SIP 03692 User manual

SIP Engine Leveller
03692
For help or advice please
contact your distributor, or sip
directly on: Tel.: [phone]
Email:[email protected] or
[email protected]om
www.sip-group.com
SIP Industrial Products Limited
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
United Kingdom

CONTENTS

Page No. Descripon
3.
Safety Instrucons
4.
6.Guarantee
7.
8.
9.
Operang Instrucons
10.
Maintenance
11.
UK - Declaraon Of Conformity
EU - Declaraon Of Conformity
CONTENTS
Notes
Contents

Danger / Cauon: This picture indicates risk of personal injury and/
or the possibility of damage.
Note: This picture indicates supplementary informaon.
Important: Please read the following instrucons carefully, failure to
do so could lead to serious personal injury and / or damage to the
item.
4
SAFETY INSTRUCTIONS
When using your engine leveller, basic safety precautions should always be
followed to reduce the risk of personal injury and / or damage to the product or
load.
Read all of these instructions before operating the product and save this user
manual for future reference.
The product should not be modified or used for any application other than that
for which it was designed.
It was designed for lifting engines & loads up to 680kg. If you are unsure of its
relative applications do not hesitate to contact us and we will be more than
happy to advise you.
Before operating the product always check no parts are broken, and that no parts
are missing.
Always operate the product safely and correctly.
KNOW YOUR EGINE LEVELLER: Read and understand the owner's manual and
labels affixed to the product. Learn its applications and limitations, as well as the
potential hazards specific to it.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All
visitors should be kept at a safe distance from the work area; never allow
untrained persons to operate the shop press.
STAY ALERT: Always watch what you are doing and use common sense.
NEVER LEAVE THE ENGINE LEVELLER UNATTENDED: When in use / under load.
HAVE YOUR PRODUCT REPAIRED BY A QUALIFIED PERSON: The product is in ac-
cordance with the relevant safety requirements. Repairs should only be carried
out by qualified persons using original spare parts, otherwise this may result in
considerable danger to the user and void the warranty.

5
SAFETY INSTRUCTIONS...cont
DANGER! Check that the product is in sound condition and good working order; Take
immediate action to repair or replace damaged parts.
WARNING! Only operate on a level and stable surface and never use on soft ground
where the product is likely to “sink” whilst in operation.
NEVER STAND ON THE PRODUCT: The product is not designed for this purpose.
DO NOT dismantle or tamper with the product, as this may be dangerous and will
invalidate the warranty.
If a problem with the product is experienced or suspected stop using the product
immediately and contact your distributor for repair.
Do not attempt to apply a load that exceeds the rated capacity of the product.
Regularly inspect, clean and lubricate the product, ensuring that it is in good
working order and condition.
Always ensure that the work area is clean and tidy, free from unrelated materials and
has adequate lighting.
Keep hands, limbs etc. clear of moving parts during operation.
Failure to follow the warnings in this manual, may result in personal injury and/
or property damage.
Prior to applying the load, be sure that all chains are secure and connected
correctly.
Components of this product are specially designed to withstand the rated capacity.
Do not substitute bolts, pins, or any other components.
Always lift the load evenly. Offset loads can cause damage to the product and the
item being lifted..
Before operating, check for signs of cracks, bent support pins , loose or missing
bolts, or any other structural damage. Do not operate if any of these conditions
exist. Have repairs made only by an authorised service centre / engineer.
Due to various applications, it is your responsibility to always use adequate
protection, such as eye protection and heavy protective clothing, when operating
this .
Do not stand in front of work area where the load is applied.

6
ELECTRICAL CONNECTIONS
SAFETY INSTRUCTIONS...cont
If the product appears to be damaged in any way, is found to be badly worn, or
operates abnormally IT SHOULD BE REMOVED FROM SERVICE until necessary
repairs are made by an authorised service centre.
Understand the operating environment; Before each use the operator should as-
sess, understand and where possible reduce the specific risks and dangers associat-
ed with the operating environment. Bystanders should also be made aware of
any risks associated with the operating environment.
CAUTION: The warnings and cautions mentioned in this user manual can not cover all possible
conditions and situations that may occur. It must be understood by the oper-ator that common
sense and caution are factors which cannot be built into this product, but must be applied.
Danger: Never exceed the maximum capacity of 680kg, overloading can lead
to personal injury or damage to the pipe bender.
This SIP Engine Leveller is covered by a 2 year parts and labour warranty
covering failure due to manufacturers defects. This does not cover failure due to
misuse or operating the product outside the scope of this manual - any claims
deemed to be outside the scope of the warranty may be subject to charges
Including, but not limited to parts, labour and carriage costs.
This guarantee does not cover consumables such as nuts, bolts, etc.
In the unlikely event of warranty claims, contact your distributor as soon as possible.
Note: Proof of purchase will be required before any warranty can be honoured.
GUARANTEE

7
OPERATION
Raise a Load Squarely.
Attach the leveller to the load via the recommended lifting points.
If this is an engine, ensuring that all necessary components are disconnected, i.e.
exhaust, gearbox, cables, electrical connections etc.
Very slowly take the weight of the engine.
As the load begins to lift it may rise unevenly at one end only.
Turn the crank handle of the Leveller so that the load moves AWAY from that end.
Continue to raise the load a little at a time whilst moving the load away from the
raised end until the load rises squarely.
If there is a degree of twist, this may be taken up by adjusting the chain and shackle
arrangement to lengthen or shorten the hooks as appropriate.
ALWAYS ensure that the FULL thickness of the bolt is in contact with the threaded end
of the shackle.
If this method is insufficient to compensate for the degree of twist, you should adjust
the chain length on one or more of the lifting points.
Raising a Load at an Angle
In some cases, it may be necessary to raise the load at an angle.
Adjust the chains and shackles appropriately, and select the correct hole in the sliding
bar.
Gently raise the load,turning the crank handle as required to achieve the required
degree of tilt.

8
MAINTENANCE
Always visually inspect before each use to ensure no cracks are present and no
damage is evident, and that the tool is in good general condition.
If it is damaged or if in doubt as to its serviceability, consult SIP After Sales -
01509 500400 or your local SIP distributor.
Remove from service immediately.
Regularly:-
Check the sliding bar for wear, damage and distortion.
Lubricate lightly the sliding bar and adjusting lead screw.
Inspect the chains for damage, wear, elongation etc.
If any irregularities are present change them.

9
NOTES

Declaraon of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer within the UK, England, Scotland & Wales,
declare that the
SIP Engine Leveller - SIP Code 03692
Conforms to the requirements of the following regulaon(s), as indicated.
Supply of Machinery (Safety) Regulations 2008
And the relevant harmonised standard(s, including
BS EN1494:2000+A1:2008
Signed:
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 14/07/2021
UK - DECLARATION OF CONFORMITY

Declaraon of Conformity
We
SIP (Machinery Europe) Ltd
ASM Chartered Accountants
First Floor Block One
Quayside Business Park
Dundalk
County Louth
Republic of Ireland
As the manufacturer’s authorised representave within the EC
declare that the
SIP Engine Leveller - SIP Code 03692
Conforms to the requirements of the following direcve(s, as indicated.
2006/42/EC - Machinery Directive
And the relevant harmonised standard(s), including
EN1494:2000+A1:2008
Signed:
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 14/07/2021
EU - DECLARATION OF CONFORMITY

Please dispose of packaging for the product in a
responsible manner. It is suitable for recycling. Help
to protect the environment, take the packaging to
the local amenity p and place into the appropriate
recycling bin.
Never dispose of electrical equipment or baeries
in with your domesc waste. If your supplier oers
a disposal facility please use it or alternavely use
a recognised recycling agent. This will allow the
recycling of raw materials and help protect the
environment.
Ref: 14072021
