Sim2 LUMIS 3D-S User manual

SIM2 Multimedia
Lumis 3D-S
User Guide

Contents
3Important information
Safety
3D content
Environment
Notice
7Chapter 1: Introduction
Key Features and enefits
System Components
Optional Accessories
9Chapter 2: Overview
Remote Control
Projector Keypad
Connections
3D IR Emitter
3D Glasses
13 Chapter 3: Installation
Location
Mounting
Connections
Switching On and Off
19 Chapter 4: Operation
Viewing 3D Content
3D Menu
Input Menu
Main Menu
Setup
Menu
Memories
Info
Quick Menus
Messages
35 Chapter 5: Trou leshooting
37 Chapter 6: Specifications
39 Chapter 7: Projection Distances
40 Chapter 8: Dimensions
Lumis 3D-S
User Guide
2

Important information
Safety
To reduce the risk of electrocution, disconnect the power cord on the
rear panel before removing the top cover of the projector. For technical
service refer to trained personnel authorized by the manufacturer.
If the lamp suddenly explodes with a loud bang, turn off the projector immediately
and air the room thoroughly. Do not attempt to restart the projector and do attempt
to replace the bulb: contact your local service center.
Read this manual
Read all chapters of this manual carefully before switching on the projector. This
manual provides basic instructions for operating the Lumis 3D-S projector. Installation,
preliminary adjustments and procedures that necessitate the removal of the top cover
and contact with electrical components must be performed by authorized, trained
technicians. To ensure safe operation and long term reliability use only the power
cords supplied by the manufacturer. Observe all warnings and precautions. Keep the
manual for future consultation.
Do not touch internal parts of the projector
Inside the housing there are electrical parts carrying dangerously high voltages and
parts operating at high temperature. Never open the housing. Entrust all servicing and
repair work to a SIM2 Authorized Service Center. Opening the housing voids the war-
ranty.
Disconnect the appliance from the power supply
The device that disconnects the projector from the mains is the power plug. Ensure
that the power cord plugs and the electrical outlets are easily accessible during install-
ation operations. Pull the plug, not the cord, to disconnect the projector from the
mains. Use only the specified power supply. Connect the projector to a mains electric-
al supply with rated voltage of between 100-240 V AC, 50/60 Hz and equipped with a
protective earth connection. If you are not sure of your domestic mains rating, contact
an electrician. Take care to avoid overloading the power socket and any extension
leads.
Switching the projector off
Pay attention to the switch off procedure for the projector. The projector must always
be brought back to the standby state to allow the projector to carry out the cooling
procedure. Should this not happen, for example due to a power cut, the projector may
enter a state of protection that leads to switch-on being blocked. This block will last
until the internal components of the projector have completely cooled down.
Changing the fuses
efore changing the fuse, disconnect the projector from the mains power supply. The
fuse compartment is next to the power supply connector. Remove the fuse holder
Important information Lumis 3D-S
User Guide
3

with a flat head screwdriver and replace the fuse. Fit the replacement fuse. Use only
type T 10 A L H fuses for the projector.
Be careful with ca les
Make sure cables are routed so that people are not impeded or become a trip hazard.
Keep all cables away from children. Install the projector as close to the wall socket as
possible. Avoid stepping on power cords, make certain they do not become tangled,
and never jerk or tug them; do not expose them to sources of heat, and make sure
they do not become knotted or crimped. If the power cords become damaged, stop
using the projector and request the assistance of an authorized technician.
Disconnect the projector from the mains power during electrical storms and when
not in use
To prevent damage from lightning strikes in the vicinity, disconnect the projector dur-
ing storms or when the projector is going to be left unused for a long time.
Avoid contact with liquids and exposure to damp
Do not use the projector near water (sinks, tubs and so on); do not place objects con-
taining liquids on or near the projector and do not expose it to rain, humidity, drops of
water or sprays; do not use water or liquid detergent to clean it.
Place the projector on a sta le surface
Place the projector on a stable surface or use a suitable ceiling mounting bracket. Nev-
er place the projector on its side or rear, on the lens or top panel.
Do not allow the projector to overheat
To prevent overheating, allow a free space of at least 0.25 m (10 in.) on the left, right
and rear sides of the projector. Do not obstruct the ventilation slots. Do not place the
projector near heat sources such as heaters, radiators or other devices (including
amplifiers) that generate heat. Do not place the projector in an area where there is
insufficient space (shelving units, bookshelves and so on) and in general avoid placing
it in poorly ventilated areas as this may prevent sufficient cooling and significantly
reduce lamp life.
Never look directly at the projection lamp
Never look directly into the lens when the lamp is on as the intense light may damage
your eyes. Take particular care that children cannot do so.
Take special care regarding movement of the lens
Do not place objects in the slots on the side of the lens and also ensure that vertical
lens movements are not impeded by external objects.
Do not insert o jects through the openings in the projector
Make sure that no objects are inserted inside the projector. If this should occur, dis-
connect the projector from the power supply immediately and call an authorized tech-
nician.
Power saving
We advise disconnecting the projector from the power supply when not in use. In this
way you will achieve considerable power savings while at the same time protecting in-
ternal electrical parts from wear.
Important information Lumis 3D-S
User Guide
4

3D content
Discomfort (such as eye strain, headaches, motion sickness, nausea, dizziness, disori-
entation) may be experienced while watching 3D content. In this case, stop watching
and consult a doctor if symptoms are severe.
Consult a doctor before allowing young children (especially those under six years old)
to watch 3D content as their visual system is still under development.
Monitor children (including teenagers) watching 3D content, as they are more at risk
of experiencing discomfort and less inclined to report symptoms.
Individuals who may be susceptible to epileptic seizures or strokes (on the basis of
personal and family history) should consult a doctor before watching 3D content.
All viewers should take regular breaks from watching 3D content. Length and fre-
quency of these breaks may vary from person to person.
Environment
This product contains materials derived from natural resources during its manufac-
ture. It may contain materials that constitute a health and environmental hazard. To
prevent harmful materials from being released into the environment and to promote
the use of natural materials, SIM2 provides the following information regarding the
disposal and recycling of the product.
Waste electrical and electronic materials (WEEE) should never be disposed of in nor-
mal urban waste disposal facilities.
The label on the product, shown here, indicating a canceled garbage can,
is intended to remind you that the product requires special handling at
the end of its service life. Materials such as glass, plastic and some chem-
ical compounds are recoverable and can be recycled for reuse.
Observe the following instructions:
•When you no longer wish to use your electrical and electronic equipment,
take it to your local waste disposal facility for recycling.
•You may return your old equipment to your SIM2 Authorized Dealer free of
charge when you buy a new product that is equivalent or has the same func-
tions as the old one. Contact SIM2 to find your local dealer.
•If you need more information regarding recycling, reuse and product ex-
changes, contact SIM2 customer service.
Lastly we suggest further measures to safeguard the environment, such as recycling of
internal and external packaging (including that used for shipping) in which the product
was delivered. With your help, we can reduce the amount of environmental resources
required to make electric and electronic equipment, reduce the use of waste tips for
used equipment and, in general, improve our quality of life by making sure that haz-
ardous materials are correctly scrapped. Incorrect treatment of the product at the end
of its service life and failure to follow the above disposal instructions are punishable
under local legislation.
Important information Lumis 3D-S
User Guide
5

Product disposal
The lamp inside this projector contains mercury and may be subject to
special disposal or recycle regulations. Dispose or recycle in accordance
with local laws. For more information contact the Electronic Industries
Alliance at www.eiae.org or check www.lamprecycle.org
Notice
The appliance has been subjected to exhaustive operating tests by SIM2 to guarantee
the highest quality. The projector bulb life should thus initially be around 30-60 hours.
In addition to the customary checks, the Quality Control department also runs addi-
tional statistical tests before shipment. In such cases, the packaging may show signs of
having been opened, and the hours of lamp operation may prove to be higher than
those normally shown when only standard tests are performed.
As the optical system of the Lumis 3D-S is extremely compact and has the purpose of
developing very high brightness and contrast, it is possible that a small quantity of
light is visible outside of the projection area and will vary depending on the type of
lens used and the zoom and shift setup. This characteristic of the optical system is to
be deemed as normal. In order to reduce this effect SIM2 recommends that the area
surrounding the projection screen is as dark as possible.
The Lumis 3D-S is a three chip DLP projector and uses three high resolution DMD (red,
green, blue). These three DMD are precisely aligned through a high precision process
that reduces the alignment error to within the foreseen limits of tolerance. The max-
imum limits of misalignment are the following:
•Screen Center: up to 0.7 pixels between each color
•Screen orders: up to 2 pixels between each color
These limits are perfectly normal for this optical system and will not be considered as
a malfunction of the product.
Note: One pixel corresponds to 10 thousandths of a millimeter on the DMD.
Important information Lumis 3D-S
User Guide
6

1 Introduction
The Lumis 3D-S is a high-end compact 3-chip DLP 3D single unit projector that utilizes
SIM2’s state-of-the-art optical technologies to produce images with exceptional black
level and contrast performance.
The Lumis 3D-S is able to emulate the best 3D cinema projection systems, in terms of
color fidelity, definition and depth of image. These are all conveyed accurately, as is
the fluid motion of fast-action movies and sports. This all adds up to an incredible 3D
experience at home.
The Lumis 3D-S is designed for use with large screen sizes – up to 5 m (16.5 ft.) wide.
A choice of three high quality glass lenses (T1, T2 and T3) is available, giving the pro-
jector a total throw ratio of 1.37-3.90:1.
To aid calibration SIM2’s Live Color Calibration software enables complete control
over:
•primary, secondary and white point color coordinates
•gamma tables
allowing calibration experts to accurately calibrate the final image via a user-friendly
application for Windows-based computers.
Key Features and Benefits
•high picture quality: SIM2 renown image processing and the latest 0.95 in.
1080p DarkChip4 DMD from Texas Instruments
•precision optics: SIM2 ALPHAPATH light engine
•high brightness: 3-chip DLP projector
•artifact-free fast-action images: SIM2 PureMotion processing
•high resolution: actual full HD 3D images, without blur and ghosting
•comfortable 3D viewing: high brightness ghost-free sharp images
•immersive 3D effect: large screen sizes thanks to high brightness images
•3D wide viewing angle: stereo separation independent from viewing angles
•screen flexibility: no constraints in the choice of the screen material
•compatibility: no need of dedicated sources and preprocessing for 3D viewing
•longer lamp life: affordable and reliable UHP lamps
System Components
Your Lumis 3D-S DLP projector ships with the following items:
•1 x backlit remote control unit (with four AAA/LR03 batteries)
•1 x SIM2 3D sync IR emitter (E103-S)
•2 x pairs of SIM2 103-S active shutter glasses (including CR2032 batteries)
•3 x AC power cords (US, EU and UK), 2 m (6.6 ft.) long
•3 x jacks for 12 V output connectors
•1 x 4.0-millimeter Hex wrench (for lens shift adjustment)
•1 x User guide (this document)
•1 x CD with Live Color Calibration software (for Windows-based computers)
1 Introduction Lumis 3D-S
User Guide
7

If any items are missing or damaged, contact your SIM2 Authorized Dealer as soon as
possible. Keep the original packaging in case anything has to be shipped.
Optional Accessories
•Additional SIM2 103-S active shutter glasses for E103-S IR emitter (part num-
ber 78 024 2000)
•Xpand X103 universal active shutter glasses (part number 78 024 1000) for
Xpand AE110 IR emitter
•Xpand AE110 IR emitter (part number 79 021 0000). Requires Xpand X103 uni-
versal active shutter glasses
•Projector ceiling bracket
•Anamorphic lens systems (fixed or motorized)
1 Introduction Lumis 3D-S
User Guide
8

2 Overview
Remote Control
❶Turn backlight on for about 5
seconds
❶
❸
❹
❺
❼
❽
❾
⓫
⓬
⓮
❷
❻
❿
⓭
⓰
⓯
❷ turns the projector off
❸1-9 select inputs and turn the projector
on
❹0enters OSD Input menu and turns
the projector on
❺●OK enters submenus, confirms ac-
tions
❻ESC exits OSD
❼
▴
◂ ▸
▾
select menu items, adjust settings or
cycle through the test patterns
❽
MENU
+ / -
enter OSD Main menu and select
the desired section, each press of
the key selects the next tab in the
menu
❾II 3D enters 3D menu
❿Memory enters Memories menu
⓫ ⓬ F1, F2
perform user-defined actions (de-
fault assignments are: F1 = Zoom, F2
= Focus)
⓭Info displays projector Info
⓮A Auto performs Auto Adjustment
⓯Aspect enters Aspect Quick menu
⓰Not used
Custom Remotes
You can use your own IR remote control to control your Lumis 3D-S projector.
•If you are using a remote control with learning capabilities, use the projector
remote control to teach the commands to your remote.
•If you are using a programmable remote control, the setup software probably
allows importing of Pronto Hex codes. See SIM2 Lumis 3D-S IR Control for a list
of all the projector codes in Pronto Hex format, including a number of discrete
codes for:
◦Aspects
2 Overview Lumis 3D-S
User Guide
9

◦Memories
◦3D Controls (3D Mode and Input Formats)
Operation
The Lumis 3D-S projector has two IR receivers, one on the front and one on the back
of the unit. The operative range of the remote control is approximately 10 m (33 ft.).
Make sure that there is nothing obstructing the infrared beam between the remote
control and the IR receiver you are pointing to. You can point the remote control to-
wards the screen, as the IR beam is reflected by the screen towards front IR receiver
of the projector. In this case the effective range of the remote control may be smaller
than declared.
Batteries
To install batteries in the remote control:
1. Open the battery cover.
2. Insert four AAA (LR03) batteries making sure the polarities match the + marks
inside the battery compartment.
3. Replace the cover.
Replace the batteries with new ones when the operating range of the remote control
decreases. Dispose of used batteries according to local regulations. Make sure you do
not mix old and new batteries or different types of batteries.
Warning: If you will not use the remote control for a long time, remove the batteries
to avoid battery leakage.
Projector Keypad
turns the projector on or off
◂ ▸ ▴ ▾ select menu items, adjust settings or switch test patterns
MENU enters OSD Main menu and selects the desired section
ESC exits OSD
SOURCE/Oenters OSD Input menu/selects a menu item
2 Overview Lumis 3D-S
User Guide
10

Connections
❶ ❷ ❸ ❹ ❺ ❻
❼ ❽
Inputs ❶HDMI 1
HDMI 2
Accept both HDMI and DVI digital video inputs.
❷Components/RG -HV Four RCA connectors. They accept both standard
and high-definition component (YPrPb) and
RG -HV signals. Also used as RG input for SCART
RG S signals.
❸Video One RCA connector. Accepts composite video sig-
nals. Also used as composite sync input for SCART
RG S signals.
❹Graphics RG One D-Sub 15-pin female connector. Accepts
component or RG high-definition signals.
Control/
Service
❺US US 1.1 (type ) port for serial commands and
firmware upgrade.
❻RS-232 RS232 (female D-Sub 9-pin) port for serial
commands and firmware upgrade.
Outputs ❼TRIG 1 12 V 100 mA max output, for motorized screen
control. Activates when the projector is switched
on.
TRIG 2 12 V 100 mA max output, for motorized screen
masking systems control. See “Screen” on page
27.
TRIG 3 12 V 100 mA max output, for motorized ana-
morphic lens position control. See “Anamorphic
Lens” on page 27.
❽3D Sync OUT VESA DIN-3 connector for 3D IR Emitter cable.
2 Overview Lumis 3D-S
User Guide
11

3D IR Emitter
The 3D infrared emitter is designed to be placed near the projector and aimed at the
screen. It receives the 3D sync signal from the projector and emits infrared pulses that
bounce off the screen and the walls to reach the 3D glasses infrared receiver.
Note: The emitter emits sync pulses only when the projector displays 3D content.
3D Glasses
When displaying 3D content, the projector alternately displays one image for the left
eye and one image for the right eye in rapid succession. The 3D glasses turn on and off
their lenses, in sync with the projector, so that each eye receives exactly the image in-
tended for it. The sync is possible thanks to the infrared pulses received by the glasses
from the 3D IR emitter.
❶ ❷
❸ ❹ ❺
❶Indicator light Indicates glasses status
❷attery compartment For CR2032 (3 V DC / 0.2 A) batteries
❸IR receiver Receives infrared signals from the 3D Emitter
❹Lens Liquid crystal shutter
❺utton utton for on and off
2 Overview Lumis 3D-S
User Guide
12

3 Installation
This section provides instructions for the installation of the Lumis 3D-S projector.
Important: Installation procedures should be performed by a qualified AV system spe-
cialist.
Location
When installing the Lumis 3D-S projector, take the following considerations into ac-
count.
Installation Type
Select the installation type that best suits your needs:
•front or rear projection
•floor or ceiling mount
Lens Type
Choose the desired distance from the screen and select the lens type (T1, T2 or T3)
that determines the desired screen size.
Cooling
Make sure that the planned location for the projector has adequate ventilation. Check
that room temperature is below 35° C and that the projector is away from heating
vents. Ensure a minimum 0.25 m (10 in.) clearance on the left, right and rear sides of
the projector.
Power Outlets
Verify that the powers outlets are grounded and preferably shielded from power
surges and fluctuations. A UPS is optional. Lumis 3D-S power supply operates on any
nominal line voltage between 100-240 V AC, 50-60 Hz.
Ca les
Check planned cable lengths for video and control cables and make sure these lengths
do not exceed specifications.
Am ient Light
Avoid or minimize light sources directed at the screen to preserve the quality of the
projected image.
Mounting
The projector can be Floor mounted (upright) or Ceiling mounted (inverted). Choose
the method that best suits your installation.
Important: The projection lens is not centered to the chassis (it is off-center horizont-
ally by 75 mm or 2.95 in., see “Dimensions” on page 40 for details). Make sure the
centerline of the lens is centered horizontally to the center of the screen.
Floor Mounting
Position the projector on a secure and flat surface (such as a table or a shelf). Adjust
the three feet at the bottom of the projector until the projector is level on all sides.
3 Installation Lumis 3D-S
User Guide
13

Ceiling Mounting
Invert the projector and suspend it from the ceiling using a specific bracket.
•To fit the bracket unscrew and remove the 3 rubber feet
•Attach bracket by using 3 x M6 screws not exceeding 15 mm in length
For ceiling mounting use only SIM2-approved ceiling brackets and adhere
to the installation instructions and safety guidelines provided with the
bracket. Do not over-tighten the screws.
Orientation
y default, the Lumis 3D-S is configured for a Front installation (projector installed up-
right and in front of the screen). If the projector is installed behind the screen or inver-
ted, you can use the image orientation function of the projector (see “Orientation” on
page 29)
Vertical Lens Shift
Ideally, the projector should be positioned at a right angle to the screen and in such a
way that:
•the lens center and screen center are aligned with each other
•the projected image fills the screen perfectly
3 Installation Lumis 3D-S
User Guide
14

If it is not possible to position the projector perpendicular to
the projection screen (so that the lens center and screen cen-
ter are aligned with each other) you can use the mechanical
lens control at the top of the projector to shift the projected
image vertically:
•insert the provided hex wrench into the vertical lens
shift adjuster
•turn the wrench to shift the lens in the desired direc-
tion
The Lumis 3D-S provides up to 50% of vertical lens shift up. For example, with a 16:9
150 in. diagonal size screen, you can shift the image up to 0.93 m (36.8 in.) above the
screen center (see “Projection Distances” on page 39).
Keystone
If the projector is ceiling-mounted and the screen is lower than the projector, you may
need to tilt the projector by adjusting the ceiling mount. If you do so:
•the top and bottom borders of the image will be unequal in length
•the sides of the image will be inclined
If the tilt is not excessive, you can use the Keystone function of the projector to cor-
rect the image shape. See “Keystone” on page 29.
Note: Keystone correction may cause artifacts in the image and may not be available
when displaying specific 3D content (see Table 4.2).
Zoom and Focus
The Lumis 3D-S provides motorized Zoom and Focus controls. You can access these
adjustments through the remote control directly:
•F1 key for optical Zoom
•F2 key for Focus
See “F1-F2 Keys” on page 31 for details.
Connections
Proceed as follows to connect the Lumis 3D-S to video sources, control devices, screen
control systems, 3D sync emitter and AC power.
When connecting your equipment:
•turn off all equipment before making any connections
•use the correct signal cables for each source
•make sure cables are routed so that people are not impeded or become a trip
hazard
•ensure that the cables are securely connected (tighten the thumbscrews on
connectors that have them)
Video
Often the sources ( lu-ray Players, Set Top oxes, Game Consoles and so on) have sev-
eral outputs. Choose HDMI whenever possible.
•HDMI The major benefits of this signal type are:
◦best image quality, because the signal is carried in the digital domain
3 Installation Lumis 3D-S
User Guide
15

throughout the entire signal path
◦highest available resolution, because video sources can deliver full resolu-
tion content via HDMI only
◦availability of 3D content, because most 3D compatible sources deliver 3D
content from HDMI only
◦optimization of several image parameters (2D/3D content, color space, as-
pect, signal range, over scan), thanks to auxiliary information (AVI in-
foframe) sent by the source device together with the signal.
If your source has dual HDMI outputs, we would recommend direct connec-
tion to the projector from one of the HDMI connections and the second HDMI
output to the input of an appropriate AV receiver/processor for audio.
Sources with a DVI-D output can be connected to the HDMI input of the pro-
jector using a suitable DVI-D to HDMI cable. In this case no auxiliary informa-
tion is sent from the source to the projector.
Note: HDMI uses a code known as HDCP (High-bandwidth Digital Copy Protec-
tion), which protects the recorded supports from being copied illegally. The
connection between the source and display require that the two devices per-
form a handshake and exchange code keys before being able to display an im-
age. The InstaPort technology allows a simultaneous pre-authentification of
every attached device at the same it is connected, reducing drastically the
time required for HDMI source switching. For this reason you may note a
slight delay before the image appears on the screen, but it is perfectly normal.
•Graphics RGB Input for Personal Computer and other sources that outputs
RG or YPrPb signals. These sources must be able to provide separate H/V
sync or composite H+V sync.
•RGB/YPrP Input for DVD Players, Set Top oxes and other sources that
output one of the following signals:
◦Component (YPrPb)
◦RG with composite sync on green (RGs )
◦RG with HV composite sync
RG connectors also provides RG input for SCART RG S sources. See “Video”
below and “RG S Sync” on page 29.
•Video This is the the input for composite video sources (such as VCR or
camcorders). This connector is also the composite sync input for SCART RG S
sources. See “RG /YPrPb” above and “RG S Sync” on page 29.
Control
You can connect the Lumis 3D-S projector to a Personal Computer or a control system
through one of the following methods:
•RS-232 port, using a standard 9-pin straight serial cable
•RS-232 port, using a US to serial converter cable. In this case, installation of a
device driver provided by the cable manufacturer may be required
•US port, using a US Type A (rectangular) to Type (square) cable connector.
In this case, installation of a device driver provided by SIM2 may be required –
ask your SIM2 Authorized Dealer
3 Installation Lumis 3D-S
User Guide
16

Note: RS-232 communications are limited to 15 m (50 ft.), whereas US are limited to
5 m (16 ft.).
Triggers
Some Home Theater devices can be controlled through a 12 V signal. The projector
can output three 12 V (100 mA max) signals:
•TRIG1 for motorized screens control
•TRIG2 and TRIG3 are for motorized screen masks and anamorphic lens motors
control. See “Screen” and “Anamorphic Lens” on page 27 for instructions on
how to do configure them from OSD
Note: Three jack adapters are shipped with the projector.
IR Emitter
The IR emitter sends the infrared pulses that sync the 3D glasses. Proceed as follows
to install the emitter:
1. place the emitter near the projector on a secure surface or use an appropriate
mount kit
2. connect the supplied 3D IR emitter to the projector 3D Sync Out output
3D Glasses
The glasses are shipped with the battery already inserted in its compartment:
1. Remove the battery insulating sheet by pulling it. As a result of this, the
glasses turn on.
2. Press the button once (for less than 1 second) to turn them off. You will see
the indicator light ramp from bright to off.
For more information on glasses status and transitions, refer to “3D Glasses” on page
20.
To install the battery:
1. Open the battery cover.
2. Insert one CR2032 battery making sure the polarity match the mark inside the
battery cover.
3. Replace the cover.
Replace the battery with a new one when the glasses fail to work prop-
erly. Dispose of used battery according to local regulations. Keep away
from children.
AC Power
Choose the AC power cord that is appropriate in your area among those shipped with
the product. Plug the female end of the power cord to the AC receptacle located on
the right hand side of the projector (100-240 V AC, 50-60 Hz) and the other end into a
grounded AC outlet. An high-quality surge protector is recommended while a UPS is
optional.
3 Installation Lumis 3D-S
User Guide
17

Switching On and Off
Switching On
1. Turn on the main power switch on the right hand side of the projector. The
projector enters the low power Standby status. The indicator light on the left
hand side of the projector turns red and the status display next to it shows . .
2. Press any of the numeric keys (0-9) on the remote control or the I/O button
on the projector keypad to switch on the projector.
3. The indicator light turns green and red and the status display shows 88 for a
while.
4. When the projector is ready for use an image appears on screen (this can take
approximately one minute).
5. If a valid signal is detected, an image appears on the screen, otherwise a black
screen with a “No Signal” message is displayed.
Switching Off
1. Press and hold the Off key on the remote control or the I/O button on the
projector keypad.
The indicator light flashes green and red to indicate that the projector is cool-
ing down. Cooling fans remain on for approximately four minutes to cool the
lamp. In the meanwhile the projector cannot be turned on again.
2. After cooling is complete the projector enters Standby status. The indicator
light turns solid red and the status display turns black, unless an error or
warning code is displayed.
Warning: Wait for the cooling fans to turn off before turning off the main power
switch or unplugging the projector.
3 Installation Lumis 3D-S
User Guide
18

4 Operation
Viewing 3D Content
3D stereo visualization offers clear and sharp 3D images thanks to 3 chip DLP Imaging
technology. This technique achieves channel separation using Xpand active shutter
glasses.
•Active shutter glasses turn on and off in rapid succession and stop light reach-
ing your eyes. The glasses are synced using a IR emitter connected to the pro-
jector.
•When an image is destined for the left eye, the right lens of the glasses goes
dark preventing any of the image for your left eye from reaching the right eye.
The left lens is completely open.
•The process repeats very quickly (up to 144 times per second) for each eye.
•The human brain combines the two images and creates the illusion of 3D.
Important: Read 3D safety information at the beginning of this User Manual before
viewing 3D content.
Your Lumis 3D-S projector is capable of displaying 3D Images of exceptional high qual-
ity; to ensure maximum enjoyment and trouble free viewing we recommend the fol-
lowing guidelines.
•You will need a lu-ray player or equivalent that is capable of play-
ing 3D content and is HDMI 1.4 compliant plus of course a copy of
a film that has released on lu-ray in 3D. Only films with the 3D logo are com-
patible.
•Ensure your player has the latest software installed.
•If your lu-ray Player has dual HDMI outputs, we would recommend direct
connection to the projector from one of the HDMI connections and the
second HDMI output to the input of an appropriate AV receiver/processor for
audio.
•If you are routing all of your HDMI sources through an AV receiver/processor
the product must be 3D compatible and HDMI 1.4 compliant. Ensure your
equipment has the latest firmware installed (refer to the manufacturer for fur-
ther information).
•Other 3D content providers are available such as Satellite roadcasters, Cable
providers, VOD and Streaming services, gaming consoles such as PlaySta-
tion 3. Details of the 3D service provided can be obtained by contacting your
local/regional operators.
To watch 3D Content via Blu-ray
•Switch on the Lumis 3D-S and all other relevant products such as lu-ray
player and AV receiver and ensure the correct inputs have been selected.
•Insert your 3D lu-ray disc and press play, follow the on-screen menus.
Note: Some discs contain both the 3D and 2D versions of the film, ensure you
4 Operation Lumis 3D-S
User Guide
19

select the correct one.
•Switch on your 3D glasses. Refer to the instructions supplied with the glasses
to ensure correct operation.
•The projector will automatically detect the 3D signal and you will be prompted
to wear your glasses via the OSD.
To Watch 3D Content via Satellite, Ca le and Games Console
•Switch on the Lumis 3D-S and all other relevant products such as Satellite
receiver and AV receiver and ensure the correct inputs have been selected.
•Select the appropriate 3D channel.
•If the projector displays two distorted images side by side or one on top of
each other, select the 3D menu by pressing II on the remote control.
•Select 3D mode via the OSD (this will expand the menu). Select the correct
version of the 3D format using the up/down/left/right keys.
•Switch on your 3D glasses. Refer to the instructions supplied with the glasses
to ensure correct operation.
Important: All 3D technologies currently available today filter out a large amount of
light. Therefore it is perfectly normal for the 3D image to be noticeably dimmer when
compared to the picture in 2D mode. Adjust the 3D picture and lamp settings accord-
ingly for 3D viewing.
3D Glasses
Follow the simple instructions below to operate your 3D glasses:
•On Press the button once (see “3D Glasses” on page 12). You will see the
indicator light ramp from off to bright, and then turn off again. You are now in
SIM2 Cinema mode and the glasses and the projector are synced. If, for any
reason, the glasses behave differently, reset them (see below).
•Off Press the button once. You will see the indicator light ramp from bright to
off.
Note: Glasses will turn themselves off after a few minutes without the sync
signal.
•Reset In the unlikely event that you need to reset your glasses, remove the
battery from its compartment, and then replace it.
Note: For battery replacement refer to “3D Glasses” on page 17.
3D Menu
To view 3D content additional adjustments are required. With 3D content playing,
press II on the remote to access the OSD 3D menu.
3D Mode
•3D Activates 3D mode and the IR emitter will be activated. Automatic selec-
tion is determined by the source sending the projector the correct informa-
tion. If the incorrect 3D image is displayed after approximately 10 seconds go
to the 3D Input Format and manually select the correct 3D mode for the in-
coming signal.
4 Operation Lumis 3D-S
User Guide
20
