Silvercrest SBTF 10 C3 User manual

IAN 279754
Bluetooth®HANDS-FREE KIT SBTF 10 C3
HÅNDFRIT Bluetooth®-
SÆT
Betjeningsvejledning
Bluetooth®- FREISPRECH-
EINRICHTUNG
Bedienungsanleitung
Bluetooth®
HANDS-FREE KIT
Operating instructions
KIT MAINS-LIBRES
Bluetooth®
Mode d’emploi
Bluetooth®-
HANDSFREESET
Gebruiksaanwijzing

GB/IE/NI Operating instructions Page 1
DK Betjeningsvejledning Side 21
FR/BE Mode d’emploi Page 41
NL/BE Gebruiksaanwijzing Pagina 63
DE/AT/CH Bedienungsanleitung Seite 85
Before reading, unfold the page containing the illustrations and
familiarise yourself with all functions of the device.
Før du læser, vend siden med billeder frem og bliv bekendt med
alle apparatets funktioner.
Avant de lire le mode d’emploi, ouvrez la page contenant les
illustrations et familiarisez-vous ensuite avec toutes les fonctions de
l’appareil.
Vouw vóór het lezen de pagina met de afbeeldingen open en
maak u vertrouwd met alle functies van het apparaat.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus
und machen Sie sich anschließend mit allen Funktionen des
Gerätes vertraut.

SBTF 10 C3 GB│IE│NI │ 1 ■
Content
Correct Usage................................. 2
Safety instructions .............................. 3
Introduction, trademark rights ..................... 5
Package contents (see fold-out page)............... 6
Technical data................................. 6
Controls (see fold-out page) ...................... 7
Installing the hands-free appliance in a vehicle ....... 7
Switching the hands-free appliance on and off ....... 8
Coupling the hands-free appliance with a mobile
telephone .................................... 8
Multipoint function ............................10
Pairing the hands-free kit with an additional mobile
phone ......................................10
Separating the connection ......................11
Using the hands-free appliance ..................11
Resetting the hands-free kit ......................14
Charging 5 V Devices..........................14
Troubleshooting...............................15
Cleaning and Care ............................16
Storage when not in use ........................16
Disposal ....................................17
Notes on the EU Declaration of Conformity .........17
Kompernass Handels GmbH warranty.............18
Service .....................................20
Importer ....................................20

SBTF 10 C3
■ 2 │ GB│IE│NI
Congratulations on the purchase of your new appliance.
You have clearly decided in favour of a quality product.
These operating instructions are a part of this product.
They contain important information in regard to safety, use
and disposal. Before using the product, familiarise your-
self with all of these operating and safety instructions. Use
the product only as described and only for the specified
areas of application. In addition, pass these documents
on, together with the product, to any future owner.
Correct Usage
The Bluetooth®hands-free device SBTF 10 C3 is an
information technology device intended for use in vehicles
supplying an on-board voltage of 12–24 V. The device is
designed to create an open voice connection with a mobile
phone via a Bluetooth®connection, in order to allow
the user to make telephone calls while travelling by car,
without having to hold the mobile phone to his or her ear.
The handsfree phone system uses both Bluetooth®radio
technology aswell as a digital signal processor (DSP) to
carry out telephone functions. In addition, mobile devices
with an operating voltage of 5V (MP3 players, cell
phones, etc.) can be charged via the USB port*.
This device may be used ONLY for private domestic pur-
poses, not for industrial or commercial applications. This
product is not intended for use in activities concerned with
medicinal, lifesaving or life sustaining applications. All of
the additional connecting cables and external devices used
MUST match the safety-related, electromagnetic compata-
bility and shielding quality standards of the device at hand.
This appliance is not intended for any other use or for uses
beyond those mentioned. Claims of any kind for damage
resulting from unintended use will not be excepted. The
operator alone bears liability.
*USB®is a registered trademark of USB Implementers
Forum, Inc.

SBTF 10 C3 GB│IE│NI │ 3 ■
Safety instructions
Symbol definitions:
Danger!
A warning notice at this hazard level indicates a
potentially hazardous situation.
Failure to avoid this hazardous situation could result
in severe injuries and even death.
ƔFollow the instructions in this warning notice to
prevent injury.
Caution!
A warning notice at this hazard level indicates a
potential for property damage.
Failure to avoid this hazardous situation could result
in property damage.
ƔFollow the instructions in this warning notice to pre-
vent property damage.
Note:
ƔA note provides additional information that will assist
you in using the appliance.
Danger! Traffic safety has priority!
ƔComply with all local laws. When driving, your hands
must ALWAYS be free to operate the vehicle safely.
Traffic safety must ALWAYS take priority whilst driving.
ƔOnly manipulate the hands-free appliance on those
occasions in which the traffic situation permits it and in
which you will not endanger, injure, obstruct or cause
annoyance to other road users. Therefore you should
only operate the hands-free set in a stationary vehicle.
ƔDo not permit your concentration on the road traffic to
be compromised by the manipulation and displays of
the handsfree appliance!
ƔBecome familiar with the operation of it before driving
off and practice the safe operation of the facility!

SBTF 10 C3
■ 4 │ GB│IE│NI
ƔInstall the hands-free appliance in the vehicle such that
your view is not obstructed and that the appliance is
not located in an impact zone in the passenger com-
partment or in the inflation area of airbags. Read the
instruction manual of the vehicle manufacturer.
General safety instructions
ƔDo not attempt to open or repair the appliance. Should
you do so, appliance safety can no longer be assured
and the warranty becomes void.
ƔHave the defective device repaired by customer ser-
vice or an authorised specialist only. No liability will
be accepted for damage caused by misuse, improper
handling, use of force or unauthorized modification.
ƔNever subject the device to moisture, extreme tempera-
tures (greater than +70°C) or extreme vibrations.
ƔThis device is not intended for use by persons (including
children) with restricted physical, sensory or mental abili-
ties or lack of experience and/or knowledge unless, of
course, they are supervised by a person responsible for
their safety or obtain from that person instructions on
how the device should be used.
Danger!
ƔThe packaging material is not a toy. Keep plastic sheeting,
bags and all other packaging material away from
children. There is a risk of suffocation.
ƔChildren should be supervised to ensure that they do
not play with the device.
Attention
ƔDisconnect the device from the cigarette lighter socket
immediately if you notice any unusual sounds or smoke.
Caution! Pairing with a mobile phone
ƔIf you wish to pair the device with a mobile phone,
read its operating instructions to obtain detailed safety
instructions relating to the mobile phone. Only pair
compatible products.

SBTF 10 C3 GB│IE│NI │ 5 ■
Caution! High frequency signals in
vehicles
HF signals can, under circumstances, negatively influence the
function of not properly installed or not sufficiently shielded
electronic systems in vehicles, e.g. electronic ABS, electronic
tempo controllers and airbag systems. For further informa-
tion about your vehicle or its possible ancillaries make con-
tact with the respective manufacturer or their representative.
Introduction, trademark rights
Bluetooth®is a wireless communication system with
a short range. It makes possible wireless connections
between Bluetooth®appliances, such as for example
mobile telephones, PDA and PCs. Bluetooth®relates
itself to a worldwide standard for operation in the inter-
nationally recognised ISM Frequency Range (Industrial,
Scientific and Medical). Within the ISM Frequency Range
(2.402 - 2.480 GHz), a data transfer range of ca. 10 meters
(class II) is achieved. The disturbance susceptibility through
other users of the ISM Frequency Range, such as for
example microwaves, WLAN (802.11) or garage door
openers, is minimised by so-called “Frequency-Hopping“.
With Frequency-Hopping, a change of frequency levels
takes place at up to 1600 times per second, thereby
Bluetooth®is also reckoned to be relatively tap-proof.
However, data transferred via a radio link can be inter-
cepted by unauthorised third parties.
The Bluetooth®logotype and Bluetooth®logo are
registered trademarks of Bluetooth SIG, Inc. (Special
Interest Group). Any use of the trademarks by Kompernaß
Handels GmbH is made under the provisions of a licence.
All other names and brands are the property of their owner.
The HSP (Headset-Profil) makes possible standard func-
tions such as voice transference, as well as the accept-
ance and rejection of calls.
The HFP (Handsfree-Profil) makes possible the hands-free
call functions of a mobile telephone, for example with the
help of voice commands.

SBTF 10 C3
■ 6 │ GB│IE│NI
Package contents (see fold-out page)
Bluetooth®Hands-Free Kit
Operating instructions
ƔTake the device out of the packaging and remove all
packaging materials.
Note:
ƔCheck the package for completeness and for signs of
visible damage.
ƔIf any items are missing or damaged as a result of
defective packaging or insufficient care during trans-
portation, contact the Service hotline (see the section
Service).
Technical data
Operating voltage/
current consumption: 12-24 V / 1000 mA
Bluetooth®Specification: Version 3.0 + EDR,
up to a range of 10 meters
Supported Bluetooth®
profiles: HSP and HFP
Output voltage/
max. power via USB port: 5 V / 1 A
Fuse: F2AL / 250 V
Dimensions: approx. 16.2 x 5.5 x 2.3 cm
Weight: approx. 78 g
Operational temperature: +5° to +40°C
Storage temperature: 0° to +70°C
Humidity: 5 to 75%
(no condensation)

SBTF 10 C3 GB│IE│NI │ 7 ■
Controls (see fold-out page)
Vehicle connector plug
Microphone
+/- Buttons (Raise/lower the sound level)
USB port
Loudspeakers
Multi-function button
LED status indicator
Installing the hands-free appliance
in a vehicle
So that the hands-free appliance can function correctly, it
is connected to the vehicle cigar lighter socket or on-board
power socket and provided with electricity from there.
ƔEnsure that the hands-free appliance engages
completely and that the operation of the vehicle is
not negatively influenced. The hands-free set must be
easily accessible and the speaking distance kept to
a minimum. The LED status indicator blinks twice
every 3 seconds and a short high signal tone sounds
once. The appliance is in standby mode.
Note:
It is possible that the cigar lighter only functions when the
vehicle ignition is switched on. In cases of doubt, consult
the operating instructions for the particular vehicle.
Caution!
For vehicles in which the cigar lighter, resp. the vehicle cir-
cuit plug, also functions when the ignition is switched off:
ƔUse the hands-free appliance only when the motor is
running. Otherwise, the vehicle batteries could become
discharged over an extended period of time.
Note:
When you are not using the hands-free equipment remove
it from the vehicles cigarette lighter socket. Store it in a dry,
dust free location protected from direct sunlight.

SBTF 10 C3
■ 8 │ GB│IE│NI
Switching the hands-free
appliance on and off
Switching on: The appliance is switched off.
ƔPress and hold the multi-function button for 3 sec-
onds, until a short and high signal tone is heard. The
LED status indicator blinks twice every 3 seconds.
Note:
The hands-free set switches on automatically as soon as it
is connected to a power supply.
Switching off: The appliance is in standby mode.
ƔPress and hold the multi-function button for 5 seconds,
until a long and deep signal tone is heard. The LED
status indicator extinguishes.
Coupling the hands-free appliance
with a mobile telephone
The hands-free appliance has been especially developed
for mobile telephones that support the Bluetooth®Profile
“Handsfree (HFP) and Headset (HSP)“. Further informa-
tion about Bluetooth®radio technology is to be found
in the operating instructions for your mobile telephone.
Before you can use the hands-free appliance, you must
connect it with a compatible mobile telephone (pairing).
ƔCheck to make sure the mobile telephone is switched on.
ƔProgramme the mobile telephone so that it searches
for Bluetooth®appliances. A detailed description of
how to do this is to be found in the operating instruc-
tions for your mobile telephone.
ƔEnsure that the hands-free appliance is correctly set up
and switched off.
ƔTo switch the device off, press and hold the multi-function
button for about 5 seconds. A long, low signal
tone will be heard and the LED status indicator 
extinguishes.

SBTF 10 C3 GB│IE│NI │ 9 ■
ƔPosition the hands-free appliance and the mobile tele-
phone so that they are not more than 1 metre away
from each other.
ƔPress and hold down the multi-function button for 6
seconds until, after 3 seconds a short, high signal tone
and after a further 3 seconds a succession of low and
high signal tones are heard. The LED status indicator
lights up constantly and the hands-free equipment is
now in the coupling mode.
ƔSelect the hands-free provision “Car Kit“ from the list
of available appliances for the mobile telephone.
ƔEnter in the pre-programmed passcode “9999“ and
then confirm it, which couples the appliances with
each other. You will hear a short, high-pitched beep
followed by a short low beep and the LED status
indicator flashes every 3 seconds.
ƔYou can now use the hands-free appliance.
Note:
When using the latest mobile phones, (Smartphones) those
that are equipped with Bluetooth®2.0 or a more mod-
ern version, it is possible that the pass code “9999“ need
not be entered. If the coupling is not completed within 2
minutes, the hands-free appliance switches itself off. The
LED status indicator extinguishes and you will hear a
long and deep signal tone. With some mobile telephones
it is possible that coupling does not automatically take
place. In this case coupling must be carried out addition-
ally on the mobile telephone. The LED status indicator 
blinks twice every 3 seconds until this has been carried
out. Further information can be found in your mobile
telephone’s operating instructions.

SBTF 10 C3
■ 10 │ GB│IE│NI
Multipoint function
The multipoint function allows you to use the hands-free kit
with two mobile phones simultaneously. This is useful for
users with a private and a business mobile phone.
If you have paired several mobile phones, the hands-free
kit will now have several “known” devices available. This
status is a prerequisite for an active connection between
the hands-free kit and other mobile phones. A maximum
of 8 mobile phones can be saved as “known” devices.
The number of devices that can be actively linked to the
hands-free kit is limited to two. As soon as one or two of
the known devices come into range of the hands-free kit,
connection to the devices is made automatically. In some
cases, you must confirm the connection manually on your
mobile phone.
If a third “known” device comes into range of the hands-
free kit, the connection to this device will remain blocked
until one of the two active connections is broken or one
of the two devices leaves the transmission range. If the
connection of one of the paired devices is broken, the
link becomes free for the third (waiting) device.
If two mobile phones are connected to the hands-free
kit, the ring tone will sound from the phone itself and not
the hands-free kit when there is an incoming call to the
second mobile phone.
Pairing the hands-free kit with an
additional mobile phone
ƔMake sure that the first mobile phone is not connected
to the hands-free kit.
ƔSwitch off the hands-free kit by pressing the multifunction
button for about 5 seconds. You will hear a long,
low beep and the LED status indicator goes out.
ƔPress and hold the multifunction button for about
6 seconds. After 3 seconds, you will hear a short
high-pitched beep followed 3 seconds later by another
high-pitched beep. The LED status indicator lights
up permanently.

SBTF 10 C3 GB│IE│NI │ 11 ■
ƔSelect the “Car Kit” hands-free kit from the list of
available devices on the mobile phone.
ƔEnter the preset pass code “9999” and then confirm
this to pair the devices with each other. You will hear
a short, low beep followed by a short, high-pitched
beep and the LED status indicator flashes every
3 seconds.
ƔSwitch off the hands-free kit after successfully pairing
the second mobile phone.
ƔPress and hold the multifunction button for about
3 seconds until you hear a short high-pitched beep. The
LED status indicator flashes twice every 3 seconds.
The hands-free kit will attempt to make a connection to
the last two connected mobile phones within the next few
seconds. You will hear a double beep once the devices
have been successfully paired.
Note:
In some cases, it will be necessary to make the connection
manually via the Bluetooth®menu on the mobile phone.
Separating the connection
If you wish separate the mobile telephone from the hands-
free appliance, for example, to connect it to another
Bluetooth®appliance:
ƔSwitch the hands-free appliance off
or
Ɣseparate the connection over the Bluetooth®menu
in the mobile telephone.
Note:
You need not erase the coupling with the hands-free appli-
ance in the Bluetooth®menu to separate the connection.
Using the hands-free appliance
After successful coupling, the following functions are
available to you. Some of the described functions are
only possible with a mobile telephone that supports the
Handsfree Profile (HFP).

SBTF 10 C3
■ 12 │ GB│IE│NI
Note:
The sound quality of the hands-free set is heavily depend-
ent on where it is installed. Where possible, set up your
hands-free set so that the microphone is pointing in
your direction.
Call function
ƔUse your mobile telephone in the usual way to make a call.
ƔFor redialing of the last number called, shortly press
the multi-function button twice.
ƔFor activation of voice dialling, shortly press the multi-
function button once.
Note:
Voice dialing is only available with mobile telephones that
support this function. Further information regarding voice
dialing is to be found in the operating instructions for your
mobile telephone.
Accepting and ending a call
When you receive a call the LED status indicator blinks
and you hear a call tone from the hands-free appliance.
If the call signal in your mobile phone is switched off, the
ringing tone is nonetheless sounded via the hands-free
appliance.
ƔPress the multi-function button shortly once,
to accept the call.
ƔPress the multi-function button shortly once,
to terminate the accepted call.
You can also accept and terminate the call over the
mobile telephone.

SBTF 10 C3 GB│IE│NI │ 13 ■
Managing calls
If you have connected two mobile phones to the hands-
free kit simultaneously, you can put one call on hold in
order to take a call from a second mobile phone and
toggle between the two calls.
Note:
If a call comes to the second mobile phone during an
ongoing call, this call will only be signalled on the
second phone.
ƔPress the multifunction button twice briefly to accept
the call on the second mobile phone while already
talking on the first mobile phone. The first call is put
on hold.
ƔPress the multifunction button again twice to toggle
between the two calls. When the current call is finished,
the hands-free kit switches automatically to the second
ongoing call.
ƔPress the multifunction button once briefly to end the
current call and automatically accept the second call.
Automatic call acceptance
If automatic call acceptance is activated in the mobile tel-
ephone, it accepts the incoming call after a determined time
period and then passes it on to the hands-free appliance. Fur-
ther information regarding automatic call acceptance is to be
found in the operating instructions for your mobile telephone.
Rejecting a call
ƔPress the multifunction button for about 3 seconds
to reject an incoming telephone call.
Adjusting the volume of the hands-free appliance
You can adjust the sound volume level of the hands free
device with the +/- buttons .
ƔDuring a conversation, press the + or - button until the
desired volume level is set. A high-pitched beep signals
that you have reached maximum volume; a low-pitched
beep signals that you have reached minimum volume.

SBTF 10 C3
■ 14 │ GB│IE│NI
Resetting the hands-free kit
The hands-free kit can be paired with up to 8 mobile
phones. To delete the pairing list and reset the hands-free
kit to the factory defaults, proceed as follows:
ƔEnsure that the hands-free kit is in standby mode.
ƔPress and hold the multifunction button for about
10 seconds until you hear two beeps and the LED
status indicator flashes five times. The pairing list
is deleted and the hands-free kit is reset to the factory
defaults.
Note:
After resetting to the factory default settings, the hands-
free kit will automatically be in pairing mode when it is
connected to a mobile phone.
If the hands-free kit is not connected to a mobile phone
after resetting to the factory defaults it will be in standby
mode.
Charging 5 V Devices
ƔCheck the max. input voltage (5V) and the max. power
input (1000 mA) of the device which you want to charge.
For this, consult the operating manual of the device.
ƔConnect the device to be charged with the USB port 
on the hands free device. The device now receives its
power supply from the hands free device. If the device
is equipped with a charging indicator light, this will in-
dicate that the device is being charged.
Note:
If the power supply does not activate automatically, you
should disconnect the USB cable from the USB port 
and re-connect it.

SBTF 10 C3 GB│IE│NI │ 15 ■
Troubleshooting
If you cannot connect the hands-free appliance with a
compatible mobile telephone, proceed as follows:
ƔEnsure that the Bluetooth®function in the mobile
telephone is activated.
ƔIs the display flashing? Ensure that the hands-free ap-
pliance is correctly installed, switched on and supplied
with electricity.
ƔIf you use several Bluetooth®appliances, ensure that
a previously created Bluetooth®connection of the
mobile telephone is separated. This may indicate that
a previously paired device is in range.
ƔEnsure that the hands-free appliance is distanced a ma-
ximum of 10 metres from the mobile telephone and that
there are no barriers or electronic devices between them.
Replacing the fuse
The hands-free set is equipped with a fuse. If the device
no longer works, check the fuse and replace if necessary.
ƔOpen the vehicle connector plug by turning the
fluted screw insert A gently anticlockwise – with pliers
if necessary – and remove it.
ƔRemove the plug tip B from the fuse C and pull the fuse
out. Ensure that the spring D in the vehicle connector
plug does not accidentally jump out and become lost.
ƔPlace a new fuse of type F2AL/250V into the vehicle
connector plug , place the plug tip B onto the end
of the fuse that is slightly protruding C and screw the
screw insert that you removed earlier A back in.
D C B A

SBTF 10 C3
■ 16 │ GB│IE│NI
Danger!
ƔReplace the fuse only with another of the same rating
as that given on the ratings plate. Fuses with a different
rating may cause fire. Smoke resulting from such a fire
is poisonous.
Note:
If these measures do not correct the problem, please con-
tact the appropriate service partner for your country.
Cleaning and Care
Danger of electrocution!
ƔBefore cleaning, always separate the electricity supply
from the appliance!
ƔNEVER submerse the appliance in water or other liquids!
ƔDo not permit liquids to permeate into the housing!
ƔNever open the housing of the appliance! There are
no user-serviceable elements inside.
ƔDo not use strong detergents, solvents or abrasive
cleaning agents to clean the appliance. These could
damage the housing surfaces.
ƔClean the housing surfaces with a slightly moist soft cloth.
Storage when not in use
Caution!
The temperatures inside the vehicle can reach extreme values
in summer and winter. Consequently, to avoid damage to
the device, you should not store it in the vehicle.
ƔStore the device somewhere clean, dry, free of dust
and out of direct sunlight.

SBTF 10 C3 GB│IE│NI │ 17 ■
Disposal
The adjacent symbol of a crossed-out wheelie
bin indicates that this device is subject to
Directive 2012/19/EU. This directive states that
this device may not be disposed of in the
normal household waste at the end of its useful life, but
must be handed over to specially set-up collection
locations, recycling depots or disposal companies.
This disposal is free of charge for the user.
Protect the environment and dispose of this
device properly.
You can obtain further information from your local dis-
posal company or the city or local authority.
Dispose of all packaging materials in an
environmentally responsible manner.
Notes on the EU Declaration
of Conformity
This appliance complies with the essential requirements and
other relevant provisions of the R&TTE Directive 1999/5/EC,
the Automotive EMC Directive 2004/104/EC, the Low
Voltage Directive 2014/35/EU and the RoHS Directive
2011/65/EU.
You can request the full EU Declaration of conformity from
the importer.
