Silvercrest SSRA1 User manual

SSRA1
Roboic Vacuum cleaner

This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
RF radiationexposure statement
The Robotic Vacuum Cleaner complies with FCC RF radiation expo-
sure limits set forth for an uncontrolled environment.
Caution: To maintain the compliance with the FCC’s RF exposure
guideline, install the Robotic Vacuum Cleaner at least 7.9” (20 cm)
from ALL persons.
The transmitter of this device must not be co-located or operating in
conjunction with any other antenna or transmitter.
MODIFICATION: Any changes or modifications not expressly
approved by the grantee of this device could void the user’s
authority to operate the device.
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Consult the dealer or an experienced radio/TV technician for help.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
WARNING:

3US-EN
Description of signal words.............................................................................................Page 4
Customer service.......................................................................................................................Page 4
List of pictograms used........................................................................................................Page 4
Introduction...................................................................................................................................Page 5
Intended use........................................................................................................................................Page 5
Trademark notice ................................................................................................................................Page 5
Parts description..................................................................................................................................Page 5
Contents...............................................................................................................................................Page 7
Technical data.....................................................................................................................................Page 7
Important safety instructions.........................................................................................Page 7
Safety warnings for batteries..............................................................................................................Page 10
Initial use.........................................................................................................................................Page 12
Charging the product..........................................................................................................................Page 12
Attaching the side brushes..................................................................................................................Page 13
Turning the product on/off................................................................................................................Page 13
Use........................................................................................................................................................Page 13
Cleaning modes..................................................................................................................................Page 14
Virtual wall...........................................................................................................................................Page 16
Scheduling...........................................................................................................................................Page 16
Operation via app...................................................................................................................Page 17
Install and register...............................................................................................................................Page 17
Connecting the product to WiFi.........................................................................................................Page 18
Connecting the product to the app....................................................................................................Page 19
Disconnecting......................................................................................................................................Page 19
Cleaning via app ................................................................................................................................Page 20
Scheduling...........................................................................................................................................Page 22
Cleaning records.................................................................................................................................Page 23
Product maintenance ..........................................................................................................................Page 23
Settings ................................................................................................................................................Page 24
Operation via Alexa..............................................................................................................Page 26
Cleaning and storage ...........................................................................................................Page 28
Troubleshooting ........................................................................................................................Page 28
Disposal............................................................................................................................................Page 31
Three year limited warranty..........................................................................................Page 31
309029_1901__silv_Saugroboter SSRA1_content_US.indd 3 11.09.19 08:26

4 US-EN
DESCRIPTION OF SIGNAL WORDS
WARNING indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.
NOTICE indicates information considered important, but not hazard
related (e.g. messages related to property damage).
CUSTOMER SERVICE
Call customer service at
1 [phone]
Visit the Website Customer Service
Platform at www.lidl.com/contact-us
Visit a LIDL store for further assistance.
IAN 309029_1901 Please have your
IAN number ready.
List of pictograms used
Follow the warnings and safety notes! Short-circuit proof safety
transformer
Please read the instructions! SMPS (Switch mode power
supply unit)
This product is only suitable for indoor
use in dry, enclosed spaces.
Note polarity/battery pack data
Direct current Power supply polarity
Alternating current
b
a
Dispose of the packaging and
product in an environmentally-
friendly manner!
Protection class III 36 month warranty
Never leave children unattended with
the packaging material or the product.
Tested according Federal
Communications Commission
309029_1901__silv_Saugroboter SSRA1_content_US.indd 4 11.09.19 08:26

5US-EN
Robot vacuum cleaner SSRA1
Introduction
Congratulations on your purchase. You have selected
a quality product. The instructions for use are a part
of the product. They contain important information
about the safety, use and disposal of the product.
Before using the product, please learn about all the
safety information and usage instructions. Only use
the product as described and for the specified ap-
plications. If you lend the product to someone else,
please also give all the instructions.
Intended use
This product is suitable for vacuuming up loose, dry
dirt, e.g. dust, lint or crumbs on smooth flooring and
low pile carpets. Only use the product indoors. This
product is only intended for private, non-commercial
use. Only use the product for the intended purpose.
Any use other than previously mentioned or product
modification is prohibited and can result in injuries
and/or damage. The manufacturer assumes no lia-
bility for damage arising from improper use.
Trademark notice
· The trademark and the brand name SilverCrest
are the property of their respective owners.
· All other names and products may be trademarks
or registered trademarks of their respective own ers.
Parts description
Robot vacuum cleaner
1Display
2Charging dock
3Charging contacts
4Power cable
5Virtual wall
6HEPA filter
7Replacement side brushes
8Cleaning brush
9Power switch
10 Charging socket
11 “Dust bin“ button
12 “Start /Pause“ button
13 “Auto mode“ button
14 “Set schedule“ button
15 “Spot mode“/Time down button
16 “Return mode“/ Time up button
9
10
11
12
13
14 16
78
2
3
1
15
5
4
6
309029_1901__silv_Saugroboter SSRA1_content_US.indd 5 11.09.19 08:26

6 US-EN
17 Dust bin
18 Side wheel
19 Combo floor brush
20 Side brushes
21 Cliff sensor
22 Front wheel
23 Anti-collision sensor
17
18
19
20
212223
18
24 Dust bin cover
25 Main filter
26 Foam filter
25
24
26
Remote control
27 Directional buttons
28 “Start /Pause“ button
29 “Spot mode“ button
30 “Corner mode“ button
31 “Find robot vacuum cleaner“ button
32 “Max mode“ button
33 “Return mode“ button
34 “Auto mode“ button
30
3133
34
29
27
28
32
309029_1901__silv_Saugroboter SSRA1_content_US.indd 6 11.09.19 08:26

7US-EN
Contents
Verify that the contents are complete and that the
product is in perfect condition immediately after
unpacking.
1 Robot vacuum cleaner
1 Dust bin
1 Charging dock
1 Virtual wall
1 Main combo floor
brush with bristles
and flexible beaters
2 HEPA filters
4 Side brushes
1 Remote control
1 Power adapter
1 Cleaning brush
2 AA batteries
2 AAA batteries
1 Instructions for use
Technical data
Robot vacuum cleaner
Model: Silvercrest SSRA1
Operating voltage: 14.8V (direct current)
Rated power: 22W
Rechargeable battery: Lithium-ion rechargeable
battery (4 cells), 2.6Ah,
14.8V, 38.5Wh
Run time: max. 120 minutes (varies
by mode and flooring)
Charging time: 5–6 hours
Charging dock
Rated output voltage: 19V (direct current)
Rated output current: 0.6A
Remote control
Model: SSRA1
Rated input voltage: 3V (direct current)
Battery: 2 x 1.5V AAA (included)
Power supply
Input: 100–240V∼ 0.5A
max. 50/60 Hz
Output:
19V (direct current) 0.6A
Virtual wall
Battery: 2 x 1.5V AA (included)
App
System requirements: iOS Version 9.0 and up,
Android™ Version 4.4 and up
IMPORTANT
SAFETY IN-
STRUCTIONS
KEEP ALL SAFETY NOTES AND
INSTRUCTIONS FOR USE FOR
FUTURE REFERENCE!
Failure to
observe the following warn-
ings may result in death or
serious injuries.
D ANGER TO LIFE AN D
RISK OF ACCIDENTS
FOR INFANTS AND CHIL-
DREN! Never leave children
unsupervised with the packaging
material. Suffocation hazard. K eep
children away from the product.
DANGER TO LIFE! Batteries are
not intended for children. Do not
leave batteries lying around. Chil-
dren or pets could swallow them.
If swallowed, seek immediate
medical attention.
This product is not intended for
use by persons (including childr en)
with reduced physical, sensory
or mental capabilities or lacking
experience and knowledge unless
supervised or instructed in safe
product use by a person respon-
sible for their safety. Children
309029_1901__silv_Saugroboter SSRA1_content_US.indd 7 11.09.19 08:26

8 US-EN
should be supervised to ensure
they do not play with the product.
Verify the line voltage matches
that specified on the charging
dock 2.
Never use the charging dock 2
if damaged.
Handle the power cable 4with
care to avoid damage. Do not
use the power cable 4to move
or pull the product or charging
dock 2. Do not allow the prod-
uct to run over the power cable
4and keep it away from heat
sources.
I f the power cable
4
is damag ed,
it must be replaced by a quali-
fied service technician to avoid
dangers.
Do not use the product in rooms
with children.
Do not use the product near
open fire.
Do not allow the product to
vacuum up flammable materials,
for example fuel or printer or
copier toner.
Do not allow the product to vac-
uum up burning items, for exam-
ple cigarettes, matches, ashes and
other objects which could cause
a fire.
Check the charging dock, power
cable or power adapter for dam-
age before every use.
To reduce the risk of electric
shock – Do not use outdoors
or on wet surfaces.
Use only manufacturer’s recom-
mended attachments.
Do not unplug by pulling on cord.
To unplug, grasp the plug, not the
cord.
Do not handle plug or appliance
with wet hands.
Changes or modifications to this
product not expressly approved
by the party responsible for
compliance could void the user‘s
authority to operate the product.
Note: This product has been
tested and complies with the lim-
its for a Class B digital device,
pursuant to Part 15 of the FCC
Rules. These limits are designed
to provide reasonable protection
against harmful interference in a
r esidential installation. This produ ct
generates, uses and can radiate
r adio frequency energy and, if n ot
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications.
However, there is no guarantee
that interference will not occur
309029_1901__silv_Saugroboter SSRA1_content_US.indd 8 11.09.19 08:26

9US-EN
in a particular installation. If this
product causes harmful interfer-
ence to radio or television recep-
tion, which can be determined
by turning the product off and on,
the user is encouraged to try and
correct the interference by one or
more of the following measures:
• Reorient or relocate the
receiving antenna.
• Increase the separation betw een
the equipment and receiver.
• Connect the product into an
outlet on a circuit different
from that to which the receiver
is connected.
• Consult the dealer or an expe-
rienced radio/TV technician
for help.
This product complies with part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
(1) This product may not cause
harmful interference, and
(2) this product must accept any
interference received, including
interference that may cause un-
desired operation.
Failure to
observe the following warn-
ings can result in injuries or
property damage.
Only use the original recharge-
able battery and charging dock
2supplied by the manufacturer.
Never use primary batteries.
For more information about the
battery, please see chapter
“Technical data“.
Do not use the product if it can‘t
work properly due to
- falls,
- damages,
- ingress water,
- outdoor use.
Have the product repaired by
the manufacturer or its customer
service department.
Keep hair, clothing and fingers
away from the openings or op-
erating parts of the product.
Regularly clean the cliff sensors.
If the floor sensors are dirty, the
product may fall down stairs or
landings.
When using the product, inform
any others in the room so nobody
steps on or trips over the product.
Discontinue using the product if
the plastic parts are cracked or
deformed. Always replace dam-
aged parts with genuine spare
parts.
309029_1901__silv_Saugroboter SSRA1_content_US.indd 9 11.09.19 08:26

10 US-EN
Do not use the product on wet
or damp floors.
Do not use the product in tempe ra-
tures over +104°F (+40°C) or
below +50°F (+10°C).
Remove any obstacles prior to
use, for example power cables,
toys and other objects.
Tuck rug edges under the rug.
Keep curtains and tablecloths
off the floor.
Try to position furniture properly.
Test the product in areas with
stairs. This allows you to verify
the product detects the edge of
the drop off.
Do not stand in the way of the
robot vacuum cleaner. Otherwise
the robot vacuum cleaner will be
unable to clean these areas.
Do not allow the product to vac-
uum up items which could clog
the product, for example stones,
paper waste, etc.
Do not use the product if the suc-
tion opening is blocked. Remove
dust, hair, cotton balls, etc., to
allow air to flow freely in the
suction opening.
Verify the dust bin 17 and the
filters 6, 25 , 26 are installed
correctly before use.
Check the area being cleaned
before every use and observe
the safety notes and information
about preparing the room.
Regularly check and clean the
filters and the dust bin to extend
the life of your product.
Never use the product without
filters, as this will damage the
motor and shorten the life of the
product.
Always turn the product off
before transporting it.
Fully charge the product at least
once a month to prevent deep
discharge, which will damage
the battery.
Do not cover or tape off the cliff
s ensors on the product. Otherw ise
the product will be unable to
navigate.
Only use the product with the re-
mote control when it is within si ght.
Safety warnings
for batteries
When used correctly, cells and
batteries provide a safe and
dependable source of portable
power. However, if they are mis-
used or abused, this may result in
leakage, burns, fire, or explosion.
309029_1901__silv_Saugroboter SSRA1_content_US.indd 10 11.09.19 08:26
