
This section of the manual is intended to help you plan your tasks to facilitate a smooth installation. Please read
this section thoroughly, especially if you are installing a 5700 panel for the first time.
3.1 What’s in the Box?
The 5700 ships with the following hardware:
• A cabinet with all hardware assembled
• Two keys for the front door
• Installation and Operation manual P/N 151295
• Ten 4.7K ohm end-of-line resistors
• A battery cable for batteries wired in series
3.2 Environmental Specifications
It is important to protect the 5700 control panel from water. To prevent water damage, the following precautions
should be FOLLOWED when installing the units:
• Intended for indoor use in dry locations only
• Do not mount directly on exterior walls, especially masonry walls (condensation)
• Do not mount directly on exterior walls below grade (condensation)
• Protect from plumbing leaks
• Protect from splash caused by sprinkler system inspection ports
• Do not mount in areas with humidity-generating equipment (such as dryers, production machinery)
When selecting a location to mount the 5700 control panel, the unit should be mounted where it will NOT be
exposed to temperatures outside the range of 0°C-49°C (32°F-120°F) or humidity outside the range of 10%-93%
at 30°C (86°F) noncondensing.

Before You Begin Installing 151295
3-2
3.3 Electrical Specifications
Table 3-1 list the terminal block on the 5700 as well as a description of the each individual terminal and their
respective electrical rating. For location of the terminals refer to Figure 3-2. See also Section 4 for installation.
* Regulated NAC application. When programmed for releasing, NAC are Special Application.
Table 3-1: Terminal Descriptions and Electrical Specifications
Terminal No. Label Description Rating
Group Individual Voltage Current
Terminal Block 1
RELAY 1 NO Normally open relay contact 27.4 VDC 2.5 A, resistiveCOM Common terminal
NC Normally closed relay contact
RELAY 2 NO Normally open relay contact 27.4 VDC 2.5 A, resistiveCOM Common terminal
NC Normally closed relay contact
Terminal Block 2
TELCO 1 RING Phone Line 1 Telco Ring
TIP Phone Line 1 Telco Tip
PHONE 1 RING Phone Line 1 Phone Ring
TIP Phone Line 1 Phone Tip
TELCO 2 RING Phone Line 2 Telco Ring
TIP Phone Line 2 Telco Tip
PHONE 2 RING Phone Line 2 Phone Ring
TIP Phone Line 2 Phone Tip
TROUBLE NO Normally open relay contact 27.4 VDC 2.5 A, resistiveCOM Common terminal
NC Normally closed relay contact
SLC IN –Used for Class A installations 32 VDC 100 mA
+
SLC OUT –SLC terminals 32 VDC 100 mA
+
SLC PROG –Used for programming SLC
Detectors 32 VDC 100 mA
+
SBUS
–SBUS Power 27.4 VDC 0.5 A
+
ASBUS Communication 5 VDC 100 mA
B
NAC1* –Notification Appliance Circuit/
Auxiliary power 27.4 VDC 2.5 Amp NAC or Aux
power
+
NAC2* –Notification Appliance Circuit/
Auxiliary power 27.4 VDC 2.5 Amp NAC or Aux
power
+

Model 5700 Installation Manual
3-3
3.4 Wiring Specifications
Induced noise (transfer of electrical energy from one wire to another) can interfere with telephone
communication or cause false alarms. To avoid induced noise, follow these guidelines:
• Isolate input wiring from high current output and power wiring. Do not pull one multi-conductor cable for
the entire panel. Instead, separate the wiring as follows:
• Do not pull wires from different groups through the same conduit. If you must run them together, do so for
as short a distance as possible or use shielded cable. Connect the shield to earth ground at the panel. You
must route high and low voltages separately.
• Route the wiring around the inside perimeter of the cabinet. It should not cross the circuit board where it
could induce noise into the sensitive microelectronics or pick up unwanted RF noise from the high speed
circuits. See Figure 3-1 for an example.
• High frequency noise, such as that produced by the inductive reactance of a speaker or bell, can also be
reduced by running the wire through ferrite shield beads or by wrapping it around a ferrite toroid.
Figure 3-1 Wire Routing Example
High voltage AC power Terminals
SLC loops
Audio input/output Phone line circuits
Notification circuits NAC1 through NAC2
SBUS
Relay circuits
Relay
NAC/Aux Power
Outputs
SBUS
Phone
SLC IN/OUT
AC Power
Input
Devices
Lines
Outputs
Maintain at least 1/4” spacing
between power limited and
non-power limited circuits.
Battery
