Silvercrest CRB-532 User manual

67
English
1 Preliminary notes
Thank you for selecting our Bluetooth car radio SilverCrest CRB-532. In order for you to utilise this device and all its options, we
recommend that you read the corresponding instructions in this manual before initial use of the device, even if you are familiar
with handling electronic devices. Please pay particular attention to the chapter “Important safety instructions” on page 71. Store
this manual in a safe location for future reference. If you sell or transfer this device, please be sure to pass along these
instructions as well.
For all product descriptions and user instructions, the German version is the ultimately valid reference in the event of possible
deviations in other languages.
2 Copyright
The contents of this manual may not be reproduced, copied or otherwise duplicated in electronic, mechanical, magnetic, optical,
chemical, manual, or any other form without the permission of our company, nor may they be stored in a search engine nor
translated into another language.
3 Manufacturer information
JNC Datum Tech GmbH
Benzstraße 33
71083 Herrenberg
Germany
www.jnc-digital.de
More information can also be found at:
www.m
y
silvercrest.de

68
4 Table of contents
1Preliminary notes ....................................................................................................................... 67
2Copyright..................................................................................................................................... 67
3Manufacturer information .......................................................................................................... 67
4Table of contents........................................................................................................................ 68
5Important safety instructions .................................................................................................... 71
6Scope of delivery........................................................................................................................ 72
7Installation................................................................................................................................... 74
7.1Installing the device 74
7.2Connecting the antenna 78
7.3Supply voltage 78
7.4Speakers 79
7.5Removal 80
8Operating panel .......................................................................................................................... 81
9Display......................................................................................................................................... 85
9.1General 85
9.2Radio Mode 86
9.3CD Mode 86
9.4MP3/WMA/OGG-CD Mode 87
9.5SD/MMC Mode 87
9.6USB Mode 88
10Activation .................................................................................................................................... 89
10.1Insertion of the operating panel 89
10.2Removal of the operating panel (anti-theft protection) 89
11Basic functions........................................................................................................................... 90

69
English
11.1Turning on/off 90
11.2Changing the volume 90
11.3Muting the speakers 91
12Radio (Tuner) Mode.................................................................................................................... 92
12.1Selection of the radio station 92
12.2Select the wavelength range 92
12.3Find and save radio stations 92
12.4RDS 94
12.5Traffic Announcement (“TA”, Traffic Programme “TP”) 94
12.6Alternative frequencies (“AF”) 95
12.7Regional programmes (“REG”) 96
12.8Programme type (PTY) 96
13CD Mode ...................................................................................................................................... 97
13.1Selecting a CD as a programme source 97
13.2Inserting / ejecting a CD 98
13.3Playback / pause 99
13.4Selecting or repeating tracks 99
13.5Fast forward and reverse play 99
13.6Repeat track (repeat) 99
13.7Intro 100
13.8Playing tracks in random order (Random) 100
14USB/MP3/WMA/OGG and SD/MMC Mode............................................................................... 101
14.1Connecting/removing a USB storage medium 101
14.2Selecting a USB storage medium as data source 102
14.3Selecting an iPod®as data source 102
14.4Insert / remove SD/MMC 103
14.5Selecting SD/MMC as a programme source 103
14.6MP3 functions 103
14.7Searching for track numbers 104
14.8Alphabetical search 104

70
14.9Skipping forward or backward in increments of ten 105
14.10Pause 105
14.11Repeat functions (Repeat) 105
14.12Intro 106
14.13Random playback (random) 106
14.14Turning the subwoofer on/off 106
15AUX IN ....................................................................................................................................... 106
16Settings ..................................................................................................................................... 107
16.1Menu level 1 107
16.2Menu level 2 109
16.3Recording and copying function 113
16.4Deleting tracks 115
16.5Bluetooth®telephone function 116
16.6Factory settings (“RESET”) 120
17Remote control ......................................................................................................................... 121
17.1Description of the buttons 121
17.2Changing the battery 123
18Product information ................................................................................................................. 124
18.1General information 124
18.2Technical specifications 125
19Disposal..................................................................................................................................... 126
20Troubleshooting ....................................................................................................................... 127
21Warranty information ............................................................................................................... 129

71
English
5 Important safety instructions
Please read and strictly observe the following instructions!
You are not permitted to disassemble, modify or repair the car radio.
Never open the case of the car radio; it does not contain any serviceable parts!
If the case is open, there is a risk of fatality due to electric shock.
Do not give your car radio and especially the accessories to children. Never let your children use electrical devices without
supervision. Children are not always able to recognise potential hazards. Also keep plastic packaging away from children.
There is a danger of suffocation.
The car radio and the accompanying components must not be exposed to dripping or sprayed water. Make sure that no
containers filled with liquid, such as bottles or cups, are placed in the vicinity of the device.
Make sure that the display is not subjected to any knocks. This can damage the display.
Please familiarise yourself with the different functions of your device before you begin driving. Excessively high volumes can
pose a risk for you and other road users. Therefore, always set the volume at such a level that ambient noises (horns, sirens
etc) can still be heard.
Multimedia CDs also contain recordings of files other than audio files. If you play such a CD despite the warning information, it
may result in noise at a volume that endangers traffic. Furthermore, damage may be caused to the power amplifier and
speakers.
Do not use the car radio at an excessive volume. This poses a risk to your hearing.
Pleasemakeanyadjustmentstothesettingsonlywhenyourvehicleisparkedasyourconcentrationcould
otherwisebeadverselyaffected.

72
6 Scope of delivery
1. CRB-532 Bluetooth car radio 2. Case for operating panel
3. Installation frame 4.
A
ux-in connection cable
5. External microphone 6. Screws and nuts

73
English
7. Remote control 8. User manual
Note:
The design and technical data are subject to change without any notification. Illustrations are not to scale.

74
7 Installation
7.1 Installing the device
Note:
Please observe the following safety instructions for the connection of the device:
Read the entire installation section before connecting the device.
Disconnect the negative pole of the vehicle battery for the duration of the installation.
Observe the vehicle manufacturer’s safety instructions during this task.
If you need to drill holes for the installation, make sure that no parts of the vehicle are damaged.
The cross section of the plus and minus cable must not be less than 2.5 mm².
Do not connect any plugs or cables from the vehicle to the radio without appropriate expertise!
To connect the device, use only the cable supplied.
Depending on the design layout of your vehicle, the installation may deviate from this description.
We do not assume any liability for damage caused by faulty installation or connection or any damage arising therefrom.

75
English
Fig. 8.0
transport safety screws
Fig. 8.1
Fig. 8.2
Note:
We recommend that you have the device installed by a specialist company. Then you will have created the prerequisites for a
problem-free functioning of the device. If at any point during the installation you are unsure that you can correctly connect the
device by yourself, contact a specialist. A faulty installation may cause damage to the device and the vehicle electronics.
Please note that the costs of installation (or removal in the case of a claim under guarantee) are not borne by the
manufacturer.
1. For the installation of the device, first remove the transport safety screws on the CD drive (Fig. 8.1).
2. Then remove the installation frame from the device with the aid of the release key, by sliding the release keys into the
openings provided on the right and left side of the device, as described in Fig. 8.1. Make sure that the protrusion on the
release key (Fig. 8.2) points away from the device while it is being inserted. Afterwards, the frame can be slid down over the
device towards the rear.
3. Now slide the installation frame into the installation slot provided for the car radio.

76
4. Now attach the installation frame by bending the installation brackets towards the outside with a screwdriver. The frame is
properly installed when it can no longer be pulled out, yet also keeps from sliding further into the installation slot.
5. Now connect the cable set and the antenna corresponding to Abb. 8.3 and Abb. 8.4 as well as the table below to the
vehicle’s electric system. Also observe the specifications in sections 8.2 to 8.4.
Contact Connector pin assignment ISO connector plug (also see Abb. 8.3 number 7)
Plug A Plug B
1 Rear right (+)
–
purple
2 Rear right (-) - purple / black
3 Front right (+) - grey
4 Ignition (ACC+) / red Front right (-) – grey / black
5 Car antenna / blue Front left (+) - white
6 Automatic operating panel dimmer / orange Front left (-)
–
white / black
7 Battery 12V (+) / yello
w
Rear left (+) - green
8 Ground / black Rear left (-)
–
green / black
6. Slide the device into the installation frame as far as the stop point. You will hear the device audibly lock into place.
7. Attach the front frame and then insert the operating panel.
