Simoniz Blend Rite User manual

Blend Rite
Portable
Dispenser Package Should Contain:
1. Proportioner unit.
2. Water inlet hose, 3/8" X 6'.
3. Instruction sheet.
THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS
protective clothing and eyewear when dispensing chemicals or other materials.
observe safety and handling instructions of the chemical manufacturers.
direct discharge away from you or other persons or into approved containers.
dispense cleaners and chemicals in accordance with manufacturer's instructions.
Exercise CAUTION when maintaining your equipment.
equipment clean to maintain proper operation.
protective clothing and eyewear when working in the vicinity of all chemicals, filling or
emptying equipment.
re-assemble equipment according to instruction procedures. Be sure all components
are firmly screwed or latched into position.
only to tap water outlets (85 PSI maximum).
If the unit is used to fill a sink or the discharge hose can be placed into a sink, the unit
must be mounted so that the bottom of the cabinet is above the overflow rim of the sink.
WEAR
ALWAYS
ALWAYS
ALWAYS
KEEP
WEAR
ALWAYS
ATTACH
Please use this equipment carefully and observe all warnings and cautions.
*******************************************************NOTE ********************************************
NOTE
Installation&Operation:
2a. 2b.
s
s
s
s
90087932
Rev. B 4/09
2. Insert product container into shroud until it locks into place.
1. Connect water supply
hoseof3/8"IDtowater
inlet swivel. Min. 20 PSI
pressure is required for
proper operation. Con-
-nect opposite end of
hose to water supply.
Turn water supply on.
Continuednextpage...
Flow
Select
Switch
"Off"
Button
"On"
Trigger
"On"
Trigger
3a.Slide flow select switch
towards bottle icon for low
flow then depress trigger
to begin dispensing desired
concentrate solution; push
"Off" button on top of handle
to stop flow of solution.
3b.Slideflowselectswitchtowards
bucket icon for high flow then
depress trigger to begin dis-
-pensing desired concentrate
solution; push "Off" button on
top of handle to stop flow of
solution.

DescriptionPartNo.Key
1 238100 Strainer washer
2 10090042 Shroud Seal and Bottle release ring
NOTSHOWN:
10091920 Waterinlethose,3/8"X6'
10b.
TROUBLESHOOTING CHART:
Problem Cause Solution
1. No discharge a. No water a. Open water supply
b. Excessive water pressure b. Install regulator if flowing water pressure
exceeds 80 PSI
c. Clogged water inlet strainer c. Disconnect inlet water line and clean strainer
2. No concentrate draw a. Low water pressure a. Minimum 20 PSI (with water running)
required to operate unit properly
b. Concentrate container empty b. Replace with full container
c. Concentrate container not c. Remove and install Concentrate container
properly installed
3. Foaming in discharge a. Concentrate container in unit a. Remove and reinstall Concentrate container
malfunctioning or not installed or Replace with new concentrate container
properly
4. Failure of unit to turn off a. Excessive water pressure a. Install regulator if pressure (with water
flowing) exceeds 80 PSI
5. Unit is too hard to turn a. Excessive water pressure a. Install regulator if pressure (with water
turn on flowing) exceeds 80 PSI
1
Bottle Fill Chemical
Inlet
Bucket Fill Chemi-
cal inlet
Top view of chemical inlet port
2
Parts Diagram:
Installation&Operationcontinued:
4. To remove chemical concentrate container, place
hand securely under the empty product, slide release
lever to the right and pull concentrate container out.
