SILENT KNIGHT 5860 Manual

Insert wires at an angle into the first holes past the sheet rock.
Secure the wires behind this screw.
Attach second set of wires to top of back box.
Securing Back Box to Wall for Flush Mounting
Flush Mounting with Electrical Box (Example)
Flush Mounting
Sheet rock
Electrical Box
Annunciator
back box
1-1/4"
When flush-mounting using an
electrical box, the box must be
1-1/4" (min.) from face of wall.
Bezel (external ring)
Electronic Assembly
(front view)
ENTER
GENERAL ALARM
SUPERVISORY
SYSTEM TROUBLE
SYSTEM SILENCE
SYSTEM POWER
RESET
SILENCE
12 3
45 6
78 9
0
*
#
FIRE ALARM ANNUNCIATOR
MODEL 5860
Back Box
Assembled annunciator also includes mounting
wires, 2 set screws.
Annunciator Parts
Installation Steps
1. Make sure power is off at the panel.
2. Annunciator is assembled at the factory. Disassemble as needed.
3. Mount annunciator. See pages 3-4.
4. Wire annunciator to the panel. See page 2.
5. Use dipswitches to set annunciator ID. See page 2.
Model 5860 Remote Fire Annunciator
Installation Quick Reference
Refer to 5820 installation manual (P/N 150972) for complete information.
P/N 151042
4

Assemble trim ring and back
box before attaching box to wall.
Trim Ring
Back Box
Surface Mounting
The Model *5860T-G/R Trim Ring is
available to provide a finished
look to surface-mounted annunciators.
*5860T-G is gray
5860T-R is red
1-1/4"
6-7/16"
8-1/8"
7-3/8"
9-1/8"
Bezel (escutcheon plate)
Annunciator back box
1-9/16"
1-1/4"
Side View
Annunciator Dimensions
OFF
ON
Address
1 4 5 23
*0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Address
1 4 5 23
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
*Note: Address 0 cannot be used.
Possible ID Numbers
19
-
18
+
17
A
16
B
SBUS OUT
5820 Board Assembly
SB SA S+ S-
ON
123 4 5
Model 5860 Annunciator
(back view)
Dipswitches
8 annunciators max. per system
Connection to the Panel
2 3
