Silvercrest SSMW 750 D1 User manual

IAN 317891_1901
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY
Model-Nr.: HG05427
Version: 06/2019
Page size: 143 mm x 210 mm done by Impala Services Limited
143 mm 143 mm

IAN 317891_1901
SANDWICH TOASTER SSMW 750 D1
SANDWICH TOASTER
Operation and safety notes
VOILEIPÄGRILLI
Käyttö- ja turvaohjeet
SMÖRGÅSGRILL
Bruksanvisning och säkerhetsanvisningar
OPIEKACZ
Wskazówki dotyczące obsługi i bezpieczeństwa
SUMUŠTINIŲ KEPTUVAS
Naudojimo ir saugos pastabos
SANDWICHMAKER
Bedienungs- und Sicherheitshinweise
143 mm 138 mm

138 mm
GB Operation and safety notes Page 5
FI Käyttö- ja turvaohjeet Sivu 18
SE Bruksanvisning och säkerhetsanvisningar Sidan 31
PL Wskazówki dotyczące obsługi i bezpieczeństwa Strona 44
LT Naudojimo ir saugos pastabos Psl 57
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 70

143 mm138 mm
8
5
6
7
321
4
111213
9
10

143 mm 143 mm

143 mm

5GB
Warnings and symbols used ............................................. Page 6
Introduction ................................................................ Page 6
Intended use.................................................................. Page 6
Scope of delivery.............................................................. Page 7
Description of parts ............................................................ Page 7
Technical data ................................................................ Page 7
Safety instructions......................................................... Page 7
Before first use ............................................................. Page 10
Assembly ................................................................... Page 10
Operation................................................................... Page 11
Grilling sandwiches ............................................................ Page 11
Grilling ...................................................................... Page 11
Baking waffles ................................................................ Page 12
Recipes ...................................................................... Page 12
Tuna sandwich ................................................................ Page 12
Turkey sandwich............................................................... Page 13
Belgian waffles................................................................ Page 13
Blueberry waffles .............................................................. Page 13
Ham and cheese waffles ........................................................ Page 14
Brownie Belgian waffles......................................................... Page 14
Shrimp and plum kebabs ........................................................ Page 15
Cleaning and care ......................................................... Page 15
Troubleshooting............................................................ Page 16
Storage ..................................................................... Page 16
Disposal..................................................................... Page 16
Warranty ................................................................... Page 17

6 GB
Warnings and symbols used
The following warnings are used in this user manual and on the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks a
high-risk hazard that if not prevented could
result in death or serious injury.
Voltage (alternating current)
Hertz (supply frequency)
Watts
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
Use the product in dry indoor spaces only.
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
Danger – risk of electric shock!
Caution, hot surface
This appliance is classified as protection
class I and must be connected to a
protective ground.
Food safe. This product has no adverse
effect on taste or smell.
The exchangeable plates
11
,
12
and
13
are dishwasher-safe.
SANDWICH TOASTER
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Intended use
This product is designed for making waffles,
sandwiches, and for grilling food. Do not use it for
any other purpose.
This product is only intended for private household
use, not for commercial purposes.
The manufacturer accepts no liability for damages
caused by improper use.

7GB
Scope of delivery
After unpacking the product, check if the delivery
is complete and if all parts are in good condition.
Remove all packing materials before use.
1x Sandwich toaster
3x Exchangeable plate sets
1x Instruction manual
Description of parts
1Lock
2Red indicator (power)
3Green indicator (ready)
4Power cord with power plug
5Power cord retainer
6Heating element
7Large hook catches
8Release lever
9Outer catch (small)
10
Inner catch (large)
11
Sandwich plate (upper and lower plate)
12
Grill plate (upper and lower plate)
13
Waffle plate (upper and lower plate)
Technical data
Input voltage: 220–240 V~, 50/60 Hz
Power consumption: 750 W
Protection class: I
TÜV SÜD / GS-certified
Safety instructions
BEFORE USING THE PRODUCT,
PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE
SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN
PASSING THIS PRODUCT ON TO
OTHERS, PLEASE ALSO INCLUDE
ALL THE DOCUMENTS!
In the case of damage resulting from
non-compliance with these operating
instructions the warranty claim
becomes invalid!
No liability is accepted for
consequential damage! In the case
of material damage or personal
injury caused by incorrect handling
or non-compliance with the safety
instructions, no liability is accepted!
Children and persons with
disabilities
m WARNING! RISK OF LOSS
OF LIFE OR ACCIDENT TO
INFANTS AND CHILDREN!
Never leave children
unsupervised with the packaging
material. The packaging
material represents a danger of
suffocation.
Children frequently underestimate
the dangers. Always keep
children away from the
packaging material.

8 GB
This product can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities, or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the product in
a safe way and understand the
hazards involved.
Children shall not play with the
product.
Cleaning and user maintenance
shall not be made by children
unless they are older than 8 and
supervised.
Keep the product and its cord
out of reach of children less than
8 years.
Intended use
m WARNING! Misuse may
lead to injury. Use this product
solely in accordance with these
instructions. Do not attempt to
modify the product in any way.
Electrical safety
m DANGER! Risk of electric
shock! Never attempt to repair
the product yourself. In case of
malfunction, repairs are to be
conducted by qualified personnel
only.
DANGER! Risk of burns!
During use the product gets hot.
Do not touch the product while in
use nor immediately after use.
m WARNING! Risk of electric
shock! Do not immerse the
product in water or other liquids.
Never hold the product under
running water.
m WARNING! Risk of electric
shock! Never use a damaged
product. Disconnect the product
from the power supply and
contact your retailer if it is
damaged.
The product is not to be used if
it has been dropped, if there are
visible signs of damage.
The product is powered at all
times while it is connected to the
power supply.

9GB
Before connecting the product
to the power supply, check that
the voltage and current rating
corresponds with the power
supply details shown on the
product’s rating label.
Regularly check the power plug
and the power cord for damages.
If the power cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
Protect the power cord against
damages. Do not let it hang over
sharp edges, do not squeeze or
bend it. Keep the power cord
away from hot surfaces and open
flames.
Operation
The product must not be left
unattended while it is connected
to the supply mains.
Do not move the product while it
is in operation.
Do not use the product without an
inserted set of plates.
Do not place the product on hot
plates (gas, electric, coal cooking
range etc.). Operate the product
on a level, stable, clean, heat-
resistant and dry surface.
Do not cover the product while it
is in use or shortly after use, when
it is still hot.
Make sure that the power cord
is not pinched by the plates or
touches the rim of the plates.
The use of extension cords is not
recommended.
If the use of an extension cord is
necessary, it must be designed for
a current flow of at least 10 A.
Lay cords in such a way that
they may not be tripped over or
otherwise damaged.
The product is not intended to
be operated by means of an
external timer or separate remote-
control system.

10 GB
Cleaning and storage
m WARNING! Risk of injury!
Disconnect the product from the
power supply before cleaning
work and when not in use.
Do not store the hot product in a
cupboard or in the packaging.
Do not pull the power plug out of
the electrical outlet by the power
cord.
Protect the product, its power
cord and power plug against
dust, direct sunlight, dripping and
splashing water.
Store the product in a cool, dry
place, protected from moisture
and out of the reach of children.
Protect the product against heat.
Do not place the product close to
open flames or heat sources such
as stoves or heating appliances.
Before first use
Remove the packaging. Check if all parts are
complete.
During production, some parts are covered with a
thin oil film for their protection.
Before first use, operate the product without any
food so that any potential residues evaporate.
Clean the product and its accessories (see the
“Cleaning and care” section).
NOTES:
The first few times the product is heated up, a
faint odour may be present. Ensure sufficient
ventilation in the area.
Discard the first set of waffles.
Assembly
mWARNING! Risk of electric shock. Before
installing/removing the plates
11
,
12
,
13
:
Disconnect the power plug 4from the wall
outlet.
DANGER! Risk of burns. Do not change/
remove the plates
11
,
12
,
13
right after
operation. Let the product cool first.
Installing the plates
Open the lock 1. Open the product.
Place the inner catch
10
of the chosen plate into
the large hook catches 7.
Push down the plate until it clicks in place.
Repeat on the other side of the product.
NOTE: Install only plates of the same type.
Removing the plates
Open the lock 1. Open the product.
Pull the release levers 8. Remove the plate.
Repeat on the other side of the product.

11GB
Operation
Preparation: Grease the upper and lower
exchangeable plates
11
,
12
,
13
with suitable
cooking oil.
Turning the product on: Connect the power plug
4to a suitable wall outlet. The red indicator 2
lights up.
Turning the product off: Disconnect the power
plug from the wall outlet. The red indicator 2
goes off.
Keep the product locked while preheating.
Preheat until the green indicator 3lights up.
Light indicator Status
Red indicator 2on Product on.
Red indicator 2off Product off.
Green indicator 3off Product is preheating/
reheating.
Green indicator 3on The baking temperature
has been reached.
NOTE: During operation, the green indicator 3
goes on and off from time to time. This indicates
that the product is reheating up to the baking
temperature.
This product is designed for making waffles,
sandwiches, and for grilling food (see the
following sections).
Suggested baking/grilling times
Sandwiches 3 to 4 minutes
Grilling 4 to 9 minutes
(check the degree of
browning from time
to time)
Waffles (sweet/savoury) 5 minutes
For reference only (see the “Recipes” section for
estimated cooking times)
Grilling sandwiches
Suitable for: Sandwich pockets with sweet or savoury
filling
Plates:
Sandwich plates (upper and lower plate)
11
Open the lock 1. Open the product.
Place 2 prepared sandwiches onto the lower
sandwich plate
11
.
Close the product. Close the lock 1. The
sandwiches are grilled now.
NOTE: Grilling takes approx. 3 to 4 minutes.
Depending on how crunchy you want your
sandwiches to be, the baking time may be
shortened or increased.
Removing sandwiches: Use a plastic/wooden
spatula (or other suitable non-metallic tools) to
avoid damaging the product's non-stick coating.
While the sandwiches are being grilled, the green
indicator 3will turn off and on again. This is to
regulate the required operating temperature.
When you are done with grilling: Disconnect the
power plug 4from the wall outlet.
Grilling
Suitable for: Grilling smaller meat chunks, sausages,
or vegetables
Plates:
Grill plates (upper and lower plate)
12
Open the lock 1. Open the product.
Place the food to be grilled onto the lower grill
plate
12
.
Close the product. Close the lock 1. The food is
grilled now.
mCAUTION! Danger of splashes. Do not
use wet food for grilling. Fat splashes and rising
steam will occur when opening the product.

12 GB
NOTE: Grilling takes approx. 4 to 9 minutes.
Check the degree of browning from time to time.
Removing the grilled food: Use a plastic/wooden
spatula (or other suitable non-metallic tools) to
avoid damaging the product's non-stick coating.
While the food is grilled, the green indicator
3will turn off and on again. This is to regulate
the required operating temperature.
When you are done with grilling: Disconnect the
power plug 4from the wall outlet.
Baking waffles
Suitable for: Sweet and savoury waffles
Plates:
Waffle plates (upper and lower plate)
13
Open the lock 1. Open the product.
Use a wooden or heat-resistant plastic ladle to
pour batter onto the lower waffle plate
13
. Do
not use metal ladles, as this could damage the
non-stick surface of the plates.
Do not overfill the lower waffle plate
13
with
batter.
Close the product. Close the lock 1. The batter
is cooked now.
NOTE: The baking process takes
approx.5 minutes. Depending on how brown
you want your waffles to be, the baking time may
be shortened or increased.
Removing waffles: Use a plastic/wooden spatula
(or other suitable non-metallic tools) to avoid
damaging the product's non-stick coating.
While the waffles are baking, the green indicator
3will turn off and on again. This is to regulate
the required operating temperature.
When you are done with cooking: Disconnect the
power plug 4from the wall outlet.
Recipes
Tuna sandwich
Plates:
Sandwich plates (upper and lower plate)
11
Ingredients:
4 slices Toast bread
85 g Tahini
85 g Low fat Greek yogurt
80 g Tuna
65 g Fresh basil
1 Squeezed lemon
14 ml Olive oil
1 pinch Salt
1 pinch Pepper
Preparation:
Preheat the product.
Blend tahini, Greek yogurt and lemon juice until
combined.
Add basil, salt and pepper. Blend until combined.
Add the olive oil into the tahini yogurt sauce.
Spread the tahini yogurt sauce over 2 bottom
toast bread slices.
Spread drained tuna on top.
Top with remaining toast bread slices.
Bake for about 4 minutes.
Serve immediately.

13GB
Turkey sandwich
Plates:
Sandwich plates (upper and lower plate)
11
Ingredients:
4 slices Toast bread
2slices Young Gouda cheese
50 g Sliced turkey breast
10 g Mustard
½ Onion
1 pinch Salt
1 pinch Pepper
Preparation:
Preheat the product.
Spread mustard on the inside of the toast bread
slices.
Chop the onion into small pieces.
Spread the turkey breast and onion over
2 bottom toast bread slices.
Sprinkle with salt and pepper.
Spread the cheese slices on top.
Top with remaining toast bread slices.
Bake for about 4 minutes.
Serve immediately.
Belgian waffles
Plates:
Waffle plates (upper and lower plate)
13
Ingredients:
5Eggs
250 g Butter
200 g Sugar
400 ml Milk
500 g Flour
2 packets Vanilla sugar
5 g Baking powder
Preparation:
Preheat the product.
In a medium bowl combine egg, vanilla sugar,
sugar and butter.
Add baking powder, around half of the flour and
half of milk into the bowl and stir.
Add the rest of flour and milk, then stir until the
batter become creamy.
Spray both exchangeable plates with cooking
spray.
Evenly spoon the batter onto the lower plate.
Bake for 5 minutes.
Blueberry waffles
Plates:
Waffle plates (upper and lower plate)
13
Ingredients:
120 ml Vegetable oil
250 ml Milk
2Eggs
200 g Sugar
170 g Flour
2.5 g Baking powder
130 g Blueberries (fresh or frozen)
Preparation:
Preheat the product.
In a large bowl, whisk together the oil, milk, eggs,
and sugar. Add the flour, baking powder and stir
until well combined.
Fold in the blueberries.
Spray both exchangeable plates with cooking
spray.
Evenly spoon the batter onto the lower plate.
Bake for about 10 minutes, until golden brown.

14 GB
Ham and cheese waffles
Plates:
Waffle plates (upper and lower plate)
13
Ingredients:
570 g Package refrigerated hash brown
potatoes
225 g Black forest ham, diced
200 g Shredded cheddar cheese
3 Large eggs, beaten
2 cloves Garlic (minced)
2 tsp Chopped fresh parsley leaves
½ tsp Dried thyme
¼ tsp Smoked paprika
Salt and freshly ground black pepper, to taste
Preparation:
Thaw the hash brown potatoes.
Preheat the product.
Spray both exchangeable plates with cooking
spray.
In a large bowl, combine hash brown potatoes,
ham, cheese, eggs, garlic, parsley, thyme and
paprika. Season with salt and pepper, to taste.
Evenly spoon the potato mixture onto the lower
plate. Bake for about 15 minutes, until golden
brown and crisp.
Serve immediately.
Brownie Belgian waffles
Plates:
Waffle plates (upper and lower plate)
13
Ingredients:
180 g All purpose flour
65 g Unsweetened cocoa powder
20 g Granulated sugar
1 tsp Baking powder
1 tsp Sea salt
10 tbsp Melted unsalted butter
2 Large eggs
2 tsp Vanilla extract
60 ml Water
120 g Mini chocolate chips
Optional toppings: Vanilla ice cream, chocolate
sauce, powdered sugar
Preparation:
Preheat the product. In a large bowl, mix the
flour, cocoa powder, sugar, baking powder, and
salt. Melt the butter and set aside to cool a little.
In a small bowl, beat the eggs, vanilla extract,
and water. Whisk the egg mixture into the dry
mixture, then quickly mix in the melted butter. Stir
in the chocolate chips.
Spray both exchangeable plates with cooking
spray.
Evenly spoon the batter onto the lower plate.
Bake for about 3 minutes.
Lift the lid to check the waffle. The waffle should
be fully formed, but soft to the touch.
Serve with powdered sugar, vanilla ice cream or
chocolate sauce.

15GB
Shrimp and plum kebabs
Plates:
Grill plates (upper and lower plate)
12
Ingredients:
2 tbsp Canola oil
2 tbsp Cilantro (chopped fresh)
1 tsp Lime zest (freshly grated)
3 tbsp Lime juice
½ tsp Salt
12 Raw shrimps (8 to 12 shrimps per
500 g / peeled and deveined)
3 Jalapeño peppers (stemmed, seeded
and quartered lengthwise)
2 Plums (pitted and cut into sixths)
Preparation:
Preheat the product.
In a large bowl, whisk canola oil, cilantro, lime
zest, lime juice and salt.
Set aside 3 tablespoons of the mixture in a small
bowl.
Add shrimp, jalapeños and plums to the
remaining marinade. Toss the mixture to coat and
marinade.
Alternate shrimps, jalapeños and plums evenly
among 4 skewers (25 cm). Discard the marinade.
Grill the kebabs until the shrimp are cooked
through. Turn the kebabs once. Grill for about
2 minutes on each side.
Drizzle with the remaining dressing.
Cleaning and care
mDANGER! Risk of electric shock! Before
cleaning: Always disconnect the product from the
wall outlet.
DANGER! Risk of burns! Do not clean the
product right after operation. Let the product cool
first.
mWARNING! Do not immerse the product’s
electrical components in water or other liquids.
Never hold the product under running water.
NOTE: Clean the product right after it has
cooled. Once the food residues have dried, they
are not easy to remove.
Part Cleaning method
Sandwich
toaster
Wipe down the housing
with a slightly damp cloth.
Do not let any water or
other liquids enter the
product interior.
Plates
11
,
12
,
13
Rinse the plates in water
and/or mild detergent.
You can also clean the
plates in the dishwasher.
Spaces
underneath the
plates
Heating
element 6
Lock 1
Removing fat and liquids:
Use a piece of kitchen
paper.
Removing stuck-on burnt
residues: Use a wooden
spatula or small wooden
skewers.

16 GB
Do not use any abrasive, aggressive cleaners
or hard brushes to clean the product or its
accessories.
After cleaning: Let all parts dry.
Troubleshooting
Problem Solution
The product is
not working. Connect the power cord 4
with a suitable wall outlet.
The waffles/
sandwiches are
too dark.
Shorten the baking time.
The waffles/
sandwiches are
too light.
Extend the baking time.
The finished
waffles/
sandwiches
are difficult to
remove from
the product.
Lightly grease the plates
11
,
13
before baking.
Try using a different batter
recipe.
Storage
DANGER! Risk of burns! Do not store the
product right after operation. Let the product cool
first.
Clean the product before storage.
Wind the power cord
4
around the power cord
retainer
5
on the bottom of the product.
Store the product in the original packaging when
it is not in use.
Store the product at a dry location out of the
reach of children.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning: 1 – 7:
plastics / 20 – 22: paper and fibreboard /
80 – 98: composite materials
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal authority
for more details of how to dispose of your
worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information on
collection points and their opening hours
can be obtained from your local authority.

17GB
Warranty
The product has been manufactured to strict quality
guidelines and meticulously examined before delivery.
In the event of product defects you have legal rights
against the retailer of this product. Your legal rights
are not limited in any way by our warranty detailed
below.
The warranty for this product is 3 years from the
date of purchase. Should this product show any fault
in materials or manufacture within 3 years from the
date of purchase, we will repair or replace it – at our
choice – free of charge to you.
The warranty period begins on the date of purchase.
Please keep the original sales receipt in a safe
location. This document is required as your proof
of purchase. This warranty becomes void if the
product has been damaged, or used or maintained
improperly.
The warranty applies to defects in material or
manufacture. This warranty does not cover product
parts subject to normal wear, thus possibly considered
consumables (e. g. batteries) or for damage to fragile
parts, e. g. switches, rechargeable batteries or glass
parts.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
Please have the till receipt and the item number
(e.g. IAN 123456_7890) available as proof of
purchase.
You will find the item number on the type plate,
an engraving on the front page of the instructions
(bottom left), or as a sticker on the rear or bottom of
the appliance.
If functional or other defects occur, please contact the
service department listed either by telephone or by
e-mail.
You can return a defective product to us free of
charge to the service address that will be provided
to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is
and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]

18 FI
Varoitukset ja merkit...................................................... Sivu 19
Yleistä ....................................................................... Sivu 19
Tarkoituksenmukainen käyttö ..................................................... Sivu 19
Toimituksen sisältö ............................................................. Sivu 20
Osien kuvaus ................................................................. Sivu 20
Tekniset tiedot................................................................. Sivu 20
Turvallisuusohjeet ......................................................... Sivu 20
Ennen ensimmäistä käyttöä.............................................. Sivu 23
Asennus ..................................................................... Sivu 23
Käyttö ....................................................................... Sivu 24
Kerrosvoileipien valmistus........................................................ Sivu 24
Grillaus...................................................................... Sivu 24
Vohveleiden valmistus........................................................... Sivu 25
Reseptit ..................................................................... Sivu 25
Tonnikalaleipä ................................................................ Sivu 25
Kalkkunaleipä ................................................................ Sivu 26
Belgialaiset vohvelit ............................................................ Sivu 26
Mustikkavohvelit............................................................... Sivu 26
Kinkku-juustovohvelit............................................................ Sivu 27
Belgialaiset brownie-vohvelit ..................................................... Sivu 27
Katkarapu-luumuvartaat ......................................................... Sivu 28
Puhdistus ja hoito.......................................................... Sivu 28
Vianmääritys............................................................... Sivu 29
Säilytys ..................................................................... Sivu 29
Hävittäminen............................................................... Sivu 29
Takuu........................................................................ Sivu 30
