SIP 01456 User manual

01456
Spindle Moulder
with Tilting Shaft
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.

1
NOTE: The above specifications and the constructions were current at the time this manual was published, but
because of our policy of continuous improvement, we reserve the right to change specifications and the
constructions without notice and without incurring obligations.
SPECIFICATIONS
CONTENT
Motor power 230V~, 50Hz, 2800W
Motor speed R.P.M. 2800
Motor Protection Thermal link
Table size mm 640x710
Table height mm 900
Spindle diameter mm 30
Spindle travel mm 100
Table opening mm 200
O O
Table tilt -5 -+30
Table ring mm 200
Tool diameter Max. mm 200
Speed R.P.M. 1800/3000/6000/9000
Suction nozzle mm 100
Specification P1
Safety Instructions P2
Safety Instructions for Power Tools P2
Additional Safety Instructions for Spindle Moulder P2
Getting to Know Your Machine P4
Assembly P5
Unpacking P5
Installing the Work Stand P5
Installing the Machine Housing onto Work Stand P5
Installing the Cutting Tools P5
Installing the Safety Guard P5
Installing the Feeder Ass'y P6
Installing the Sliding Carriage (optional) P6
Installing the Mobile Wheel Kit (optional) P8
Adjustment & Operation P9
Speed Change P9
Adjust the Height of Spindle P9
Spindle Tilt Setting P9
Rotation P9
Fence Adjustment P10
Adjust the Feed Roller P10
Sanding P10
Wiring Diagram P11
Maintenance P11
Trouble Shooting P12
Diagram & Parts List P13

17. USE RECOMMENDED ACCESSORIES. Consult
SAFETY INSTRUCTIONS the owner's manual for recommended accessories.
The use of improper accessories may cause risk of
injury.
For Your Own Safety Read Instruction Manual
Before Operating This Equipment 18. CHECK DAMAGED PARTS. Before further use of
the tool, a guard or other part that is damaged should
Safety Instructions For Power Tools be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
1. KEEP GUARDS IN PLACE and in working order. breakage of parts, mounting, and any other
conditions that may affect its operation.Aguard or
2. REMOVE ADJUSTING KEYS AND WRENCHES. other part that is damaged should be properly
Form habit of checking to see that keys and adjusting repaired or replaced.
wrenches are removed from tool before turning on.
19. NEVER LEAVE TOOL RUNNING UNATTENDED.
3. KEEP WORK AREA CLEAN. Cluttered areas and TURN POWER OFF. Do not leave tool until it comes
benches invite accidents. to a complete stop.
4. NEVER USE IN DANGEROUS ENVIRONMENT. Do 20. NEVER USE UNDER THE INFLUENCE of alcohol
not use power tools in damp or wet locations, or or drugs, or when tired.
where any flammable or noxious fumes may exist.
Keep work area well lighted. 21. NEVER ALLOW UNSUPERVISED OR UNTRAINED
PERSONNEL TO OPERATE THE MACHINE. Make
5. KEEP CHILDREN AND VISITORS AWAY. All children sure any instructions you give in regards to the
and visitors should be kept a safe distance from work operation of the machine are approved, correct, safe,
area. and clearly understood.
6. MAKE WORKSHOP CHILD PROOF with padlocks,
master switches, or by removing starter keys.
7. NEVER FORCE TOOL. It will do the job better and Additional Safety Instructions For Spindle
safer at the rate for which it was designed. Moulder
8. USE RIGHT TOOL. Do not force tool or attachment to
do a job for which it was not designed. Like all power tools, there is danger associated with
spindle moulder. Accidents are frequently caused
9. USE PROPER EXTENSION CORD. Make sure your by lack of familiarity or failure to pay attention. Use
extension cord is in good condition. Conductor size this tool with respect and caution to lessen the
should be in accordance with the amperage rating possibility of operator injury. If normal safety
listed on the motor or tool nameplate. An undersized precautions are overlooked or ignored, serious
cord will cause a drop in line voltage resulting in loss personal injury may occur.
of power and overheating. Your extension cord must
also contain a ground wire and plug pin. Always
repair or replace extension cords if they become No list of safety guidelines can be complete. Every
damaged. shop environment is different. Always consider
safety first, as it applies to your individual working
10. WEAR PROPER APPAREL. Do not wear loose conditions. Use this and other machinery with
clothing, gloves, neckties, rings, bracelets, or other caution and respect. Failure to do so could result in
jewelry which may get caught in moving parts. Non- serious personal injury, damage to equipment or
slip footwear is recommended. Wear protective hair poor work results.
covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use face or 1. NEVER ALLOW YOUR HANDS to come within 12
dust mask if cutting operation is dusty. Everyday inches of the cutters. Never pass your hands directly
eyeglasses only have impact resistant lenses, they over or in front of the cutter.
are NOT safety glasses.
2. BLIND CUT WHENEVER POSSIBLE. This keeps the
12. SECURE WORK. Use clamps or a vise to hold work knives on the underside of the workpiece and
when practical. It is safer than using your hand and provides a distance guard for the operator.
frees both hands to operate tool.
3. WHEN SHAPING CONTOURED WORK and using a
13. NEVER OVERREACH. Keep proper footing and rub collar, NEVER start out at a corner. See the “Rub
balance at all times. Collar” instructions further on in the manual.
14. MAINTAIN TOOLS WITH CARE. Keep tools sharp 4. WITH THE MACHINE UNPLUGGED, always rotate
and clean for best and safest performance. Follow the spindle by hand with any new setup to ensure
instructions for lubricating and changing proper cutter clearance before starting the machine.
accessories.
5. DO NOT SHAPE STOCK SHORTER than 12 inches
15. DISCONNECT TOOLS before servicing and without special fixtures or jigs. Where practical,
changing accessories, such as blades, bits, cutters, shape longer stock and cut to size.
and the like.
6. NEVER ATTEMPT to remove too much material in
16. REDUCE THE RISK OF UNINTENTIONAL one pass. You are far more likely to enjoy safer and
STARTING. Make sure switch is in off position before higher quality results if you allow the cutter to remove
plugging in. material in multiple passes.
2

7. THE DANGER OF kickback is increased when the
stock has knots, holes, or foreign objects in it.
Warped stock should be run through a jointer before
attempting to run it through a shaper.
8. KEEP THE UNUSED PORTION of the cutter below
the table surface.
9. THE USE OF PUSH STICKS as safety devices in
some applications is smart; in others it can be quite
dangerous. If the push stick comes in contact with
the cutter on the end grain, it can fly out of your hand
like a bullet potentially causing serious injury. We
recommend using some type of fixture, jig, or hold-
down device as a safer alternative. Always use the
guard as described in the manual.
10. NEVER FORCE MATERIALS through the shaper.
Let the cutters do the work. Excessive force is likely
to result in poor cutting results and will cause
dangerous kickback conditions.
11. ALWAYS ensure that the cutters, fence, and spindle
elevator knob have been tightened properly before
beginning any operation.
12. ALWAYS feed the work toward the cutters in the
direction opposite of the cutter rotation. Also, using
and maintaining a sharp cutterhead will greatly
reduce the chance of kickback.
13. NEVER REACH BEHIND CUTTER to grab the
workpiece. Your hand may suddenly be pulled into
the cutter in the event of a kickback.
14. IF AT ANY TIME YOU ARE EXPERIENCING
DIFFICULTIES PERFORMING THE INTENDED
OPERATION, STOP USING THE SPINDLE
MOULDER! Then contact our service department or
ask a qualified expert how the operation should be
performed.
Working Clearances
Working clearances can be thought of as the distances
between machines and obstacles that allow safe
operation of every machine without limitation. Consider
existing and anticipated machine needs, size of
material to be processed through each machine, and
space for auxiliary stands and/or work tables. Also
consider the relative position of each machine to one
another for efficient material handling. Be sure to allow
yourself sufficient room to safely run your machines in
any foreseeable operation.
Lighting and Outlets
Lighting should be bright enough to eliminate shadow
and prevent eye strain. Electrical circuits should be
dedicated or large enough to handle combined motor
amp loads. Outlets should be located near each
machine so power or extension cords are not
obstructing high-traffic areas. Be sure to observe local
electrical codes for proper installation of new lighting,
outlets, or circuits.
Dust Collector
As a rule, this machine must be vacuumed during use. A
time relayed socket is available as an accessory. In
addition, the vacuum performance must be sufficient to
achieve the required negative pressures and a
maximum air speed of 20m/sec at the connector.
Read the manual before assembly and
operation. Become familiar with the
machine and it's operation before
beginning any work. Serious personal
injury may result if safety or operational
information is not understood or
SITE CONSIDERATIONS followed.
General Condition:
1.Electrical connection: Steady state voltage: 0.9-1.1
of nominal voltage.
Frequency: 0.99-1.01 of nominal frequency
continuously; 0.98-1.02 short time
2.Altitude are not exceeding 1000m,
O
Maximum ambient air temperature is +40 C,
minimum ambient air temperature is not less Than+5
OC,
Storage and transportation temperature range is -15
O O
C～+55 C.
The relative humidity does not exceed 50% at a
O
maximum temperature of +40 C, higher relative
humidity may be permitted at lower temperature
O
(e.g. 90%@ 20 C).
Floor Load
This machine represents a moderately large weight
load in a small footprint. Most commercial shop floors
will be adequate for the weight of the machine. Some
floors may require additional support. Contact an
architect or structural engineer if you have any question
about the ability of your floor to handle the weight.
3

GETTING TO KNOW YOUR MACHINE
1．Workstand 10．Safety guard
2．Machine housing 11．Dust outlet
3．Spindle height display 12．Feeder ass'y
4．Spindle tilt handwheel 13．Feed roller
5．Spindle speed display 14．Sliding bench (optional)
6．Reversing switch 15．Sliding carriage (optional)
7．Main switch(No-volt release) 16．Spindle height lock
8．Spindle tilt lock 17．Spindle height adjust handwheel
9．Table
4

ASSEMBLY
Unpacking
The spindle moulder is shipped from the manufacturer in a
carefully packed carton. If you discover the machine is
damaged, you will need to file a freight claim. Save the
containers and all packing materials If you need assistance
determining, please contact our Customer Service.
After all the parts have been removed from the carton, you
should have:
Spindle Moulder Machine Housing Ass'y
Workstand panel (4) Column (4) & hardware (1 bag)
Safety Guard Ass'y
Feeder Ass'y
Fence Extrusion (2)
Tools & Hardwares
Installing the Cutting Tools
Most of your spindle moulder has been assembled at the
factory, but some parts must be assembled or installed after
delivery. We have organized the assembly process into steps.
Install tool on the spindle as low as possible.
Please follow along in the order presented in this section. It should turn freely in the lowest spindle position. Make sure
that tool does not make contact with the table ring or fence
Installing the work stand extrusion when the spindle tilted.
1. Take 4 panels and 4 columns from main carton. Danger of personal injury!
2. Take the following hardware from the workstand hardware Form habit of turning tool by hand before switching machine on
bag. to be sure tool runs clear.
16-Hex head screw M8x20
32-8mm Flat washer 1. Lay the table ring flat into table plate.
16-Hex Nut The table ring, when mounted, should not stand out over the
table surface, in order to allow workpiece to be pushed
3. Assemble the work stand as shown in Figure 1.smoothly over the table surface. When doing milling work
with the raising mill, take the table ring out of the table part.
2. Position the moulding tool with the spindle ring onto the
spindle and secure the lock flange with Allen bolt M12x25.
See Figure 3.
Installing the machine housing onto work
stand 3. Adjust the moulding tool height on shaft, using other
thickness spindle ring or rings. The thickness of spindle ring
is 30, 25, 15, 10, 5, 2 & 1 mm.
Do not lift the machine housing without help.
This machine housing is over 70 Kg, customers should
seek assistance from staff to lift this item. Installing the Safety Guard
1. Place the machine housing over the thread holes on the
work stand. 1. Place the safety guard over the threaded holes on the table.
2. Loosen 2-Startype Screw to open the machine housing door 2. Insert the ratchet lever M8x150 with a 8mm large washer
and remove 6-Allen Bolt to the sidepanel. into the safety guard as shown in Figure 4, and thread the
ratchet lever clockwise to secure to the table.
3. Take the following hardware from the workstand hardware
bag. 3. Slide the fence extrusion onto the fence extrusion carriage,
4-Hex head screw M8x20 and secure it.
8-8mm Flat washer
4-Hex Nut 4. To align the fence extrusion, adjust one or both fence so they
are in close alignment. Check the alignment with a
4. Secure all screws as shown in Figure 2. straightedge as shown in Figure 5.
5

Adjust the scale mount
1. Release the 2x allen bolts M6x16 and shift the scale mount
to the left or to right make sure the pointer with the “0”
scale，then tighten the 2x allen bolts
2. Slide the guide rail (3) over the intermediate plates (2) and
tighten the thumbscrews .
3. Insert the folding stop (4) into the end stop and tighten
the T-screw.
Installing the feeder ass'y
1. Insert the feeder arm into feeder base and secure it with
startype screw M8x25.
2. Place the Feeder Ass'y and Anti-kickback Ass'y onto the
Feeder Arm and secure it.
Mounting bracket
Fit the two mounting brackets with two "I" shape insert block to
machine housing.
4 allen bolts M8x45
Installing the Sliding Carriage (optional)
Installing the sliding bench
1. Fit the scale mount (1) to the sliding bench.
2 allen bolts M6x16
2. Insert the intermediate plates (2) into the stop tube do not
tighten the screws.
2 washers 6mm
2 thumbscrew M6
3. Fit the stop tube on the sliding bench.
1 swing bolt
2 washers 8mm
1 Wave washer 8mm Mounting the sliding rail
1 hex nut M8
Insert the Sliding rail from above at a slight angle into the
The wave washer must be between the stop tube and the mounting brackets and tighten the wing nuts.
sliding bench.
6
Figure 7
Figure 8
Figure 9

3. Test and measure the parallel motion of the slide bench to
the cutting bench.
4. Measure in front and back positions.
5. If necessary, release 4x allen bolts on two mounting bracket
to measure the parallel motion.
6. Tighten the hexagon nuts (5).
Mounting the sliding bench
1. To mount the sliding bench on the sliding rail, unlock the
stop bolt.
2. Pull out the ball knob and turn clockwise or counter-
clockwise (1/4turn).
3. Slide the bench on the sliding rail, ensuring that the bearings
line up correctly and the bench runs smoothly. Workpiece stop angle correction
4. Turn the ball knob until it is in its original position to prevent
the bench from falling from the rail unintentionally.
O
1. After making a test cut, check the 90 angle.
2. Loosen the cap nut to make the necessary correction.
3. Swing back the stop tube a short way and set the
adjusting nut (8) by hand.
4. Tighten the cap nut again and make a further test cut.
5. Repeat the correction procedure if necessary.
Adjusting the sliding bench
Adjust the sliding table so that it is flush with the main table of
the machine. To assist with the alignment, use the main rip-
fence (inverted) from the machine. Lay it across both the
sliding table and fixed main table and adjust the height / angle
until both are completely level.
The adjustment is made at the left and right rail fixture.
1. Loosen the two hexagon screw (5) slightly. Installing the stop rail.
2. By alternately adjusting the height adjustment screw (6) and
the angle adjustment screw (7),align the slide bench so that The stop rail is 1500 mm long when it is fully pulled out.
it is at the same height as the cutting table.
1. Adjust the folding stop on the end stop to exactly 900
mm. when pulling out the end stop rail, read the
length on the scale.
2.Fine adjustment can be made using the knurled screw
on the folding stop.
1 devision=0.1mm
1 turn = 2mm
3. Tighten the screw (9) onto the axle of the stop lever
(10) so that the stop lever does not drop down when
folding.
Figure 12
7
Figure 13
Figure 14

2. Attach the workpiece clamp (12) to the pulling rod;
the desired height can be held with the handwheel.
Mounting the angle stop
O O 3. Place the workpiece on the bench.
The angle stop can swing to 45 either side of 0 .
4. Apply the workpiece clamp with the lever in
1. Loosen the handwheel on the swing segment, pull out position(a) to the pulling rod.
and turn the ball knob (situated under the slide
bench) 1/4 of a turn, the desired angle between 45°
O5. Loosen the height adjusting handwheel and place the
either side of 0 can now be set, re-tighten the lever in position (b), lower the clamp until it is
handwheel to lock in place. touching the workpiece, retighten the handwheel to
secure.
2. When swinging the angle stop back, lock the ball
knob back into place below the slide bench by hand. 6. To clamp the workpiece, move the clamp into
position(c).
Installing the sliding rail
The sliding rail can be moved forwards or backwards.
1. Loosen the 2 wing nuts on the left and right hand
mounting brackets. Installing Mobile Wheel Kit (optional)
2. Depending on the size of the workpiece, move the
sliding rail into the ideal position relative to the main 1. Place “U” Shape Bracket(1) onto Front Wheel Kit Ass'y(2).
table, then tighten both sets of wing nuts.
2. Insert Hex Head Screw M10x70(3), secure Front Wheel Kit
and Sleeve(4) to work stand.
3. Insert Special Thread(5) and secure Front wheel kit.
4. Secure Rear Castor Frame(7) to workstand with two Hex
Head Screw M10x20 & washer.
5. When move the machine adjust the Allen Bolt M12x50,and
raise the machine about 5mm above floor. Insert the Rear
Castor Ass'y, push the lever down and pull the machine
round the workshop.
Installing the Workpiece Clamp
Safe workpiece guidance is a precondition for accurate
and safe working. It is therefore important that you use
the workpiece correctly.
1. Fit the pulling rod into its locating hole situated on the
stop tube (see Figure 18). Hold the rod in place with
the supplied counter sunk screw (from below).
Figure 15
8
Figure 18

ADJUSTMENT & OPERATION Adjust the height of Spindle
Read the manual before assembly and operation. Become Perform this adjustment must switch off the power first.
familiar with the machine and its operation before
beginning any work. Serious personal injury may result if 1. Loosen the Spindle Height Lock(a).
safety or operational information is not understood or
followed. 2. Make sure the fence & table cleaning with milling tool.
3. Move the spindle up or down with the Spindle Height
Speed Changes Handwheel(b) until the desired position is obtained.
To raise = turn counter-clockwise
To lower = turn clockwise
This machine is equipped with a V-belt drive system Any height adjustment can be read directly from the scale(c).
that controls the speeds. To change spindle speeds:
4. Secure the Spindle Height Lock(a).
1. Unplug the machine.
2. Loosen the two Startype Screw M6x30, open the
Machine Housing Door.
3. Loosen the Allen Bolt M12x40(a) with allen wrench,
Pull the Motor Tension Lever(b) out.
Spindle Tilt Setting
Perform this adjustment must switch off the power first.
Using the Tilting table ring!
4. Select the desired speed. There are four speeds:
1800 R.P.M., 3000 R.P.M., 6000 R.P.M., 9,000 R.P.M. 1. Loosen the Spindle Bevel Lock(a).
Figure 22 shows the belt positions for each available To loosen = turn counter-clockwise
speed. To lock = turn clockwise
2. Make sure the fence & table cleaning with milling tool. And
secure that if the spindle tilted, it can touch the fence and
table ring.
3. Move the spindle bevel with the Spindle Tilting Hand-
wheel(b) until the desired position is obtained.
To right = turn leftside
To left = turn rightside
3. Secure the Spindle tilt Lock(a).
5. Align the belt along the appropriate pulley grooves.
6. Push up the Motor Tesion Lever(b) and tighten the
Allen Bolt(a).
When the belt is properly tensioned, there should be
approximately 1/4" of deflection in the center of the belt
when you press it with moderate pressure.
7. Tighten all the adjusting bolts.
8. Spin the pulley by hand to ensure proper tracking.
Rotation
9. Close the door.
Always check the direction of cutter rotation before
beginning any milling operation.
9
Figure 23
Figure 21

Adjust the Feed Roller
This machine was designed to be started and
stopped with the Main Switch(No-volt Release)not
the reversing switch. Perform this adjustment must switch off the power first.
This machine is equipped with a FORWARD/REVERSE
switch as shown in Figure 25. In many instances, you 1. Loosen the Startype Screw M8x25(a) and (b).
will find it necessary to flip the cutter over and reverse 2. Move the Feed Roller above the workpiece.
cutter rotation.
3. Lock the Startype Screw M8x25(a), make feed roller on the
Whenever possible, mount the cutter so the board is center line of workpiece.
milled on the bottom side. This method does a better job
and is safer for the operator. 4. Lock the Startype Screw M8x25(b), make secure the roller
as close as possible to workpiece.
5. Loosen the Startype Screw M8x25(c) and (d).
Before turning the Reversing Switch, must switch
off the power and wait the machine standstill. 6. Move the Anti-kickback Plate near the workpiece.
7. Lock the Startype Screw M8x25(c), make the Plate is 5-
The reversing switch turns left, the machine is running 10mm above work table.
at forward mode, the spindle is running counter-
clockwise. 8. Lock the Startype Screw M8x25(d), make the plate is as
close as possible to the work piece.
The reversing switch turns right, the machine is running
at reverse mode, the spindle is running clockwise.
Sanding
Fence adjustment
The fence is a two-piece adjusting system. Each fence
is independently adjustable to compensate for different Perform this operation must at 1800 R.P.M. spindle speed.
cutting thicknesses and special milling applications. To
adjust the fence: 1. Remove the Safer Guard and Feed Roller.
1. Loosen the fence lock handle (Startype Screw M8x25 2. Adjust the spindle to Highest Position.
a). 3. Insert the Sanding Drum(a) to Sanding Sleeve(b).
2. Turn the Spindle Latch Setting Knob(b) until the 4. Place Support Disc(c) and Sanding Drum Ass'y onto spindle.
fence is set to the desired position.
5. Secure the Lock Flange(d) with Allen Bolt M12x25(e).
3. Tighten the fence lock handle.
Perform this adjustment, must wait the spindle and milling
tool standstill.
Figure 28
10
Figure 27

WIRING DIAGRAM
The electric motor is designed for the S6 40%
operating mode. And the motor is equipped with a
thermal protect system, therefore the motor is
automatically switched off in the event of an overload.
The motor can be switched on again after a cooling
down period that can vary. Electrical connection
cables often suffer insulation damage. Such defective
electrcal connection cable must not be used as the
insulation damaged makes them extremely
hazardous.
Check electrical connection cables regularlly for damage.
Make sure the cable is disconnected from the mains when
checking.
Electrical connection cables must comply with the
regulations applicable in your country.
MAINTENANCE
Always siwtch off the motor and disconeect the plug
from the power supply prior to any maintenance and
cleaning work.
Before operation:
1. Visual check distance which is 3-8mm,between the
milling tool and fence extrusion, between milling tool
and table.
2. Visual check of power cable and power cable plug for
damage; if necessary have damage parts replaced by a
qualified electrician.
General maintenance:
Check for the following conditions and repair or replace
when necessary.
1. Loose mounting bolts.
2. Worn switch.
3. Worn or damaged cords and plugs.
4. Damaged V-belt.
5. Any other condition that could hamper the safe
operation of this machine.
Table
Tables can be kept rust-free with regular applications of
light grease.
Lubrication
The only parts on this machine that require periodic
lubrication are the ways where the cartridge slide rides on
the machine housing and where the worm gear and
bushing are located. Use a light grease or anti-seizing
compound on the ways and worm gear, and give the shaft
mount a shot of light oil.
V-Belt
Avoid getting grease or oil on the V-belt or pulleys. Check
the V-belt, as part of a monthly inspection for proper
tension and belt condition.
Cracking and glazing could result in belt failure. Replace
the belt if such conditions appear.
Schedule
Regularly blow out air vents with compressed air and
keep the exhaust port clear. Always wear a dust mask
during this operation.
For every 1 hour of use, clean and wipe down with light
grease:
Table and miter gauge slide
Fence faces
For every 5 hours of use, clean and oil:
Spindle column and cartridge
Offset adjustment mechanisms on fence
All worm drive and other gears
Once a year, replace the V-belt.
11

TROUBLE SHOOTING
Before carrying out any fault service or maintenance work always:
1. Switch machine OFF
2. Unplug power cable
3. Wait for spindle moulder to come to standstill.
Motor is slow or weak
Motor overheats.
When milling, the cut burns the work-
piece, or stalls the motor.
Height Handles are hard to turn.
Spindle moulder vibrates excessively.
Spindle moulder does not start.
Power Switch does not operate.
Fuses or circuit breakers open
frequently.
Motor stalls, blows fuses, or trips
circuit breakers.
Spindle moulder is noisy when
running.
Request a voltage check from local power
company.
Have the Motor checked / repaired.
Have the Power Switch replaced.
Do not use other appliances or electrically
powered equipment on the same circuit when
using the Table Saw.
Request a voltage check from the local power
company.
Replace the milling tool.
Sharpen or replace the milling tool.
Replace the work-piece.
Clean and lubricate the mechanisms inside the
base.
Readjust the Leveling Feet.
Replace the V-belt.
Replace the milling tool.
Tighten all Hardware.
Plug in Motor Cord to volt electrical outlet.
Replace circuit fuse.
Reset circuit breaker.
Have the Motor Cord or Switch replaced.
Have the Power Switch replaced.
Request a voltage check from the local power
company.
Have the Capacitor replaced.
Have the wiring connections checked /
repaired.
Feed work-piece more slowly.
Replace fuses or circuit breakers.
Replace the milling tool.
Have the Power Switch replaced.
Request a voltage check from the local power
company.
Replace the milling tool.
Replace fuses or circuit breakers.
Feed work-piece more slowly.
Have the Motor checked/repaired
Voltage from source is low.
Windings are burned out or open.
Power Switch is defective.
Circuit is overloaded with appliances，
lights, or other electrically powered
equipment.
Motor is overloaded.
Dull milling tool.
Milling tool is dull.
Work-piece is warped.
Dust has collected on the mechanisms
inside the base.
Floor surface is uneven.
V-belt is damaged.
Milling tool is damaged.
Loose bolt, Screws, Nuts.
Motor Cord is not plugged in.
Circuit fuse is blown.
Circuit breaker is tripped.
Motor Cord or Switch is damaged.
Power Switch contacts are burned out.
Capacitor is defective.
Wiring connections are loose or damaged.
Motor is overloaded.
Fuses or circuit breakers are wrong size or
defective.
Dull milling tool.
Power Switch is defective.
Motor is overloaded.
Dull milling tool.
Fuses or circuit breakers are wrong size or
defective.
Feeding work-piece too rapidly.
Motor is loose or defective.
Trouble Shooting Guide
Problem Cause Solution
Warning: To prevent personal injury and/or damage to the spindle moulder, maintenance and repairs should be done only
by a qualified technician.
12

No. DESCRIPTION No. DESCRIPTION
B-1 Table B-28 Insert, feed arm
B-2 Table ring 200mm for tilt B-29 Ratchet lever
B-3 Table ring 110/80mm B-30 Flat washer 8mm
B-4 Table ring 150/110mm B-31 Spring washer 8mm
B-5 Table ring 200/150mm B-32 Allen bolt M8x25
B-6 End cap, fence B-33 End cap,feeder arm
B-7 Carriage bolt, M8x40 B-34 Feed arm
B-8 Guide, bolt B-35 Block, feeder joint
B-9 Fence extrusion B-36 Feeder joint
B-10 Countrsunk head screw M8x20 B-37 Rod, roller
B-11 Fence extrusion carriage B-38 Rod, roller
B-12 Startype nut B-39 Plate, anti-kickback
B-13 Safety guard B-40 Pin, roller
B-14 Starknob M8x25 B-41 Spring washer 8mm
B-15 Ratchet lever M8x150 B-42 Hex nut M8
B-16 Lock spacer B-43 Roller frame
B-17 Dust outlet B-44 Roller house
B-18 Cross recessed pan head screw M5x12 B-45 Hex head screw M6x35
B-19 Lock piece, handle B-46 Plate spring
B-20 Guide spindle, spindle latch B-47 Lock nut M6
B-21 Hex nut M5 B-48 Spring
B-22 Setting knob, spindle latch B-49 Roller
B-23 Large washer B-50 Bolt
B-24 Cover, safer guard B-51 Socket screw
B-25 Allen bolt M8x16 B-52 Circle ring
B-26 Feeder base B-53 Block, fence extrusion
B-27 Block, feeder base
Parts list of diagram B
DIAGRAM & PARTS LIST
NOTE: The above specifications and the constructions were current at the time this manual was published, but
because of our policy of continuous improvement, we reserve the right to change specifications and the
constructions without notice and without incurring obligations.
No. DESCRIPTION No. DESCRIPTION
A-1 Spindle shaft A-12 Allen wrench 10mm
A-2 Spindle ring F50x30x30mm A-13 Allen bolt M8 x16
A-3 Spindle ring F50x30x15mm A-14 Spindle ring F50x30x25mm
A-4 Not supplied A-15 Spindle ring F50x30x10mm
A-5 Not supplied A-16 Spindle ring F50x30x5mm
A-6 Not supplied A-17 Spindle ring F50x30x2mm
A-7 Not supplied A-18 Spindle ring F50x30x1mm
A-8 Not supplied A-19 Washer-Sanding drum
A-9 Lock flange A-20 Sanding drum
A-10 Allen bolt M12x25 A-21 Sanding paper
A-11 Wrench 45mm
Parts list of diagram A
13

No. DESCRIPTION No. DESCRIPTION
C-1 Swivel, turnion C-57 Lock nut M10
C-2 Spring washer 10mm C-58 Motor
C-3 Allen bolt M10x30 C-59 Flat washer 12mm
C-4 Support, swivel turnion C-60 Spring washer 12mm
C-5 Hex head bolt M10x30 C-61 Allen bolt M12x30
C-6 Allen bolt M10x40 C-62 Thread, joint
C-7 Swivel guide C-63 Joint, motor tension
C-8 Spring C-64 Lock nut M10
C-9 Swivel head C-65 Guide bar
C-10 Scale wire mount C-66 End stop, guide
C-11 Countersunk head screw M4x6 C-67 Allen bolt M10x15
C-12 Spring washer 8mm C-68 Cross recessed pan head screw M4x12
C-13 Allen bolt M8x25 C-69 Lock lever, rise
C-14 Circle ring 15mm C-70 Spring, lock lever
C-15 Flat key 5x5x14 C-71 Pear plate, lock lever
C-16 Swivel rod C-72 Cross recessed pan head screw M4x6
C-17 Nut, swivel rod C-73 Flat washer 4mm,Tilt locking block
C-18 Joint, swivel rod C-74 Pointer
C-19 Cup, Spindle guide tube C-75 Allen bolt M6x25
C-20 Allen bolt M4x16 C-76 Bushing, pointer
C-21 Spring washer 4mm C-77 Bracket, pointer
C-22 Ball bearing 80106 C-78 Housing, rise shaft
C-23 Spindle guide tube C-79 Rise shaft
C-24 Allen bolt M6x12 C-80 Rising spindle
C-25 Large washer 6mm C-81 Flat key 6x6x14
C-26 Cone gear C-82 Carrier, rise gear
C-27 Thrust bearing 8102 C-83 Worm
C-28 Gear base C-84 Bushing, worm
C-29 Circle 24mm C-85 Ball bearing 80202
C-30 Hex head screw M8x20 C-86 Roll pin 4x20
C-31 Flat washer 8mm C-87 Gear-helical
C-32 Countersunk head screw M5x12 C-88 Ball bearing 8105
C-33 Large washer 6mm C-89 Bushing, spindle
C-34 Wheel-handle C-90 Special washer
C-35 Mount, wheel-handle C-91 Thin hex nut M20
C-36 Pin, cone gear C-92 Allen bolt M10x22mm
C-37 Flat key 4x4x12 C-93 Tilt locking lever
C-38 Spindle shaft C-94 Washer 10mm
C-39 Flat key 8x8x25 C-95 Plate, Locking handle
C-40 Lock nut M30 C-96 Locking nut
C-41 Set screw M6x8 C-97 Socket screw M6x10mm
C-42 Spindle pulley C-98 Allen bolt M10x15mm
C-43 Large washer 10mm C-99 Support bracket
C-44 Allen bolt M10x20 C-100 Nut M8
C-45 Allen bolt M12x40 C-101 Bolt
C-46 Hex nut m16 C-102 Allen boltM6x12mm
C-47 Flat washer 16mm C-104 Washer M6
C-48 Mount, motor C-105 Allen bolt M6x12mm
C-49 Special nut, 24mm C-106 Block
C-50 Hex head screw M12x40 C-107 Teeth belt
C-51 Motor pulley C-108 Mounting bracket
C-52 Flat key 8x8x40 C-109 Pan head screw M5x16mm
C-53 Joint, tension C-110 Tap screw M3.5x10mm
C-54 Hex nut M10 C-111 Mounting cover
C-55 Thread, tension
C-56 Lever, tension
Parts list of diagram C
14

No. DESCRIPTION No. DESCRIPTION
D-1 Hex nut M10 D-25 Nut scale
D-2 Set screw M10x70 D-26 Hex nut M4
D-3 Flat washer 6mm D-27 Wire scale
D-4 Allen bolt M6x30 D-28 Wire holder
D-5 Left panel, machine housing D-29 Pan head tapping screw M4x30
D-6 Left frame, machine housing D-30 Front panel, machine housing
D-7 Hex Nut M8 D-31 Cross recessed tapping screw M4x10
D-8 Washer M8 D-32 View glass
D-9 Allen bolt M8x20mm D-33 Cross recessed pan head screw M4x10
D-10 Rear panel, machine housing D-34 Column A
D-11 Right frame, machine housing D-35 Side panel,workstand
D-12 Open door, machine housing D-36 Column B
D-13 Startype screw M6x30 D-37 Side panel,workstand
D-14 Box, switch D-38 Column C
D-15 Display ass'y D-39 Column D
D-16 Seal D-40 Washer M4
D-17 Panel, switch D-41 Micro-switch
D-18 Turning switch D-42 Nut M5
D-19 Cross recessed sunk head screw M4x10 D-43 Nut M4
D-20 Main switch (No volt release) D-44 Pan head screw M4x30mm
D-21 Pan head tapping screw M4x10 D-45 Pan head screw M5x10mm
D-22 Scale holder D-46 Plastic block
D-23 Spring D-47 Mounting plate, micro switch
D-24 Scale
Parts list of diagram D
No. DESCRIPTION No. DESCRIPTION
E-1 Allen screw M8x20 E-15 Wing nut M8
E-2 Flat washer 8mm E-16 Guide carriage -left
E-3 Flat washer 8mm E-17 Guide carriage -right
E-4 Mounting bracket E-18 Allen bolt M8x25mm
E-5 Nut M8 E-19 Nut M6
E-6 Bushing,mounting bracket E-20 Bolt guide
E-7 Allen bolt M8x50mm E-21 Carriage bolt M8X30
E-8 Adjusting nut E-22 Allen bolt M6x20mm
E-9 Guide holder -right E-23 Steel rod, sliding rail
E-10 Guide holder -left E-24 Sliding rail
E-11 Washer M8 E-25 End cap, sliding rail
E-26 Allen screw M8x20
E-12 Allen bolt M8x20mm E-27 Rubber bushing
E-13 Washer M6
E-14 Allen bolt M6x65mm
Parts list of diagram E (optional SIP item no.: 01457)
15

No. DESCRIPTION No. DESCRIPTION
F-1 Flower handle F-44 U' shape steel plate
F-2 Workpiece clamp F-45 Cap nut M8
F-3 Circle ring F-46 Handle
F-4 Pin F-47 Flat washer 8mm
F-5 Cam F-48 Nut M5
F-6 Lever F-49 Pan head screw M5x20mm
F-7 Plastic knob F-50 Guage, sliding table
F-8 Circle ring F-51 End plate, sliding bench
F-9 Holder rod F-52 Taping screw 3.5x13 E-19 Scale mount
F-10 Spring F-53 Locking pin
F-11 Holder F-54 Spring, Locking pin
F-12 Countersunk head screw M6x16 F-55 Sleeve, Locking pin
F-56 Sliding bench
F-13 Ratchet lever M6 F-57 Intermediate plate -short
F-14 Washer 8mm F-58 Intermediate plate -long
F-15 Spring F-59 Intermediate plate- guage
F-16 Adjusting wheel F-60 Pan head screw-M6x12mm
F-17 Mounting plate, micro-adjustment F-61 Scale, guage
F-18 Bolt guide F-62 Guage base
F-19 Working stop F-63 Allen bolt M6x16
F-20 Carriage bolt M6x36 F-64 support plate, locking pin
F-21 End stop F-65 Roll pin
F-22 Pan head tap screw ST3.5X10mm F-66 Ball knob
F-23 Scale F-67 Spring
F-24 Sliding rail F-68 Carriage bolt M8x90mm
F-25 Intermediate plate F-69 Mounting bracket
F-26 Thumbscrew M8x20 F-70 Hexagon head screw M6x20
F-27 End cap,fence F-71 Serrated washer 6mm
F-28 Scale F-72 Domant socket screw
F-29 Fence, sliding table F-73 self-locking nut
F-30 Bushing F-74 Shaft
F-31 Pan head screw M5x5mm F-75 Domant socket screw
F-32 Taping screw 4x13 F-76 Bearing 80100
F-33 Carriage bolt M6x50 F-77 spacer
F-34 Bolt guide F-78 upper -Roller seat
F-35 Allen bolt M8x25mm F-79 self-locking nut
F-36 Swing bolt F-80 Lower roller seat
F-37 Pulling rod F-81 U bracket
F-38 Steel tube, fence F-82 Hexagon head screw
F-39 End cap F-83 teeth washer
F-40 Washer 6 mm F-84 bolt M6x20mm
F-41 Wing nut M6 F-85 scale
F-42 Nut M8
F-43 Allen bolt M8X12mm
Parts list of diagram F (optional SIP item no.: 01457)
16

Diagram A
17

Diagram B
18

Diagram C
19
