Sime EDEA Manual

BRAVA DGT HE
25 - 30 - 35
199838
INSTALLATION AND SERVICING INSTRUCTIONS
ENSURE THAT THESE
INSTRUCTIONS ARE LEFT
FOR THE USER AFTER
COMPLETION OF THE
BENCHMARK SECTION
PLEASE READ THE
IMPORTANT NOTICE
WITHIN THIS GUIDE
REGARDING YOUR BOILER
WARRANTY
EN Cod. 6316191 - 08/2013
6331861A - 04/2022 - R3
BRAVA DGT HE
25 - 30 - 35
199838
INSTALLATION AND SERVICING INSTRUCTIONS
ENSURE THAT THESE
INSTRUCTIONS ARE LEFT
FOR THE USER AFTER
COMPLETION OF THE
BENCHMARK SECTION
PLEASE READ THE
IMPORTANT NOTICE
WITHIN THIS GUIDE
REGARDING YOUR BOILER
WARRANTY
EN
Cod. 6316191 - 08/2013
please position here a sticker
from installation pack
BOILER DETAILS
USER, INSTALLATION AND SERVICING INSTRUCTIONS
EDEA
Condensing wall mounted boiler
Cod.
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
To consult the documentation,
visit our website www.sime.it
199839

2
RANGE RATED CERTIFICATION
The maximum power, in heating mode, of Edea boilers can
be adapted, during the installation, to the thermal needs of
the system by modifying the setting of PAR 15 in the
0 .. 100
range.
The setting of PAR 15 = 100 is the factory setting that allows
the boiler to deliver its maximum power in heating mode. It
can be reduced by modifying the setting of PAR 15 as shown
in the table appearing below.
Once the new setting of PAR 15 has been made, the reduced
maximum power value (kW)
for models with power above 35
kW
MUST MANDATORILY be applied beside the boiler’s data
plate. For checks and adjustments after the modification,
refer to the new value for the maximum power.
The useful nominal power levels used are those relative to the
operating conditions (80-60°C) (Pn min - Pn max).
Example for Edea 30 :
– default heating power range: 2,8 - 24,5 setting of PAR 15 = 100
– “reduced” heating power range: 2,8 - 18,9 setting PAR 15 = 80
DESCRIPTION
Edea
30 40 Setting of PAR 15
Min Max Min Max
A - Factory power range (heating) kW 2,8 24,5 4,2 34,1
100
B - Reduced power ranges for
maximum power reduction
(heating)
kW 2,8 21,2 4,2 30,7
90
kW 2,8 18,9 4,2 27,3 80
kW 2,8 16,5 4,2 23,9 70
kW 2,8 14,2 4,2 20,5 60
kW 2,8 11,8 4,2 17,0 50
kW 2,8 9,4 4,2 13,6 40
Boiler technical data plate

3
SAFE HANDLING
IMPORTANT NOTICE
For the first year all of our appliances are protected by our manufacturer’s guarantee which covers both parts and
labour.
As you would expect from Sime Ltd, it is our aim to provide our valued customers with the best in after sales and
service.
To take advantage of any extended warranty offered, all you have to do is to adhere to these 3 simple conditions:
The installation must be carried out to Manufacturers/Benchmark Standards by a Gas Safe Registered
Engineer, and recorded in the installation manual.
The appliance must be registered with both Sime Ltd and Gas Safe within 30 days of installation.
The appliance must be serviced every 12 months, within 30 days of the anniversary of the installation date, by either
Sime Ltd or a Gas Safe registered engineer- ensuring that the Benchmark service record in the installation
manual is completed.
Failure to comply with the above will result in only the 12 month warranty being offered.In the absence of any proof
of purchase, the 12 month warranty period will commence from the date of manufacture of the boiler as shown on the
appliance data plate.
This boiler may require 2 or more operatives to move it into its installation site, remove it from its packaging and
during movement into its installation location. Manoeuvring the boiler may include the use of a sack truck and involve
lifting pushing and pulling.
Caution should be exercised during these operations.
Operatives should be knowledgeable in handling techniques when performing these tasks and the following precau-
tions should be considered:
– Grip the boiler at the base
– Be physically capable
– Use personal protective equipment as appropriate e.g. gloves, safety footwear.
During all manoeuvres and handling actions, every attempt should be made to ensure the following unless unavoi-
dable and/or the weight is light.
– Keep back straight
– Avoid twisting at the waist
– Always grip with the palm of the hand
– Keep load as close to the body as possible
– Always use assistance
WARNING
Caution should be exercised when performing any work on this appliance.
Protective gloves and safety glasses are recommended.
– Avoid direct contact with sharp edges.
– Avoid contact with any hot surfaces.
NOTICE
Please be aware that due to the wet testing of the appliance, there may some residual water in the hydraulic circuit.
– Protect any surfaces, carpets or floorings.
– Use a suitable container to catch any water that escape when removing the protective caps from the connections.
All descriptions and illustrations provided in this manual have been carefully prepared but we reserve the right to make
changes
and improvements in our products that may affect the accuracy of the information contained in this manual.

4

5
The Benchmark Scheme
Sime Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and
commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise
safety, efficiency and performance.
Benchmark is managed and promoted by the Heating and Hotwater Industry Council.
For more information visit www.centralheating.co.uk.
Please ensure that the installer has fully completed the Benchmark Checklist in the use and maintenance section of
the installation instructions supplied with the product and that you have signed it to say that you have received a full
and clear explanation of its operation.
The installer is legally required to complete a commissioning checklist as a means of complyng with the appropriate
Building Regulations (England and Wales).
All installations must be notified to Local Area Building Control either directly or through a Competent Persons
Scheme.
A Building Regulations Compliance Certificate will then be issued to the customer who should, on receipt, write the
Notification Number on the Benchmark Checklist.
This product should be serviced regularly to optimise its safety, efficiency and performance.
The service engineer should complete the relevant Service Record on the Benchmark Checklist after each service.
The Benchmark Checklist may be required in the event of any warranty work and as supporting documentation
relating to home improvements in the optional documents section of the Home Information Pack.
Please refer to commissioning instructions for filling in the checklist at the back of this installation guide.
Note: All Gas Safe registered installers carry a ID Card.
You can check your installer is Gas Safe Registered by calling 0800 408 5577
SIME COMBINATION BOILERS
Installer checklist
Important Information
IT IS A STATUTORY REQUIREMENT THAT ALL GAS APPLIANCES ARE INSTALLED BY COMPETENT PERSONS,
IN ACCORDANCE WITH THE GAS SAFETY (INSTALLATION AND USE) REGULATIONS (CURRENT EDITION). The
manufacturer’s instructions must not be taken as overriding any statutory requirements, and failure to comply
with these regulations may lead to prosecution.
No modifications to the appliance should be made unless they are fully approved by the manufacturer.
GAS LEAKS: DO NOT OPERATE ANY ELECTRICAL SWITCH, OR USE A NAKED FLAME. TURN OFF THE GAS SUPPL
Y
AND VENTILATE THE AREA BY OPENING DOORS AND WINDOWS CONTACT THE GAS EMERGENCY SERVICE
ON
0800111999.
Please remember to carry out the following checks after installation. This will achieve complete customer
satisfaction, and avoid unnecessary service calls. A charge will be made for a service visit where the fault is not
due to a manufacturing defect.
Has a correct by-pass been fitted and adjusted?
Has the system and boiler been flushed?
Is the system and boiler full of water, and the correct pressure showing on the pressure gauge?
Is the Auto Air Vent open?
Has the pump been rotated manually?
Is the gas supply working pressure correct?
Is the boiler wired correctly? (See installation manual).
Has the D.H.W. flow rate been set to the customer requirements?
Has the customer been fully advised on the correct use of the boiler, system and controls?
Has the Benchmark Checklist in the use and maintenance section of this manual, been completed?
––

6
SAFETY WARNINGS AND REGULATIONS
m
WARNINGS
– After having removed the packaging
make sure that the product supplied is
integral and complete in all its parts.
If this is not the case, please contact
the Dealer who sold the appliance.
– The appliance must be used as intend-
ed by
Sime Ltd who is not responsible
for any damage caused to persons,
animals or things, improper instal-
lation, adjustment, maintenance and
improper use of the appliance.
– In the event of water leaks, discon-
nect the appliance from the mains
power supply, close the water mains
and promptly inform professionally
qualified personnel.
– Periodically check that the operating
pressure of the water heating system
when cold is
1-1.2 bar . If this is not the
case, increase the pressure or contact
professionally qualified personnel.
– If the appliance is not used for a long
period of time, at least one of the fol-
lowing operations must be carried
out:
-
set the main system switch to "OFF";
- close the gas and water valves for
the water heating system.
– In order to ensure optimal appliance
operations Sime Ltd recommends that
maintenance and checks are carried
out ONCE A YEAR .
– If the power cable is damaged, replace
it with a cable ordered as a spare part
with the same characteristics (type
X). Assembly must be by carried out
by a qualified professional.
m
WARNINGS
– It is recommended that all operators
read this manual carefully in order to
use the appliance in a safe and ration-
al manner.
–
This manual is an integral part of the
appliance. It must therefore be kept
for future reference and must always
accompany the appliance in the event
the appliance is transferred or sold to
another Owner or User or is installed
on another system.
–
Installation and maintenance of this ap-
pliance must be carried out by a qual-
ified company or by a professionally
qualified technician in accordance
with the instructions contained in the
manual. Once the work is complete,
the company or technician will issue
a declaration of conformity with na-
tional and local technical standards
and legislation in force in the country
where the appliance will be used.
–
Any repairs on the appliance must be
carried out solely by professional-
ly qualified personnel, using original
spare parts only. Failure to comply
with these instructions can jeopard-
ise the appliance’s safety and void the
warranty with immediate effect.
–
Fonderie SIME S.p.A. reserves the right
to make improvements to its prod-
ucts at any time without prior notice,
without compromising their essential
characteristics. The graphic illustra-
tions and/or images in this document
may show optional accessories that
vary according to the country in which
the appliance is used.

7
RESTRICTIONS
d
IT IS FORBIDDEN
– To allow children under the age of 8 to
use the appliance. The appliance can
be used by children no younger than 8
years old, by people with physical or
cognitive disabilities, and by people
lacking experience or the necessary
knowledge, provided that they are su-
pervised or have been instructed on
how to use the appliance safely and
that they understand the risks asso-
ciated with it.
– To allow children to play with the ap-
pliance.
– To allow unsupervised children to per-
form user maintenance and cleaning.
– To use electrical devices or applianc-
es such as switches, electrical appli-
ances etc if you can smell fuel. If this
should happen:
-
open the doors and windows to air
the room;
- close the gas isolation device;
- promptly call for professional assis-
tance.
– To touch the appliance with bare feet
or with any wet part of the body.
– To carry out any technical interven-
tion or cleaning operation before hav-
ing disconnected the appliance from
the mains power by setting the main
switch to "OFF", and closing the gas
supply.
– To modify the safety or adjustment
devices without authorization and in-
structions from the manufacturer.
d
IT IS FORBIDDEN
– To block the condensate drain (if
present).
– To pull, detach or twist the electrical
cables coming out of the appliance
even if the appliance is disconnected
from the mains power supply.
– To expose the appliance to the ele-
ments. It is suitable for operating in a
partially protected area in accordance
with the EN 15502 standard, with a
maximum ambient temperature of 60
°C and minimum - 5 °C. We recom-
mend installing the appliance under
a pitched roof extension, on a bal-
cony or in a protected recess, none-
theless never exposed directly to the
elements (rain, hail, snow). The appli-
ance is equipped with a series of an-
ti-freeze functions.
– To block or reduce the size of the ven-
tilation openings of the room where
the appliance is installed, if present.
– Remove the mains power and gas
supply from the appliance if the ex-
ternal temperature could fall below
ZERO (risk of freezing).
– To leave containers with flammable
substances in the room where the ap-
pliance is installed.
– To dispose of the packaging material
irresponsibly as it could be danger-
ous. Packaging must be disposed of
as specified by the legislation in force
in the country where the appliance
will be used.

8
Dear Customer,
Thank you for purchasing a
Sime Ltd Edea boiler, a new-gen-
eration modulating condensing device with technical features
and excellent performance, allowing you to satisfy your heat-
ing and instant domestic hot water requirements with the ut-
most safety and limited running costs.
RANGE
MODEL CODE GAS COUNCIL
NUMBER
EDEA 30 8116900 GC No 47-283-91
EDEA 40 8116902 GC No 47-283-92
COMPLIANCE
Our company declares that the Edea appliances conform to
the essential requirements of the following directives:
– Gas Appliances EU Regulation 2016/426
– Boiler Efficiency Directive 92/42/EEC
– Low Voltage Directive 2014/35/EU
– Electromagnetic Compatibility Directive 2014/30/EU
– Ecodesign Directive 2009/125/EC
– Regulation (EU) No. 811/2013 - 813/2013
– Energy labelling Regulation (EU) No. 2017/1369
Please refer to the technical data plate for the serial number
and year of manufacture.
SYMBOLS
a
WARNING
To indicate actions which, if not carried out correctly,
can result in injury of a general nature or may dam-
age or cause the appliance to malfunction; these
actions therefore require particular caution and ad-
equate preparation.
f
ELECTRICAL HAZARD
To indicate actions which, if not carried out correct-
ly, could lead to injury of an electrical nature; these
actions therefore require particular caution and ad-
equate preparation.
d
IT IS FORBIDDEN
To indicate actions which MUST NOT BE carried out.
m
CAUTION
To indicate particularly important and useful infor-
mation.
MANUAL STRUCTURE
This manual is organized as follows.
USER INSTRUCTIONS
TABLE OF CONTENTS 9
DESCRIPTION OF THE APPLIANCE
TABLE OF CONTENTS 15
INSTALLATION AND SERVICING
INSTRUCTIONS
TABLE OF CONTENTS 25

9
USER INSTRUCTIONS
TABLE OF CONTENTS
VERY IMPORTANT!
PLEASE MAKE SURE YOUR COMMISSIONING CHECKLIST AND THE SERVICE INTERVAL RECORDS ENCLOSED
ARE FILLED IN CORRECTLY.
ALL GAS SAFE REGISTERED INSTALLERS CARRY A GAS SAFE ID CARD.
BOTH SHOULD BE RECORDED IN YOUR COMMISSIONING CHECKLIST AND A SERVICE INTERVAL RECORDS.
YOU CAN CHECK YOUR INSTALLER IS GAS SAFE REGISTERED
BY CALLING ON 0800 408 5500 OR ALTERNATIVELY WWW.GASSAFEREGISTER.CO.UK
1 OPERATING WITH EDEA 10
1.1 Control panel ..................................10
1.2 Preliminary checks .............................11
1.3 Ignition .......................................11
1.4 Adjusting the heating temperature ................11
1.5 Adjusting the domestic hot water temperature ......11
1.6 Fault / malfunction codes ........................12
1.6.1 Maintenance request .................. 12
2 SHUTDOWN 12
2.1 Temporary shutdown............................12
2.2 Shutting down for long periods ...................13
3 MAINTENANCE 13
3.1 Adjustments...................................13
3.2 External cleaning...............................13
3.2.1 Cleaning the cladding.................. 13
4 DISPOSAL 13
4.1 Disposal of the equipment (European Directive
2012/19/EU) ...................................13

10
1 OPERATING WITH EDEA
1.1 Control panel
321
Fig. 1
1 FUNCTIONAL BUTTONS
yIf pressed once or more times for at least 1 second
during normal operation, this button allows the user
to change the appliance’s operating mode in a cyclical
sequence (Stand-by – Summer – Winter). If the appli-
ance is experiencing a resettable fault, it can be used
to unlock it.
<This allows the user to scroll through the parameters
or decrease the values.
>This allows the user to scroll through the parameters
or increase the values.
CProgramming connector cover plug.
2 KNOBS
tThe heating knob allows the user to set the heating
temperature to between 20 and 80°C during normal
operation.
rThe domestic hot water knob allows the user to set the
domestic hot water temperature to between 10 and
60°C during normal operation.
NOTE: pressing any button for more than 30 seconds causes a
fault to appear on the display (ALL 42) without preventing the
appliance’s operation. The warning disappears when normal
conditions are restored.
3 DISPLAY
l
“SUMMER” . This symbol appears when the boiler is op-
erating in "Summer" mode or if only the domestic hot
water mode is enabled via the remote control.
n
“WINTER” . The symbol is present in the “Winter” oper-
ating mode, or with the remote control if both the do-
mestic hot water and heating modes are enabled. The
flashing land nsymbols signal that the “chimney
sweep” function is active.
d
“RESET REQUEST” . The wording indicates that, once the
fault has been repaired, the appliance’s normal opera-
tion can be reset by pressing the ybutton.
r
“DOMESTIC HOT WATER” . This symbol is present during
a DHW request or during the "chimney sweep func-
tion" It flashes during the selection of the domestic hot
water set point.
t
“HEATING” . This symbol lights up during heating oper-
ation or during the "chimney sweep function It flashes
during the selection of the heating set point.
f
“BLOCK” DUE TO NO FLAME .
F
“FLAME PRESENCE" .
v
“POWER LEVEL” . Indicates the power level at which the
appliance is operating.
p
“PARAMETER" . This indicates that the user may be in
parameter setting/display, or "info" or "counter", or in
"activated alarms" (history).
A
“ALARM" . This indicates that a fault has occurred.
The number specifies the cause which generated the
alarm.
z
“CHIMNEY SWEEP" . This indicates that the "chimney
sweep function" has been activated.
e
“EXTERNAL TEMPERATURE SENSOR” . Indicates that the
external temperature sensor has been installed and
that the appliance is working at a sliding temperature.
a
“HEATING SYSTEM PRESSURE" . Display of heating sys-
tem pressure.
E
"ECO", ALTERNATIVE ENERGY SOURCES . Where active, it
indicates that there is a solar system available.
c
“MAINTENANCE REQUEST” . If active, it indicates that it is
time to perform maintenance on the appliance.

11
1.2 Preliminary checks
a
WARNING
– Should it be necessary to access the areas in the
bottom part of the appliance, make sure that the
system components and pipes are not hot (risk of
burning).
– Before replenishing the heating system, put on
protective gloves.
The initial start-up of
Edea must be carried out by profession-
ally qualified personnel, after which the appliance can func-
tion automatically. It may be necessary for the user to restart
the appliance automatically, without contacting the techni-
cian; for example, after a holiday.
First of all check that the gas isolation and water system
valves are open.
1.3 Ignition
After completing the preliminary checks, start up Edea :
– set the main system switch to "ON" in order for the display
to show the pressure level in the system during refilling
–
make sure that the operating mode is set to "Stand-by"; if this
is not the case, press the button yuntil "Stand-by" mode
has been selected
ON
Fig. 2
– check that the pressure in the heating system, when cold, is
1-1.2 bar . If the pressure is less than this, use the external
filling device to repressurise the system to
1-1.2 bar
– ensure that the filling device is turned off after use
– press and hold the button yfor more than 3 seconds and
check whether normal operating conditions are restored.
Fig. 3
– select the "SUMMER" loperating mode by pressing and
holding the y button for at least 1 second. the value of
the delivery sensor detected at that moment will appear on
the display
– open one or more hot water taps. Edea will work at its max-
imum power until the tap or taps are closed.
Once
Edea is commissioned in “SUMMER mode” l, with
the ybutton, pressed for at least 1 second, it is possible to
choose the “WINTER mode” n. The display will show the val-
ue of the delivery water temperature measured at that time.
In this case it is necessary to adjust the room thermostat(s) at
the desired temperature or, if the system is equipped with a
timer-controlled thermostat, verify that it is “active” and ad-
justed.
1.4 Adjusting the heating temperature
To increase or decrease the delivery temperature of Edea , in-
stead of modifying the specific parameter, it is possible to turn
knob ton the control panel. The temperature can be set to
between 20 and 80°C.
Fig. 4
1.5 Adjusting the domestic hot water tem-
perature
If the domestic hot water temperature is to be increased or
decreased, act on the rknob on the control panel. The tem-
perature can be set to between 10 and 60°C.
Fig. 5

12
1.6 Fault / malfunction codes
If, during the operation of Edea , an anomaly/fault occurs, the
display will show
“ALL” followed by the anomaly code.
If you see alarm
“02” (low water pressure in the system):
– check that the pressure in the heating system, when cold, is
1-1.2 bar . If the pressure is less than this, use the external
filling device to repressurise the system to
1-1.2 bar
– ensure that the filling device is turned off after use
– press and hold the button yfor more than 3 seconds and
check whether normal operating conditions are restored.
1
Fig. 6
If you see alarm “06” (no flame detected) and “07” (safety ther-
mostat intervention):
– press and hold the button yfor more than 3 seconds and
check whether normal operating conditions are restored.
If this operation is not successful, ONLY ONE MORE ATTEMPT
can be made, therefore:
– close the gas isolation valve
– set the main system switch to "OFF"
– contact the Personale Tecnico Abilitato.
OFF
Fig. 7
m
CAUTION
Should you see an alarm not described here, contact a
qualified technical professional
.
1.6.1 Maintenance request
When it is time to perform maintenance on the boiler, the c
symbol shows on the display.
Contact the technical assistance service to organise the nec-
essary work.
2 SHUTDOWN
2.1 Temporary shutdown
To temporarily interrupt the operation of Edea , press the y
button for at least 1 second, once from the “WINTER mode”
nor twice from the “SUMMER mode” l.
"- -" will appear on the display.
f
ELECTRICAL HAZARD
The boiler will still be powered.
If the user is away temporarily, for a weekend, short trip etc
and if the outside temperature is at ZERO:
– press the ybutton, once from the “WINTER mode” n
or twice from the “SUMMER mode” l, to put the
Edea in
stand-by
– set the main system switch to "OFF"
– close the gas valve.
OFF
Fig. 8
m
CAUTION
If the outside temperature might fall below ZERO,
since the appliance is equipped with an "antifreeze
function"
– ONLY PUT THE BOILER INTO STAND-BY
– leave the system’s main switch set to “ON” (appli-
ance powered electrically)
– leave the gas valve open.

13
2.2 Shutting down for long periods
If the boiler is to be left unused for a long period, the following
operations need to be carried out:
– press the ybutton for at least 1 second, once from the
“WINTER mode” nor twice from the “SUMMER mode”
l, to put the
Edea in stand-by. The display will show "- -"
– set the main system switch to "OFF"
OFF
Fig. 9
– close the gas valve
– close the heating and domestic hot water isolation valves
– drain the heating and domestic hot water system if there is
the risk of freezing.
m
CAUTION
Contact the Personale Tecnico Abilitato if the proce-
dure described above cannot be easily carried out.
3 MAINTENANCE
3.1 Adjustments
For the appliance to operate correctly and efficiently it is rec-
ommended that the User calls upon the services of a Pro-
fessionally Qualified Technician to carry out
ANNUAL mainte-
nance.
m
CAUTION
Maintenance must ONLY be carried out by qualified
professionals who follow the indications provided in
the INSTALLATION AND MAINTENANCE INSTRUC-
TIONS.
3.2 External cleaning
a
WARNING
– Should it be necessary to access the areas in the
bottom part of the appliance, make sure that the
system components and pipes are not hot (risk of
burning).
– Before performing any maintenance, put on pro-
tective gloves.
3.2.1 Cleaning the cladding
When cleaning the cladding, use a cloth dampened with soap
and water or alcohol for stubborn marks.
d
IT IS FORBIDDEN
to use abrasive products.
4 DISPOSAL
4.1 Disposal of the equipment (European
Directive 2012/19/EU)
At the end of their life span, the appliance
and electrical and electronic devices coming
from households or classifiable as house-
hold waste must be delivered to appropriate
waste collection systems, in accordance with
the law and with Directive 2012/19/EU. This
product was designed and manufactured for
minimising its impact on the environment and
on human health, but it contains components
that could be detrimental if managed improp-
erly. The symbol (crossed-out wheelie bin)
depicted here and also appearing on your ap-
pliance means that the appliance at the end of
its life must be managed in accordance with
the law and treated as electrical and electron-
ic waste. Before delivering the appliance for
its disposal, consult the applicable provisions
of the laws in force in the country where the
appliance is used and get information on the
authorised waste disposal facilities by con-
tacting the relevant local offices.
d
IT IS FORBIDDEN
dispose of the product with urban waste.

14

15
DESCRIPTION OF THE APPLIANCE
TABLE OF CONTENTS
5 DESCRIPTION OF THE APPLIANCE 16
5.1 Characteristics ................................16
5.2 Check and safety devices ........................16
5.3 Identification ..................................16
5.3.1 Technical Data Plate................... 17
5.4 Structure .....................................18
5.5 Main water circuit ..............................20
5.6 Sensors.......................................20
5.7 Expansion vessel ...............................21
5.8 Circulation pump ...............................21
5.9 Control panel ..................................22
5.10 Wiring diagram ................................23

16
5 DESCRIPTION OF THE APPLIANCE
5.1 Characteristics
Edea are last generation condensing wall mounted boilers
which
Sime Ltd has produced for heating and instant domestic
hot water production when combined with a storage tank. The
main design choices made by
Sime Ltd for the Edea boilers are:
– the total pre-mix microflame burner combined with a stain-
less steel heat exchanger with a plaster outer shell, for
heating
– the sealed combustion chamber which can be classified
"Type C" or "Type B" in relation to the room where the boil-
er is installed, depending on the smoke outlet configuration
adopted during installation
– the electronic control and command circuit board with mi-
croprocessor, for optimal management of the heating sys-
tem and modulation of up to 1:10 for the instant produc-
tion of domestic hot water. It allows for connecting room
thermostats, an auxiliary sensor for managing kits, and the
external sensor. The presence of the external sensor will
make the boiler work at a variable temperature, in other
words, the temperature in the boiler will vary in relation to
the outdoor temperature, in accordance with the optimal cli-
matic curve selected during the installation phase, result-
ing in considerable energy and financial savings. Moreover,
the command board has an internal connection for inserting
an expansion board which is used to control external relays.
Other special features of the
Edea boilers are:
– the anti-freeze function which activates automatically if the
temperature of the water inside the boiler falls below the
threshold of the value set at parameter "PAR 10" and , if
there is an external sensor, if the external temperature falls
below the threshold of the value set at parameter "PAR 11"
– the anti-blocking function of the pump and diverter valve,
this activates automatically every 24 hours if no request for
heat has been made
– the chimney sweep function lasts 15 minutes and makes
the job of the qualified technician easier when measuring
the parameters and combustion efficiency
– domestic hot water comfort function which allows the time
necessary for the hot water to become available to be re-
duced and ensures that the temperature is stable
– screen display of the operating and self-diagnostic param-
eters with error code display when the fault occurs. This
makes repair interventions easier and allows appliance op-
eration to be restored correctly.
5.2 Check and safety devices
The Edea boilers are equipped with the following check and
safety devices:
– thermal safety thermostat 100°C
– 3 bar relief valve
– heating water pressure transducer
– delivery sensor
– DHW sensor
– smoke flue gas probe
– return sensor.
d
IT IS FORBIDDEN
To commission the appliance with safety devices
which do not work or which have been tampered
with.
a
WARNING
Safety device may only be replaced by professional
qualified personnel using
Sime Ltd original spare
parts.
5.3 Identification
The Edea boilers can be identified by means of:
1 Packaging label: this is located on the outside of the pack-
aging and provides a code, the serial number of the boiler
and the bar code.
2 Energy Efficiency Label: this is positioned on the outside of
the packaging to notify the User of the level of energy sav-
ings and reduced environmental pollution produced by the
appliance.
3 Technical Data Plate: this is located inside the front panel of
the boiler and provides the technical data, appliance per-
formance information and any other information required
by law in the country where the appliance will be used.
4 Steaker of product identification .
1
3
1
I II
A
B
C
D
E
F
G
2015 811/2013
Cod. 6244745
dB
kW
A++
A+
A
B
C
D
E
F
G
2
3
2
4
4
Code
Model
Serial/N.
GC No
_ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _
_ _ - _ _ _ - _ _
Fig. 10

17
5.3.1 Technical Data Plate
TYPE OF GAS
CODE
APPLIANCE TYPE
MAX OPERATING TEMPERATURE
MIN USEFUL INPUT (50-30°C)
MAX D.H.W. TEMPERATURE
MIN HEAT INPUT
MIN USEFUL OUTPUT (80-60°C)
APPLIANCE CLASSIFICATION
TYPE OF GAS
SUPPLY PRESSURE
MIN HEAT INPUT
NOx CLASS
GAS COUNCIL NUMBER CODE (UK)
WRAS CERTIFICATION (UK)
ELECTRICAL PROTECTION DEGREE
N° PIN
YEAR OF MANUFACTURE
SERIAL NUMBER
NAME
MAX USEFUL OUTPUT (50-30°C)
MAX OPERATING PRESSURE
MAX USEFUL OUTPUT (80-60°C)
MAX HEAT INPUT
WATER CONTENT IN BOILER
FLOW RATE
MAX OPERATING PRESSURE
ELECTRICAL SUPPLY
MAXIMUM ABSORBED POWER
MAX HEAT INPUT
COUNTRY OF INTENDED INSTALLTION
APPLIANCE CATEGORY
D.H.W. CONTENT
Fig. 11
m
CAUTION
Tampering with, removing or failing to display the identification plate or carrying out any other operation which does not
allow safe identification of the product or which may hinder installation and maintenance operations.

18
5.4 Structure
24
25
26
27
30
13 14 15
17
16 21
19 20
18
1
2
3
4
5
6
9
10
11
12
8
7
2829
22
23
1 Heat exchanger
2 Combustion chamber door
3 Oversleeve
4 Flame viewing window
5 Ignition/detection electrode (EAR)
6 Safety thermostat (TS)
7 Fan (V)
8 Boiler delivery sensor (SMC)
9 Condensate siphon outlet
10 Diverter solenoid valve (EVD)
11 System filling unit
12 Domestic hot water sensor (SS)
13 Control panel
14 Domestic hot water heat exchanger
15 Gas valve
16 Domestic hot water flow meter (FLM)
17 Domestic hot water filter
18 Relief valve (FS)
19 Water pressure transducer (TPAC)
20 System pump (PI)
21 Boiler drain
22 Automatic bleed valve
23 Boiler return probe (SRC)
24 Air-gas mixer
25 Expansion vessel (VE)
26 Air inlet pipe
27 Air-smoke chamber
28 Air inlet
29 Smoke outlet duct (CSFU)
30 Smoke flue gas probe (SF)
Fig. 12

19
DESCRIPTION
Edea
30 40
CERTIFICATIONS
Country of intended installation GB
Fuel G20 - G31
PIN number 1312CU6393
Category II2H3P
Appliance classification B23P - B33P - B53P - C13 - C33 - C43 - C53 - C63 - C83 - C93 - C(10)3
DHW rated useful heat output kW 30,0 40,0
Class NOx(*) 6 (< 56 mg/kWh)
HEATING PERFORMANCE
HEAT INPUT (**)
Nominal flow (Qnmax) kW 25 34,8
Minimum flow G20/G31 (Qnmin) kW 3,0 / 4,0 4,5 / 5,5
HEAT OUTPUT
Nominal (80-60°C) (Pnmax) kW 24,5 34,1
Nominal (50-30°C) (Pnmax) kW 26,4 36,7
Minimum G20 (80-60°C) (Pnmin) kW 2,8 4,2
Minimum G20 (50-30°C) (Pnmin) kW 3,1 4,7
Minimum G31 (80-60°C) (Pnmin) kW 3,7 5,1
Minimum G31 (50-30°C) (Pnmin) kW 4,2 5,7
EFFICIENCY
Max useful efficiency (80-60°C) % 98 98
Min useful efficiency (80-60°C) % 93,3 93,3
Max useful efficiency (50-30°C) % 105,8 105,6
Min useful efficiency (50-30°C) % 104,7 104,2
Useful efficiency at 30% of load (40-30°C) % 108,7 108,5
Losses after shutdown at 50°C W 105 115
DOMESTIC HOT WATER PERFORMANCE
Nominal heat input (Qnw max) kW 30 40
Minimum heat input G20/G31 (Qnw min) kW 3,0 / 4,0 4,5 / 5,5
Specific D.H.W. flow rate ∆T 30°C (EN 13203) l/min 13,0 18,8
Continuous D.H.W. flow rate (∆T 25°C / ∆T 35°C) l/min 16,9 / 12,0 22.5 / 16.1
Minimum D.H.W. flow rate l/min 2,0 2,0
Max (PMW) / Min Pressure bar 7 / 0,5
kPa 700 / 50
ENERGY PERFORMANCE
HEATING
Heating seasonal energy efficiency class A A
Heating seasonal energy efficiency % 93 93
Sound power dB(A) 55 56
DOMESTIC HOT WATER
Domestic hot water energy efficiency class A A
Domestic hot water energy efficiency % 86 86
Stated domestic hot water profile load XL XXL
ELECTRICAL SPECIFICATIONS
Power supply voltage V 230
Frequency Hz 50
Absorbed electrical power (Qnmax) W 93 113
Absorbed electrical power at (Qnmin) W 67 65
Absorbed electrical power in stand-by W 4 6
Electrical protection degree IP X5D
COMBUSTION DATA
Smoke temperature at Max/Min flow (80-60°C) °C 80,0 / 62,0 74,5 / 58,2
Smoke temperature at Max/Min flow (50-30°C) °C 51,3 / 42,5 52,3 / 44,2
Smoke flow Max/Min g/s 14,5 / 1,5 18,8 / 2,2
CO2at Max/Min flow rate (G20) % 9,2 / 9,0 9,3 / 9,1
CO2at Max/Min flow rate (G31) % 10,2 / 10,0 10,0 / 10,0
NOx measured mg/kWh 15 34
Gas consumption at Max/Min flow rate (G20) m3/h 3,17 / 0,32 4,23 / 0,48
Gas consumption at Max/Min flow rate (G31) kg/h 2,33 / 0,31 3,11 / 0,43
Gas supply pressure (G20/G31) mbar 20 / 37 20 / 37
kPa 2 / 3,7 2 / 3,7

20
DESCRIPTION
Edea
30 40
NOZZLES  GAS
Number of nozzles No. 2 2
Nozzle diameter (G20) mm 3,5 / 4,0 4 / 4,5
Nozzle diameter (G31) mm 2,8 / 3,0 2,8 / 3,4
TEMPERATURE  PRESSURE
Max operating temperature (T max) °C 85
Heating adjustment range °C 20÷80
Domestic hot water adjustment range °C 10÷60
Max operating pressure (PMS) bar 3
kPa 300
Water content in boiler l 5,1 5,8
(*) NOx class according to UNI EN 15502-1:2015
(**) Heat input calculated using the lower heat output (Hi)
Lower Heat Output (Hi)
G20 Hi. 9.45 kW/m
3
(15°C, 1013 mbar) - G31 Hi. 12.87 kW/kg (15°C, 1013 mbar)
5.5 Main water circuit
4
6
7
15
14
16 17
19
20
11
10
9
12
18
21
13
8
M U G E R
Sc SVS
5
3
2
1
22 23 24 25
Fig. 13
KEY:
M System delivery
R System return
U Domestic hot water outlet
E Domesti hot water inlet
SVS Safety valve outlet
G Gas supply
Sc Condensate outlet
1 Smoke flue gas probe (SF)
2 Heat exchanger
3 Combustion chamber
4 Fan (V)
5 Boiler return probe (SRC)
6 Safety thermostat (TS)
7 Boiler delivery sensor (SMC)
8 Domestic hot water heat exchanger
9 Water pressure transducer (TPAC)
10 Automatic bleed valve
11 System pump (PI)
12 Expansion vessel (VE)
13 Diverter solenoid valve (EVD)
14 Automatic by-pass
15 Domestic hot water sensor (SS)
16 Gas valve
17 Domestic hot water flow meter
18 Domestic hot water filter (FLM)
19 Boiler drain
20 Relief valve (FS)
21 Condensate siphon outlet
22 System delivery valve
23 Gas valve
24 Domestic hot water inlet valve
25 System return valve
5.6 Sensors
The sensors installed have the following characteristics:
– NTC R25°C (delivery) sensor; 10kΩ β25°-85°C: 3435
– domestic hot water sensor NTC R25°C; 10kΩ β25°-85°C:
3435
– External temperature sensor NTC R25°C; 10kΩ β25°-85°C:
3435
TR
0°C 1°C 2°C 3°C 4°C 5°C 6°C 7°C 8°C 9°C
Resistance R (Ω)
0°C 27279
17959
12090
8313
5828
4161
3021
2229
1669
1266
973
26135
17245
11634
8016
5630
4026
2928
2164
1622
1232
25044
16563
11199
7731
5440
3897
2839
2101
1577
1199
24004
15912
10781
7458
5258
3773
2753
2040
1534
1168
23014
15289
10382
7196
5082
3653
2669
1982
1491
1137
22069
14694
9999
6944
4913
3538
2589
1925
1451
1108
21168
14126
9633
6702
4751
3426
2512
1870
1411
1079
20309
13582
9281
6470
4595
3319
2437
1817
1373
1051
19489
13062
8945
6247
4444
3216
2365
1766
1336
1024
18706
12565
8622
6033
4300
3116
2296
1717
1300
998
10°C
20°C
30°C
40°C
50°C
60°C
70°C
80°C
90°C
100°C
Correspondence of Temperature Detected/Resistance
Examples of reading:
TR=75°C → R=1925Ω
TR=80°C → R=1669Ω.
