Simoniz S1700 User manual

Electric Pressure Washer
S1700
039-8604-6
OWNER’S MANUAL
SKU 39-8604-6
If you have any questions or comments, visit our website at www.simoniz.ca or call
our toll free hotline 1-866-4SIMONIZ (1-866-474-6664)
PLEASE KEEPTHE ORIGINAL BOX, PACKAGING AND RECEIPT. BEFORE OPERATING
THIS UNIT, PLEASE READTHIS MANUALTHOROUGHLY AND RETAIN IT FOR FUTURE
REFERENCE. IFYOU MUST STOREYOUR PRESSURE WASHER IN A PLACE WHERE
TEMPERATURE IS BELOW 5ºC,YOU MUST APPLY WINTERIZING PROCEDURETO
PROTECT IT. FAILURETO WINTERIZETHE UNIT MAY PERMANENTLY DAMAGE PUMP
AND VOIDTHE WARRANTY.

1
TABLE OF CONTENTS
Technical specifications ........................................................................................................ 1
Warranty ............................................................................................................................... 2
Important precautions – Read first!...................................................................................... 3
Safety features and electrical power information ................................................................. 5
Parts and diagram list ........................................................................................................... 6
Assembly instructions .......................................................................................................... 7
Operating instructions .......................................................................................................... 8
Using the accessories..................................................................................................11
Working with detergents .............................................................................................12
Shutting down and cleaning up....................................................................................13
Taking a break ..............................................................................................................13
Winterizing and long-term storage ......................................................................................15
Cleaning and user maintenance .........................................................................................16
Troubleshooting .................................................................................................................. 18
TECHNICAL SPECIFICATIONS
Pressure Washer Specifications
Max Pressure: 1700 PSI
Power Source Requirement: 120 V / 60 Hz
Electrical cord: 35’ (10.7 m) 16 AWG
High-pressure hose: 23’ (7 m)
Water Flow Rate (at 100 PSI): 1.4 GPM (5.3 L/min)
Current Drawn: 12.5 A
Detergent Injection Rate (adjustable): 0–15%
Inlet water: Cold tap water
Nozzle spray angle (high pressure): 0–60°
Nozzle spray angle (low pressure): 0–90°
Turbo Nozzle: 30°

2
WARRANTY
Product Warranty
Always keep your receipt as proof of purchase.
We’re here to help! If you have any questions or comments, call our toll-free hotline
1-866-4SIMONIZ (1-866-474-6664). Have your serial number ready. The serial number can
be found on the back plate, located on the rear of the unit.
This product has a Parts Replacement, Product Exchange and/or Repair Warranty only.
NO REFUNDS will be provided. Please see stores for Product Exchange details.
Two-(2) year Warranty - Motor
This product is warranted to be free from defects in material and workmanship for two
years from the date of its original purchase. If such a defect appears during the warranty
period, upon presentation of proof of purchase, Trileaf Distribution will repair or replace the
product (at its option). Shipping charges may apply.
Ninety-(90) day Warranty - Accessories
Trigger gun, hose, spray wands and other accessories are warranted for 90 days from the
date of purchase. You may purchase accessories directly through place of purchase, or by
calling our toll-free hotline 1-866-4SIMONIZ (1-866-474-6664).
This warranty does not cover accidental damage, unreasonable use, normal wear and tear,
use of improper detergents, freezing, neglect, or non-compliance with Operating Instruc-
tions. Warranty does not cover loss of use, or other consequential damages arising from
any of the above, nor does it cover repairs made or attempted by unauthorized persons.
Warranty is void if the equipment is used for commercial, rental or industrial purposes.
If you have more questions, visit our website (www.simoniz.ca), or call 1-866-4SIMONIZ
(1-866-474-6664).

3
IMPORTANT PRECAUTIONS – READ FIRST
Safety Warnings
When using this product, basic precautions should always be followed:
•Readalltheinstructionsbeforeusingtheproduct.
•Waterspraymustneverbedirectedtowardanyelectricwiring,devicesordirectlytoward
the pressure washer machine itself, or fatal electric shock may occur.
•Toreducetheriskofinjury,donotoperatethemachinenearchildren.
•Learnhowtostopthemachineandreleasepressurequickly.Bethoroughlyfamiliarwith
the controls.
•Stayalert—watchwhatyouaredoing.
•Forusewithcoldwatersupplyonly.Donotdrawotherliquids.
•Thepressurewashershouldnotbeusedinareaswheregasvapoursmaybepresent.An
electric spark could cause an explosion or fire.
•Tominimizetheamountofwatergettingintothepressurewasher,theunitshouldbe
placed as far as possible from the cleaning site during operation.
•Avoidaccidentalstarts.Shutpower“OFF”beforeconnectingordisconnectingcordto
electrical outlets.
•Donotoperatetheproductwhenfatiguedorundertheinuenceofalcoholordrugs.
•Donotstandonunstablesurfaces.Standwithbothfeetbalancedatalltimes.
•Priortostartingthepressurewasherincoldweather,besureicehasnotformedonany
part of the equipment.
•Nevercarryyourpressurewasherbythecord.
•Donotpullonthecordtodisconnectfromtheoutlet.
•Toallowfreeaircirculation,thepressurewashershouldnotbecoveredduringoperation.
•Keepoperatingareaclearofallpeople.
•Followthemaintenanceinstructionsspeciedinthemanual.
If replacement of the plug or cord is needed, use only identical replacement parts.
•Thisproductoritspowercordcontainslead,achemicalknowntocausecancer,birth
defects or other reproductive harm. Wash hands after use.
Warnings
•Donotusewithammableliquidsandtoxicchemicals.
•InjectionHazard:Equipmentcancauseseriousinjuryifthespraypenetratestheskin.
•Donotpointthegunatanyoneoranypartofthebody.Incaseofpenetration,seek
medicalaidimmediately.
•Thissystemiscapableofproducing1700PSI.
•Toavoidruptureandinjury,donotoperatethispumpwithcomponentsratedless
than1700PSIworkingpressure(includingbutnotlimitedtosprayguns,hoseand
hoseconnections).
•Beforeservicing,cleaningorremovalofanyparts,shut“OFF”powerand
relievepressure.
•Donotsprayelectricalapparatusandwiring.
•Ifconnectionismadetoaportablewatersystem,thesystemmustbeprotected
againstbackow.

4
Save These Instructions
In a double-insulation product, two systems of insulation are provided instead of
grounding. No grounding means is provided on a double-insulated product, nor should
a means for grounding be added to the product. Servicing a double-insulated
product requires extreme care and knowledge of the system, and should be
done only by qualified service personnel.
Replacement parts of a double-insulated product must be identical to the parts they re-
place. A double-insulated product is marked with the words “DOUBLE INSULATION”
or “DOUBLE INSULATED”. The symbol “ ” may also be marked on the product.
IMPORTANT PRECAUTIONS – READ FIRST
WARNING - Risk of Injury
Do Not Direct Discharge Stream at Persons.
•High-pressure jet can be dangerous if misused.
•Thejetmust not be directed at persons, animals, electrical devices, or the unit itself.
WARNING - Risk of Explosion
•Do not spray liquids.
•Do not use acids and solvents in this product.
•These products can cause physical injuries to the operator and irreversible damage
to the machine.
CAUTION - Gun Kicks Back
•Hold with both hands.
•The trigger gun safety lock prevents the trigger from being engaged accidentally.
•The safety feature DOES NOT lock trigger in the ON position.
WARNING - Risk of Electric Shock
•Inspect cord before using - Do not use if cord is damaged.
•Keep all connections dry and off the ground.
•Do not touch plug with wet hands.
•Do not use extension cords longer than 50’ (15.2 m) = AWG.

5
SAFETY FEATURES & ELECTRICAL POWER INFORMATION
The pressure washer is equipped with a stop device that will sense when the trigger on
the gun is released. It will open the power circuit to the motor, and cause the pressure
washer motor to stop. The motor will start again when the trigger is pulled.
WARNING
Thepressurewasherisalsoequippedwithamainpower“ON/OFF”switchlocated
ontheunit.Itshouldalwaysbemovedtothe“OFF”positionwhenthepressure
washerisnotbeingusedtopreventpossibleinjuryordamage.
DANGER
Improperconnectionoftheequipment-groundingconductorcanresultinariskof
electricshock.Checkwithaqualiedelectricianorservicepersonnelifyouarein
doubtastowhethertheoutletisproperlygrounded.Donotmodifytheplugpro-
videdwiththeproduct—Ifitwillnotttheoutlet,haveaproperoutletinstalledbya
qualiedelectrician.Donotuseanytypeofadaptorwiththisproduct.
ExtensionCords
If possible, do not use extension cords with this product. However, if you must use one,
observe all of the warnings and instructions listed below:
WARNING
Extensioncordsarenotrecommendedunlesstheyarepluggedintoagroundfault
circuit-interrupterfoundincircuitboxesorprotectedreceptacles.
Useasufcientgauge:
Maximum cable length: 50’ (15.2 m) = 14 AWG
•Useonlyextensioncordsthatareintendedforoutdooruse.Theseextensioncordsare
identiedbyamarkingthatreads“Acceptableforusewithoutdoorappliances;store
indoorswhilenotinuse.”
•Useonlyextensioncordshavinganelectricalratingnotlessthantheratingoftheproduct.
•Donotusedamagedextensioncords.Examineextensioncordbeforeusingandreplace
if damaged. Do not abuse extension cord and do not yank on any cord to disconnect.
•Keepcordawayfromheatandsharpedges.
•Alwaysdisconnecttheextensioncordfromthereceptaclebeforedisconnectingthe
product from the extension cord.
•Toreducetheriskofelectricshock,keepallconnectionsdryandofftheground.Donot
touch plug with wet hands.
CAUTION
Thismachinehasbeendesignedforusewithcleaningdetergentsuppliedorrecom-
mendedbytheRetailer.Theuseofothercleaningdetergentsmayaffecttheopera-
tionofthemachineandvoidthewarranty.

6
PARTS AND DIAGRAM LIST
Item No. Quantity Part Name Parts Number
A 1 Turbo wand ZE04-090-0004
B 1 Adjustable wand ZE04-090-0003
C 1 Gun assembly ZE03-090-0001
D 1 Left wing (Gun holder) ZE05-090-0007
E 1 High-pressure hose ZE05-090-0001
F 1 Gun holster ZE04-000-0001
G 1 Hose bracket ZE05-090-0000
H 1 Detergent bottle assembly ZE04-090-0010
J 1 Right wing (Wand holder) ZE05-090-0006
K1 1 Quick-connect coupling ZE01-050-0000
*K2 1 Inlet adaptor ZE01-050-0000
*L 1 Water filter ZE01-000-0003
M 1 Needle ZE01-900-0001
N 1 Universal Pressure Washer
Accessories Adaptor
ZE05-062-0002
A
G
Manual
C
J
FL
M
B
H
D
E
K2
K1
* Inlet adaptor and Water filter come pre-attached on the water inlet, located on the back of
the pressure washer.
N

7
Surface Preparation
Before starting any cleaning task, it is important to inspect the area for objects that could
create a hazard. Remove any objects from the work area that could be tripped over, such as
toys or outdoor furniture. Ensure that all doors and windows are closed tightly.
CAUTION
•Never use the pressure washer to draw in water contaminated with solvents (e.g.
paint thinners, gasoline, oil, etc.).
•Dirt in the water inlet will damage the unit.To avoid this risk, we recommend checking
the water (located inside the water inlet; to clean it out see Maintenance section).
•Always prevent debris from being drawn into the unit by using a clean water source
and an additional accessory water if required.
•To prolong the life of the unit, it is recommended to rest the unit for 5 minutes after
every 30 minutes of use.
Water Supply (Cold Water Only)
Only draw water through the unit. For use with cold water supply only. Water hose must
be at least a 1/2” (13 mm) in diameter. Flow rate of water supply must not fall below 2
GPM (gallons per minute) [9.1 LPM (litres per minute)]. Flow rate can be determined by
running the water for one minute into an empty 5-gallon (19 L) container. The water supply
temperature must not exceed 104°F (40°C).
ASSEMBLY INSTRUCTIONS
1
Attach the left wing (D) and the right wing (J) to the
pressure washer unit.
Attach gun holster.
D
J
2
F

8
OPERATING INSTRUCTIONS
OFF
1
2
MakesuretheON/OFFswitchisinthe“OFF”position.
Fasten the quick-connect coupling (K1) onto the garden hose, and then attach the quick-
connect coupling (K1) to the inlet adaptor (K2).
K2 K1

9
OPERATING INSTRUCTIONS
3
45
Insertthewand(AorB)intothespraygun,andtwist1/4turnuntilrectangulartabappears.
Fasten the high-pressure hose (E) tightly
onto the gun assembly (C), and tighten to
avoid leakage.
Attach garden hose to water supply, and
turn water on.
AorB
C
E

10
OPERATING INSTRUCTIONS
ON
6
7
8
Plug the unit into an outlet.
Before turning the unit “ON”, depress the trigger to bleed any trapped air out of the
pump and hose.
Release trigger, and start the pressure washer by turning ON/OFF switch to ON.

11
OPERATING INSTRUCTIONS
Adjustingthespray
The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet
to fan spray by turning the nozzle as shown.
CAUTION
Jetsprayadjustmentisveryaggressive.Donotadjustwhilespraying.Werecommend
a20ºsprayangleformostcleaningapplicationstoavoiddamagetothesurface
beingsprayed.
CAUTION
Toprolongthelifeoftheunit,itisrecommendedtoresttheunitfor5minutesafter
every30minutesofuse.
USING THE ACCESSORIES

12
OPERATING INSTRUCTIONS
Working with detergent ensures a quick soaking of the dirt, and allows the high-pressure
water to penetrate and remove the dirt more effectively. Always spray detergent on a dry
surface, do not pre-soak area. Wetting the surface first dilutes the detergent and reduces
its cleaning ability.
To apply detergents you must be operating at low pressure. This provides a gentle applica-
tion of detergent, with the pressure equivalent to that of a garden hose. The high-pressure
setting is used for cleaning; you cannot apply detergents when working at high pressure.
Always test detergent in an inconspicuous area before use.
CAUTION
Only use cleaning detergents recommended for pressure washers.
WORKING WITH DETERGENTS
1 2
Insert the adjustable wand (B) into spray
gun (C), and twist. Turn until rectangular
tab appears.
Set the adjustable wand to the low-pressure
setting by pulling the nozzle out.
The wand must be set in the low-pressure
position to apply detergent.
4
3
Turn on the pressure washer. Pull trigger to operate unit. The liquid detergent will automati-
callymix with water, and be discharged through the nozzle. Apply detergent to a DRY work
surface, from bottomto top.
Gently pull detergent containers (H) out of storage position, and fill with detergent. Push
containers back into storage position.
B
H
C

13
SHUTTING DOWN AND CLEANING UP
1
3
2
4
(If you are not using detergent, go directly to Step 2.) When you have finished using
the detergent injection system, remove detergent suction tube from bottle and insert
into 1 gallon (5 L) of fresh water. Siphon water at low pressure for one minute so that
all detergent is through system. Remove detergent bottle and rinse it until it is
thoroughly cleaned.
Unplug the power cord from the outlet.
Turn the switch to “OFF” (0) position.
Press trigger to release water pressure.
5
6
Disconnect the garden hose from the water inlet on the unit.
Disconnect the high-pressure hose from the high-pressure outlet and engage the
gun safety lock.
WARNING
Turn off water supply and squeeze trigger to depressurize the unit. Failure to do so
could result in personal injury due to discharge of high-pressure water.
TAKING A BREAK
1
3
2
Engage gun safety lock.
Unplug the power cord from the outlet.
Turn unit to “OFF” (O) position.
If taking a break of five minutes or more:
OPERATING INSTRUCTIONS
5
6
7
Allow detergent to remain on the surface for a short time before rinsing. Do not allow
detergent to dry on surface.
Rinse with clean water under high pressure. On a vertical surface, rinse from the
bottom up, then rinse from the top down to avoid streaking. Hold nozzle 6-8” (15-20
cm) from the work surface, at a 45° angle.
When you have finished using the detergent injection system, remove detergent
suction tube from bottle and insert into 1 gallon (5 L) of fresh water. Siphon water at
low pressure for one minute, so that all detergent is through system. Remove
detergent bottle, and rinse it until it is thoroughly cleaned.
CAUTION
Damage may occur to painted surface if chemical is allowed to dry on surface.Wash
and rinse a small section at a time. Avoid working on hot surfaces or in direct sunlight.

14
OPERATING INSTRUCTIONS
CAUTION
Failuretocleanproperlywillcausetheinjectionsystemtobecomeclogged
andinoperable.
CAUTION
Neveruse:
•Bleach,chlorineproductsandothercorrosivechemicals
•Liquidscontainingsolvents(i.e.,paintthinners,gasoline,oils)
•Tri-sodiumphosphateproducts
•Ammoniaproducts
•Acid-basedproducts
Thesechemicalswillharmtheunitandwilldamagethesurfacebeingcleaned.

15
WINTERIZING AND LONG-TERM STORAGE
Optimum Winterizing Procedure
Winterizing your pressure washer will help protect and prolong its life. We strongly recom-
mend you follow the below steps using antifreeze. Prepare the pressure washer for stor-
age by running a 50/50 mix of water and antifreeze into the unit. This will keep the internal
parts lubricated, protected from rust, and prevents the pump from freezing.
1. Connect the antifreeze hose onto the adaptor and quick-connect coupling.
2. Depress button on top of antifreeze container.
3. Continue until exits the pump outlet.
4. Remove the hose from pump inlet.
Use Simoniz® Pressure Washer Antifreeze (39-8602-0).
Quick Winterizing Procedure
If you cannot do the Optimum Winterizing
procedure, you can still protect your pres-
sure washer from winter damage by doing
below:
1. Disconnect all water connections.
2. Turn on the machine for a few seconds,
until the remaining water in the pump
exits. Turn off immediately.
3. Do not allow high-pressure hose to
become kinked.
4. Store the machine and accessories in
a room that does not reach freezing
temperatures. Do not store near furnace
or other sources of heat as it may dry out
the pump seals.
ANTI-FREEZE
(or PUMP SAVER)
ANTI-FREEZE
(or PUMP SAVER)

16
CLEANING AND USER MAINTENANCE
Connections
Connections on pressure washer hoses; gun and spray wand should be cleaned regularly
and lubricated with non-water soluble grease.
Air Vents
The air vents located on the back of the unit must be kept clean and free of any
obstructions to ensure proper air cooling of the motor during operation.
B
N
LK2
Adjustable Nozzle Only
Clogging of the nozzle causes the pump
pressure to be too high and cleaning is
immediately required. You can clean the
nozzle by carefully inserting a thin, sharp
instrument (i.e. paperclip) into the tip to rid
it of deposits.
For the adjustable nozzle, you can also
lubricate the nozzle collar (high-pressure/
low-pressure) by using non-water soluble
grease regularly.
Water Filter Screen
The pressure washer is equipped with a
water inlet screen to protect the pump. If
the screen is not kept clean, the of wa-
ter to the pressure washer will be restricted
and the pump may be damaged.
1. To clean inner water screen, remove
quick-connector and remove the filter
screen from the pump inlet.
2. Rinse screen until it is free of debris
and blockage.
3. Replace screen and quick-connector im-
mediately to prevent any foreign matter
from entering the pump.
B
LK2
M

17
TROUBLESHOOTING
Disconnect the machine from the power source before making any repairs.
Symptom Cause Solution
Motor will not start. On/Off switch is in the
“OFF” (O) position.
Turn switch to the “ON”
( | ) position.
Power cord is notplugged in. Plug in power cord.
Extension cord is too long.
Extension cord is not
proper gauge.
Extension cord is damaged.
Replace extension cord
with either a 25’ (7.6 m)
14/3 gauge cord or a 50’
(15 m) 14/3 gauge cord.
Electrical outlet does not
supply adequate power.
Try a different outlet.
Tripped pressure washer
circuit breaker.
Allow to cool, and restart unit.
Unit does not reach
high pressure.
Diameter of garden hose is
too small.
Replace with a 1” (25 mm) or
5/8” (16 mm) garden hose.
Water supply is restricted. Check garden hose for
kinks, leaks and blockage.
Not enough inlet water supply. Open water source fully.
Water inlet filter is clogged. Remove filter and rinse in
warm water.
Power nozzle is in low-
pressure position.
Turn power nozzle to high-
pressure position.
Pump is sucking air. Check that hoses and
fittings are airtight. Turn
“OFF” machine, and purge
pump by squeezing trigger
gun until a steady of
water emerges through
the nozzle.
Output pressure varies high
and low.
Not enough inlet water supply. Turn water on fully. Check
garden hose for kinks, leaks
or blockage.
Pump is sucking air. Check that hoses and
fittings are airtight. Turn
“OFF” machine, and purge
pump by squeezing trigger
gun until a steady of
water emerges through
the nozzle.
Water inlet filter is clogged. Remove filter and rinse in
warm water.

18
TROUBLESHOOTING
Symptom Cause Solution
Discharge nozzleis obstructed. Blow out or remove debris
with a fine needle.
Calcified gun, hose or
power nozzle.
Run distilled vinegar
through detergent tank.
No Detergent Detergent container is empty. Add more detergent.
Detergent bottle or suction
tube notproperly connected.
Check connections.
Detergent is too thick. Dilute detergent.
Filter on detergent suction
tube is clogged.
Run warm water through
filter to remove debris.
Damaged or clogged deter-
gent suction tube.
Remove obstruction or
replace detergent
suction tube.
Nozzle is in high-pressure
position.
Turn nozzle tip to low-pres-
sure position.
Discharge nozzleis obstructed. Blow out or remove debris
with a fine needle.
Garden hose connection leaks. Loose Tighten fittings.
Missing/worn rubber washer. Insert new washer.
Spray wand, extension, or
nozzle leaks.
Spray nozzle not
properly attached.
Insert the spray nozzle into
the trigger gun. Carefully
press in against the spring
tension, and twist into the
locked position.
Broken o-ring or plastic insert. Call the Toll-Free Hotline.
Pump is noisy. Pump is sucking air. Check that hoses and fit-
tings are airtight. Turn off
machine and purge pump
by squeezing trigger gun
until a steady of water
emerges through the nozzle.
Water leaks from pump (up
to 10 drops per minute
is permissible).
Loose Check that all fittingsare tight.
Water seals are damaged
or worn.
Call the Toll-Free Hotline.
Oil is dripping. Oil seals are damaged or
worn.
Call the Toll-Free Hotline.

19
TROUBLESHOOTING
IF YOU ENCOUNTER ANY ADDITIONAL DIFFICULTIES NOT LISTED, VISIT OUR WEBSITE AT
WWW.SIMONIZ.CA OR CALL CUSTOMER SERVICE AT 1-866-4SIMONIZ (1-866-474-6664) FOR HELP.
Symptom Cause Solution
Motor buzzes but fails to run. Supply voltage
below minimum.
Verify that only the pres-
sure washer is running on
this circuit.
System has residual pressure. Turn unit “OFF”, squeeze
trigger on spray wand to
release pressure, then turn
unit “ON”.
Voltage loss due to
extension cord.
Unplug any extension cords
attached and plug the unit
directly into the outlet.
Pressure washer not used
for long periods.
Call the Toll-Free Hotline.
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
