Simplified MFG EXACKT User manual

1
EXACKT
HDMI over AC Extender Kit
VER 1.0

2
Thank you for purchasing this product
The Simplified MFG EXACKT is designed to provide years of reliable service. At
Simplified MFG, we want the experience with this device to be the best possible and are
committed to helping achieve that experience.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical
spikes, surges, electric shock, lighting strikes, etc. Use of surge protection systems is
highly recommended in order to protect and extend the life of your equipment.
Table of Contents
1. Introduction...................................................................................................... 2
2. Features ............................................................................................................ 3
3. Package Contents ............................................................................................. 3
4. Specifications.................................................................................................... 4
5. Operation Controls and Functions .................................................................... 5
5.1 Transmitter Panel..................................................................................... 5
5.2 Receiver Panel.......................................................................................... 6
5.3 IR Pin Definition....................................................................................... 6
6. Application Example ......................................................................................... 7
7. Warranty Information…..……….……...………………………………………………… 8
8. Contact Information.……….……………………………………………………………… 8
1. Introduction
The EXACKT can extend a 1080p/720p high definition video / audio signal and one-way IR
up to 70 meters (230 feet) between transmitter and receiver over the existing AC wiring.
The EXACKT transmitter encodes a 1080p/720p HDMI signal into H.265 and uses the
existing AC wiring to transmit the HDMI signal to the receiver elsewhere in the same
venue as long as the AC is in the same electrical box and same phase. Most residences
have the electrical outlets wired in the same phase.
The EXACKT kit includes two units: transmitter unit and receiver unit. The transmitter unit
is responsible for transmitting the HDMI input signal via the AC wiring and emitting IR
control signals sent from the IR RX at the receiver end. The receiver unit is responsible for
receiving the HDMI signal and transmitting IR control signal.

3
2. Features
•Plug and play operation
•Supports video resolutions 480i/480p/720p/1080i/1080p/1400x1050
•Distance up to 230ft / 70 meters
•Can be used with up to two extra receivers (sold separately)
•Supports LPCM Stereo at 32kHz., 44.1kHz., & 48kHz.
•IR transmission from Display (RX Device) to TX device at source end
3. Package Contents
•1× HDMI over AC transmitter
•1× HDMI over AC receiver
•1× IR Blaster (1.5m length)
•1× 20~60KHz IR Receiver (1.5m length)
•2x Power Cords
•1× User Manual
4. Specifications
Technical
HDMI Compliance
HDMI 1.3
HDCP Compliance
HDCP 1.4
Video Bandwidth
6.75Gbps
Video Resolution
Up to 1080p
Color Space
RGB / YCbCr 4:4:4, YCbCr 4:2:2/4:2:0, YUV 4:4:4
Color Depth
8/10/12-bit
HDMI Audio Formats
LPCM 2.0 32kHz., 44.1kHz., & 48kHz.
ESD Protection Human body model — ±8kV (Air-gap discharge)
&±4kV (Contact discharge)
Connections

4
Transmitter
Inputs: 1x HDMI Type A [19-pin female]
Outputs: 1x HDMI Type A [19-pin female]
1x IR OUT [3.5mm Stereo Mini-jack]
Receiver Inputs: 1x IR IN [3.5mm Stereo Mini-jack]
Outputs: 1x HDMI Type A [19-pin female]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
Transmitter / Receiver:
135mm (5.31”)[W] x 96.5mm (3.8”)[D] x
29mm (1.14”)[H]
Weight
Transmitter/Receiver: 405g (14.28oz.)
Power Supply
Input: AC 100 - 240V 50/60Hz.
Power Consumption
3.5 W Max Each
Operating
Temperature
32 - 104°F / 0 - 40°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)
Cable Length
Use Premium Highspeed HDMI cable up to 10m
5. Operation Controls and Functions
5.1 Transmitter Panel
Name
Function description
Power LED
Red LED indicates that power is connected to
transmitter/Encoder
Link LED
•
Blinking = Not paired to Receiver
•
Blinking Rapidly = Pairing/Paired
Recessed Reset
Button
Press the recessed button with paperclip or other pin-like
object (gently) for 3 seconds to reset the device
AC/220V
110/220V cable input (110V Supplied)
HDMI Out
HDMI “Loop out” for intercepting the signal to a current
display
HDMI In
Connect to the HDMI source
IR OUT Connect to wideband IR Blaster (included). The IR signal is
from the IR IN port of the receiver.

5
5.2 Receiver Panel
Name
Function description
Power LED
Red LED indicates that power is connected to
Receiver/Decoder
Link LED
•Blinking = Not paired to Receiver
•
Blinking Rapidly = Pairing/Paired
Recess Reset
Button
• Short press will copy EDID of connected display
•3 Second press will reset the receiver
AC/220V
110/220V cable input (110V Supplied)
HDMI Out
HDMI output for signal to display
IR IN
Connect to wideband IR Receiver. The IR signal will be
transmitted to the IR OUT port of the transmitter.
5.3 IR Pin Definition

6
6. Application Example
Please note up to two more receivers (decoders) can be added to an EXACKT kit (sold
separately).All devices need to be on the same electrical panel in order to operate
correctly. The part number is EXACDEC.

7
7. Warranty
Should you feel that this product does not function adequately due to defects in
materials or workmanship, we (referred to as “the warrantor”) will, for the length of
the period indicated below (starting from the original date of the purchase) either a)
repair the product with new or refurbished parts. Or b) Replace the product with new
or refurbished product. All Simplified MFG products are covered by a 3-year PARTS
and LABOR warranty. During this period there will be no charge for unit repair,
replacement of unit components or replacement of the product if deemed necessary.
The decision to repair or replace is made by the warrantor. The purchaser must mail
in the product during the warranty period. This limited warranty only covers the
product purchased as new and is extended to the original purchaser only. It is non-
transferrable to subsequent owners, even during the warranty period. A purchase
receipt or other proof of purchase date is required for the limited warranty service.
8. Contact Information
Sales and Tech Support
P. 833-HDMI-411 (833-436-4411)
E. [email protected]om
Simplified MFG • 550 W Baseline Rd Ste 102-121 • Mesa AZ 85210

2.
HDMI OUT HDMI IN IR OUTHDMI OUT HDMI IN IR OUT
AC Cord
IR
HDMI OUT IR INHDMI OUT IR IN
IR
DisplayDisplay
HDMI
AC Cord
[phone] |simpliedmfg.com
550 West Baseline Road, Suites 102-121, Mesa, AZ 85210
HD MI OUT HDMI IN IR O UTHD MI OUT HDMI IN IR O UT
IR
IR
1.
Transmitter
Transmitter (ENC)
Receiver (DEC)
Receiver
HD MI OUT I R INHD MI OUT I R IN
HDMI SourceHDMI Source
HDMI
AC Cord
AC Cord
EXACKT HDMI over AC Extender Kit

EXACKT
HDMI over Electrical Wiring Extender
833-HDMI–411 (436-4411) • www.simplifiedmfg.com • 550 W Baseline Rd., Ste #102-121 • Mesa, AZ 85210
Specifications:
The EXACKT is a HDMI over power
wire solution. Perfect when you have
no wiring infrastructure and it is cost
prohibitive to retrofit it. The EXACKT
is a kit that allows HDMI 1080p to be
transmitted on the existing electrical
wiring in the venue. Simply plug your
source into the transmitter, plug it
into the wall and it will broadcast over
the existing wiring to a receiver
where you will have an HDMI output
to your display.
Features:
• Works on the AC wiring
• 1080p
• Simple set up, just plug it in
• 1-Way IR (kit included)
• Long distance (up to 100m)
• Supports up to 3 receivers
(optional EXACDEC)
• 3-Year Warranty
Technical
HDMI
Compliance HDMI 1.3
HDCP
Compliance HDCP 1.4
Video Bandwidth 3.97 Gbps
Video
Resolutions 480i/480p/720p/1080i/1080p/1400x1050
Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth 8-bit, 10-bit, 12-bit
HDMI Audio
Formats
(Pass-through)
LPCM 2 channel stereo @ 32kHz., 44.1kHz., & 48kHz.
ESD Protection Human body model — ±8kV (air-gap discharge) & ±4kV
(contact discharge)
Connections
Inputs
TX: 1x HDMI Type A [19-pin female]
1x AC input type C13
RX: 1x AC input type C13
1x IR INPUT [3.5mm Stereo Mini-jack]
Outputs TX: 1x IR OUTPUT [3.5mm Stereo Mini-jack]
RX: 1x HDMI Type A [19-pin female]
Mechanical
Housing Metal Enclosure
Color Black
Dimensions 135mm (5.31”)[W] x 96.5mm (3.8”)[D] x 29mm (1.14”)
[H]
Weight RX/TX 405g/405g (14.28oz.)
Power Supply Input: AC100 - 240V 50/60Hz
Power
Consumption 3.5W each device (Max)
Operation
Temperature 32 - 104°F / 0 - 40°C
Storage
Temperature -4 - 140°F / -20 - 60°C
Relative
Humidity 20 - 90% RH (no condensation)
