DEHUMIDIFIER SLE 450 A1
IAN 111670
DEHUMIDIFIER
Operating instructions
LUFTENTFEUCHTER
Bedienungsanleitung
CPE111670_Luftentfeuchter_Cover_LB6.indd 2 06.03.15 10:06

English..................................................................................... 2
Deutsch.................................................................................. 16
ID: SLE 450 A1_15_V1.3_GB
__CPE111670_B6.book Seite 1 Mittwoch, 11. März 2015 12:51 12

Overview / Übersicht
5
6
1 2 3
4
7
10
12 11
8
9
16
18
1713 15
+
DRY CLOTHES
AIR CLEAN
TARGET-HUMIDITY AUTOMATIC OPERATION
T
ANK F
U
L
L
TIMER
TIMER
RH% Hr.
SETTING
MODE STAND-BY
MID
HIGH
LOW
>75%


192021
14
A
25
22
23
1
B
22
24
23
C
__CPE111670_B6.book Seite 2 Mittwoch, 11. März 2015 12:51 12

2 GB
Contents
1. Overview ........................................................................................ 3
2. Intended purpose ............................................................................ 4
3. Safety information ........................................................................... 5
4. Items supplied ................................................................................. 7
5. How to use ...................................................................................... 7
6. Notes on operation .......................................................................... 7
7. Operation ........................................................................................ 7
7.1 Switching on and off ............................................................................. 7
7.2 Displays............................................................................................... 8
7.3 Modes of operation............................................................................... 9
7.4 Water tank........................................................................................... 9
7.5 Timer................................................................................................. 10
7.6 Child safety lock ................................................................................. 10
8. Hose drainage ............................................................................... 10
9. Cleaning and replacing the filter .................................................... 11
10. Cleaning ........................................................................................ 11
11. Protection against overheating ...................................................... 12
12. Storage ......................................................................................... 12
13. Trouble-shooting ............................................................................ 12
14. Refrigerant .................................................................................... 13
15. Disposal ........................................................................................ 13
16. Technical specifications .................................................................. 14
17. Warranty of the HOYER Handel GmbH ........................................... 14
__CPE111670_B6.book Seite 2 Mittwoch, 11. März 2015 12:51 12

3
GB
1. Overview
1Mobile flap valve for air outlet
2Operating panel
3Handle
4Recessed grip for water tank
5Water tank (5.5 L)
6Rollers
7MAX maximum filling level of the water tank
8Grid for air inlet (removable)
9Storage for mains plug
10 Hook for coiling up the power cable
11 Power cable with safety plug
12 Rating plate
13 TANK FULL LED illuminates when water tank is full
14 TIMER LED illuminates when timer is active
15 Display Indication of humidity in the room;
LC: child safety lock activated;
during adjustment: selected target humidity/switch-off
time
16 Modes of operation LEDs display the active mode
17 OPERATION LED illuminates during operation
18 STAND-BY Switch the device on and off
19 MODE Switch between the 4 modes
20 RH% Hr./ SETTING Set humidity and timer
21 TIMER Switch the timer on and off
22 Plug
23 Fastener for the hose connection
24 Hose
25 Garden hose adapter
Rear fold-out page
26 Float for water level
27 Water tank handle
28 Lid of the water tank
29 Plastic filter
30 Carbon filter
__CPE111670_B6.book Seite 3 Mittwoch, 11. März 2015 12:51 12

4 GB
Thank you for your trust!
Congratulations on your new dehumidifier.
For a safe handling of the product and in or-
der to get to know the entire scope of fea-
tures:
• Thoroughly read these operat-
ing instructions prior to initial
commissioning.
• Above all, observe the safety in-
structions!
• The device should only be used
as described in these instruc-
tions.
• Keep these instructions for refer-
ence.
• If you pass the device on to
someone else, please include
these instructions.
We hope you enjoy your new dehumidifier!
2. Intended purpose
The dehumidifier is intended exclusively for
dehumidifying residential, cellar and stor-
age rooms with a temperature of between
5°C and 35°C.
The device must only be used indoors.
This device must not be used for commercial
purposes.
Foreseeable misuse
DANGER! Risk of illness!
GThe water collected is not suitable
for drinking or for watering plants.
There is a risk of illness.
DANGER! Risk of electric
shock!
Do not place the device in water /
also do not place in pools or pud-
dles of water.
WARNING! Risk of material dam-
age!
~Do not use the device in swimming
pools, washrooms, or any similar
rooms.
~The device is not intended for drying in-
sulation material. If lagging or insulat-
ing material has become damp after a
water pipe has broken, always consult
a specialist.
~Never expose the device to tempera-
tures of 0°C or lower. Residual water in
the piping could freeze and damage
the system.
~Do not use the device in environments
that are dusty or which contain chlorine.
__CPE111670_B6.book Seite 4 Mittwoch, 11. März 2015 12:51 12

5
GB
3. Safety information
Warnings
If necessary, the following warnings will be
used in these operating instructions:
DANGER! High risk: failure to ob-
serve this warning may result in in-
jury to life and limb.
WARNING! Moderate risk: failure to ob-
serve this warning may result in injury or se-
rious material damage.
CAUTION: low risk: failure to observe this
warning may result in minor injury or mate-
rial damage.
NOTE: circumstances and specifics that
must be observed when handling the de-
vice.
Instructions for safe operation
~This device can be used by children from the age of 8 and peo-
ple with restricted physical, sensory or intellectual abilities or
people without adequate experience and/or understanding, if
they are supervised or instructed on how to use this device safely
and if they are aware of the resulting danger. Children must not
play with the device. Cleaning and maintenance by the user
must not be performed by children without supervision.
~Do not install the device in a narrow space. Leave a minimum
clearance of approx. 20 cm at the rear and sides, 10 cm at the
front, and 30 cm at the top.
~The device must only be operated in rooms with a temperature of
between 5°C to 35°C.
~Only use the device in rooms with a size of max. 20 m
2
.
~Only connect the mains plug to a properly installed and easily
accessible grounded wall socket whose voltage corresponds to
the specifications on the rating plate. The wall socket must contin-
ue to be easily accessible after the device is plugged in.
~The appliance shall be installed in accordance with national wir-
ing regulations.
~If the mains power cable of this device should become damaged,
it must be replaced by the manufacturer, the manufacturer's cus-
tomer service department or a similarly qualified specialist, in or-
der to avoid any hazards.
__CPE111670_B6.book Seite 5 Mittwoch, 11. März 2015 12:51 12

6 GB
DANGER for children
~Packing materials are not children's
toys. Children should not be allowed to
play with the plastic bags. There is a
risk of suffocation.
~Keep the device out of the reach of chil-
dren.
DANGER of explosion
~The device must never be operated in
areas with potentially aerosol-forming
or explosive atmosphere.
DANGER! Risk of electric
shock due to moisture
~This device must never be operated
close to a bathtub, shower, filled hand
basin or similar.
~The device, the power cable and the
mains plug must not be immersed in wa-
ter or any other liquids.
~Protect the device from water drops and
water spray.
~If liquid gets into the device (except in
the water container), pull out the mains
plug immediately. Have the device
checked before reusing.
~Never touch the device with wet hands.
~If the device falls into water, disconnect
the mains plug immediately. Only then
is it safe to retrieve the device.
DANGER! Risk of electric
shock
~Ensure that the power cable cannot be
damaged by sharp edges or hot points.
Do not wrap the power cable around
the device.
~The device is not fully disconnected from
the power supply, even after it is
switched off. In order to fully disconnect
it, pull out the mains plug.
~When using the device, ensure that the
power cable cannot be trapped or
crushed.
~When removing the mains plug from the
grounded power socket, always pull on
the plug and never the cable.
~Pull the safety plug out of the grounded
power socket, …
… if there is a fault,
… when you are not using the device,
… before you clean the device, and
… during thunderstorms.
~
Do not use the device if there is visible
damage to the device or the power cable.
~To avoid any risk, do not make modifi-
cations to the device. You also must not
replace the power cable yourself. Re-
pairs must be carried out by a specialist
workshop or the Service Centre.
WARNING! Risk of material damage
~Never place objects filled with liquid on
top of the device, e.g. vases.
~Heavy objects must never be placed on
the device.
~Protect the device from heat.
~The device must not be covered (e.g.
with newspapers, cushions or blankets).
~Never insert objects into the ventilation
slit.
~Open sources of ignition, e.g. burning
candles, must never be placed on or im-
mediately next to the device.
~Place the device somewhere that it will
never be exposed to direct sunlight.
~Place the device on a solid, flat surface.
~Clean the air filter before it becomes
heavily contaminated.
~When draining water through the hose,
ensure that the hose does not become
blocked, and that the open end of the
hose is lower down than the device.
~Only operate the device with the water
tank installed, or the hose attached. The
hose end must be placed over a drain.
~Only use the original accessories.
~Do not use any astringent or abrasive
cleaning agents.
~Only clean the device with a slightly
damp cloth.
__CPE111670_B6.book Seite 6 Mittwoch, 11. März 2015 12:51 12

7
GB
4. Items supplied
1 Dehumidifier with water tank 5
1Hose24
1 Garden hose adapter 25
1 Set of operating instructions
5. How to use
• Remove all packing material.
• Remove all transport packing material.
• Strip off the foil from the operating pan-
el.
• Check to ensure that all parts are pres-
ent and undamaged.
1. Place the device on a level, dry and solid
surface.
2. Let the device rest in its working position
for about 30 minutes, so that the coolant
fluid can settle.
3. Check that the float in the water tank
26
can move freely. To do this, pull out the
empty water tank
5 and turn it upside
down so that the float moves.
4. Check that the water tank
5 is inserted
correctly. If it is installed incorrectly, or if
the water tank has been removed, the
LED
13 TANK FULL will illuminate.
5. Connect the mains plug
11 to a ground-
ed power socket.
6. Notes on operation
• If the relative humidity in residential
rooms is continuously excessive, the
cause should be found and rectified.
(Continuous ventilation - i.e. for several
years - is generally not reasonable.)
• The optimum ambient temperature for
removing humidity from the air is 5°C
to 35°C. Below 5°C, the use of a de-
humidifier is not helpful, as there is only
relatively little humidity in the air.
• During operation, the room temperature
may rise by between 1°C and 4°C,
depending on room size. This is normal.
Automatic defrosting
In order to prevent the device from freezing
over while in continuous operation, it de-
frosts itself automatically. To do this, the de-
humidification process is interrupted, and
the motor switches to its highest setting.
The intervals at which this happens vary.
7. Operation
7.1 Switching on and off
• By pressing the button STAND-BY 18,
you can switch the device on and off.
The corresponding LEDs illuminate or go
out.
- The device will start with the setting
last selected.
• If a timer has been set, the device will
shut down after the time has run out (1-
24 hours).
• If a value has been set for relative hu-
midity in the TARGET-HUMIDITY mode,
the device will stop when the value has
been reached, and re-start when the val-
ue is exceeded again.
• The device switches off when the water
tank is full or has been removed.
Conditions Defrosting
Temperature:
over 20°C no defrosting
Temperature:
12°C to 20°C
after 40 minutes dehu-
midification,
8 minutes defrosting
Temperature:
5°C to 12°C
after 25 minutes dehu-
midification,
10 minutes defrosting
Temperature:
under 5°C operation not possible
__CPE111670_B6.book Seite 7 Donnerstag, 12. März 2015 11:50 11

8 GB
Air outlet flap valve
•Figure A: irrespective of which mode
the device is being operated in, open
the top flap valve 1. It's infinitely adjust-
able. If the flap valve is not opened, the
overheating protection will switch the
device off after a while for approx.
3minutes.
7.2 Displays
The mode of operation LEDs 16 and the dis-
play 15 show the selected functions and the
humidity range.
Mode of operation LEDs
Display
LED illuminated Meaning
TANK FULL The water tank is full or has not been
inserted.
TIMER A switch-off time is
activated.
AIR CLEAN
DRY CLOTHES
TARGET-HUMIDITY
AUTOMATIC
Selected mode
OPERATION The device is
switched on.
Display Meaning
This display can be seen
continuously during oper-
ation. It shows the humid-
ity range in the room:
LOW:
under 65%
MID:
65% to 75%
HIGH:
over 75%
NOTE: this display is not
visible if the child safety
lock is activated.
LC
The child safety lock is
activated. The device
cannot be operated by
using the buttons.
1 -24
flash for 5 sec.
Timer for all modes:
These values (1 - 24 hours)
will flash for 5 seconds
when you use the arrow
keys to select a switch-off
time.
30 - 80 or CO
flash for 5 sec.
Enter relative humidity as
target humidity.
Values between 30 and
80 or CO will flash for
5seconds when
selected.
CO: The device dehu-
midifies continuously.
MID.
LOW
HIGH
MID.
LOW
HIGH
MID.
LOW
HIGH
__CPE111670_B6.book Seite 8 Mittwoch, 11. März 2015 12:51 12

9
GB
7.3 Modes of operation
NOTE: the values selected for relative hu-
midity (RH%) are recognised with an up-
wards or downwards deviation of approx.
3%. This is necessary so that the device does
not constantly switch on and off.
• The device has 4 different modes avail-
able.
• By pressing the button MODE 19, you
can switch between the modes.
• The mode of operation LED 16 over the
active mode blinks for 5 seconds and
then glows permanently.
AUTOMATIC
The setting for the target relative humidity
(RH) is fixed at 55%. The compressor dehu-
midifies until this value has been reached,
and will then switch off. When the relative
humidity rises again, the compressor switch-
es on again.
In this mode, the device operates in 3 differ-
ent stages:
- RH over 70%: the device dehumidifies
at its highest setting.
- RH between 55% and 70%: the device
dehumidifies at its normal setting.
- RH under 55%: no dehumidification,
only the fan is running.
NOTE: the relative humidity values of the
automatic system are not identical to the val-
ues HIGH/MID/LOW on the display15.
Select this mode for continuous dehumidifi-
cation to a pleasant relative humidity of 55%.
TARGET-HUMIDITY
In the TARGET-HUMIDITY mode, you can set
the relative humidity in 5% increments to be-
tween 30% and 80%. The device dehumidi-
fies at a low level until the set value has been
reached, and then deactivates itself. When
the relative humidity rises again, the device
switches on again.
-30 - 80%: setting for the desired relative
humidity in the room.
-CO: the device dehumidifies continu-
ously.
Select this mode for continuous dehumidifi-
cation, or for dehumidification to a value
that you have set.
DRY CLOTHES
You can use this mode in order to dry damp
clothes or shoes faster. The device dehumid-
ifies at its highest setting. Shift the flap
valve1of the air outlet in such a way that
the jet of air is directed towards the items of
clothing to be dried.
AIR CLEAN
No dehumidification takes place with this
mode. The room air is drawn in through the
filter in front of the air inlet, and is cleaned
there.
7.4 Water tank
• The water tank 5has a holding capaci-
ty of 5.5 litres.
• The maximum filling level is indicated
with the marking MAX 7.
• The device can only be operated with
the water tank in place.
• If the water tank 5is full, the LED 13
TANK FULL begins to blink. An alarm
sounds for approx. 20 seconds. The de-
vice switches off after a few seconds.
The TANK FULL LED13 flashes until the
tank has been emptied.
1. Figure D: in order to empty the water
tank
5 , pull it out slightly on the left and
right-hand sides, and then carry it by the
handle
27 .
2. Pour the water out and place the tank
back in the device.
__CPE111670_B6.book Seite 9 Donnerstag, 12. März 2015 11:50 11

10 GB
7.5 Timer
• The timer can be combined with all
4modes.
• There are 24 switch-off times that can
be selected, from 1 to 24 hours.
• After the expiry of the time that has
been set, the device is shut down and
the timer function is terminated.
1. During operation, press the TIMER 21
button. The TIMER LED 14 will flash.
2. Use the arrow keys
20 to select a switch-
off time of between 1 to 24hours. The se-
lected time flashes in the display
15 for
5seconds and is then saved.
• If you want to end the timer earlier than
the set time, press TIMER 21 twice or
switch the device off by pressing
STAND-BY 18.
7.6 Child safety lock
• You can switch on the child safety lock
during operation.
• If the child safety lock is switched on,
the device cannot be operated using the
buttons.
1. To activate the child safety lock, hold
down the button
MODE 19 for approx.
5 seconds until
LC appears on the dis-
play
15 . The buttons are locked.
2. To deactivate the child safety lock, hold
down the button
MODE 19 again for
approx. 5 seconds until
LC disappears
from the display
15 . The device can now
be operated again by using the buttons.
8. Hose drainage
In the case of very damp rooms it often
makes more sense to discharge the water di-
rectly through a hose, instead of collecting it
in the water tank. Check the connection sys-
tem regularly for tightness.
• For the hose drainage you can either
use the supplied hose 24 or connect a
garden hose.
WARNING! During hose drainage, the de-
vice runs in continuous mode. This means
that the water collected must be able to
drain reliably, otherwise puddles will form
on the floor.
1. Figure B/C: unscrew the fastener 23
on the rear.
2. Remove the plug
22 .
3.
Figure B: Supplied hose 24 : place
the supplied hose on the opening.
Figure C: Garden hose: screw the
garden hose adapter
25 onto the open-
ing. Pay special attention to the correct fit
of the sealing ring. Now screw the gar-
den hose onto the adapter.
WARNING! Only hand-tighten the adapt-
er. Do not use any wrenches, as this could
damage the adapter.
NOTE: depending on the garden hose sys-
tem used, a further adapter could be re-
quired. This can be purchased at specialist
retailers.
4. Place the device in a position where the
end of the hose is over a drain. The open
end of the hose should lie below the outlet
of the device. (The hose should be in-
clined.)
5. Switch the device on as described above
and select a mode.
__CPE111670_B6.book Seite 10 Mittwoch, 11. März 2015 12:51 12

11
GB
6. If you want to drain into the water tank 5
again, switch off the device. Pull off the
hose
24 or unscrew the garden hose and
adapter
25 . Insert the plug 22 tightly
again into the opening.
9. Cleaning and
replacing the filter
The performance of the device also depends
on the cleanliness of the filter.
•Thecarbonfilter30 should be cleaned
every 2 weeks and replaced every
6months. Clean the filter by brushing
or vacuum suction.
• The normal plastic filter 29 should be
washed every 2 weeks.
1. Switch the device off and pull out the
mains plug
11 .
2.
Figure F: pull the grid 8 away from the
device using the handle and remove it
downwards.
3. Turn the grid
8 around. Insert one finger
into the recess on the plastic filter
29 and
pull it upwards to remove it.
4. Remove the carbon filter
30 and clean it.
(The carbon filter
30 should be replaced
after approx. 6 months.)
5. Wash the plastic filter
29 with lukewarm
water.
6. Let the plastic filter
29 dry completely.
7. Place the filters into the grid
8 .
8. Place the grid
8 onto the device. Press the
grid down all around to ensure that it clos-
es flush with the surface.
NOTE: new carbon filters are available in
almost all household goods shops. The pads
just need to be cut to size.
10. Cleaning
Clean the device prior to its first use!
DANGER! Risk of electric
shock!
~Pull the mains plug 11 out of the
grounded power socket before you
clean the device.
~The device, the power cable and the
mains plug 11 must not be immersed in
water or any other liquids.
WARNING! Risk of material dam-
age!
~Do not use any astringent or abrasive
cleaning agents.
• Wipe the housing and the power ca-
ble11 with a damp cloth if necessary.
• Remove the water tank 5, pour out the
water, and dry the tank well from the
outside before re-inserting it into the de-
vice.
Cleaning the water tank
We recommend cleaning and disinfecting
the water tank approximately every two
weeks in order to prevent the formation of
moulds and bacteria.
1. Figure E: fold the handle of the water
tank
27 in such a way that you can press
it out of the attachments on the sides. Re-
move the handle.
2. Take out the lid of the water tank
28 .
3. Clean the inside of the water tank
5 with
lukewarm water and mild detergent and
rinse out several times with fresh water.
4. For the purposes of disinfection, use a
commercially available disinfectant on an
alcohol base or high-percentage alcohol.
Then rinse thoroughly with clean water.
5. If you are not going to use the device for
an extended period of time, dry the inside
of the water tank
5 completely.
6. Put the lid
28 and the handle 27 back in
place.
7. Put the water tank
5 back into the device.
__CPE111670_B6.book Seite 11 Mittwoch, 11. März 2015 12:51 12

12 GB
11. Protection against
overheating
The device has an overheating protection
system.
• The overheating protection system will
switch the device off automatically if
there is a risk of overheating.
• It is then impossible to switch the device
on again for 3 minutes.
• After approx. 3 minutes, the device
starts automatically.
• Check whether external conditions
could have triggered the overheating
protection system, e.g. temperature
above 35°C or a closed flap valve 1
over the air outlet.
12. Storage
DANGER for children!
~Keep the device out of the
reach of children.
• Always store the device in an upright
position.
• Select a location where neither frost,
high temperatures nor moisture can af-
fect the device.
13. Trouble-shooting
If your device fails to function as required,
please try this checklist first. Perhaps there is
only a minor problem, and you can solve it
yourself.
DANGER! Risk of electric
shock!
~Do not attempt to repair the device your-
self under any circumstances.
Fault Possible causes/Action
No function
• Has the device been
connected to the power
supply?
• Check the water level in
the water tank 5.
• Check the position of
the water tank.
• The overheating protec-
tion system has
switched the device off.
Wait for approx. 3 min-
utes.
•Thedevicewas
switched off shortly be-
forehand. Wait for a
few minutes.
The dehumid-
ification
does not
seem to be
working very
well.
• Are the filters 29, 30
dirty?
• Is the air inlet 8 blocked?
• The temperature is low.
• Is the device operating
in AIR CLEAN mode?
No dehumidification
takes place with this
program.
• Is a window open, or
has steam been generat-
ed in the room?
Excessive
noise • Is the device standing on a level, solid surface?
__CPE111670_B6.book Seite 12 Mittwoch, 11. März 2015 12:51 12

13
GB
14. Refrigerant
EU 517/2014: This air-conditioning device
contains the refrigerant R134a. However,
the quantity of refrigerant is less than 1 kg
and it is contained in an enclosed cooling
circuit. Although the refrigerant does not
have any ozone-depleting potential, accord-
ing to the Kyoto Protocol it is a so-called
greenhouse gas and can therefore contrib-
ute to global warming if it is released into
the atmosphere. For this reason, only trained
technicians with a refrigerant certificate are
allowed to fill or empty the appliance. Your
air-conditioning device does not have to be
refilled with refrigerant if it is correctly used
and the refrigerant circuit is undamaged.
GWP: 1430
15. Disposal
The symbol showing a wheel-
ie bin crossed through indi-
cates that the product requires
separate refuse collection in
the European Union. This ap-
plies to the product and all ac-
cessories marked with this symbol. Products
identified with this symbol may not be dis-
carded with normal household waste, but
must be taken to a collection point for recy-
cling electric and electronic appliances. Re-
cycling helps to reduce the consumption of
raw materials and protect the environment.
Packaging
When disposing of the packaging, make
sure you comply with the environmental reg-
ulations applicable in your country.
Refrigerant
This device contains the refrigerant R134a
and must be returned undamaged for prop-
er disposal.
Occasion-
ally the
device stops
working.
• Room temperature
above 35°C?
• Room temperature be-
low 5°C?
• Defrosting mode is ac-
tive.
Damp cloth-
ing is not
drying, or is
only drying
very slowly.
• Is the air flow from the
device directly pointed
at the damp clothing?
• Is the room temperature
too low?
Fault Possible causes/Action
__CPE111670_B6.book Seite 13 Mittwoch, 11. März 2015 12:51 12

14 GB
16. Technical
specifications
Subject to technical modification.
17. Warranty of the
HOYER Handel GmbH
Dear Customer,
your device is provided with a 3 year war-
ranty starting with the purchase date. In the
event of product defects, you are entitled to
statutory rights against the vendor. These
statutory rights are not restricted by our war-
ranty presented in the following.
Warranty conditions
The warranty period starts with the purchase
date. Please keep the original purchase re-
ceipt in a safe place. This document is re-
quired to verify the purchase.
If within three years from the purchase date
of this product a material or factory defect
occurs, the product will be repaired or re-
placed by us – at our discretion – free of
charge to you. This warranty implies that
within the period of three years the defective
device and the purchase receipt are present-
ed, including a brief written description of
the defect and the time it occurred.
If the defect is covered by our warranty, the
repaired or a new product will be returned
to you. No new warranty period starts with
a repair or replacement of the product.
Warranty period and statutory
claims for defects
The warranty period is not extended when
the warranty has been claimed. This also ap-
plies to replaced and repaired parts. Any
damages and defects already existing at the
time of purchase must be reported immedi-
ately upon unpacking. Repairs arising after
the expiration of the warranty period are
subject to a charge.
Warranty coverage
The device was produced carefully according
to strict quality guidelines and tested diligent-
ly prior to delivery.
Model: SLE 450 A1
Mains voltage : 220 - 240 V~ 50 Hz
Protection class: I
Input power: 360 W (27°C 60%)
Power rating max.: 450 W
(35°C 90%)
Nominal current: 2.15 A (27°C 60%)
Power consump-
tion: max.2.40 A (35°C 90%)
Dehumidification
capacity:
20 L /day (30°C 80%)
11 L /day (27°C 60%)
Air flow: 195 m
3
/h
Coolant /
Volume: R134a/95g
Coolant group: L1
Water tank: 5.5 l
Room size: 20m
2
‚ (Rh. 2.3m)
Room
temperature: 5 - 35°C
Weight: 14.5 kg
Dimensions:
WxDxH 370 x 270 x 610 mm
Noise level: 46 dB(A)
Intake pressure: 0.5 MPa
Exhaust pressure: 1.5 MPa
__CPE111670_B6.book Seite 14 Donnerstag, 12. März 2015 11:50 11

15
GB
The warranty applies to material or factory
defects. This warranty does not include prod-
uct parts that are subject to standard wear
and therefore can be considered wear parts;
the same applies to damages at fragile parts,
e.g. switches, rechargeable batteries or parts
made of glass.
This warranty expires if the product is dam-
aged, not used as intended or not serviced.
For the proper operation of the product, all in-
structions listed in the operating instructions
must be observed carefully. Any form of use
and handling that is advised against in the
operating instructions or warned against
must always be avoided.
The product is only intended for private and
not for commercial use. In the case of incor-
rect and improper treatment, use of force and
interventions not performed by our author-
ised Service Centre, the warranty shall cease.
Handling in case of a warranty
claim
In order to ensure prompt processing of your
matter, please observe the following notes:
• Please keep the article number
IAN: 111670 and the purchase receipt
as a purchase verification for all inquiries.
• If faulty operation or other defects occur,
first contact the Service Centre listed in
the following by telephone or email.
• Then, you are able to send a product re-
ported as defective free of charge to the
service address specified to you, includ-
ing the purchase receipt and the infor-
mation on the defect and when it
occurred.
Please visit www.lidl-service.com to
download this and many other
manuals, product videos and soft-
ware.
Service Centre
Service Great Britain
Tel.: [phone] (£ 0.10/Min.)
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: [email protected]
IAN: 111670
Supplier
Please note that the following address is no
service address. First contact the afore-
mentioned Service Centre.
HOYER Handel GmbH
Kühnehöfe 5
22761 Hamburg
Germany
GB
IE
__CPE111670_B6.book Seite 15 Mittwoch, 11. März 2015 12:51 12

16 DE
Inhalt
1. Übersicht ....................................................................................... 17
2. Bestimmungsgemäßer Gebrauch .................................................... 18
3. Sicherheitshinweise ....................................................................... 19
4. Lieferumfang ................................................................................. 21
5. Inbetriebnahme ............................................................................. 21
6. Hinweise zum Betrieb .................................................................... 21
7. Bedienung ..................................................................................... 22
7.1 Ein- und Ausschalten ............................................................................ 22
7.2 Anzeigen ........................................................................................... 22
7.3 Programme ........................................................................................ 23
7.4 Wassertank ........................................................................................ 23
7.5 Timer ................................................................................................. 24
7.6 Kindersicherung .................................................................................. 24
8. Schlauchentwässerung .................................................................. 24
9. Filter reinigen und tauschen ........................................................... 25
10. Reinigen ........................................................................................ 25
11. Schutz vor Überhitzung .................................................................. 26
12. Aufbewahrung .............................................................................. 26
13. Problemlösung .............................................................................. 26
14. Kältemittel ..................................................................................... 27
15. Entsorgen ...................................................................................... 27
16. Technische Daten ........................................................................... 28
17. Garantie der HOYERHandel GmbH ................................................ 28
__CPE111670_B6.book Seite 16 Mittwoch, 11. März 2015 12:51 12

17
DE
1. Übersicht
1bewegliche Klappe für den Luftauslass
2Bedienfeld
3Tragegriff
4Griffmulde für den Wassertank
5Wassertank (5,5 L)
6Rollen
7MAX maximale Füllhöhe des Wassertanks
8Gitter für Lufteinlass (abnehmbar)
9Aufbewahrung für Netzstecker
10 Haken zum Aufwickeln der Anschlussleitung
11 Anschlussleitung mit Schutzkontaktstecker
12 Typenschild
13 TANK FULL LED leuchtet, wenn der Wassertank voll ist
14 TIMER LED leuchtet, wenn der Timer aktiv ist
15 Display Anzeige der Luftfeuchtigkeit im Raum;
LC: Kindersicherung aktiviert;
beim Einstellen: gewählte Ziel-Luftfeuchtigkeit/Aus-
schaltzeit
16 Programme LEDs zeigen das aktive Programm an
17 OPERATION LED leuchtet während des Betriebs
18 STAND-BY Schaltet das Gerät ein und aus
19 MODE schaltet zwischen den 4 Programmen um
20 RH% Hr./ SETTING Luftfeuchtigkeit und Timer einstellen
21 TIMER Zeitschaltuhr ein- und ausschalten
22 Pfropfen
23 Verschluss für Anschluss des Schlauches
24 Schlauch
25 Gartenschlauch-Adapter
Hintere Ausklappseite
26 Schwimmer für Wasserstand
27 Griff des Wassertanks
28 Deckel des Wassertanks
29 Kunststofffilter
30 Kohlefilter
__CPE111670_B6.book Seite 17 Mittwoch, 11. März 2015 12:51 12

18 DE
Herzlichen Dank für Ihr
Vertrauen!
Wir gratulieren Ihnen zu Ihrem neuen Luft-
entfeuchter.
Für einen sicheren Umgang mit dem Produkt
und um den ganzen Leistungsumfang ken-
nenzulernen:
• Lesen Sie vor der ersten Inbe-
triebnahme diese Bedienungsan-
leitung gründlich durch.
• Befolgen Sie vor allen Dingen die
Sicherheitshinweise!
• Das Gerät darf nur so bedient
werden, wie in dieser Anleitung
beschrieben.
• Bewahren Sie diese Anleitung
auf.
• Falls Sie das Gerät einmal wei-
tergeben, legen Sie bitte diese
Bedienungsanleitung dazu.
Wir wünschen Ihnen viel Freude mit Ihrem
neuen Luftentfeuchter!
2. Bestimmungsgemäßer
Gebrauch
Der Luftentfeuchter ist ausschließlich zum
Entfeuchten von Wohn-, Keller- oder Lager-
räumen mit einer Temperatur von 5°C bis
35°C vorgesehen.
Das Gerät darf nur in Innenräumen benutzt
werden.
Dieses Gerät darf nicht für gewerbliche
Zwecke eingesetzt werden.
Vorhersehbarer Missbrauch
GEFAHR von Krankheiten!
GDas gesammelte Wasser ist nicht
zum Trinken oder Wässern geeig-
net. Es besteht Gesundheitsgefahr.
GEFAHR durch Stromschlag!
Stellen Sie das Gerät nicht in Was-
ser / auch nicht in Wasserlachen
oder Pfützen.
WARNUNG vor Sachschäden!
~Benutzen Sie das Gerät nicht in
Schwimmbädern, Wasch- oder ähnli-
chen Räumen.
~Das Gerät ist nicht für die Trocknung
von Dämmung geeignet. Falls nach ei-
nem Rohrbruch Isolierung oder Dämm-
material feucht geworden sind, fragen
Sie auf jeden Fall einen Fachmann.
~Setzen Sie das Gerät niemals Tempera-
turen von 0 °C oder weniger aus. Rest-
wasser in den Leitungen könnte
gefrieren und das System beschädigen.
~Verwenden Sie das Gerät nicht in stau-
biger oder chlorhaltiger Umgebung.
__CPE111670_B6.book Seite 18 Mittwoch, 11. März 2015 12:51 12
