Simplicity 3539 Setup guide

Attachment
Illustrated
Parts List
Rev. 12/2002
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
MANUFACTURING, INC.
© Copyright Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.2003 TP 400-3539-00-AT-SMA
Mf
g
. No. Descri
p
tion
Attachment
1694267 Quad Bagger Dump Cart

Quad Bagger Dump Cart
NOTE: Unless noted otherwise,
use the standard hardware torque
specification chart.
Hitch -
Prestige / 1800 / 2800 / GT Series &
Conquest / 1700 / 2700 /YT Series
Tractor Rear
Frame Wrapper
Hitch -
Broadmoor / 1600 / 2600 Series
DECAL
Rear Tractor Frame
11
11
17
15
19
12
18
19
24
25
23
23
32
26
30
23
27
28
26
29
23
19
29
19
14
16
13
20
21
22
23
1
7
5
31
9
9
2
8
8
4
6
3
3
10
33
986146
The above parts group applies to the following Mfg. Nos.:
2003 1 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694267 - Quad Ba
gg
er
TP 400-3539-00-AT-SMA

PART NO. DESCRIPTIONREF NO. QTY.
Quad Bagger Dump Cart
Footnotes
1 1708239 1 TAILGATE
2 1703338 1 BOX, Cart
3 1930644 2 LOCKNUT, Two-Way, 1/2-13
4 1703335 1 BRACKET, Hinge, RH
5 1700765 1 HANDLE, Latch
6 1920161 1 NUT, Jam, 5/16-18
7 1917372 1 NUT, 5/16-18
8 177649 2 WASHER, Compression, 5/16
9 1919326 2 WASHER, 5/16
10 1921977 1 CAPSCREW, 5/16-18 x 1-1/4
11 1923114 4 CAPSCREW, Hex Head, 1/2-13 x 1
12 1921958 2 CAPSCREW, Hex Head, 1/4-20 x 1/2
13 1700768 1 HANDLE, Lift
14 1916964 2 LOCKWASHER, 1/4
15 1916622 2 NUT, 1/4-20
16 1703336 1 FRAME
17 176012 2 SAFETY CLIP
18 102004 2 PIN, Round Head, 1/2 x 1-1/2
19 1930651 14 LOCKNUT, Center Lock, 3/8-16
20 1924940 8 WASHER, 3/8
21 1676892 2 WHEEL ASSEMBLY, (Includes Item # 31)
22 1703334 1 BRACKET, Hinge, LH
23 1921210 14 CAPSCREW, 3/8-16 x 1
24 1723888 1 BRACKET, Hitch, LH
25 1723887 1 BRACKET, Hitch, RH
26 1918431 2 WASHER, 1/2
27 1723884 1 ADAPTER, Hitch, LH
28 1723885 1 ADAPTER, Hitch, RH
29 1922134 3 LOCKNUT, Center Lock, 1/2-13
30 1723883 1 HITCH
31 * 1 DECAL, No Riders, Max. Weight 300 Lbs.
32 1921176 1 CAPSCREW, Hex Head, 1/2-13 x 1-1/4
33 1712288 2 BEARING, Wheel
* Not a Service Part.
The above parts group applies to the following Mfg. Nos.:
2003 2 © Copyright Simplicity Manufacturing, Inc. All Rights Reserved.
1694267 - Quad Ba
gg
er
TP 400-3539-00-AT-SMA

Torque Specification Chart
FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%)
Hardware
Grade
SAE Grade 2 SAE Grade 5 SAE Grade 8
Size Of in/lbs in/lbs in/lbs
Hardware ft/lbs Nm. ft/lbs Nm. ft/lbs Nm.
8-32 19 2.1 30 3.4 41 4.6
8-36
20 2.3 31 3.5 43 4.9
10-24
27 3.1 43 4.9 60 6.8
10-32
31 3.5 49 5.5 68 7.7
1/4-20
66 7.6 810.9 12 16.3
1/4-28
76 8.6 10 13.6 14 19.0
5/16-18 11 15.0 17 23.1 25 34.0
5/16-24 12 16.3 19 25.8 27 34.0
3/8-16 20 27.2 30 40.8 45 61.2
3/8-24 23 31.3 35 47.6 50 68.0
7/16-14 30 40.8 50 68.0 70 95.2
7/16-20 35 47.6 55 74.8 80 108.8
1/2-13 50 68.0 75 102.0 110 149.6
1/2-20 55 74.8 90 122.4 120 163.2
9/16-12 65 88.4 110 149.6 150 204.0
9/16-18 75 102.0 120 163.2 170 231.2
5/8-11 90 122.4 150 204.0 220 299.2
5/8-18 100 136 180 244.8 240 326.4
3/4-10 160 217.6 260 353.6 386 525.0
3/4-16 180 244.8 300 408.0 420 571.2
7/8-9 140 190.4 400 544.0 600 816.0
7/8-14 155 210.8 440 598.4 660 897.6
1-8 220 299.2 580 788.8 900 1,244.0
1-12 240 326.4 640 870.4 1,000 1,360.0
Hex Head Capscrew
Hex Nut
Lockwasher
Washer
Carriage Bolt
NOTES
1. These torque values are to be used for all hardware
excluding:locknuts, self-tapping screws, thread forming
screws, sheet metal screws and socket head setscrews.
2. Recommended seating torque values for locknuts:
a. for prevailing torque locknuts - use 65% of grade 5
torques.
b. for flange whizlock nuts and screws - use 135% of
grade 5 torques.
3. Unless otherwise noted on assembly drawings, all torque
values must meet this specification.
Hardware Identification & Torque Specifications
Common HardwareTypes
Screw, 1/2 x 2
Body
Diameter
Body
Length
Inside
Diameter
Nut, 1/2”
No
Marks
3/8”Bolt or Nut
Wrench—9/16”
3/8
5/16”Bolt or Nut
Wrench—1/2”
5/16
1/4”Bolt or Nut
Wrench—7/16”
1/4
1/2”Bolt or Nut
Wrench—3/4”
1/2
DIA.
7/16
DIA.
7/16”Bolt or Nut
Wrench (Bolt)—5/8”
Wrench (Nut)—11/16”
Wrench & Fastener Size Guide
Standard Hardware Sizing
When a washer or nut is identified as 1/2”, this is the
Nominal size , meaning the inside diameter is 1/2 inch; if a
second number is present it represent the
threads per inch
When bolt or capscrew is identified as 1/2 - 16 x 2”, this
means the
Nominal size , or body diameter is 1/2 inch; the
second number represents the
threads per inch (16 in this
example, and the final number is the
body length of the
bolt or screw (in this example 2 inches long).
The guides and ruler furnished below are designed to
help you select the appropriate hardware and tools.
0
1/4 3/4
1/2
1
1/4 3/4
1/2
2
1/4 3/4
1/2
3
1/4 3/4
1/2
4
