Silhouette DDR600R User manual

PORTABLE 2-IN-1 HOME COMFORT
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . 1
APPAREIL PORTABLE DE CONFORT
AU FOYER 2 EN 1
Table des matières . . . . . . . . . . . . . . . . . . . . . . . 14
CONFORT HOGAREÑO 2-EN-1 PORTÁTIL
Índice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Danby Products Limited, Guelph, Ontario Canada N1H 6Z9
Danby Products Inc., Findlay, Ohio USA 45840
03/05 ver.1
OWNER’S MANUAL
MANUEL
D'UTILISATION
MANUAL DEL
USUARIO
Model • Modèle • Modelo
DDR600R
CAUTION:
Read complete installation and
operating instructions before
installing and/or using the
dehumidifier.
MISE EN GARDE :
Lire attentivement les consignes
de sécurité et les instructions
d'utilisation avant l'utilisation
initiale de ce produit.
ADVERTENCIA:
Lea completamente el manual de
instalación y de operación antes
de instalar y/o usar el
deshumidificador.
KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE.
If the Dehumidifier changes
ownership, be sure this manual
accompanies the unit.
CONSERVER CES
INSTRUCTIONS POUR LA
RÉFÉRENCE FUTURE
En cas de revente du
déshumidificateur, ce manuel doit
être inclus avec l'appareil.
GUARDE ESTAS
INSTRUCCIONES PARA
REFERENCIA FUTURA.
Si el deshumidificador cambia de
dueño, asegúrese de que este
manual permanezca con la
unidad.

Page
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings, and Important Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features and Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Key Pad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Location and Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Operating Instructions/Air Filter Removal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Direct Drain Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Trouble Shooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1
Table Of Contents

2
Introduction
Thank you for choosing this Danby appliance to provide you and your family with all of the “Home Comfort”
requirements for your home, cottage or office. This Owner’s Manual will provide you with valuable information
necessary for the proper usage, care and maintenance of your new appliance. If properly maintained, your
Danby®appliance will give you many years of trouble free operation. Please take a few moments and read
the instructions thoroughly and familiarize yourself with all of the operational aspects of this appliance.
This unit can be conveniently moved from room to room within your home and set-up in just minutes.
For easy reference, may we suggest you attach a copy of your sales slip/receipt to this page, along with the
following information which is located on the manufacturers nameplate located on the rear wall of the water
tank compartment.
Model Number: ___________________________________________________
Serial Number: ___________________________________________________
Date of Purchase: _________________________________________________
Dealer’s Name and Address: ________________________________________
________________________________________
This information will be required if your unit requires servicing and/or for general inquiries. To contact a
Customer Service Representative, telephone
1-800-26-DANBY (1-800-263-2629)
Keep these instructions for future reference.
This symbol denotes a caution or warning
CAUTION
Do not leave this unit unattended or operate in an
area where people or animals may not be able to
react quickly. A failed unit may cause over-heating
reaulting in personal injury or property damage.

3
NOTE: The WARNING instructions issued in this manual are not meant to cover all possible conditions and
situations that may occur. It must be understood that common sense, caution and carefulness are factors
that cannot be built into all appliances.These factors must be supplied by the person(s) installing,
maintaining, or operating the appliance. Failure to install, maintain, and/or operate the equipment according
to the manufacturer's instructions may result in conditions which can produce bodily injury and/or property
damage. Contact your dealer, service agent or the manufacturer about any problems or conditions you do
not fully understand. (For Danby Customer Service call 1 800 26 DANBY / 1 800 263 2629)
WARNING - IMPORTANT NOTICES
FOR YOUR SAFETY -To reduce the risk of fire or explosion, do not store or use gasoline or other flammable
vapors or liquids in the vicinity of this or any other appliance.
ELECTRICAL SERVICE INFORMATION -To reduce the risk of fire, electric shock or personal injury, all wiring
and grounding must conform with the latest edition of Local and National Electrical Codes It is the customer's
responsibility to have the wiring and fuses checked by a qualified electrician to make sure adequate electrical power is
available.
This appliance is designed to operate on a separate branch, polarized, three-wire, effectively grounded, 120 Volt 60
Hertz (alternating current) circuit protected by a 15 ampere fuse, equivalent fusetron or circuit breaker.
The three-prong grounding plug on the power cord should be plugged directly into a polarized three slot effectively
grounded receptacle rated 110/120 V.A.C.
GROUNDING INSTRUCTIONS -Improper connection of the equipment-grounding conductor can result in a risk of
electrical shock. Check with a qualified electrician or serviceman if you are in doubt as to whether your appliance
outlets are properly grounded.
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of
electrical shock by providing a path of least resistance for electrical current.This appliance is equipped with a cord
having an equipment-grounding conductor and 3 prong grounding plug.The plug must be connected into an outlet that
is properly installed and grounded in the accordance with all local codes and ordinances.
Do not modify the plug provided with the appliance. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
If the household electrical supply does not meet the above specifications, or if you are not sure your home has an
effective ground, have a qualified electrician or your local electrical utility company check it and correct any problems.

Electrical Specifications
1. All wiring must comply with local and national
electrical codes and be installed by a qualified
electrician. If you have any questions regarding the
following instructions, contact a qualified electrician.
2. Check available power supply and resolve any wiring
problems BEFORE installation and operation of this
unit.
3. For your safety and protection, this unit is grounded
through the power cord plug when plugged into a
matching wall outlet. If you are not sure whether the
wall outlets in your home are properly grounded,
please consult a qualified electrician. DO NOT USE
PLUG ADAPTERS OR EXTENSION CORDS.
4. The manufacturers nameplate is located on the rear
(back) wall of the cabinet.The nameplate contains
electrical and other technical data specific to this unit.
5. To avoid the possibility of personal injury, always
disconnect the power supply before attempting to
clean and/or service the unit.
4
Dehumidifying Capacity (Pints / Liters) 60 / 28.4
Electrical Requirements 115 Volts / 60 Hz
Power Input (watts) 785
Rated Amperage
• Dehumidifying 7.26
• Heating Not Applicable
Air Flow Circulation - High /Low Fan Speed (Cubic Feet per Minute) 183 / 160
Type of Refrigerant R22
Water Tank Capacity (Liters / Pints) 5.3 / 11.2
Operating Noise Level (dB A) 50
Unit Dimensions Width / Height / Depth 13-3/4” x 30-1/2” x 13-3/16”
Net Weight (kg / lbs.) 25 / 55.1
NOTE: Specifications are subject to change without notice, for further improvements.
Unit Specifications: DDR600R

5
• Soft Touch (Electronic) Control Key Pads (Illuminated)
• LED Readout
• Auto-Sensing Humidity Control
• Adjustable Humidity Settings (35% ~ 80%, Continuous)
• 2 Fan Speed Settings (High/Low)
• Delay Start Protection (compressor)
• Auto-Defrost (De-Icer)
• Low Temperature Operation
• Energy Star Rated
• Water Full (Bucket) Indicator Light & Audible Signal
• Easy Roll Casters (4)
• Front Mounted Water Tank (Removable)
• Direct Drain Option (Hose not Included)
• Euro-Design Styling
• Quiet Operation
• Removable Air Filter
FEATURES
Control Panel
Air Inlet
Front Panel Side Panel
Handle
Unit Parts Identification
Water Tank
(Front)
Easy-roll Castors

I/O Button :
Each time this button is pressed turns the unit On/Off.
Fan Button: Each time this button is pressed the fan speed
will alternate between HIGH FAN & LOW FAN.
Timer Button: Used to initiate a delayed start “on” time
and/or delayed “off” stop time. Each time the button is
pressed the dalayed start/stop time can be adjusted (between
0.5 hrs ~ 24 hrs.) as follows;
0.5 hr increments. (from 0.5hrs ~ 10 hrs.)
1.0 hr increments (from 10hrs. ~ 24hrs.)
This button allows you to decrease relative humidity settings. Each
time the button is pressed the SET RH% value will decrease by
5%. (adjustable values between 80% ~35%) This button can also
be used to decrease auto timed (delay start / delay stop) programs
This button allows you to increase the relative humidity settings.
Each time the button is pressed the SET RH% value will increase
by 5%. (adjustable values between 35% ~ 80%) This button can
also be used to increase auto timed (delay start / delay stop)
programs
Mode Button: Each time this button is pressed will alternate
between dehumidifier and fan mode.The symbol for the mode
selected will appear in the LED display
LED READOUT:The LED displays the following information:
1. ROOM AIR = Real Time Room Ambient RH% Conditions
2. SET AIR = The Set Operating RH% Value.
3. MODE: = The selected operating mode.
4. FAN SPEED = The selected fan speed.
5. TIMER = The selected delayed start/stop time.
6
Explanation of key pad functions on the electronic control board.
12 5
34
I/O

7
Indicator Light Function:
Arrow Symbols (Operation - Blue Light): This light
illuminates and remains illuminated as long as the unit is
operational.
Bucket Symbol (Water Full - Red Light): This light
illuminates under the following conditions;
1.When the internal water tank is not properly installed
inside the cabinet.
2.When the internal water tank is full.Water tank must be
emptied and replaced back in the cabinet before normal
operating conditions can resume.
Water Tank Operation:
Proper installation of the water tank is crucial in
maintaining reliable dehumidifier operation.
The water tank holds accumulated condensed water
routed from the evaporator (cooling) coil during
dehumidifier operation.The water level inside the tank is
controlled by a float switch mechanism that automatically
stops dehumidifier operation when the water level
reaches a pre-determined level.
When the water tank is full and /or incorrectly positioned
inside the cabinet, the (water full) red light flashes and a
signal (beep) sounds for 10 seconds.This condition
results in the immediate shut down of the dehumidifying
system. (compressor cycle terminated, however the fan
motor will continue to operate) The water tank must be
emptied and/or correctly re-positioned before
dehumidifier operation can resume NOTE: It may take
several minutes before operating conditions resume.
This is normal.
IMPORTANT: Never tamper with or attempt to defeat the
float switch mechanism. (as this will result in flooding)
Factory Default Setting:
When the unit is first connected to a power supply, the
electronic circuit board will automatically default to the
following factory settings;
Mode: Dehumidification
Humidity SET AIR Value: 60%
Fan Speed: Low
Custom Default Setting:
When you modify any or all of the factory default settings , your
new settings become the current default settings. W
hen the unit
is switched "Off” or in the event of a power failure, all
your custom settings are retained and then restored once
the power is switched “On”/resumes.

Remote Control Features
The hand held remote unit allows you to control all
operational aspects of your dehumidifer from the
convenience of your favorite armchair. Here are
some things you should know about operating the
unit with the hand held remote.
Control Buttons
I/O: Power switch (On/Off).
MODE: Selects the required operating mode
(Dehumidifier Mode /Fan Mode).
:
Selects the fan speed settings (HIGH FAN / LOW FAN).
Each time the button is pressed will alternate
between HI FAN and LOW FAN speed.
Used to adjust (decrease) relative humidity
settings. Each time the button is pressed the
SET RH% value will decrease by 5%
(adjustable values between 80% ~ 35%) This
button can also be used to decrease the auto
timed (delay start / delayed stop) programs.
0.5 hr increments (from 0.5 hrs. ~ 10hrs.)
1.0 hr increments (from 10hrs. ~ 24hrs.)
Used to adjust (increase) relative humidity
settings. Each time the button is pressed the
SET RH% value will increase by 5%
(adjustable values between 35% ~ 80%) This
button can also be used to increase the auto
timed (delay start / delayed stop) programs.
0.5 hr increments (from 0.5 hrs. ~ 10hrs.)
1.0 hr increments (from 10hrs. ~ 24hrs.)
: Used to initiate a delayed start “on” time
and/or delayed stop “off” time.
F / C: Used to switch temperature readings (LED
readout display) from Celsius to Farenheight.
Each time button is pressed will alternate
between both temperature scales.
To operate the hand held remote control will require
two “AAA”(1.5 volt) Alkaline batteries (included ).
Batteries should be replaced when:
a) No signal (beep) is heard from the main unit
when pressing the buttons on the remote control
while attempting to program the main unit.
b) The main unit does not respond to the any of the
commands issued by the remote control unit.
Battery replacement:
1. Open the rear cover on the backside of the
remote control unit in the direction of the arrow.
Continue pulling (gently) until the cover separates
completely from the unit.
2. Replace the (2) batteries “AAA” (1.5 volts)
following the same orientation (polarity) as
depicted inside the battery chamber.(+/-)
3. Re-install lower cover.
4. If the remote control will not be used for extended
periods of time (vacations etc.), batteries should
be removed.
The remote operates within a range of 7 meters
(23 ft.) from the receiver located inside the main unit.
Any obstruction between the receiver and remote
may cause signal interference, limiting the ability to
program the main unit.
8

9
Location:
Select a suitable location, making sure you have easy
access to an electrical outlet. (avoid the use of
extension cords) If it is absolutely necessary to use an
extension cord, use an approved "air conditioner”
heavy duty extension cord only. (available at most local
hardware stores)
Select a suitable location making sure there are no
obstructions restricting airflow through the front air
intake grill. Maintain a minimum clearance of a least
20cm (8”) between adjacent walls and the back of the
unit to allow for proper air circulation and maximum
efficiency.
To obtain maximum operating efficiency from your
dehumidifier, the recommended (room ambient)
operating temperatures should be between 6ºC /
42.8ºF ~ 35ºC / 95ºF.
It is important to remember the efficiency of a
dehumidifier will be effected /influenced by the rate at
which new humid air (moisture) is allowed to infiltrate
the same space/area.To maintain efficiency, the
dehumidifier must be operated in an enclosed area.
Keep all doors and windows closed.
INSTALLATION

10
Operating Instructions:
Dehumidifying is a means of removing moisture from the
air.that will help to protect your home and valued
possessions from damage (swelling) caused by moisture
in the air. It also prevents mold and mildew from
accumulating in damp areas of the home. Essentially a
dehumidifier removes moisture from the air, as moist air
passes over a dehumidifying (evaporator cooling) coil.
Moisture is condensed on the evaporator coil, drained
and collected inside an internal (removable) water tank
located at the front of the unit.The exhausted air being
returned into the room environment is elevated several
degrees causing the surrounding air temperature to
increase (slightly).This process contributes to lowering
the relative humidity of the surrounding air.
Factory Default Setting:
When the unit is first connected to a power supply, the
electronic circuit board will automatically default to the
following factory settings.
Mode: Dehumidifier
Humidity Set Air Value:60% RH
Fan Speed: = Low
NOTE:In the event of a power failure or the unit is
switched ‘Off’, the most recent settings are retained and
restored once the power is switched “On”/resumed.
IMPORTANT NOTE: Depending on humidity conditions,
(when power is restored or switched ‘On’) the
dehumidifier may not start automatically under the factory
or custom (
see page 7 ) default setting .This is an
indication the RH% level of the surrounding environment
is lower than the current default setting and it may be
necessary to select a lower SET AIR (RH%) value.
DEHUMIDIFYING MODE SELECTION:
1. The unit does not have to be switched on
(operational) to select/set a program. All programs can be
selected with the unit in the “off” position
2. Press the MODE button and select dehumidifier mode
(a rain drop symbol will appear in the display). Each time
the button is pressed, the setting will alternate between
DRY (dehumidifier) mode and FAN (only) mode.
3. Press the “UP” or “DOWN” buttons to select the desired
SET AIR operating value. (between 35% ~ 80%) To
select CONTINUOUS dehumidifying mode, press the
DOWN button until the symbol “- -” appear in the SET
AIR display. NOTE: During CONTINUOUS mode
operation, the humidistat (control) will be by-passed and
the compressor will operate non-stop regardless of
humidity conditions.
FAN SPEED SELECTION:
4. Press the fan symbol on the keypad. Each time the
button is pressed, the mode selection will alternate
between "High Fan" and "Low Fan" speed options.The
fan speed you select will appear in the LED display;
either a 5 blade fan symbol for ‘high fan’ or a 3 blade fan
symbol for ‘low fan’ will be shown in the display area.
5.When all settings are complete, press the I/O button to
start dehumidifier operation and the blue operation light
will illuminate.
FAN MODE SLECTION:
1. The unit does not have to be switched on
(operational) to select/set a program. All programs can be
selected with the unit in the “off” position
2. Press the MODE.button and select fan mode (fan blade
symbol will show in display). Each time the button is
pressed, the setting will alternate between dehumidifier
mode and fan (only) mode.
3. Press the "Fan” symbol on the keypad. Each time the
button is pressed, the mode selection will alternate
between "High Fan" and "Low Fan" speed options.
4.When all settings are complete, press the on/off button
to start fan mode operation and the blue operation light
will illuminate.
AIR FILTER:
Your dehumidifier features a removable Air Filter.This
filter is located at the front of the unit (behind the front air
intake grill) The air filter plays an important role in helping
to reduce (minimize) dust/dirt particles from the
surrounding environment. A blocked/clogged air filter
reduces air flow impacting negatively on operating
efficiency.To maintain maximum operating efficiency;The
filter must
be checked and cleaned regularly. (every 2 weeks) More
frequent cleaning may be required depending upon
indoor air quality.
IMPORTANT: Never operate the unit without the air
filter in place.
AIR FILTER REMOVAL:
1. Locate the air filter (handle) tab on the upper right side
of the front air intake grill and slide-out the filter to
the right.
2. Clean the filter thoroughly using a vacuum cleaner or
wash using luke warm water and mild detergent.
Dry thoroughly before re-installing.
3. To re-install the air filter, slide the filter back inside
the tracks until it snaps (locks) into position.
Operating Instructions

11
Direct Drain Feature:
This dehumidifier is inclusive of a direct drain feature,
located at the lower (left) rear side of the cabinet. NOTE:
The drain hose is not included with the unit. Use a
standard garden hose with standard female connection.
This type of hose can be purchased at any local
hardware store.The direct drain feature is intended for
use in basements inclusive of a floor drain only.
NOTE: Do not attempt to operate the direct drain
feature using drain/stem pipes above ground level.
CONNECTING THE DIRECT DRAIN:
1. Unscrew the drain cap on the direct drain connection.
at the back of the unit.
2. Cut drain hose to required length. (to suit your needs)
Attach garden hose coupler directly onto the direct
drain and tighten.
3. Position the open end of the drain hose directly over
the floor drain and start the unit.
4. Position the dehumidifier as close as you can to the
floor drain.
5. When the direct drain feature is not being used,
remove the drain hose and re-install cap.
CAUTION: Before attempting to clean and/or service this
unit, always disconnect the power supply cord from the
electrical power supply/outlet.
1. DO NOT use gasoline, benzene, paint thinner, or any
other chemicals to clean this unit, as these substances
will damage/deform both plastic components and
luster finish.
2. Never attempt to clean the unit by pouring water
directly over any of the surface areas, as this will
cause deterioration of electrical components and
wiring insulation.
3. Use only a mild dishwashing detergent, lukewarm
water and a soft cloth to wipe the exterior surface of
the unit and dry throughly.
When the dehumidifier is not being used for long time
periods, please follow these instructions.
1. Disconnect the power cord from the power supply.
2. Empty the water tank and wipe (clean) thoroughly.
3. Clean air filter thoroughly
4. Re-package the unit in the original carton.
5. Store the unit upright in a dry location.
Care and Maintenance
Storage
Fig.3
(Rear View)
DIRECT DRAIN

Frequently, some problems are of a minor nature and a
service call may not be necessary. Use this
troubleshooting guide to identify possible problems you
may be experiencing. If the unit continues to operate
improperly, call your local Danby® Service Depot or 1-800-
26-DANBY
(1-800-263-2629) for assistance.
TROUBLE SHOOTING GUIDE
Check power cord connection.
Check electrical outlet for blown fuse.
Check if water tank is full (empty).
Check water tank is properly installed.
Air filter is dirty and/or blocked.
Ambient room temperature too low. (below 5C/41F)
Poor airflow circulation / obstruction of front grill.
Relative Humidity in surrounding environment very low.
Check all doors and windows are closed.
Area/room is too large for the capacity of the dehumidifier.
PROBLEM POSSIBLE CAUSE
Unit will not operate.
Dehumidifying capacity
(moisture removal) low.
Relative Humidity setting not
reached after long period of
operation.
12

LIMITED PRODUCT WARRANTY
This quality product is warranted to be free from manufacturer’s defects in material and workmanship, provided that the unit is used under normal operating
conditions intended by the manufacturer.
This warranty is available only to the person to whom the unit was originally sold by Danby or by an authorized distributor of Danby, and is non-transferable.
TERMS OF WARRANTY
Plastic parts (ie. evaporator door, door rails, covers and trays are warranted for thirty (30) days only from purchase date, with no extensions provided.
First Two Years During the first two years (2), any electrical part(s) of this product found to be defective, including any sealed system units, will be
repaired or replaced, at warrantor’s option, at no charge to the ORIGINAL purchaser. Consumable parts (ie. light bulbs when applicable)
are not warranted or guaranteed for any length of time.
Third Through During the next three years (3) any part of the sealed system found to be defective (consisting of compressor, condenser, evaporator,
Fifth Year dryer and all related tubing) will be replaced without charge, however, all labour charges associated with the replacement of the sealed
system componets will be the sole responisbilty of the purchaser. The purchaser shall pay for all labour and return freight during this
three year (3) period for repair or replacement of any sealed system components. Any unit being diagnosed as non-repairable due to
sealed system failure and warranting an exchange during the existing three (3) years will be subject to an appropriate depreciation or
user fee, including any and all freight charges being levied against the purchaser.
To obtain Service Danby reserves the right to limit boundaries of “In Home Service” due to the proximity of an Authorized Service Depot. Any appliance
requiring service outside the limited boundaries of “In Home Service”, it will be the customer’s responsibility to transport the appliance to
the closest Authorized Service Depot at their own expense. Contact your dealer from whom your unit was purchased, or contact your
nearest authorized Danby service depot, where service must be performed by a qualified service technician. If service is performed on
the units by anyone other than an authorized service depot, or the unit is used for commercial application, all obligations of Danby under
this warranty shall be at an end.
The following clause refers to Chest Freezers, (under 7.0 cu.ft.) single and double door refrigerators, supplied with or without a separate freezer section. Nothing
within this warranty shall imply that Danby will be responsible or liable for any spoilage or damage to food or other contents of this appliance, whether due to any
defect of the appliance, or its use, whether proper or improper. EXCLUSIONS
Save as herein provided, Danby Products Limited (Canada) or Danby Products Inc. (U.S.A.), there are no other warranties, conditions, representations or
guarantees, express or implied, made or intended by Danby Products or its authorized distributors and all other warranties, conditions, representations or
guarantees, including any warranties, conditions, representations or guarantees under any Sale of Goods Act or like legislation or statue is hereby expressly
excluded. Save as herein provided, Danby Products Limited (Canada) or Danby Products Inc. (U.S.A), shall not be responsible for any damages to persons or
property, including the unit itself, howsoever caused or any consequential damages arising from the malfunction of the unit and by the purchase of the unit, the
purchaser does hereby agree to indemnify and save harmless Danby Products Limited from any claim for damages to persons or property caused by the unit.
GENERAL PROVISIONS
No warranty or insurance herein contained or set out shall apply when damage or repair is caused by any of the following:
1) Power Failure.
2) Damage in transit or when moving the appliance.
3) Improper power supply such as low voltage, defective house wiring or inadequate fuses.
4) Accident, alteration, abuse or misuse of the appliance such as inadequate air circulation in the room or abnormal operating conditions,
(extremely high or low room temperature).
5) Use for commercial or industrial purposes.
6) Fire, water damage, theft, war, riot, hostility, acts of God such as hurricanes, floods etc.
7) Service calls resulting in customer education.
Proof of purchase date will be required for warranty claims; so, please retain bills of sale. In the event warranty service is required, present this document to our
AUTHORIZED SERVICE DEPOT.
Danby Products Limited
PO Box 1778, 5070 Whitelaw Road,
Guelph, Ontario, Canada N1H 6Z9
Telephone: [phone] FAX: [phone]
Danby Products Inc.
PO Box 669, 101 Bentley Court,
Findlay, Ohio, U.S.A. 45839-0669
Telephone: [phone] FAX: [phone]

Page
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Avertissement - Avis importants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Spécifications de l'appareil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Caractéristiques et pièces de l'appareil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fonctions des touches du tableau de commande électronique. . . . . . . . . . . . 19
Télécommande. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Choix de l'emplacement et instructions d'installation. . . . . . . . . . . . . . . . . . . . 22
Instructions d'utilisation / retrait du filtre . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Soins et entretien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Drainage direct . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Remisage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Guide de dépannage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Garantie . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
14
Table des matières

15
Introduction
Merci d’avoir choisi un appareil Danby qui vous fournira ainsi qu’à votre famille, le confort au foyer, à la
maison, au chalet ou au bureau. Ce manuel d’utilisation vous offre des renseignements pratiques pour le
soin et l’entretien de votre nouvel appareil. Un appareil DanbyMD bien entretenu vous fournira plusieurs
années de service sans ennui.
Veuillez prendre quelques moments pour lire attentivement toutes les directives pour vous renseigner et vous
familiariser avec tous les aspects du fonctionnement de votre appareil.
Cet appareil peut être aisément déplacé d’une pièce à l’autre de la maison et il est installé en quelques
minutes seulement. Pour la référence aisée, nous vous suggérons de joindre une copie de votre reçu de
caisse et/ou facture d’achat à cette page, et d’inscrire les renseignements suivants qui sont trouvés sur la
plaque d’identification du fabricant. Celle-ci est située sur la paroi arrière du compartiment du réservoir
d’eau.
Numéro de modèle: _______________________________________________
Numéro de série: _________________________________________________
Date d’achat : ____________________________________________________
Nom du marchand et adresse: _______________________________________
________________________________________
Ces renseignements seront requis si le service est demandé et/ou si vous désirez obtenir des
renseignements supplémentaires. Pour consulter un Représentant du service à la clientèle, composez le
NUMÉRO D’APPEL SANS FRAIS suivant :
1-800-26-DANBY (1-800-263-2629)
Conservez ces directives pour la référence future.
Ce symbole représente une mise en garde ou un avertissement
MISE EN GARDE
Ne jamais laisser cet appareil en marche dans un endroit
fermé où des personnes ou animaux qui ne peuvent pas
réagir à une défectuosité de l’appareil se trouvent. Un
appareil en panne peut occasionner la surchauffe
extrême de cet appareil et causer des blessures
corporelles ou des dommages à la propriété.

16
NOTE : Les instructions de sécurité et AVERTISSEMENTS présentés dans ce manuel ne couvrent pas
toutes les conditions possibles et situations qui pourraient se produire. Tous et chacun doivent comprendre
que le bon sens et la prudence sont des facteurs qui ne peuvent être incorporés dans l’appareil lui-même.
Ceux-ci relèvent uniquement du comportement de la personne qui installe ou utilise l’appareil, ou qui en fait
l’entretien.
Le défaut d’observer les directives de l’installation, de l'utilisation ou de l'entretien de l’appareil fournies par
le fabricant pourrait causer des blessures corporelles et/ou des dommages matériels. L’utilisateur devrait
communiquer avec le détaillant ou un agent de service d’après-vente du fabricant au sujet de tout problème
ou situation qui n’est pas parfaitement compris. (Pour le Service à la Clientèle Danby, composez le 1-800-
26-DANBY / (1-800-263-2629)
AVERTISSEMENT – AVIS IMPORTANTS
POUR LA SÉCURITÉ DES UTILISATEURS – Pour minimiser tout risque d’incendie ou d’explosion, ne
jamais remiser d’essence ou autres produits liquides ou gazeux inflammables à proximité de cet appareil
ou de tout autre appareil ménager.
CIRCUIT ÉLECTRIQUE – Pour réduire le risque d’incendie, de choc électrique ou de dommages corporels,
on doit s’assurer que tout câblage électrique et circuit de mise à la terre soient conformes aux codes
national et local de l’électricité. C’est à l’acquéreur qu’incombe la responsabilité de consulter
éventuellement un électricien qualifié qui pourra inspecter le câblage et les fusibles de la résidence et
déterminer si la source d’électricité disponible est adéquate pour l’alimentation de l’appareil. Cet appareil
est conçu pour être alimenté par un circuit 120 volts CA, 60 Hz (circuit indépendant à 3 conducteurs,
alimentant une prise de courant convenablement polarisée et mise à la terre) protégé par un fusible de 15
ampères (ou disjoncteur ou fusible temporisé équivalent).
La fiche de branchement à trois broches du cordon d’alimentation doit être branchée directement sur une
prise de courant polarisée de même configuration et mise à la terre, conçue pour les circuits 110/120 V CA.
INSTRUCTIONS DE MISE À LATERRE – La mise à la terre incorrecte de cet appareil peut susciter un
risque de choc électrique. En cas de doute quant à la qualité de la mise à la terre de la prise de courant
disponible, consulter un électricien qualifié.
Cet appareil doit être mis à la terre. Advenant une anomalie de fonctionnement ou une panne, la mise à la
terre réduira le risque de choc électrique, grâce à une voie de moindre résistance disponible pour le
passage du courant électrique. Cet appareil est équipé d’un cordon d’alimentation comportant un
conducteur de mise à la terre et une fiche de branchement à trois broches (pour mise à la terre). La fiche
de branchement doit être branchée sur une prise de courant convenablement installée et mise à la terre
conformément aux prescriptions des codes et règlements locaux en vigueur.
Ne jamais modifier la fiche de branchement de l’appareil. Si la configuration de la fiche de branchement ne
permet pas son branchement sur la prise de courant, il sera nécessaire de faire installer une prise de
courant adéquate par un électricien qualifié.
Si les caractéristiques de la source d’alimentation électrique de la résidence ne correspondent pas aux
spécifications ci-dessus, ou en cas d’incertitude quant à la qualité de la mise à la terre, demander à un
électricien qualifié ou à la compagnie de distribution d’électricité d’inspecter l’installation électrique et
d’effectuer tout travail correctif nécessaire.

Capacité de déshumidification (Pintes/Litres) 60 / 28,4
Alimentation électrique 115 Volts / 60 Hz
Consommation d’énergie (watts) 785
Intensité nominale
• Déshumidification 7.26
• Chauffage Non applicable
Circulation d’air – Vitesse de ventilateur haute / basse (pi. cu. /min)(L/min) 183 / 160
Type de réfrigérant R22
Capacité du réservoir d’eau (litres / pintes) 5,3 / 11,2
Niveau de bruit en fonctionnement (dB A) 50
Dimensions (largeur/hauteur/profondeur) 13-3/4 po x 30-1/2 po x 13-3/16 po
Poids net (kg/lb) 25 / 55,1
Circuit d’alimentation électrique - Spécifications
1.Tout câblage doit être réalisé par un électricien
qualifié, en conformité avec les prescriptions des\
codes national et local régissant les installations
électriques. Pour toute question au sujet des instru
tions qui suivent, contacter un électricien qualifié.
2. AVANT l’installation et AVANT l’utilisation de cet
appareil, contrôler les caractéristiques de la source
d’électricité, et résoudre tout problème affectant le
câblage.
3. Pour la sécurité et la protection des utilisateurs, cet
appareil est mis à la terre lorsqu’il est branché sur une
prise de courant de même configuration que la fiche
de branchement. En cas de doute quant à la qualité
de la mise à la terre de la prise de courant, consulter
un électricien qualifié. NE JAMAIS UTILISER UN
CÂBLE DE RALLONGE NI UN ADAPTATEUR SI LA
CONFIGURATION DE LA FICHE DE
BRANCHEMENT NE CORRESPOND PAS À
CELLE DE LA PRISE DE COURANT.
4. La plaque signalétique de l’appareil est située sur la
paroi (arrière) du cabinet. On y trouve les
caractéristiques électriques et techniques spécifiques
de cet appareil.
5. Pour éviter les risques de blessures corporelles, on
doit toujours débrancher l’appareil de la source
d’électricité avant d’entreprendre des travaux de
nettoyage ou d’entretien.
17
NOTE: Les spécifications sont sujettes aux changements sans préavis (pour l'amélioration des produits).
Spécifications de l’appareil: DDR600R

18
• Clavier de commande tactile (électronique) (illuminé)
• Affichage à diodes (LED)
• Auto-détection de l’humidité relative ambiante
• Réglage selon l’humidité relative ambiante (35% - 80%
constante).
• Ventilateur à 2 vitesses (haute/basse)
• Protection de mise en marche temporisée - (compresseur)
• Auto-dégivrage
• Fonctionnement à basse température
• Homologué Energy Star
• Afficheur « réservoir d’eau plein » et signal sonore
• Roulettes pivotantes « Easy Roll » (4)
• Réservoir d’eau monté à l’avant (amovible)
• Option de drainage direct (boyau non compris)
• Style européen
• Fonctionnement silencieux
• Filtre à air amovible
CARACTÉRISTIQUES
Tableau de commande
Entrée d’air
Panneau de
façade
Panneau
latéral
Poignée
Pièces de l’appareil
Réservoir
d’eau avant
Roulettes pivotantes
Easy Roll

Touche I/O :
À chaque fois que cette commande est pressée,
l’appareil
se met en marche ou s’éteint.
Touche Ventilateur :
À chaque fois que cette commande est pressée, la
vitesse du ventilateur alternera entre haute et basse.
Touche Minutrie :
Utilisée pour amorcer une mise en service
temporisée et/ou une mise hors de service
temporisée. À chaque fois que cette commande est
pressée l’heure temporisée de la mise en service
et/ou mise hors de service peut être réglée (entre 0,5
heure et 24 heures) comme suit :
En incréments de 0,5 heure (de 0,5 heure à 10
heures)
En incréments de 1 heure (de 10 heures à 24 heures)
Cette touche vous permet de réduire les réglages
d’humidité relative. Avec chaque pression sur la touche,
la valeur SET RH% réduira par 5% (les valeurs réglables
sont entre 80% et 35%).
Cette touche peut aussi être utilisée pour réduire l’heure
de la mise en service et ou hors de service des
programmes temporisés.
Cette touche vous permet d’augmenter les réglages
d’humidité relative. Avec chaque pression sur la touche,
la valeur SET RH% augmentera par 5% (les valeurs
réglables sont entre 80% et 35%). Cette touche peut
aussi être utilisée pour augmenter l’heure de la mise en
service et ou hors de service des programmes
temporisés.
Touche Mode : À chaque fois que cette commande
est pressée, le mode de fonctionnement alternera
entre déshumidificateur et ventilateur. Le symbole
pour la mode choisi apparaîtra sur l’écran d’affichage
à diodes.
AFFICHAGE À DIODES : L’écran d’affichage indique
l’information suivante :
1. ROOM AIR = Conditions actuelles ambiantes du %
d’humidité relative de la pièce.
2. SET AIR = La valeur de fonctionnement réglée du %
d’humidité relative.
3. MODE = Le mode de fonctionnement choisi.
4. FAN SPEED = La vitesse du ventilateur choisie.
5.TIMER = L’heure choisie de la mise en service / hors
de service temporisée.
19
Fonctions des touches du tableau de commande électronique :
12 5
34
I/O
