SImx LHT0331 User manual

Thank you for purchasing this 12W x2 LED Twinspot Floodlight
This light is suitable for sheltered outdoor use and requires a 230-240V AC power supply.
Please read this manual throughly before installation and retain for future reference.
* This light is designed for wall mount installation only.
Ensure adequate ventilation space is allowed between the unit and any object above, in front or to either side of the unit.
INSTALLATION INSTRUCTIONS
IMPORTANT
This product is suitable for use only with a supply voltage of 230-240V AC 50Hz.
All electrical work must be carried out in accordance with local and national electrical codes as applicable. We
strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of main power isolation must be installed on the circuit for the
purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety. Young children should be supervised to
ensure that they do not play with the appliance.
Any changes or modifications made or attempted to this product, without the prior written approval of the
manufacturer, will void any and all stated warranties.
Manual Override Mode
MODEL: LHT0331 and LHT0332
The light can be switched on for longer time periods by use of the Manual Override Mode. To activate Manual Override for
continuous light at night, toggle the internal wall switch twice (OFF/ON//OFF/ON) within 1 -2 seconds.
The unit will now illuminate continuously until dawn or until it is switched back into Automatic Mode.
The permanent illumination of the red LED at the top of the sensor head indicates that Manual Mode is activated.
To cancel Manual Override Mode and switch the unit back into Automatic Mode, toggle the internal wall switch once
(OFF/ON) within 1 second. The unit will return to normal motion sensor operation. The light will flash on once to confirm
activation and cancellation of this mode. The red LED’s will scroll left and right indicating the unit is in Automatic Mode.
PIR Operation:
PIR Detection Range:
PIR Detection Angle:
PIR Auto Time Off:
PIR Time Control:
PIR Dusk Control:
Lamp Adjustment:
Construction:
Supply Voltage:
Wattage:
Power Factor:
Stand By Load:
Light Beam Angle:
Lamp Data:
Luminous Flux:
Working Temperature:
Ingress Protection:
Protection Class:
230-240V AC 50Hz
24 watts
>0.92
0.5W max
105º-110º
5000k, CRI >80
Total: 1600lm
-20°C to +40°C
IP44
Class I
Auto / Manual / Time Control
Up to 12 metres
180º at 3m; 80º at 12 metres
Min: 3 secs Max: 7 mins (approx)
Approx. 1 - 8 hours (adjustable)
Day to night (adjustable)
Pan left 80º and right 80º (+42º)
Tilt down 55º
Alloy UV Stabilised Polycarbonate,
Stainless Steel 304 Screws
TECHNICAL SPECIFICATIONS
WARNING
PRODUCT COMPLIANCE
MANUFACTURERS EXTENDED WARRANTY
This product will get warm when in normal use. It can be installed on surfaces of normal flammability e.g.
wood, plasterboard, brickwork and other masonry.
Do not install on flammable surfaces such as plastics.
Product complies with:
EN55015:2006/A1:2007 EN61000-3-2:2006 EN61000-3-3:2008 EN 61547:1995/A1:2000
IEC 61000-4-2:2008 IEC 61000-4-3:2006/A1:2007 IEC 61000-4-4:2004 IEC 61000-4-5:2005
IEC 61000-4-6:2008 IEC 61000-4-8:1993/A1:2000 IEC 61000-4-11:2004 EN 60598-1:2008
EN60598-2-5:1989 EN61347-2-13:2006 AS/NZ 60598-2-5 EN62031
IEC/EN 62471 IEC/TR62471-2 and relevant amendments.
This product is guaranteed by Ventair Pty Ltd for 36 MONTHS from the date of purchase against faulty materials or
workmanship which affects its designed ability to switch or operate. During this period if the product has a defect of this
nature it will be repaired or replaced free of charge by Ventair with the same item, or a similar item, or a similar one of
higher specification.
ON CONDITION THAT:
The buyer returns it to the seller from whom it was bought, freight paid.
The product has been bought by the user i.e. a receipt/sales invoice is produced as proof of purchase.
The product has not been misused or handled carelessly, installed in anyway contrary to the installation instructions, or
installed in any unusually exposed or harsh environmental conditions.
This guarantee excludes liability for discolouration of paint or plastic, or any user replaceable parts.
It does not confer any rights other than those expressly set out above and does not cover any claims for consequential loss
or damage.
Our Goods come with guarantees that cannot be excluded under the Australian Consumer law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the Goods repaired or replaced if the Goods fail to be of acceptable quality and the failure
does not amount to a major failure.
SIMX is proudly distributed by Ventair Pty Ltd
4 Capital Place, Carrum Downs, 3201 VIC, AUSTRALIA.
Technical Support: 1300 665 926
e: [email protected] | www.ventair.com.au | www.simx.com.au 260620

ASSEMBLY INSTALLATION INSTRUCTIONS
*** IMPORTANT ***
This light fitting should be installed by a registered electrician
Motion Detector Head AdjustmentDetection Range:
WALK TEST PROCEDURE
MASKING THE SENSOR LENS
KNOB SETTINGS
TIME CONTROL MODE
LUX Knob Setting
Recommended installation height is 2.5m above ground,
the maximum detection range about 12m and at angle of
about 80 degrees. Up to 3m range, detection angle is
about 180º.
Adjust the sensor to point in the required direction. Adjust time knob to lowest setting. Turn the power to the unit on.
The lamp will illuminate for approximately 30-60 seconds. The unit is now in Test Mode. Walk across the detection area to
determine the trigger zone and adjust aiming of sensor to suit. Left unactivated for 60 seconds, the light will switch to
AUTO Mode, confirmed by red LED scrolling left and right.
To restrict the sensor coverage, preventing detection in unwanted areas, mask the sensor lens using the masks provided
in the accessory pack.
• When setting the Lux knob at “MOON”, PIR
activation will only operate in the dark.
• When setting the Lux knob at “SUN”, PIR
activation will operate at any light level.
TIME Knob Setting
• You can set the time knob from 3 sec to about 7 min,
LED floodlight will turn ON the lamp, for the time duration
set after each detection movement.
Toggle the internal wall switch 3 times (off/on off/on off/on) within 3 seconds.
A single flashing red LED at the top of the sensor head indicates Time Control Mode. The unit
will now illuminate for a user defined time between 1 and 8 hours. The time can be set by rotating the
centre adjustment knob as required. (The adjustment knob is identified by the letter T inside a circle.)
Do not adjust this setting if you do not wish to use the Time Control Mode facility.
This time adjustment is preset to 1 hour. Please note: Fully clockwise is 8 hours, fully anticlockwise is 1 hour.
After the defined period has elapsed, the unit will return to Sensor Control Mode and operate as previously set up and the
three scrolling LED's will illuminate from left to right.
Time Control Mode is different to Manual Control Mode in that it will NOT reset to Sensor Control Mode at dawn, it will
repeat each night until reset by the user. To cancel Time Control Mode, toggle the internal wall switch once (Off/On) within
one second. The unit will turn to Sensor Control Mode indicated by the scrolling LEDs.
The detector head can be 20º turned left or right by hand,
it can be tilted 60º downward.
Do not use the adjuster knobs to turn the detector head.
Note:
Make sure sensor head is
positioned with control knobs
facing towards the ground to
maintain IP rating.
3m
2.5m
12m
180
This light fitting is rated to IP44. This means that it is suitable for use in
sheltered exterior locations. Please ensure the desired location does not
exceed this rating.
When deciding on location of your light fitting, be aware that PIR sensors are
more sensitive to movement across the detection zone, and less sensitive to
movement towards the sensor.
For your information, the top section of the lens
covers long range detection, the bottom covers
short range. Similarly the left and right lens
sections cover the left and right detection areas
respectively.
