SINED SOLE Series Specification sheet

Solar heated outdoor showers
DOCCIA-SOLE-BIANCA –SOLE-WHITE –SOLE WHITE
DOCCIA-SOLE-BIANCA-LUCE –SOLE-WHITE-LIGHT –SOLE WHITE LUCE
DOCCIA-SOLE-GRIGIA –SOLE-GREY –SOLE GREY
DOCCIA-SOLE-NERA –SOLE-BLACK –SOLE BLACK
DOCCIA-SOLE-BLU –SOLE-BLU –SOLE BLUE
DOCCIA-SOLE-ROSSA –SOLE-RED –SOLE RED
DOCCIA-SOLE-VERDE –SOLE-GREEN –SOLE GREEN
Instructions for Use and Maintenance
The photo is only indicative. The real product may appear slightly different in color

Number
01
Shower head
02
Hot Cold Mixer
03
Foot Washing Faucet
04
Water / Faucet Inlet
05
Water drain plug

Thank you for purchasing this SINED product. We are constantly improving our products. However, in case this
product may show any defect, we apologize and please contact our customer service.
USE AND MAINTENANCE MANUAL
This manual is an integral part of the product you have purchased. It contains important information for the
installation and use of the product. Before using the product, read the instructions carefully, especially the
safety warnings. Failure to follow the instructions and warnings can result in serious personal injury and
damage to the product. The instructions provided are based on the standards and regulations valid in the
European Union. For other countries follow the specific regulations. Keep the instructions for future reference
and pass them on to third parties.

INTENDED USE
This Solar heated shower model is recommended for family use.
A solar shower is designed to be used exclusively outdoors. In addition, the shower is equipped with a foot
wash tap at the bottom which supplies water (e.g. for watering cans). Only use the product as described in the
instructions. Any other use may result in damage to property or even personal injury. This product is not a toy.
The manufacturer or seller accepts no liability for any damage resulting from incorrect or improper use.
Safety warnings
Carefully read and follow all warnings and instructions. Failure to comply may result in property damage,
serious personal injury or even death. These warnings, instructions and product safety precautions cover
many, but not all, of the possible hazards and risks. You are advised to exercise caution and to evaluate all
hazardous situations correctly. Improper use of the product may also result in death.
Caution! All repairs must be carried out by qualified personnel only to avoid possible hazards. If necessary,
contact a qualified technician. In the event of self-initiated repairs, improper installation or misuse, liability
and warranty claims will lapse. Only spare parts that correspond to the original product data may be used for
repairs.
WARNING! Hazards for children and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge: Children must not play with this product. Cleaning must not be carried out by
children or persons with reduced physical, sensory or mental capabilities.
Content control
WARNING! Danger of damage to the product! If the packaging is opened with a sharp knife or other pointed
tool without due care, the contents may be damaged. Therefore, be careful when opening the packaging:
•Take the product out of the package
•Check the contents of the package - see Fig. L1.
•Check that the product and its individual components are intact and undamaged. If this is not the case,
do not use the product and contact the seller immediately.
Determine the installation location
To ensure the best possible stability and your safety, the solar shower must be installed on a stable surface.
Place the shower in a sunny location taking care that the back of the shower is exposed to the sun and facing

south if possible. Do not lean the shower against a wall or anything else that blocks sunlight. The installation
must be carried out by qualified personnel.
Installation
1) A drill is required for mounting. Determine the drilling points in correspondence with the holes in the
mounting base using the paper template see Fig. 1) and the screws and fixing plugs contained in the
package. Do not drill directly through the holes in the shower base.
2) The drilling depth in concrete or rock should be at least 45 mm. This gives the screws a good tensile
strength and the necessary tightness.
3) Insert the dowels into the respective holes.
4) Place the bottom of the shower (mounting base) over the holes and secure with screws using the
appropriate tools and taking care not to damage the surface.
5) Damage caused by incorrect assembly is not covered by warranty.
Commissioning
Connect the garden hose to the water inlet of the shower. The maximum operating pressure of the shower is 3
bar. Ensure that the hose is properly secured.
First start-up
Connect the water hose to the shower. Check that the inlet tap is open. Set the shower mixer to "hot" and let
the water flow into the shower: this will prevent air bubbles from forming in the tank.
It takes approx. 4-6 minutes to fill the tank. When the water flows evenly and smoothly out of the overhead
shower, close the mixer with the lever in the middle - the tank is now completely full.
Use
Caution: Solar radiation causes the water in the solar tank to become hot. We therefore recommend that you
always set the cold/hot mixer to the middle position (between hot and cold).
Then set the desired temperature.
1) Set the mixer to the "ON" position and you can enjoy a hot shower with water heated by the sun.
Attention: the water supply must be opened for the shower to work!
2) After use, turn off the water supply to the shower.
If you are not going to use the shower for 24 hours or more, let the water run for at least 2 minutes to allow
the water in the solar tank to be completely replaced. In hot environments, stagnant water may cause
pathogenic bacteria to multiply.

The water in the tank no longer corresponds to drinking water quality!
Important information
Water leaking from the shower head after turning off the shower faucet is not a defect but a technical
requirement!
A solar shower is not a closed system. If there is a demand for hot water, cold water enters the tank from
below through the valve pushing out the hot water already in the top of the tank.
The entire shower body is filled with water and serves as solar heating.
The pressure that builds up as a result of heating can leak out of the shower head.
Dismount at the end of the season
During the winter period, the shower must be COMPLETELY drained of its water content. Also during the
winter the shower must be disassembled and stored in a dry place.
Failure to observe this warning may result in frost damage to the product.
Frost damage is not covered by warranty.
1) Close the shower and remove the garden hose.
2) To drain the shower, turn the mixer back to the "ON" position (approx. 2 minutes) and open the drain
plug.
3) Remove the fixing screws on the base and drain the remaining water from the bottom of the shower by
tilting the shower (this is absolutely necessary!).
Cleaning
Use commercially available cleaning agents for cleaning. Do not use cleaning agents containing solvents,
abrasive cleaners or hard sponges, brushes, etc.
Warranty
The provisions in force in the European Community shall apply.
Production: Starmatrix Group Inc.
Address: 253 Mengxi Road
Zhenjiang, Jiangsu, CHINA
Made in China Imported in Italy by M.P.C. srl Via Pulci 15 20126 Milano Italy Tel [phone] e-mail
[email protected] website www.sinedtechnology.com
The trademark SINED and the logo SINED are registered by SINED VENTAS ONLINE S.L.U. EUTM 018196373
