SIP Fireball 27 User manual

16
Ref: 210716
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
Never dispose of electrical equipment or batteries in with your
domestic waste. If your supplier offers a disposal facility please
use it or alternatively use a recognised re-cycling agent. This will
allow the recycling of raw materials and help protect the envi-
ronment.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
1
Fireball 27
Wall Mounted Heater
09118
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.

2
15
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
Fireball 27 Wall Mounted Heater - SIP Part. No. 09118
Conforms to the requirements of the following directive(s), as indicated.
2006/95/EC Low Voltage Directive
2014/30/EU EMC Directive
2011/65/EU RoHS Directive
And the relevant harmonised standard(s), including:
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 60335-2-30:2009+A11:2012
EN 60335-1:2012+AC:2014+A11:2014
EN 62233:2008
Signed: …………………………………...
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 23/06/2016.
DECLARATION OF CONFORMITY

14
NOTES
3
CONTENTS
Page No. Description
4. Safety Symbols Used Throughout This Manual
4. Safety Instructions
7. Electrical Connection
8. Guarantee
9. Technical Specifications
9. Getting to Know Your Heater
10. Assembly Instructions
11. Operating Instructions
12. Exploded Drawing & Parts List
13. Circuit Diagram
15. Declaration of Conformity

4
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
Danger / Caution: Indicates risk of personal injury and/or the possibility of
damage.
Note: Supplementary information.
Warning: Risk of electrical injury or damage!
SAFETY INSTRUCTIONS
IMPORTANT: Please read the following instructions carefully, failure to do
so could lead to serious personal injury and / or damage to the heat-
er.
When using your heater, basic safety precautions should always be followed to re-
duce the risk of fire, electric shock, personal injury and / or damage to the heater.
Read all these instructions before operating the heater and save this user manual for
future reference.
SIP recommends that this heater should not be modified or used for any application
other than that for which it was designed. If you are unsure of its relative applications
do not hesitate to contact us and we will be more than happy to advise you.
KNOW YOUR HEATER: Read and understand the owner's manual and labels affixed to
the heater. Learn its applications and limitations, as well as the potential hazards spe-
cific to it.
DO NOT USE THE HEATER IN DANGEROUS ENVIRONMENTS: Do not use your heater in
damp or wet locations, including bathrooms or similar or expose it to rain. Always pro-
vide adequate space around the heater.
DO NOT install the heater in the immediate vicinity of bath tubs, showers, wash basins,
swimming pools, etc.
DO NOT OPERATE THE HEATER IN EXPLOSIVE ATMOSPHERES: Do not use the heater in
the presence of flammable liquids, gases, dust or other combustible sources.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area.
STAY ALERT: Always watch what you are doing and use common sense.
DISCONNECT THE HEATER FROM THE MAINS SUPPLY: When not in use.
13
CIRCUIT DIAGRAM

12
EXPLODED DRAWING & PARTS LIST
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Protection cover PW09-00185 11. Left wall bracket PW09-00195
2. Side support PW09-00186 12. Right wall bracket PW09-00196
3. Quartz element PW09-00187 13. Mains lead PW09-00197
4. Reflection plate PW09-00188 14. Slide block PW09-00198
5. Back cover PW09-00189 15. Insert pin PW09-00199
6. Tilting bracket PW09-00190 16. Spring PW09-00200
7. Terminal block cover PW09-00191 17. Pressing plate PW09-00201
8. Cover PW09-00192 18. Switch PW09-00202
9. Terminal block PW09-00193 19. Dial PW09-00203
10. Junction box PW09-00194 20. Display window PW09-00204
5
SAFETY INSTRUCTIONS….cont
AVOID UNINTENTIONAL STARTING: Make sure on the display window it is on “0” (off) be-
fore connecting the heater to the mains supply.
DO NOT ABUSE THE MAINS LEAD: Never carry the heater by the mains lead or pull it to
remove the plug from the mains socket. Keep the mains lead away from heat, oil and
sharp edges. If the mains lead is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid unwanted hazards.
HAVE YOUR HEATER REPAIRED BY A QUALIFIED PERSON: The heater is in accordance
with the relevant safety requirements. Repairs should only be carried out by qualified
persons using original spare parts, otherwise this may result in considerable danger to
the user.
DANGER! Check that the heater is in sound condition and good working order. Take
immediate action to repair or replace damaged parts.
Use recommended parts only - Unapproved parts may be dangerous and will invali-
date the warranty.
WARNING! Do not direct the heater towards any combustible materials (e.g. wood-
en items, cloth, plastics, paper, etc).
WARNING! Do not use the heater near flammable material, liquids, solids, gases or
compressed gas cylinders.
Do not allow untrained persons to operate the heater and do not operate the heater
without all covers etc. correctly fitted.
Do not handle the heater when it is on or still hot - always turn it off and allow it to
cool.
Do not leave the heater unattended when in use. Switch the heater off and unplug
from the mains supply before leaving the area.
Do not obstruct the front of the heater.
Do not use any form of ducting in front of the heater.
Do not use the heater to dry clothes or similar.
Do not allow children or animals near the heater, particularly when in use, or whilst
still hot.
WARNING! RISK OF ELECTRIC SHOCK. Do not expose the heater to water spray, rain,
dripping water or moisture of any kind.
Do not touch the protection cover or any internal parts when operating, or when first
switched off as these can be hot and will take time to cool.
Ensure that the heater is correctly turned off when not in use and store in a safe, dry
area, out of reach of children.
Do not unplug the heater to switch it off - pull the cord till it reaches 0 (off).
NEVER use this heater where flammable vapours may be present.
Keep all combustible materials away from this heater.
NEVER cover the heater.
NEVER move or handle the heater whilst still hot.
ALWAYS keep children and animals away from heater.

6
SAFETY INSTRUCTIONS….cont
Only use the heater in an horizontal position.
Never stand on the heater.
Never connect any other electrical appliances to the same socket as the heater.
DO NOT dismantle or tamper with the heater, as this may be dangerous and will in-
validate the warranty.
DO NOT install the heater in a bathroom or anywhere that has a water supply.
Never install the heater behind a door.
Understand the operating environment; Before each use the operator should assess,
understand and where possible reduce the specific risks and dangers associated
with the operating environment. Bystanders should also be made aware of any risks
associated with the operating environment.
If a problem with the heater is experienced, or if the mains lead or plug become
damaged, stop operation and contact your distributor for repair.
If the heater is used in a place of work all rules and laws etc. relating to the use of
portable electrical appliances should be followed.
WARNING: Risk of Electric Shock!
Use only the electrical power (voltage and frequency) specified on the specification
label of the heater.
Use only a three-prong, grounded outlet.
ALWAYS unplug the heater when not in use.
Caution: The warnings and cautions mentioned in this user manual can
not cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors
which cannot be built into this product, but must be applied.
11
OPERATING INSTRUCTIONS
Plug into the mains supply and switch on.
Use the pull cord to turn the heater on.
Note: You may notice when turning on the heater that there is a slight vi-
brations, don’t become alarmed as they will fade away. This is normal be-
havior of the heater.
SWITCHING THE HEATER ON
To switch off the heater pull the cord until it reaches 0 (off) on the display window.
Turn off on the wall socket and remove the plug.
TURNING THE HEATER OFF
Display Window
To adjust the heat settings pull on the cord and check the display window, the heat
settings are: 1=500w
2=1000w
3=1500w

10
ASSEMBLY INSTRUCTIONS
You will need to drill four holes into the wall, see
right diagram for measurements (centre to cen-
tre).
117mm
41mm
Insert four screws into the pre-drilled holes.
Place the heater over the four screw heads, then gently push down on the heater
so the screw heads drop down into the slots.
RECOMMENDED CLEARANCE
MOUNTING THE HEATER TO A WALL
Note: Do not install the heater in a bathroom or anywhere that has a water
supply.
The minimum clearance should be 500mm from the ceiling and 500mm from any per-
pendicular wall and 1800mm from the floor. Make sure that surface is capable of support-
ing the weight of the heater.
Wall
Floor
Ceiling
1800mm
500mm
500mm
7
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the power supply:
This SIP heater is fitted with a standard 230v ~ 13 amp type plug. Before using the
heater, inspect the mains lead and plug to ensure that neither are damaged. If any
damage is visible have the heater inspected / repaired by a suitably qualified per-
son. If it is necessary to replace the plug a heavy duty impact resistant plug would be
preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be connect-
ed to the terminal, which is marked L or coloured red. The wire which is coloured yel-
low / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly.
Secure the cable in the cord grip carefully.
ELECTRICAL CONNECTION

8
ELECTRICAL CONNECTION….cont
Warning: Never connect live or neutral wires to the earth terminal of the plug.
Only fit an approved plug with the correct rated fuse. If in doubt consult a
qualified electrician.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always
replace the fuse with the same value as the original.
Note: If an extension lead is necessary in order to reach the mains supply; The
cross section should be checked so that it is of sufficient size so as to reduce
the chances of voltage drops. Always fully unwind the lead during use.
GUARANTEE
This SIP heater is covered by a 12 month parts and labour warranty covering failure
due to manufacturers defects. This does not cover failure due to misuse or operating
the heater outside the scope of this manual - any claims deemed to be outside the
scope of the warranty may be subject to charges Including, but not limited to parts,
labour and carriage costs.
The warranty does not cover consumable parts such as the quartz elements, pull cord,
etc.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
9
Part Number 09118
Input Voltage 220V - 240V ~ 50hz
Heat Output
Setting 1 - 500w
Setting 2 - 1000w
Setting 3 - 1500w
Tilting Range 0° - 45°
Minimum Mounting Height 1800mm
Minimum Ceiling/Wall Clearance 500mm
Net Weight 1.75Kg
TECHNICAL SPECIFICATIONS
GETTING TO KNOW YOUR HEATER
Display Window
Pull Cord
(Heat Adjustment)
Quartz Element
Quartz Element
Tilting Bracket
