Silicon Laboratories C8051F41 Series User manual

Rev. 0.2 9/06 Copyright © 2006 by Silicon Laboratories C8051F41x-DK
C8051F41x-DK
C8051F41XDEVELOPMENT KIT USER’SGUIDE
1. Kit Contents
The C8051F41x Development Kit contains the following items:
• C8051F410 Target Board
• C8051Fxxx Development Kit Quick-Start Guide
• Silicon Laboratories IDE and Product Information CD-ROM. CD content includes:
• Silicon Laboratories Integrated Development Environment (IDE)
• Keil 8051 Development Tools (macro assembler, linker, evaluation C compiler)
• Source code examples and register definition files
• Documentation
• C8051F41x Development Kit User’s Guide (this document)
• AC to DC Power Adapter
• USB Debug Adapter (USB to Debug Interface)
• USB Cable
2. Hardware Setup using a USB Debug Adapter
The target board is connected to a PC running the Silicon Laboratories IDE via the USB Debug Adapter as shown
in Figure 1.
1. Connect the USB Debug Adapter to the DEBUG connector on the target board with the 10-pin ribbon cable.
2. Connect one end of the USB cable to the USB connector on the USB Debug Adapter.
3. Connect the other end of the USB cable to a USB Port on the PC.
4. Connect the ac/dc power adapter to power jack P1 on the target board.
Notes:
•UsetheReset button in the IDE to reset the target when connected using a USB Debug Adapter.
• Remove power from the target board and the USB Debug Adapter before connecting or disconnecting the
ribbon cable from the target board. Connecting or disconnecting the cable when the devices have power can
damage the device and/or the USB Debug Adapter.
Figure 1. Hardware Setup using a USB Debug Adapter
PC
USB
Cable
USB Debug Adapter
AC/DC
Adapter
Target Board
SILICON LABORATORIES
PWR
P1.6
P3.7RESET
Port 4Port 3Port 1
Port 2 Port 0
MCU
Silicon Laboratories
USB DEBUG ADAPTER
Run
StopPower
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
2 Rev. 0.2
3. Software Setup
The included CD-ROM contains the Silicon Laboratories Integrated Development Environment (IDE), Keil software
8051 tools and additional documentation. Insert the CD-ROM into your PC’s CD-ROM drive. An installer will
automatically launch, allowing you to install the IDE software or read documentation by clicking buttons on the
Installation Panel. If the installer does not automatically start when you insert the CD-ROM, run autorun.exe found
in the root directory of the CD-ROM. Refer to the readme.txt file on the CD-ROM for the latest information
regarding known IDE problems and restrictions.
4. Silicon Laboratories Integrated Development Environment
The Silicon Laboratories IDE integrates a source-code editor, source-level debugger and in-system Flash
programmer. The use of third-party compilers and assemblers is also supported. This development kit includes the
Keil Software A51 macro assembler, BL51 linker and evaluation version C51 C compiler. These tools can be used
from within the Silicon Laboratories IDE.
4.1. System Requirements
The Silicon Laboratories IDE requirements:
• Pentium-class host PC running Microsoft Windows 98SE or later.
• One available COM or USB port.
• 64 MB RAM and 40 MB free HD space recommended.
4.2. Assembler and Linker
A full-version Keil A51 macro assembler and BL51 banking linker are included with the development kit and are
installed during IDE installation. The complete assembler and linker reference manual can be found under the Help
menu in the IDE or in the “SiLabs\MCU\hlp” directory (A51.pdf).
4.3. Evaluation C51 C Compiler
An evaluation version of the Keil C51 C compiler is included with the development kit and is installed during IDE
installation. The evaluation version of the C51 compiler is the same as the full professional version except code
size is limited to 4 kB and the floating point library is not included. The C51 compiler reference manual can be
found under the Help menu in the IDE or in the “SiLabs\MCU\hlp” directory (C51.pdf).
4.4. Using the Keil Software 8051 Tools with the Silicon Laboratories IDE
To perform source-level debugging with the IDE, you must configure the Keil 8051 tools to generate an absolute
object file in the OMF-51 format with object extensions and debug records enabled. You may build the OMF-51
absolute object file by calling the Keil 8051 tools at the command line (e.g. batch file or make file) or by using the
project manager built into the IDE. The default configuration when using the Silicon Laboratories IDE project
manager enables object extension and debug record generation.
Refer to Applications Note AN104 - Integrating
Keil 8051 Tools Into the Silicon Labs IDE
in the “SiLabs\MCU\Documentation\Appnotes” directory on the CD-
ROM for additional information on using the Keil 8051 tools with the Silicon Laboratories IDE.
To build an absolute object file using the Silicon Laboratories IDE project manager, you must first create a project.
A project consists of a set of files, IDE configuration, debug views, and a target build configuration (list of files and
tool configurations used as input to the assembler, compiler, and linker when building an output object file).
The following sections illustrate the steps necessary to manually create a project with one or more source files,
build a program and download the program to the target in preparation for debugging. (The IDE will automatically
create a single-file project using the currently open and active source file if you select Build/Make Project before a
project is defined.)
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 3
4.4.1. Creating a New Project
1. Select Project→New Project to open a new project and reset all configuration settings to default.
2. Select File→New File to open an editor window. Create your source file(s) and save the file(s) with a rec-
ognized extension, such as .c, .h, or .asm, to enable color syntax highlighting.
3. Right-click on “New Project” in the Project Window. Select Add files to project. Select files in the file
browser and click Open. Continue adding files until all project files have been added.
4. For each of the files in the Project Window that you want assembled, compiled and linked into the target
build, right-click on the file name and select
Add file to build . Each file will be assembled or compiled as
appropriate (based on file extension) and linked into the build of the absolute object file.
Note: If a project contains a large number of files, the “Group” feature of the IDE can be used to organize.
Right-click on “New Project” in the
Project Window . Select Add Groups to project . Add pre-defined
groups or add customized groups. Right-click on the group name and choose
Add file to group . Select files
to be added. Continue adding files until all project files have been added.
4.4.2. Building and Downloading the Program for Debugging
1. Once all source files have been added to the target build, build the project by clicking on the Build/Make
Project button in the toolbar or selecting Project→Build/Make Project from the menu.
Note: After the project has been built the first time, the Build/Make Project command will only build the
files that have been changed since the previous build. To rebuild all files and project dependencies, click
on the Rebuild All button in the toolbar or select Project→Rebuild All from the menu.
2. Before connecting to the target device, several connection options may need to be set. Open the
Connection Options window by selecting Options → Connection Options... in the IDE menu. First, select
the appropriate adapter in the “Serial Adapter” section. Next, the correct “Debug Interface” must be selected.
C8051F41x family devices use the Silicon Laboratories 2-wire (C2) debug interface. Once all the selections
are made, click the OK button to close the window.
3. Click the
Connect button in the toolbar or select Debug → Connect from the menu to connect to the device.
4. Download the project to the target by clicking the Download Code button in the toolbar.
Note: To enable automatic downloading if the program build is successful select Enable automatic con-
nect/download after build in the Project→Target Build Configuration dialog. If errors occur during the
build process, the IDE will not attempt the download.
5. Save the project when finished with the debug session to preserve the current target build configuration,
editor settings and the location of all open debug views. To save the project, select Project→Save Project
As... from the menu. Create a new name for the project and click on Save.
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
4 Rev. 0.2
5. Example Source Code
Example source code and register definition files are provided in the “SiLabs\MCU\Examples\C8051F41x”
directory during IDE installation. These files may be used as a template for code development. Example
applications include a blinking LED example which configures the green LED on the target board to blink at a fixed
rate.
5.1. Register Definition Files
Register definition files C8051F410.inc and C8051F410.h define all SFR registers and bit-addressable control/
status bits. They are installed into the “SiLabs\MCU\Examples\C8051F41x” directory during IDE installation. The
register and bit names are identical to those used in the C8051F41x data sheet. Both register definition files are
also installed in the default search path used by the Keil Software 8051 tools. Therefore, when using the Keil 8051
tools included with the development kit (A51, C51), it is not necessary to copy a register definition file to each
project’s file directory.
5.2. Blinking LED Example
The example source files blink.asm and blinky.c show examples of several basic C8051F41x functions. These
include; disabling the watchdog timer (WDT), configuring the Port I/O crossbar, configuring a timer for an interrupt
routine, initializing the system clock, and configuring a GPIO port. When compiled/assembled and linked this
program flashes the green LED on the C8051F410 target board about five times a second using the interrupt
handler with a C8051F410 timer.
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 5
6. Target Board
The C8051F41x Development Kit includes a target board with a C8051F410 device pre-installed for evaluation and
preliminary software development. Numerous input/output (I/O) connections are provided to facilitate prototyping
using the target board. Refer to Figure 2 for the locations of the various I/O connectors.
P1 Power connector (accepts input from 7 to 15 VDC unregulated power adapter)
J1 22-pin Expansion I/O connector
J3 Port I/O Configuration Jumper Block
J4 DEBUG connector for Debug Adapter interface
J5 DB-9 connector for UART0 RS232 interface
J6 Analog I/O terminal block
J7 Connector for IDAC0 voltage circuit
J8 USB Debug Adapter target board power connector
J9, J10 External crystal enable connectors
J11 Connector for IDAC1 voltage circuit
J12 Connector block for Thermistor circuitry
J13, J14 ADC external voltage reference connectors
Figure 2. C8051F410 Target Board
DEBUG
P1
J5
Prototype Area
J11
C8051
F410
P1.4 P1.5
RESET
P2.3
P2.1
J33
R21
J4
J10
J19
J9
R23
J26
J24
J23
D1
D2
J21
J32
J12
J17
J30
BH1
J15
J25
J15
J25
D12
J6
J16
J1 J3
J27
J18
J29
J2
J7
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
6 Rev. 0.2
6.1. System Clock Sources
The C8051F410 device installed on the target board features a calibrated programmable internal oscillator which is
enabled as the system clock source on reset. After reset, the internal oscillator operates at a frequency of
191.4 kHz (±2%) by default but may be configured by software to operate at other frequencies. Therefore, in many
applications an external oscillator is not required. However, if you wish to operate the C8051F410 device at a
frequency not available with the internal oscillator, an external crystal may be used. Refer to the C8051F41x data
sheet for more information on configuring the system clock source.
The target board is designed to facilitate the installation of an external crystal. Remove shorting blocks at headers
J9 and J18 and install the crystal at the pads marked Y2. Install a 10 MΩresistor at R4 and install capacitors at
C44 and C43 using values appropriate for the crystal you select. Refer to the C8051F41x data sheet for more
information on the use of external oscillators. The target board also has a 32.768 kHz watch crystal installed to
provide a timebase for the smaRTClock. Jumper J26 may be used to short the XTAL3 and XTAL4 pins if internal
clock mode is desired.
6.2. Power Options
The C8051F41x Target Board has many power options. This allows the user to exercise the different operating
modes of the C8051F410. The board has 2 voltage regulators. A 3.3 V LDO and a 1.2–5.25 V variable regulator.
To use the 3.3 V regulator, pin 2–3 of J9 should be shorted and a jumper installed in J10.
To use the variable regulator, pin 1–2 of J19 should be shorted and an output voltage should be selected using J21.
After selecting the appropriate voltage, pin 1–2 of J21 should be shorted to enable the output of the variable
regulator. If the voltage "VAR" is selected, the potentiometer R23 should be adjusted until the desired voltage is
reached. The input to the variable regulator can be obtained from the unregulated 9 V supply or from the 5 V USB
VBUS supply available when using a USB debug adapter.
Note: Before enabling either voltage regulator, the user should check the 4 supply rail selection headers
(J29+J30, J17, J12, J31+32) to ensure the correct voltage is being routed to the correct power pin. An
incorrect jumper setting may permanently damage the board. Note that VDD cannot exceed 2.5 V and is
typically derived from the on-chip regulator. Do not connect the 5.25 or 3.3 V output directly to VDD.
The three power LEDs for VIO, VREG, and VDD indicate if the appropriate supply rail is connected to a power
supply. Check to make sure all supply rails (with exception of VREG if not using the on-chip regulator) are
powered.
For the VIO voltage rail, the user may choose from the 3 V regulator (+3 VD), the variable regulator, or the on-chip
regulator. The selections are marked on the target board silkscreen.
For the VREG on-chip voltage regulator input, the user may choose from the 3 V regulator (+3VD), the 5 V USB
VBUS source obtained from the USB debug adapter (5VEC3), or from the variable regulator (VREG). The
selections are marked on the target board silkscreen.
For VDD, the user may choose the output of the on-chip regulator (VDD_) or the output of the variable regulator
(VREG).
6.3. Switches and LEDs
Three switches are provided on the target board. Switch SW1 is connected to the RESET pin of the C8051F410.
Pressing SW1 puts the device into its hardware-reset state. Switch SW2 and SW3 are connected to the
C8051F410’s general purpose I/O (GPIO) pins through headers. Pressing SW2 or SW3 generates a logic low
signal on the port pin. Remove the shorting block from the jumper J5 to disconnect SW2 and/or SW3 from their
associated port pins. The port pin signals are also routed to pins on the J11 I/O connector. See Table 1 for the port
pins and headers corresponding to each switch.
Three LEDs are also provided on the target board. The red LED labeled PWR is used to indicate a power
connection to the target board. The green LEDs labeled with port pin names are connected to the C8051F410’s
GPIO pins through headers. Remove the shorting blocks from the headers to disconnect the LEDs from the port
pins. The port pin signals are also routed to pins on the J1 I/O connector. See Table 1 for the port pins and headers
corresponding to each LED.
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 7
6.4. Expansion I/O Connector (J1)
The 24-pin Expansion I/O connector J11 provides access to all signal pins of the C8051F410 device. A small
through-hole prototyping area is also provided. All I/O signals routed to connector J1 are also routed to through-
hole connection points between J11 and the prototyping area (see Figure 2 on page 5). Each connection point is
labeled indicating the signal available at the connection point. See Table 2 for a list of pin descriptions for J1.
Table 1. Target Board I/O Descriptions
Description I/O Jumper
SW1 Reset none
SW2 P1.4 J5[3–4]
SW3 P1.5 J5[7–8]
Green LED D3 P2.1 J5[1–2]
Green LED D5 P2.3 J5[5–6]
Red LED D1 VREGIN J24
Red LED D2 VDD J23
Red LED D12 VIO J33
Table 2. J1 Pin Descriptions
Pin # Description Pin # Description
1 P0.0 13 P1.4
2 P0.1 14 P1.5
3 P0.2 15 P1.6
4 P0.3 16 P1.7
5 P0.4 17 P2.0
6 P0.5 18 P2.1
7 P0.6 19 P2.2
8 P0.7 20 P2.3
9P1.0 21
P2.4
10 P1.1 22 P2.5
11 P1.2 23 P2.6
12 P1.3 24 P2.7
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
8 Rev. 0.2
6.5. Target Board DEBUG Interface (J4)
The DEBUG connector (J4) provides access to the DEBUG (C2) pins of the C8051F410. It is used to connect the
Serial Adapter or the USB Debug Adapter to the target board for in-circuit debugging and Flash programming.
Table 3 shows the
DEBUG pin definitions.
6.6. Serial Interface (J5)
A RS232 transceiver circuit and DB-9 (J5) connector are provided on the target board to facilitate serial
connections to UART0 of the C8051F410. The TX, RX, RTS and CTS signals of UART0 may be connected to the
DB-9 connector and transceiver by installing shorting blocks on header J3.
J27[1–2] - Install shorting block to connect UART0 TX (P0.4) to transceiver.
J27[3–4] - Install shorting block to connect UART0 RX (P0.5) to transceiver.
J27[5–6] - Install shorting block to connect UART0 RTS (P1.4) to transceiver.
J27[7–8] - Install shorting block to connect UART0 CTS (P1.5) to transceiver.
6.7. Analog I/O (J6)
Many of the C8051F410 target device’s port pins are connected to the J2 terminal block. Connections for VDDA,
AGND, ADC external voltage references, IDAC outputs and ADC inputs are available. Refer to Table 4 for the J6
terminal block connections.
Table 3. DEBUG Connector Pin Descriptions
Pin # Description
1 +3VD(+3.3VDC)
2, 3, 9 GND (Ground)
4C2D
5/RST(Reset)
6P3.0
7C2CK
8 Not Connected
10 USB Power
Table 4. J6 Terminal Block Pin Descriptions
Pin # Description
1 P0.0/IDAC0
2 P0.1/IDAC1
3VREFIN
4GND
5AIN0
6AIN1
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 9
6.8. IDAC Connectors (J7, J11)
The C8051F410 target board also features two Current-to-Voltage 750 Ωload resistors that may be connected to
the 2-bit current-mode Digital-to-Analog Converters (IDACs) on port pins P1.0 and P1.1. Install a shorting block on
J13 to connect the IDAC0/P1.0 pin of the target device to a load resistor. Install a second shorting block on J14 to
connect the IDAC1/P1.1 pin of the target device to a load resistor. The IDAC signals are then routed to the J1 and
J13 and J14 connectors.
6.9. USB Debug Adapter Target Board Power Connector (J8)
The USB Debug Adapter includes a connection to provide power to the target board. This connection is routed
from J4[10] to J8[1]. Place a shorting block at header J8[2–3] to power the board directly from an ac/dc power
adapter. Place a shorting block at header J8[1-2] to power the board from the USB Debug Adapter. The second
option is not supported with either the EC1 or EC2 Serial Adapters.
6.10. smaRTClock (Real Time Clock)
The C8051F41x Target Board is designed for developing system using the on-chip smaRTClock. A 32 kHz watch
crystal is installed in Y1 and a battery holder (BH1) is installed for use as a backup power source. To connect the
battery to the VBAT input on the MCU, connect pin 1 and 2 of J30 and short J29. The variable voltage regulator
with potentiometer (R23) may also be used to generate the battery voltage and simulate a battery in its various
charge conditions. See the C8051F41x data sheet for more details about the smaRTClock.
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
10 Rev. 0.2
7. Schematics
Figure 3. C8051F410 Target Board Schematic (Page 1 of 3)
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 11
Figure 4. C8051F410 Target Board Schematic (Page 2 of 3)
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
12 Rev. 0.2
Figure 5. C8051F410 Target Board Schematic (Page 3 of 3)
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
Rev. 0.2 13
DOCUMENT CHANGE LIST
Revision 0.2 to Revision 0.3
Removed Section 9. USB Debug Adapter. See USB Debug Adapter User's Guide.
Downloaded from Elcodis.com electronic components distributor

C8051F41x-DK
14 Rev. 0.2
CONTACT INFORMATION
Silicon Laboratories Inc.
4635 Boston Lane
Austin, TX 78735
Tel: 1+[phone]
Fax: 1+[phone]
Toll Free: 1+[phone]
Email: [email protected]
Internet: www.silabs.com
Silicon Laboratories and Silicon Labs are trademarks of Silicon Laboratories Inc.
Other products or brandnames mentioned herein are trademarks or registered trademarks of their respective holders.
The information in this document is believed to be accurate in all respects at the time of publication but is subject to change without notice.
Silicon Laboratories assumes no responsibility for errors and omissions, and disclaims responsibility for any consequences resulting from
the use of information included herein. Additionally, Silicon Laboratories assumes no responsibility for the functioning of undescribed features
or parameters. Silicon Laboratories reserves the right to make changes without further notice. Silicon Laboratories makes no warranty, rep-
resentation or guarantee regarding the suitability of its products for any particular purpose, nor does Silicon Laboratories assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation conse-
quential or incidental damages. Silicon Laboratories products are not designed, intended, or authorized for use in applications intended to
support or sustain life, or for any other application in which the failure of the Silicon Laboratories product could create a situation where per-
sonal injury or death may occur. Should Buyer purchase or use Silicon Laboratories products for any such unintended or unauthorized ap-
plication, Buyer shall indemnify and hold Silicon Laboratories harmless against all claims and damages.
Downloaded from Elcodis.com electronic components distributor
