Silvercrest MTS2220 Operating and installation instructions

MTS2220
HOME TECH
Wireless Keyboard
with wireless mouse and USB receiver
Wireless Keyboard with wireless
mouse and USB receiver
User manual and
service information
GB
IE
Langaton näppäimistö mukana
langaton hiiri ja USB-vastaanotin
Käyttöopas ja huolto-ohjeet
FI
Trådlöst tangentbord med
trådlös mus och USB-port
Bruksanvisning och
serviceinformation
SE
Radiostyret tastatur med radiostyret
mus og USB-modtager
Brugervejledning og
serviceinformation
DK
GR
CY AT
Funktastatur mit Funkmaus und
USB-Empfänger
Bedienungsanleitung und
Serviceinformationen
CY
CH
Ασύρματο πληκτρολόγιο με
ασύρματο ποντίκι και δέκτη USB
Εγχειρίδιο χρήσης και πληροφορίες
για την τεχνική εξυπηρέτηση
mts2220_lb3_0912.qxd 12.01.2010 14:34 Uhr Seite 1

Wireless keyboard with wireless mouse MTS2220 English
1
Wireless keyboard with wireless mouse and USB receiver
MTS 2220
Package Contents
1 Wireless keyboard
2 Wireless mouse
3 Miniature USB receiver
4 2 batteries type AAA, 1,5V (Micro) for the
wireless keyboard (not illustrated)
5 1 battery type AA, 1,5V (Mignon) for the
wireless mouse (not illustrated)
6 Software CD-ROM (not illustrated)
7 Operating manual (not illustrated)

English Wireless keyboard with wireless mouse MTS2220
2
System Requirements
-Intel®Pentium®III / AMD Athlon™ or higher
-1 free USB-2.0 port
-Microsoft®Windows®2000 Professional, Windows®XP,
Windows Vista®or Windows®7
-CD-ROM drive or DVD drive for installing the software
Overview
1 Special keys (hotkeys)
2 Miniature USB receiver
3 Battery level indicator*
4 Volume control
* After inserting the batteries into the keyboard, the indicator will flash several
times during automatic synchronisation with the USB receiver. When the
synchronisation is completed, the status indicator will stop lighting.

Wireless keyboard with wireless mouse MTS2220 English
3
5 Toggle 500/1000 cpi (press briefly)
Toggle standard/media operation (pressed continually for 3 seconds)
6 Tilt wheel (4-way scrolling wheel)
Volume control and sound off (media operation)
7 Right mouse button
8 Left mouse button
9 Battery power control lamp
10 Forward (standard)
Next title (media operation)
11 Back (standard)
Previous title (media operation)
12 Zoom + (standard)
Start Media Player (media operation)
13 Zoom – (standard)
Play / Pause (media operation)

English Wireless keyboard with wireless mouse MTS2220
4
Contents
Package Contents 1
System Requirements 2
Overview 2
Contents 4
Important Safety Information 5
Children and Persons with Disabilities ......................................................... 5
Batteries........................................................................................................ 6
R/F Interface ................................................................................................. 6
Operating Environment................................................................................. 7
Intended Use................................................................................................. 7
Care and Repair ........................................................................................... 8
Copyright....................................................................................................... 8
Storing When Not Using the Product............................................................ 8
CE Declaration of Conformity Notice............................................................ 9
Appliance Disposal ....................................................................................... 9
Introduction 9
Hardware Installation 10
Inserting the Batteries................................................................................. 10
Connecting the Miniature USB Receiver .................................................... 11
Software Installation 12
Task Bar Symbols....................................................................................... 14
Configuration 14
Toggling between Operating Modes........................................................... 14
Configuring the Wireless Mouse................................................................. 15
Configuring the Wireless Keyboard ............................................................ 16
Attachment 19
Troubleshooting .......................................................................................... 19
Technical Data............................................................................................ 20
Warranty Information 21

Wireless keyboard with wireless mouse MTS2220 English
5
Important Safety Information
Before first using the device read the following instructions carefully and take
note of the safety warnings, even if you are familiar with using electronic
devices. Keep this manual in a safe place for future reference. If you sell or
pass on the appliance, you should absolutely ensure to hand over these
instructions as well.
Caution: LED Radiation! LED Class 1
Avoid harm to the eyes. Never look directly into the LED beam. Never point
the LED light beam directly at people or animals.
This icon denotes important information for the safe operation of
the product and for the user’s safety.
This symbol denotes further information on the topic.
Children and Persons with Disabilities
Electrical appliances do not belong in the hands of children. Also people with
disabilities shall use electrical devices accordingly. Do not allow children or
persons with disabilities to use electrical devices when not under
supervision. These people may not comprehend the presence of potential
risks. Batteries and small parts represent potential choking hazards. Keep
the batteries out of reach. If a battery is swallowed, seek medical help
immediately. Keep the packaging away from children and persons with
disabilities too. as there is danger of suffocation.

English Wireless keyboard with wireless mouse MTS2220
6
Batteries
Please always insert the batteries with the poles pointing in the proper
direction. Never attempt to recharge the batteries and under no
circumstances try to incinerate them. Do not use different batteries (e.g. old
and new, alkaline and carbon, etc.) simultaneously. Remove batteries if
appliance is not being used for any longer periods of time. Inappropriate
battery use may result in explosion and leakage risks. Please take care to
protect the environment. Used batteries do not belong in the domestic waste
and need to be handed in at a collection point for used batteries instead.
R/F Interface
Please switch off the appliance in airplanes, hospitals, operating theatres
and in the vicinity of medical electronic system. The radio waves transmitted
could impair the functionality of sensitive appliances. Observe a minimum
distance of 20 cm between the appliance and any pacemaker as the radio
waves could impair the function of the pacemaker. The transmitted radio
waves may create interference noises in hearing aids. Do not allow the
appliance to be introduced in the vicinity of inflammable gases or in
environments subject to a risk of explosion (e.g. paint shops) as long as the
radio component is switched on, because the transmitted radio waves could
trigger an explosion or fire. The coverage/range of the radio waves varies
depending on the surrounding and environmental conditions. In any data
exchange via wireless connections, unauthorized third parties are also able
to receive the data. Targa GmbH is not liable for any radio or television
interference caused by unauthorized modifications of this appliance. Targa
furthermore accepts no liability for the replacement or exchange of
connection cables and appliances not specified by Targa GmbH. The user is
solely responsible for the elimination of interferences caused by such an
unauthorized modification, as well as for the replacement or exchange of the
appliances concerned.

Wireless keyboard with wireless mouse MTS2220 English
7
Operating Environment
Position the device on a firm, even surface and do not place any objects on
top of it. The appliance is not designed for operation in spaces subject to
high humidity or temperatures (e.g. bathrooms) or in excessively dusty
locations. Operating temperature and air humidity: 5°C to 40°C, max. relative
air humidity 90%.
Please ensure that:
-the appliance is not exposed to direct sources of heat (e.g. heating
elements);
-the appliance is not exposed to direct sunlight or artificial light;
-any contact with splashes and/or drips of water and other liquids is
avoided and the device is not operated near water; in particular, the
appliance may never be submerged (do not place water-filled objects
such as vases or open drinks containers on top of or near the appliance);
-the appliance is not placed in the direct vicinity of magnetic fields (e.g.
loudspeakers);
-no sources of open flame (e. g. lighted candles) are placed on top of or
near the appliance;
-the appliance is not penetrated by foreign objects;
-the appliance is not exposed to strong temperature fluctuations;
-the appliance is not subjected to excessive shaking or vibration.
Intended Use
This Keyboard and Mouse Set, consisting of a wireless keyboard, wireless
mouse and wireless receiver, is an IT device. The device may not be used
outdoors or in tropical climates. This product has not been designed for
corporate or commercial applications. Use the product in domestic
environments for private applications only. Any use other than that
mentioned above does not correspond to the intended use. Only external
devices may be used that comply with safety standards and the
electromagnetic compatibility and shielding quality of this device. This device
fulfils all that relates to CE Conformity, relevant norms and standards. Any
modifications to the equipment other than recommended changes by the
manufacturer may result in these directives no longer being met. The
manufacturer is not liable for any damage or interference caused by

English Wireless keyboard with wireless mouse MTS2220
8
unauthorized modifications. Only use the accessories recommended by the
manufacturer.
If you are not using the appliance within the Federal Republic of Germany
you are bound by the state regulations and/or legislation applicable in the
country of operation.
Care and Repair
Repair activities are required if the appliance has been damaged, liquids or
objects have penetrated the casing, the appliance has been exposed to rain
or moisture, the appliance is not working properly or if it has been dropped. If
you notice any smoke developing, unusual noises or scents, please switch
off the appliance immediately. In such cases the appliance may not be
operated until a professional specialist has checked it. Any repairs are only
to be performed by qualified professional technicians. Never open the casing
of the appliance or of any accessories. Only clean the appliance with a clean
and dry cloth, never using any aggressive liquids.
Copyright
The entire content of this User’s Manual is copyrighted and is provided to the
reader for information purposes only.
Copying data and information without the prior written and explicit
authorization from the author is strictly forbidden. This also applies to any
commercial use of the contents and information.
All texts and figures are up-to-date as per the date of print release. We
assume no liability for any changes.
Storing When Not Using the Product
When left unused for a long period of time, remove the batteries from the
wireless keyboard and from the wireless mouse. Also make sure that the
storage temperature is maintained between 5 °C and 40 °C. The humidity
must not exceed 90% relative humidity.

Wireless keyboard with wireless mouse MTS2220 English
9
CE Declaration of Conformity Notice
The mouse and keyboard set complies with the basic and other
relevant requirements of the R&TTE Directive 99/5/EC. The
corresponding Declaration of Conformity can be found at the end
of this User's Manual.
Appliance Disposal
All appliances labelled with this symbol are subject to the
European directive 2002/96/EC. All electrical and electronic
appliances need to be disposed off separately via the facilities
provided for this purpose by the authorities and may not be
included in the domestic waste. The proper disposal of old
appliances helps to protect the environment and prevents risks for
your personal health. For further information about proper
disposal, contact your local government, disposal bodies or the
shop where you bought the device.
Also recycle the packaging material properly. Cardboard packaging can be
taken to paper recycling containers or public collection points for recycling.
Any films or plastic contained in the packaging should be taken to your public
collection points.
Introduction
Thank you for purchasing the wireless keyboard with wireless mouse
MTS2220. The devices feature a SmartLink technology that makes any
manual synchronisation obsolete. Several special keys and buttons on both
appliances help you adapt the operation of the mouse and keyboard to your
personal wishes. The mouse features a tilt wheel (4-way scroll wheel)
enabling you to scroll horizontally as well as vertically.

English Wireless keyboard with wireless mouse MTS2220
10
Hardware Installation
Unpack all the devices and use the package contents checklist on page 1 to
verify that you have received all items listed.
Inserting the Batteries
First insert the batteries into the wireless mouse and wireless keyboard, as
shown in the figures below. Please ensure that the + and – poles of the
batteries point in the right direction when you insert them. Now switch on the
wireless mouse using the On/Off switch at the underside (15). The wireless
mouse features a control lamp (9) on the top. This control lamp lights up in
red if the battery power is low. Please replace the battery in this case with a
new battery.
Abb.: Detail view of keyboard underside
Abb.: Detail view of mouse underside
14 Keyboard battery compartment
15 On/Off switch for mouse
16 Optical sensor
17 Mouse battery compartment

Wireless keyboard with wireless mouse MTS2220 English
11
Connecting the Miniature USB Receiver
Connect the miniature USB receiver to a free USB port of your running
computer.
Abb.: Miniature USB Receiver
The operating system will automatically recognize the new hardware and
install the required drivers. Depending on the operating system installed, the
following screen messages may appear:
Windows®2000/XP
When the receiver is connected for the first time, the operating system
Windows®2000/XP displays the message „New hardware detected“. Wait
until the message „The new hardware has been installed and is now ready
for use“ is displayed before using your mouse and keyboard.
Windows Vista®, Windows®7
When the receiver is connected for the first time, the operating system
Windows Vista™ displays the message „Installation of appliance driver
software“. Wait until the message „The appliances are ready for use now“
appears. The mouse and keyboard are now operational and ready to be
used.
If your previous mouse and keyboard are still connected to the computer,
please shut down the computer, disconnect the appliances in question and
then restart the computer.
Should the wireless mouse fail to work, power it off and back
on. Sometimes removing and re-inserting the batteries will also
help.

English Wireless keyboard with wireless mouse MTS2220
12
Software Installation
In order to be able to use the full function-capabilities of your wireless
keyboard and wireless mouse, you must install the supplied software. Insert
the included CD-ROM in the CD-ROM drive of your computer. The
installation process should start automatically, failing that, start the CD-ROM
file "setup.exe" manually by double-clicking it.
Only with the operating system Windows Vista®/ Windows®7 the installation
will initially be stopped by the user account control function with the
message: „An unidentified program is attempting to access the computer”.
Click on „OK“ to continue with the installation.
The following installation illustrations correspond to the operating system
Windows Vista®. The windows displayed in the operating systems Windows®
XP/2000/7 are slightly different, but their content is the same.
The installation is being prepared.
Click on Next to start the
installation.

Wireless keyboard with wireless mouse MTS2220 English
13
Here you can select the target
folder for the installation via the
Browse button or use the
suggested folder. Click on Next to
proceed with the installation.
The software data are being
copied. Please wait.
Only the operating system
Windows Vista™ requires a
restart. Select “Yes, restart the
computer now” first and then click
the Finish button.
Windows Vista™ will subsequently execute a restart. As soon as the restart
of your computer is concluded, your keyboard and optical mouse are ready
for configuration using the software.

English Wireless keyboard with wireless mouse MTS2220
14
Task Bar Symbols
A double click on this symbol opens the configuration menu for the
optical mouse (see page 15 – “Configuration of the Optical Mouse” for
a description).
A double click on this symbol opens the configuration menu for the
keyboard (see page 16 – “Configuration of the Keyboard” for a
description).
This symbol shows you that the keyboard’s „Num Lock“ function has
been activated. Press the “Num Lock” key to deactivate the function
again.
This symbol shows you that the keyboard’s „Caps Lock“ function has
been activated. Press the “Caps Lock” key to deactivate the function
again.
This symbol shows you that the keyboard’s „Scroll“ function has been
activated. Press the “Scroll” key to deactivate the function again.
The operating systems default settings will hide disabled icons
in the task bar. It is recommended to disabled the “Hide inactive
icons” option in task bar properties.
Configuration
Toggling between Operating Modes
Use the CPI button (5) to quickly toggle between 500 cpi and 1000 cpi
resolution for optical tracking. Tracking at 1000 cpi offers a higher accuracy.
If you would like to toggle between standard operation and media operation
on the mouse, press the CPI button (5) and keep it pressed for a minimum of
3 seconds until the power control lamp (9) briefly lights up. Please see the
list on page 3 for information on the functions available in the media
operation mode.

Wireless keyboard with wireless mouse MTS2220 English
15
Configuring the Wireless Mouse
Double click on this symbol in the task bar (bottom right of the screen,
next to the system clock) in order to open the configuration menu for the
mouse.
Here you can specify functions for
selected mouse buttons. Simply
click on the selection switch next to
the corresponding mouse button
and select a function from the
menu by clicking on it with the left
mouse button.
You can restore the mouse to its
original state by clicking the
„Restore to default“ button.
If you would like to apply your changes, please click on the „Apply“ button
(the window will remain open) or the „OK“ button (the window will close).
The slide switch puts you in a position to adjust the speed of double clicks. If
you move the slide to the left and then activate the function via the „Apply“
button, the mouse will react to a slow double-clicking speed. If you move the
switch to the right you will need to execute double clicks at a correspondingly
faster speed.
You can test the speed setting for double clicks by double-clicking on the
symbol next to the slide switch.

English Wireless keyboard with wireless mouse MTS2220
16
Click on the „Config of the mouse wheel“ tab in the configuration menu in
order to perform the following mouse tilt wheel settings.
Vertical Scrolling
The vertical scrolling function
determines the speed at which the
scroll wheel moves the lines on the
screen up or down. Use the option
“For pages“ in order to scroll
through a document page by page.
Audio Volume Adjustment
Select the option „Adjust the volume“ to adjust the system volume using the
tilt wheel of the mouse. The slide switch puts you in a position to define the
rate of volume change per notch.
Tip for users of Microsoft®Windows Vista™:
You can also adjust the horizontal scrolling of the tilt wheel in the system
control of the operating system in the submenu „Mouse“. The configuration
menu of the mouse driver needs to be closed in order to access the system
control menu.
Configuring the Wireless Keyboard
The wireless keyboard features 22 hotkeys (quick access keys) plus a
volume adjustment button. Following software installation, the special keys
offer the following standard functions. 19 hotkeys can furthermore be freely
programmed according to your requirements.

Wireless keyboard with wireless mouse MTS2220 English
17
Hotkey Description
Standard internet browser (e.g. Internet Explorer)
Standard email programme (e.g. Microsoft®Outlook)
Internet-browser favourites
Forward
Back
Search
Update display
Start pocket calculator
Open desktop
Switch computer on/off *
(Many mainboards feature a BIOS setting such as, for
example, „Boot on USB“, „Power on by USB“, or a
corresponding setting). Activate this function in order to be
able to switch the computer on and off via the keyboard.
Please also consult the documentation of your computer or
main board before activating the BIOS setting.
Initiate sleep mode *
Starting from sleep mode *
Starts the standard media player (e.g. Microsoft®Media
Player)
Play / Pause
Previous title
Next title
Stop replay
Sound on/off
Start Microsoft®Word (needs to be installed)
Start Microsoft®Excel (needs to be installed)
Start Microsoft®Powerpoint (needs to be installed)
Starts the default calendar (e.g. Microsoft®Outlook)
* not freely programmable

English Wireless keyboard with wireless mouse MTS2220
18
Double-click on this symbol in the task bar to configure the programmable
hotkeys (bottom right of your screen, next to the system clock). The following
menu opens:
Now left-click on the symbol corresponding to the hotkey which is to be
changed. This opens the following menu:
Use the top option „Choose a
function“ to select one of the
default programmes. Once this
function is activated by clicking
„OK“, the menu will close and you
can start the selected programme
easily via the corresponding
hotkey.
Selecting the second option
„Select a program to run“ and then
left-clicking on the „Browse“ button
will open this menu (see illustration
on right). Here you can select any
executable file on your computer’s
hard disk which is to be started via
the corresponding hotkey.

Wireless keyboard with wireless mouse MTS2220 English
19
Attachment
Troubleshooting
If after installation the wireless keyboard and the wireless mouse do not
respond, please test the following:
;Check that the batteries have been inserted properly (with the poles
pointing in the right direction).
;Check that the receiver is connected to the computer properly (see
page 11 – Connecting the Miniature USB Receiver).
;Try another USB port.
;Check the battery power (insert new batteries, if required).
;Please note that you need to use a mat (e.g. mouse pad) if you intend
to use the mouse on a glass surface or glossy surface.
If the icons for „Num Lock“, „Caps Lock“ and/or „Scroll Lock“ do not appear in
the task bar, please try the following:
;Check the taskbar settings to see if inactive icons are hidden. Disabled
this function to show all icons at all times.
