SIP 01944 User manual
01944
Safety Instrucons
Electrical Connecons
Guarantee
Your item
Technical Specicaons
Assembly Instrucons
Operang Instrucons
Maintenance
Exploded Drawing
Part List
UK - Declaraon Of Conformity
EU - Declaraon Of Conformity
Danger / Cauon: This picture indicates risk of personal injury and/
or the possibility of damage.
Warning: This picture indicates risk of electrical injury or damage!
Note: This picture indicates supplementary informaon.
Important: Please read the following instrucons carefully, failure to
do so could lead to serious personal injury and / or damage to the
item.
Woodworking can be dangerous If safe and proper operang procedures are not
followed. As with all machinery, there are certain hazards Involved with the operaon
of the product. Using the machine with respect and cauon will considerably
lessen the possibility of personal injury. However, if normal safety precauons are
overlooked or Ignored, personal injury to the operator may result. Safety equipment
such as guards, push scks, hold-downs, feather boards, goggles, dust masks and
hearing protecon can reduce your potenal for injury. But even the best guard will
not make up for poor judgment, carelessness or Inaenon. Always use common
sense and exercise cauon in the workshop. If a procedure feels dangerous, do not
try. Figure out an alternave procedure that feels safer. REMEMBER: Your personal
safety Is your responsibility.
This machine was designed for certain applicaons only. We strongly recommend
that this machine is not modied and/or used for any applicaon other than that for
which it was designed. If you have any quesons relave to a parcular applicaon,
DO NOT use the machine unl you have rst contacted your local dealer to determine
if it can or should be performed on the product.
• FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE
4
TOOL. Learn the tool's applicaon and limitaons as well as the specic hazards
peculiar to it.
• KEEP GUARDS IN PLACE and in working order.
• ALWAYS WEAR EYE PROTECTION. Wear safety glasses. Everyday eyeglasses only
have impact resistant lenses; they are not safety glasses. Also use face or dust
mask if cung operaon is dusty.
• REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to see that
keys and adjusng wrenches are removed from tool before turning it on.
• KEEP WORK AREA CLEAN. Cluered areas and benches Invite accidents.
• DO NOT USE IN DANGEROUS ENVIRONMENT. Do not use power tools in damp or
wet locaons, or expose them to rain. Keep work area well lighted.
• KEEP CHILDREN AND VISITORS AWAY. Children and visitors should be kept a safe
distance from work area.
• MAKE WORKSHOP CHILDPROOF - with padlocks, master switches, or by
removing starter keys.
• DO NOT FORCE TOOL. It will do the job beer and be safer at the rate for which
it was designed.
• USE RIGHT TOOL. Do not force tool or aachment to do a job for which it was
not designed.
• WEAR PROPER APPAREL. No loose clothing, gloves, rings, bracelets, or other
jewellery to get caught in moving pats. Non-slip footwear is recommended. Wear
protecve hair covering to contain long hair.
• SECURE WORK. Use clamps or a vise to hold work when praccal. It is safer than
using your hand and frees both hands to operate tool.
• DO NOT OVERREACH. Keep proper foong and balance at all mes.
• MAINTAIN TOOLS IN GOOD CONDITION. Keep tools sharp and clean for best and
safest performance. Follow instrucons for lubricang and changing accessories.
• DISCONNECT TOOLS before servicing and when changing accessories such as
blades, bits, cuers, etc.
• USE RECOMMENDED ACCESSORIES. The use of accessories and aachments
not recommended by the manufacturer may cause hazards or risk of Injury to
persons.
• REDUCE THE RISK OF UNINTENTIONAL STARTING. Make sure switch Is In 'OFF'
posion before plugging In power cord. In the event of a power failure, move
switch to the 'OFF' posion.
• NEVER STAND ON TOOL. Serious Injury could occur if the tool Is pped or If the
cung tool Is accidentally contacted.
• CHECK DAMAGED PARTS. Before further use of the tool, a guard or other part
that is damaged should be carefully checked to ensure that it will operate
properly and perform its intended funcon - check for alignment of moving
parts, binding of moving parts, breakage of parts, mounng, and any other
condions that may aect its operaon. A guard or other part that is damaged
should be properly replaced.
• DIRECTION OF FEED. Feed work Into a blade or cuer against the direcon of
rotaon of the blade or cuer only.
• NEVER LEAVE TOOL RUNNING UNATTENDED. TURN POWER OFF. Do not leave
tool unl comes to a complete stop.
• STAY ALERT; WATCH WHAT YOU ARE DOING, AND USE COMMON SENSE WHEN
OPERATING A POWER TOOL. DO NOT USE TOOL WHILE IVIED OR UNDER THE
INFLUENCE OF DRUGS, ALCOHOL, OR MEDICATION. A moment of Inaenon
while operang power tools may result In serious personal Injury.
• MAKE SURE TOOL IS DISCONNECTED FROM POWER SUPPLY while motor Is being
mounted, connected or reconnected.
• THE DUST GENERATED by certain woods and wood products can be injurious to
your health. Always operate machinery In well-venlated areas and provide for
proper dust removal. Use wood dust collecon systems whenever possible.
• WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING,
DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to
cause cancer, birth defects or other reproducve harm. Some examples of these
chemicals are: Lead from lead-based paints, crystalline silica from bricks and
cement and other masonry products, and arsenic and chromium from chemically
treated lumber.
Your risk from these exposures varies, depending on how oen you do this type of
work. To reduce your exposure to these chemicals: work in a well venlated area, and
work with approved safely equipment, such as those dust masks that are specially
designed to er out microscopic parcles.
• DO NOT OPERATE THE MACHINE unl it is assembled and sited according to the
instrucons.
• TAKE ADVICE FROM YOUR SUPERVISOR, instructor, or another qualied person If
you are not familiar with the operaon of this machine.
• FOLLOW ALL WIRING CODES and recommended electrical connecons.
• MAKE CERTAIN the machine Is fastened to a supporng surface to prevent it
from pping over during operaon.
• NEVER turn the morcer "ON" before clearing the table of all object (scrap
pieces, etc.).
• ALWAYS keep hands, ngers and hair away from the rotang bit.
• DO NOT aempt to machine material that does not have a at surface, unless a
suitable support Is used.
• ALWAYS posion hold-down directly over work-piece to prevent work-piece from
liing during operaon.
• ALWAYS support work-piece securely against fence to prevent rotaon.
• BE SURE drill bit is sharp, not damaged, and property secured in the chuck before
operaon.
• MAKE SURE chuck key is removed before starng machine.
• NEVER turn on the power with the drill bit or chisel contacng the worturnk-
piece.
• NEVER perform layout, assembly, or set-up work on the table while the morcer
is operang.
• ADJUST the depth stop to avoid drilling into the table.
• ALWAYS turn o the power before removing scrap pieces from the table
• SHUT-OFF The power, remove the drill bit and chisel, and clean the table before
leaving the machine.
• FOR YOUR OWN SAFETY - Don' t wear gloves when operang the machine.
• SHOULD any part of your tool be missing, damaged, or fail in any way, or any
electrical component fall to perform properly, shut o switch and remove plug
from power supply outlet. Replace missing, damaged, or failed parts before
resuming operaon.
• THE USE of aachments and accessories not recommended by SIP may result in
the risk of injuries.
• TURN THE MACHINE "OFF" AND DISCONNECT THE MACHINE from the power
source before installing or reng accessories, before adjusng or changing
setups, or when making repairs.
• TURN THE MACHINE "OFF" , disconnect the machine from the power source, and
clean the table/work area before leaving the machine.
• LOCK THE SWITCH IN THE "OFF" POSITION to prevent unauthorized use.
8
WARNING: Read these electrical safety instrucons thoroughly
before connecng the product to the mains supply.
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an
approved 13 amp plug, or a suitably fused isolator switch.
If the plug has to be changed because it is not suitable for your socket, or because
of damage, it must be removed and a replacement ed, following the wiring
instrucons shown below. The old plug must be discarded safely, as inseron into a
power socket could cause an electrical hazard.
WARNING: The wires in the power cable of this product are
coloured in accordance with the following code:
Blue = neutral / Brown = live / Yellow and Green = earth
If the colours of the wires in the power cable do not agree with the markings
on the plug:
• The BLUE wire must be connected to the terminal which is marked N or coloured
black.
• The BROWN wire must be connected to the terminal which is marked L or
coloured red.
• The YELLOW and GREEN wire must be connected to the terminal which is marked
E or or coloured green.
We strongly recommend that this machine is connected to the mains supply through
a Residual Current Device (RCD).
If you are not sure, consult a qualied electrician. DO NOT try to do any repairs.
9
NOTE: Always make sure the mains supply is of the correct voltage
and the correct fuse protecon is used. In the event of replacing the
fuse always replace the fuse with the same value as the original.
WARNING: Improper use of extension leads may cause inecient
operaon of the item which can result in overheang and motor
damage.
This item is covered by a 24 month parts and labour warranty covering failure due
to manufacturers defects. This does not cover failure due to misuse or operang the
item outside the scope of this manual - any claims deemed to be outside the scope
of the warranty may be subject to charges Including, but not limited to parts, labour
and carriage costs, failure to regularly clean your item will shorten its working life and
reduce performance.
Consumable items such as the chisels, drill bits are not covered by the warranty.
NOTE: Proof of purchase will be required before any warranty can be
honoured.
10
11
1
L - R Table adjustment handle
Chuck access cover
Front - Back Table adjustment knob
Depth stop guide
Fence clamp knob
Fixed fence
Chisel housing
Table
NVR Switch
Table stop
Operang handle
Base
Motor
NA.
3
4
8
9
10
11
13
01944
230 V - 50 Hz / 370 W
1/4" - 5/8" (6 - 16 mm)
180 mm x 157 mm
1400 rpm
130 mm
100 mm L to R / 40 mm Back to Front
50 mm
100 mm max.
80 mm
42 Kg
13
1. Insert the handle (B) through the hole (A).
2. Make sure it shows at least 5 mm through the boom end and screw the
retaining bolt.
Danger / Cauon: Do not connect the machine to the power supply
unl the machine is completely assembled and you have read and
understood the enre instrucon manual.
NOTE: If any parts are missing, please contact customer service.
Tighten the depth stop guides (A & C) in the posions desired. The chisel (B) will stop
at the desired posions in depth and height.
14
1. Loosen the lock screw shown in Fig.1.
2. In order to access the chuck, undo the lock screw of the plasc cover and pull
the release tab Fig.2.
3. Loosen the chuck with the chuck key provided with the machine.
4. Place the drill bit inside the chisel. Note: These items are sharp, wear safety
gloves when assembling.
5. Insert the chisel into the bush and the drill bit into the chuck together. Push the
chisel up as far as possible into the head. Tighten the lock screw just enough to
hold the chisel in place. Make sure you set the slot in the side of the chisel to
the le or right, NOT to the front or back. This will allow chips to escape when
cung morses. Push the drill bit up through the chisel as far as it will go.
Tighten the drill bit with the chuck key enough to hold it in place. Then lower
the chisel head using the handle. Set the "drill to chisel height" approximately
0.8mm to 1.6mm, depending on the type of wood being worked. See Fig.1. Re-
ghten the screw to hold the chisel in place.
6. Lock the drill bit in place with the chuck key. See Fig. 3.
7. Close the plasc cover of the chuck access and screw the lock screw.
Next set the chisel square to the back fence of the table. Use the operang handle
to lower the chisel down to the table. Adjust the table forward unl the back fence
touches the chisel. Check the back face of the chisel is square to the table fence and
adjust as necessary.
The fence can be moved in or out by loosening the hand-wheel, sliding the fence to
the desired posion and ghtening the hand-wheel. Fig. 5.
Dierent thicknesses of material can be accommodated by posioning the moving
fence in the threaded holes provided. Use the slots in the fence base for ne
adjustments. Fig. 6.
1. Slide the stop lever assembly on to the bar.
2. Place the bar into the hole and make sure the threaded hole aligns with the hole
of the bar. Fig.7.8. & 9.
3. Tighten the grub screw with the hex key provided. Fig.10.
18
1. Pull the handle to lower the machine head. Fig.11.
2. Li the handle to raise the machine head.
3. Changing the posion of the depth stop guides will allow you to restrict the
depth and height of the operaon. Fig.12.
NOTE: Before connecng the machine to the mains supply, make
sure all the screws and connecons have been ghtened.
1. Place the fence in the posion desired. It can be done loosening the screws and
placing them in a closer or further posion, depending on the thickness of your
piece.
2. Once it is allocated in the desired posion. Turn the knob clockwise to ght the
piece and have a safe operaon.
19
1. Turn the knob A for forward and backwards movement of the table.
2. Aach the lever B and turn it for Le & Right movement of the table.
B
When cung a slot morce it is important to start from the correct end of the work
piece. With the open side of the chisel set to the right - start the cut from the right
hand edge - or the same if cung from the le. As the cut progresses the open side
of the chisel will remain open into the hole already cut to aid chip clearance.
If dust extracon is to be used the dust throat should be posioned just above the
mber and close to the chisel for best results.
To begin the cut, press the green start buon and pull down on the operang handle.
For the inial cut, withdraw the chisel at 20mm depth. Now move the table to the
right by the width of the chisel and make a second cut to 20mm. Connue making a
series of shallow cuts unl the whole outline has been completed. Now go back to
the starng posion and make a second series of cuts deepening the morce by a
further 20mm. Connue in this fashion unl the morce is to the depth required.
If the morce now needs enlarging in width, use the handwheel to adjust the table
forwards or backwards and connue cung.
Table of contents
Other SIP Industrial Equipment manuals
