Simoniz 039-8583-4 User manual

1 | Page
GAS PRESSURE WASHER
039-8583-4
OWNER’S MANUAL
Questions?
If you have a question or if there are missing parts,
please call:
1-866-4-SIMONIZ
(1-866-474-6664)
Monday-Saturday 7:00 am-8:00 pm EST
Product #: 039-8583-4
Serial #: _____________________
Purchase Date: ________________
TO PREVENT DAMAGE AND BODILY HARM, ENSURE ENTIRE MANUAL HAS BEEN
READ BEFORE OPERATING PRESSURE WASHER UNIT. ANY QUESTIONS OR CONCERNS
REGARDING THIS MANUAL SHOULD BE DIRECTED TO THE SIMONIZ TOLL-FREE
NUMBER.

2 | Page
TABLE OF CONTENTS
SPECIFICATIONS..............................................................................................................................................................2
SAFETY INSTRUCTIONS.................................................................................................................................................3
PRESSURE WASHER FEATURES....................................................................................................................................8
ASSEMBLYAND PRE-START CHECK...........................................................................................................................9
START-UP PROCEDURES & OPERATIONS.................................................................................................................13
TROUBLESHOOTING.....................................................................................................................................................17
MAINTENANCE..............................................................................................................................................................18
DIAGRAM & PARTS LIST..............................................................................................................................................22
LIMITED WARRANTY....................................................................................................................................................24
SPECIFICATIONS
Model S2900
Product # 039-8583-4
Maximum Pressure 2900 PSI
Rated Water Pressure 2200 PSI
Maximum Water Volume 2.3 US GPM
Minimum Inlet Pressure 30 PSI
Maximum Inlet Pressure 90 PSI
Pump Type Heavy-duty maintenance-free axial cam
Thermal Relief Valve Included
Detergent Tank (Volume) Double,0.2 Gallon (US)
Maximum Temperature of Pumped Fluid 60°C
Engine Power (OHV) 6.5 HP
No Load Speed 3,600 RPM
High Pressure Hose Length 30’ (9 m)
Inlet & Discharge Ports 3/4” standard garden hose connector
Displacement 196 (cc)
Wheels 10” (25.4 cm) pneumatic wheels
Net Weight 77 lb 3 oz (35 kg)
Oil Specification SAE 10W-30
Oil Capacity (L) 0.6 L
Fuel Unleaded Gasoline
Fuel Tank (L) 3.6 L

3 | Page
SAFETY INSTRUCTIONS
WARNING
To reduce the risk of serious injury, read all instructions and precautions before operating this
machine.
SYMBOL MEANINGS:
TOXIC This symbol warns you of possible toxic gases which can
be harmful to your health or deadly if you are exposed to
them.
FLAMMABLE AND
COMBUSTIBLE MATERIALS
This symbol warns of materials/gases which are present
and extremely flammable. When you see this symbol, be
very cautious not to ignite the materials/gases.
VERY POISONOUS
This symbol warns of materials, gases, etc. which are very
poisonous and would cause serious bodily harm or death.
When you see this symbol, please take proper
precautions.
HOT SURFACE
This symbol warns of a hot surface which could cause
damage to material and/or damage to human skin if
touched. Please take proper precautions when you see
this symbol.
GENERAL WARNING
This symbol indicates that serious bodily injury or death
could occur if proper precautions are not taken. These are
warning statements which do not fall into the above
categories
EXHAUST FUMES ARE DANGEROUS
•Never operate unit in enclosed areas such as garages, basements, storage sheds, or in any
location occupied by humans or animals. Never operate the engine in a closed area or it may cause
unconsciousness and death within a short time. Operate pressure washer in a clean, dry, well-
ventilated area.
•Keep children, pets and others away from area around the unit while it is operating. Breathing
exhaust fumes will cause serious injury or death.
WARNING: Gasoline engines produce toxic carbon monoxide exhaust fumes.

4 | Page
INADEQUATE VENTILATION
•Placing materials against or near the pressure washer or operating the unit in areas where the
temperature exceeds 40°C ambient (such as storage rooms or garages) can interfere with its proper
ventilation features causing overheating and possible ignition of the materials or buildings.
•Operate pressure washer in a clean, dry, well-ventilated area a minimum of 4’ (1.2 m) from any
building, object or wall. DO NOT OPERATE UNIT INDOORS OR IN ANY CONFINEDAREA.
FUEL IS HIGHLY FLAMMABLE AND POISONOUS
•Always turn off the engine when refuelling.
•Never refuel while smoking or in the vicinity of an open flame.
•When operating or manoeuvring the pressure washer, be sure to keep it upright. If it tilts, fuel may
leak from the carburettor or fuel tank.
DO NOT ATTEMPT TO FILL GASOLINE TANK WHILE ENGINE IS RUNNING.
•Gasoline and gasoline vapours can become ignited by coming into contact with hot components
such as the muffler, engine exhaust gases, or from an electrical spark.
•Turn engine off and allow it to cool before adding fuel to the tank. Equip the area of operation with a
fire extinguisher certified to handle gasoline or fuel fires.
SPARKS, FIRE, HOT OBJECTS
•Cigarettes, sparks, fires, or other hot objects can cause gasoline or gasoline vapours to ignite.
ENGINE AND MUFFLER MAY BE HOT
•Place the pressure washer in an appropriate location, away from children and pedestrians.
•Avoid placing any flammable materials near the exhaust outlet during operation or shortly thereafter.
•Keep a 4’ (1.2 m) clearance from buildings or other equipment around the pressure washer to
prevent overheating.
WARNING The engine muffler will be very hot during and after use, avoid touching the
engine or muffler while they are still hot.

5 | Page
HOT MUFFLER & HIGH PRESSURE HOSE
•Muffler will become very hot during operation. DO NOT TOUCH MUFFLER WHILE IN USE OR
SHORTLY THEREAFTER.
•Keep hose away from the hot muffler or it may damage the hose. Do not use a damaged high
pressure hose. Do not kink the high pressure hose.
APPLICATION
•This equipment is designed for specific residential applications. Do not modify or use for any
purpose other than those for which it is designed. This equipment is not designed for industrial use..
Please refer to icons above for suggested uses. For questions regarding other uses, please refer to
our website at www.simoniz.ca or call us at 1-866-4SIMONIZ (1-866-474-6664).
NEVER OPERATE UNDER THE FOLLOWING CONDITIONS
•When a noticeable change in engine speed occurs.
•Engine misfires.
•Loss of water pressure.
•Smoke or flames in the area.
•Excessive vibration.
WATER SPRAY
•Never direct the water spray towards ANY person, animal, electrical wiring or the pressure washer
itself.
•DO NOT spray too close to the surface being cleaned or damage could occur.
•The vendor is not responsible for damage caused by improper use.
PREVENT ACCIDENTAL WATER SPRAY
•To prevent accidental water spray, the wand trigger should be in the locked position when not in
use.
KEEP HANDS AWAY
•Keep hands and other body parts away from high pressure water stream as water pressure will
cause severe bodily harm.

6 | Page
SAFETY GLASSES
•Always wear safety glasses while operating.
DETERGENTS
•Only use detergents recommended for pressure washers. Using detergents not specifically
recommended for use with pressure washers can cause damage to pump and other pressure
washer components.
•DAMAGE CAUSED TO PRESSURE WASHER UNIT BY USING NON-RECOMMENDED
DETERGENTS IS NOT COVERED UNDER WARRANTY.
COLD WEATHER STARTS
•Do not operate this pressure washer in temperatures below 5°C. Operating pressure washer in
temperatures below may cause damage to pump and other pressure washer parts.
•DAMAGE TO PRESSURE WASHER UNIT BY USER MISUSE IS NOT COVERED UNDER
WARRANTY.
SAFETY FEATURES
•Thermal Relief Valve
Protects the pump from overheating in case nozzle becomes clogged. This system should not be
abused. Make every effort to prevent the pump from overheating.
•Low-Oil Auto Shut-Off
This pressure washer is equipped with a low oil shut-off system. If the engine oil falls below
the recommended level, the pressure washer will automatically shut-off. This protects your
engine and prevents operating without proper lubrication.
STORAGE
•Store the pressure washer in a well-ventilated area with the fuel tank empty. Fuel should never be
stored or placed near the pressure washer.
•In winter, store the pressure washer indoors (at room temperature) in a dry location, away from any
heat sources.
•If unused gas will not be used for alternative purposes immediately, use fuel stabilizer to keep the
gas from breaking down.
•To protect and extend the life of your pressure washer when storing, use pump antifreeze, which
can be found at your local Canadian Tire store.
PREVENT PUMP DAMAGE
•Do not run the pressure washer engine for more than 5 minutes without pressing the wand trigger
or damage to the pump may result.
•Never let the machine run unless connected to the water supply. Ensure water supply is running
water through the pressure washer before attempting to start engine.
•Never run caustic fluids or acid through this machine

7 | Page
PRESSURE WASHER FEATURES
A– Trigger Locking Latch –Will prevent from mis-
operating or spraying accidentally.
B– Wand –Will extend your reach for easier cleaning.
C– Spray Nozzles – 0°, 15°, 25°, 40°, soap tip; Use
to apply the right pressure for each specific project
D– Muffler – Ensure you avoid contact as this will be
hot during and shortly after use. Avoid resting the
pressure hose on muffler.
E– Fuel Cap – Ensure cap is on tight during use.
F– Fuel Tank – Has a 4 L capacity.
G– Spark Plug –Should be checked every 100 hours
of operation.
H– Air Filter – Filter should be replaced annually to
ensure optimal performance
I – Throttle Lever – This will adjust the engine speed
J– Choke Lever –Will control incoming air.
K– Fuel Valve – Regulates the flow of fuel to the
engine. Must be fully open before starting engine.
L– Recoil Starter – This will start the engine
M–O/I Switch – Ensure this is set to ‘I’
before attempting to start engine.
N– Oil Dipstick – Ensure the unit has the proper
level of oil before starting engine. Use
only SAE 10W-30 oil.
O– Pump – Increases the water pressure
P– Pump Inlet – Using included quick-connect
coupling, attach your garden hose here.
Q– Pump outlet – Attach your pressure hose here.
R–Thermal Relief Valve – This includes a drain
pipe to be used if resting water inside pump
becomes too hot. This will help prevent damage
to pump.
S– Detergent Tank Caps – Take these caps off to fill
either detergent tank with pressure washer
approved detergent.
T– Detergent Dial – Allows you to switch between
different detergents without stopping.
U– Pressure Hose – Attach to pump and gun.
30’ (9 m).
V– Garden Hose Quick-Connect – Use this to make
it easier to connect and disconnect garden hose
from pump inlet.
W – Pump Breather- Will prevent pressure inside
pump from going too high.

8 | Page
ASSEMBLY & PRE-START CHECK
Before assembling or starting pressure
washer, ensure entire manual has been read.
Unpack pressure washer
Remove everything from carton except
pressure washer and all parts.
Ensure everything is ready for assembling. If
anything are damaged or missing, call
Simoniz toll-free number 1-866-4SIMONIZ (1-
866-474-6664)
You will need:
Utility knife; Adjustable wrench; Unleaded
fuel(87# or above); Engine oil(SAE10w-30);
Standard Garden hose,50ft(15m) or less;
Safety goggles(indirect vented type);
Items included:
Other Contents not shown:
Telephone Card×1, Instruction
Manual×1,Spray tip cleaner×1 ,Spark plug
wrench×1 , Screw driver×1，Replacement O-
ring ×3(2 for high pressure hose, 1 for tip
quick connector)
WARNING! Before attempting to start
pressure washer, ensure you complete the
following important steps.
1) Fill gasoline tank with unleaded gasoline. This
is a 4-cycle engine with separate reservoirs for
gas and oil. DO NOT use pre-mixed gas! DO
NOT use old gas! Fuel must be purchased
separately.
2) Fill oil tank with SAE 10W-30 oil. Running
pressure washer without oil will severely
damage engine which is not covered by
warranty! Oil must be purchased separately.
3) Ensure both the pressure hose and garden
hose have been correctly attached to the
pressure washer pump. Ensure the water tap is
on and water is running through the hose before
attempting to start engine. Not doing this will
damage the pump!
Assemble Pressure Washer
WHEEL ASSEMBLY
NOTE: Make sure that there is enough air in
wheel before assembly, if not, please fill to 25psi.
Attach the wheels (A) to the frame. First
press the spring-loaded pin (a) on the axle, then
insert the wheel shaft into the frame. Align the
spring-loaded pin with hole in frame until the pin
snaps in place. Repeat for the other wheel.
HANDLE ASSEMBLY
Attach panel(G) to handle(F) and secure
with bolts, nut, washersx4 sets(J). Tighten with
wrench (included) and screw driver(included)
Attach the handle (F) to the frame of main
unit (E) by sliding the top handle posts (b) into the
frame posts (b).
1
2-1
2-2

9 | P a g e
Insert bolt x1(L) through handle and
secure with nutx1 and washerx1(L).Tighten with
wrench (included) and screw driver(included)
HOSE SUPPORT ASSEMBLY
Attach the hose support (I) to right side of the
frame and secure with boltsx2, nutx2, washersx4
already attached. Tighten with wrench (included)
and screw driver(included)
GUN SUPPORT ASSEMBLY
Attach the gun support (H) to the left side of the
frame and secure with boltsx2, nutx2, washersx4
already attached. Tighten with wrench (included)
and screw driver(included)
GARDEN HOSE CONNECTION
Remove quick-connect coupler (d)
from the pump inlet.
Screw female quick-connect coupler
(d) to garden hose (e).
Re-attach quick-connect coupler to
pump inlet (f).
WAND ASSEMBLY
Pull back the rubber shroud (g) to expose
the threaded fitting on the wand (B).
Attach the wand (B) to the gun(C)
Slide rubber shroud over connection point.
Pull back on quick-connect collar, insert
your required nozzle (h)and
release collar. Tug on nozzle to make sure
it is securely in place
PRESSURE HOSE CONNECTION
Unscrew air shield (i) on the pump outlet.
5-1
5-2
2-3
3
4
6-2
6-1
6-3
6-4
7-1
5-3

11 | Page
To Check Oil Level;
1) Turn the oil gauge dipstick(A)
counter clockwise; remove it and clean it with a
clean cloth. （There are two ports to fill oil.）
2) Fully reinsert the oil gauge dipstick and pull it
out to check the oil level.
3) If the oil level is halfway up the dipstick or
below, refill with SAE 10W-30 oil through the
dipstick hole until the oil level reaches 3/4 up
the dipstick or until it reaches the bottom lip of
the dipstick hole as shown in illustration to the
right.
4) Re-position the oil gauge dipstick and tighten it
by turning clockwise.
PRE-START: CHECK FUEL LEVEL
WARNING! Make sure there is enough fuel in the fuel tank before operating.
1) If it is necessary to add fuel, first make sure
the engine is OFF, and then remove the fuel
cap(A) by turning it counter clockwise.
2) When refuelling, make sure the fuel filter(B)
is in place and keep in mind all safety
precautions.
3) Use clean unleaded gasoline with a minimum of
87 octane. DO NOT use old gas. DO NOT mix
oil with gasoline. Fuel tank capacity: 4.0 Litres.
*** This is a 4-cycle engine and does not require a
gas/oil mixture. There is a separate reservoir
for gas and a separate reservoir for oil.

12 | Page
PRE-START: CHECK AIR FILTER
WARNING! The air filter should be checked after prolonged storage. The following steps
should be followed when checking the air filter. It is recommended to replace the air filter every
spring.
1) Unscrew the bolt(A) and remove
the air filter cover(B).
2) Unscrew the other bolt(A) and remove the air
filter(C), wash filter in kerosene,
squeeze kerosene out, soak filter in engine oil
and squeeze engine oil out.
3) Replace filter and replace the air filter cover.
START-UP PROCEDURES & OPERATION
START-UP PROCEDURES
Follow these instructions to safely start your pressure washer:
1. Check engine oil level, fill to recommended
level if necessary. Check gasoline level, fill if
necessary. Fig A
2. Connect garden hose to the water supply and
TURN WATER ON. The water supply must
provide a minimum of 4 GPM at 30 PSI or the
pump may be damaged. Fig.B
3. Squeeze gun trigger. This will allow air to
escape from the hose in order to prime the
pump. Squeeze trigger until there is a steady
flow of water. Fig.C
4. Turn engine switch to the “I” position. Fig.D
5. Open fuel valve to the “On” position. Fig.E
6. Close the Choke lever by moving the lever
to the “CLOSE” position. Fig.F
7. Also move the throttle lever to
its maximum setting “Fast ” position. Fig.G
8. Locate recoil cord and pull slowly until
resistance is felt. At this point, pull rapidly to
H

13 | Page
OPERATION: SPRAY NOZZLE USAGE
•This pressure washer comes with a stainless
steel wand. Its tip has a quick-connect coupler
(A) to fit different nozzles.
•The spray pattern is adjusted by installing the
appropriate spray pattern nozzle to the quick
connect coupler. Five nozzles are included, 0°,
15°, 25°, 40° and a detergent nozzle.
•To install a nozzle to the quick-connect
coupler, pull the coupler ring (B) backwards
and insert the desired nozzle. Release the
coupler ring to lock it in place.
NOZZLE USAGE:
•0° (red) - Thin and powerful stream of water for
difficult stains and debris removal.
•15° (yellow) – Thin-angled spray for focused
cleaning.
•25° (green) – Medium-angled spray for focused
cleaning.
•40° (white) - Large fan pattern for wider
cleaning applications.
•Detergent (black) - This nozzle must be used
in conjunction with a cleaning detergent at low
pressure. Only use this nozzle when using a
detergent or cleaning solution
start engine. Repeat if necessary. Fig.H
Once engine starts, open choke lever by
moving the lever to the “Open” position.
9. If motor fails to start, repeat steps 3-9
10. If you have problems starting the pressure
washer, call the Simoniz toll-free number and
one of our customer service representatives
will be glad to assist you.

14 | Page
ADJUSTING WATER PRESSURE:
•The water pressure is regulated by the throttle
lever.(A)
•Moving the throttle lever towards the left will
increase the engine speed thus increasing the
water pressure.
•Moving the throttle lever towards the right will
decrease the engine speed thus decreasing
the water pressure.
DETERGENT INJECTOR (LOW PRESSURE):
•This pressure washer is intended for use with
pressure washer detergents only.
•Do not use powdered soaps which clog the
injection system.
•Follow the detergent manufacturer’s
directions or call the Simoniz toll-free number
if you have any questions or concerns.
HOW TO USE DETERGENT WITH PRESSURE WASHER:
1) Ensure detergent siphon tubes are set up
correctly. You may want to refer to assembly
instruction #9 on page 10 to verify that siphon
tubes are set up properly.
2) Pour the two kinds of detergents into the
detergent tanks. It is recommend to have one
detergent tank filled with All-Purpose detergent,
and the other filled with a more specific cleaning
detergent.
3) The indicator on the detergent dial shows the
amount and the consumption of detergent.Fig.A
4) When using a detergent, the stainless steel
wand must be fitted with the detergent nozzle
(black). See ‘OPERATION SPRAY NOZZLE
USAGE’ on page 14 for instructions on how to
connect detergent nozzle to wand. Fig.B
5) If the throttle lever is not in the fast position, the
injection of the detergent may be decreased or
stopped completely. If this happens, move the
throttle lever towards the left to increase engine
speed and pressure.
Important Note: When you have finished using the detergent injector system, remove the
injector filter from the detergent container and place it in a different larger container containing
only clean water and let the pressure washer run until you no longer see detergent coming out

15 | Page
of the wand. This will prevent detergent from gumming up the wand and reducing pressure for
next use.
USING THE PRESSURE WASHER TO CLEAN:
•Some cleaning jobs can be completed by using
only water, but for most, it is advantageous to use
a detergent to penetrate and remove the dirt more
effectively. When using pressure washer approved
detergent, make sure the surface to clean is dry.
Wetting the surface first is not recommended; it
will dilute the detergent and will reduce the
cleaning effectiveness.
•Avoid hot surfaces or direct sunlight; this will
minimize the chances of the detergent
damaging the painted surface.
•DO NOT let the detergent dry or it may damage
the painted surface. Allow the detergent to remain
on the surface for a short time before rinsing with
clean water under high pressure.
•Position the tip of the wand 6-8” (15-20 cm) away
from the surface to clean at a 45°angle.
TROUBLESHOOTING
NOTE: If your unit still is not functioning properly once you have used this guide please call the
SIMONIZ Tool-free service number at 1-866-4SIMONIZ(1-866-474-6664). Please do NOT bring the
unit back to the store until you have called this number.
PROBLEM POSSIBLE CAUSE CORRECTION
The engine power switch
is OFF Ensure the switch is in ON (I) position
No fuel Fill the fuel tank with regular
gasoline
Low oil shut down sensor
tripped to protect engine
(not applicable to
SKU#199-1010-8 2600psi
pressure washer).
Add oil until reaches minimum level
on dip stick
Excess water pressure in
pump or hose Release water pressure by squeezing trigger on gun
Choke lever not in right
position.
1 When cold starting the engine,
set the choke to “CLOSE”or
“OFF”
2 When warm starting, set the
choke to “OPEN”or “ON”or
try the middle position.
Clogged carburetor Clean the carburetor. Refer to
instruction manual for details.
Engine Engine doesn’t start
or difficult to start
Carbon build-up on spark
plug. Clean the spark plug. Refer to the instruction manual.

16 | Page
Incorrect starting method Use correct starting method, Refer
to the instruction manual.
Low oil or no fuel Check oil level and fuel
Engine stops after
starting. The choke at “Close”
position Move the Choke lever to “Open”
position immediately after starting
the engine
Clogged air filter. Clean or replace the air filter. Refer
to the instruction manual.
Engine lacks of
power. Clogged carburetor. Clean the carburetor. Refer to the
instruction manual.
Do not tilt the machine past 15⁰
when operating
Engine stops while
moving or being
tiled.
Low oil shut down sensor
tripped to protect engine
(not applicable to
SKU#199-1010-8 2600psi
pressure washer).
Check oil Level and esnure it is
above the minimum level on the dip
stick
Carburetor leaks Carburetor is clogged Clean the carburetor. refer to IM
Starter rope doesn't
recoil Recoil mechanism is broken CALL Customer Service Toll-Free 1-866-4SIMONIZ
RPM too low(not
applicable to SKU#199-
1010-8 2600psi pressure
washer).
Adjust Throttle lever to "Fast"
position.
Clogged nozzle Clean nozzle by tip cleaner
Engine sounds
abnormal or
overloaded Pressure is too high CALL Customer Service Toll-Free
Nozzle tip not attached Attach required tip nozzle
Water supply faucet
closed Turn on faucet
Ensure there are no kinks or
blockage in hose
Ensure faucet is on full
Water supply pressure is
low Check to make sure water from
supply line is a minimum 30psi,
4GPM
Inlet water filter is clogged Clean the water filter. Refer to the
instruction manual.
Water leaks at
connections
Replace the worn o-ring at the
connection point with ones supplied
with unit or they can be purchased
at CT store. SKU# 039-8552-8.
Air in pump Squeeze trigger to release the air in
pump when the machine is running
The loaded RPM is not
sent to MAX.(not
applicable to SKU#199-
1010-8 2600psi pressure
washer).
Set RPM (Throttle lever)to MAX.
Clogged check valve. CALL Customer Service Toll-Free
No pressure,low
pressure
Damaged pump. CALL Customer Service Toll-Free
Pressure too high Clogged nozzle Clean nozzle with tip cleaner
Pump
Water or oil leaks
out of pump Damaged seal ring CALL Customer Service Toll-Free

17 | Page
Cold water keeps
draining out of
thermal relieve
valve
Defective thermal relieve
valve. CALL Customer Service Toll-Free
The detergent supply hose
is not connected. Connect detergent hose properly. Refer to IM.
Damaged detergent hose. Replace the detergent hose.
Wrong nozzle Use black nozzle when applying
detergent. Refer To instruction
manual for details
Detergent adjustment
knob set at wrong position. Check adjustment knob. Refer to IM
Clogged nozzle. Clean nozzle.
Clogged pump detergent
siphon. Detach the detergent hose and clean the hole with tip cleaner
Detergent is too thick. Use only detergent approved for
use with pressure washer.
No intake of
detergent
Clogged detergent filter.
Only applies to SKU#199-
1010-8 2600psi pressure
washer Clean detergent filter
The trigger can’t be
squeezed Safety lock is not open Open the safety lock refer to IM
There is water
leakage at
joints/connections
on gun, hose
and/or pump
Damaged seal ring. Change with back-up o-ring or
purchase accessory kit sku#.039-
8552-8 at local Canadian Tire Store
Accessories
&
Connections
High Pressure
Hose can’t be
connected to pump
or gun.
The O rings are not
lubricated Put lubricating oil or water on the O rings.

18 | Page
MAINTENANCE
WATER INLET FILTER:
•This pressure washer is equipped with a
water inlet filter(A).
•This water filter must be kept clean at all
times or else it will restrict the water flow to
the pressure washer and may damage the
pump.
•Remove the quick connect coupling from the
water inlet, then remove and clean water filter.
•DO NOT operate this pressure washer
without the water inlet filter in place as
deposits could build up internally and affect
the functioning of the unit.
*** See in-store for replacement filters.
ENGINE MAINTENACE:
Engine Oil Replacement
•Engine oil should be replaced after the first
20 hours of operation or after the first month
of use.
•Thereafter, it should be replaced every 100
hours or 6 months.
•To replace engine oil: Loosen the oil gauge
dipstick (A); Place an oil pan underneath drain
hex bolt (B); Remove hex bolt and drain oil.
Once all the oil has completely drained,
retighten the hex bolt.
Recommended Engine Oil
•It is recommended to use SAE10W-30
4-stroke gasoline engine oil.
•Fill with clean engine oil through the oil gauge
dipstick hole to recommended level.
Inspecting, Replacing or Cleaning Spark Plug
•The spark plug should be checked every 100
hours of operation or every 6 months.
To replace or clean spark plug:
A B
A

19 | Page
1) Dismantle the spark plug wire (A) by pulling it
off the spark plug (B). Using the supplied spark
plug wrench, undo the spark plug by turning
counter clockwise.
2) Check to see if there is carbon sediment
build-up. If so, remove it. If the carbon sediment
is excessive, replace the spark plug.
3) Measure the electrode’s clearance using a
feeler gauge. The spark plug electrode
clearance should be between 0.7-0.8 mm. If the
clearance exceeds 0.8 mm, replace the spark
plug. The original spark plug supplied is an
LG F7RTC, you can replace it with an NGK
BP6ES spark plug or equivalent.
4) Reinstall spark plug following instructions in 1)
above in the reverse order.
PRESSURE WASHER STORAGE:
If you plan on storing your pressure washer
for an extended period of time, the following
steps should be followed:
1) Add fuel stabilizer to fuel tank to minimize the
formation of fuel gum deposits during storage.
2) Run engine at least 5 minutes after adding
stabilizer to allow it to enter the fuel system.
NOTE: If a fuel stabilizer is not used, all
gasoline must be drained from the tank and
carburetor to prevent gum deposits from
forming on these parts and causing possible
malfunction of the engine (see instructions on
draining fuel below).
3) Drain engine oil from engine as described in
“Engine Oil Replacement.”
4) Pour approximately one teaspoon of engine oil
through the spark plug hole and pull the recoil
starter slowly until you feel increased pressure
which indicates the piston is on its compression
stroke and leave it in this position. This closes
both the intake and exhaust valves to prevent
the inside of the cylinder from rusting.
5) Use pressure washer antifreeze to ensure that
your pump will not freeze during the winter and
to keep components lubricated for maximum
efficiency. See instructions below on
“Preventing Freezing Damage”.

20 | P a g e
6) Cover the pressure washer and store it in a
clean, well ventilated and dry place. Ensure
storage area is at room temperature.
*** See in-store to purchase fuel stabilizer or
pressure washer antifreeze.
If you wish to drain the fuel instead of adding
fuel stabilizer, please follow these steps:
1) Turn fuel shut-off valve to the “OFF” position.
Remove drain hex bolt (A) from the carburettor
(B).
2) Now turn fuel shut-off valve to the “ON” position
and drain the fuel from the tank, carburettor and
hose.
3) Replace the carburetor drain hex bolt once
the fuel is completely drained.
PREVENTING FREEZING DAMAGE:
•If your pressure washer is subjected to
freezing temperatures, damage could occur.
This type of damage is not covered under
warranty. To avoid possible damage, a small
amount of antifreeze can be used.
•Place the unit on its side with the water inlet
facing upwards. Pour 1/4 cup of antifreeze
into the water inlet.
•Disconnect spark plug wire, and then pull
recoil starter several times to circulate the
antifreeze in the pump system. Reconnect
spark plug wire.
•It is also important to make sure the wand and
all hoses are disconnected and drained of all
water or they may burst.
•When taking pressure washer out of storage,
run water through the system until it runs
clear.
