Sirius Satellite Radio Streamer GTR SIR-GTRH1 User manual

SIR-GTRH1 Home Installation Kit
Installation Guide

Streamer GTR SIR-GTRH1 Home Kit Installation Guide
2
Box Contents:
When you unpack your SIR-GTRH1 Home Installation Kit, it should include everything as shown below:
Home Stand
Indoor/Outdoor
Windowsill Antenna
AC Power Adapter
Audio Cable
If anything is missing or damaged, or if your SIR-GTRH1 fails to operate, notify your Streamer GTR dealer
immediately. It is recommended that you keep the original packaging in case you need to ship your
SIR-GTRH1 in the future.

Streamer GTR SIR-GTRH1 Home Kit Installation Guide 3
Safety Precautions
Caution
Take the following precautions to keep the Home Installation Kit components in proper working order:
• Installation must be performed according to this installation guide. Brix Labs is not responsible for issues
arising from installations not performed according to the procedures in this installation guide.
• Use only the included AC power supply.
• Do not install the Home Installation Kit components where they will be exposed to high levels of humidity,
moisture, or dust.
NOTE: Use of the included windowsill antenna inside a home requires placement at a North, Northwest or
Northeast facing window (depending on where you live). If a proper window location is not available, the
antenna must be placed outside the home, away from any overhead obstructions which may block the view
of the sky in the above mentioned directions. Follow the directions for proper placement of the antenna
carefully.
Warranty Support: 1-800-848-6560
Technical Support: 1-866-253-7027
!

Streamer GTR SIR-GTRH1 Home Kit Installation Guide
4
Installing the SIR-GTRH1 Home Installation Kit
Placing the Receiver in the Home Stand: Place
the Receiver into the home stand by first placing the
bottom of the Receiver into the tabs at the bottom
of the stand (1), and then pivoting the top of the
Receiver into the stand until it snaps into place (2).
1
2
Audio Connection: If you will be connecting
the Streamer GTR Receiver to your home
entertainment system, plug the mini connector of
the audio cable into the AUDIO OUT connector of
A
NTENNA
POWER
AUDIO OUT
the Receiver. Connect the audio cable’s white
RCA-type connector to your home entertainment
system’s left channel stereo input. Connect the
red connector to the right stereo input. Alternately,
you may use the FM transmitter feature of the

Streamer GTR SIR-GTRH1 Home Kit Installation Guide 5
Receiver to transmit to the FM Radio of your home
entertainment system. Consult the user guide of
the Receiver for instructions on how to use the FM
transmitter feature.
AC Power Connection: Plug the AC Power
Adapter mini connector into the POWER connector
of the Receiver. Plug the AC Adapter into a suitable
outlet.
Antenna Connection: Plug the antenna connector
into the ANTENNA connector of the Receiver,
pushing firmly until the connector is fully seated.
Antenna Placement: Proper installation of the
windowsill antenna is important for consistent
satellite signal reception. The SIRIUS satellites
follow a fixed orbit over North America, and
depending upon your location in North America, the
antenna needs to be aimed in the general direction
of the satellites. Use the map as a general guideline
for direction, aiming the antenna as straight up as
possible, while facing it toward the X shown on the
map, which represents the approximate location
of the SIRIUS satellites over North America. Make
sure the windowsill you choose for the antenna
has a clear line of sight to the sky, without any
obstructions such as an extended roof-line, a
soffit, an extended window frame, trees, bushes,
buildings, etc., blocking the view of the sky. If
you do not have a windowsill facing the correct
direction, or do not have an unobstructed view of
the sky, you can locate the antenna outside the
home in a more suitable location. It is waterproof.
In major US cities, you may be able to receive the
signal from the SIRIUS ground repeaters, which
could allow you to place the antenna away from a
window if the signal is strong enough.
From the following map, locate the number
designation of the area in which you live and
consult the key which follows for the direction in
which to aim the antenna.

Streamer GTR SIR-GTRH1 Home Kit Installation Guide
6
1
2
3
4
5
X
Map Area 1: Aim the antenna to face East,
Northeast or Southeast, towards the X.
Map Area 2: Aim the antenna to face North or
Northeast, towards the X.
Map Area 3: Aim the antenna to face North or
Northwest, towards the X.
Map Area 4: Aim the antenna to face West,
Northwest or Southwest, towards the X.
Map Area 5: Aim the antenna to face straight up.
When you have installed the antenna in a suitable
location, check the signal strength display of the
Receiver to verify that you are receiving a suitable
signal. (Consult the user guide of your Receiver for
instructions on how to access the signal strength
display.)

Streamer GTR SIR-GTRH1 Home Kit Installation Guide 7
12 MONTH LIMITED WARRANTY
Brix Labs dba Pana-Pacific/American Wireless (the “Company”) warrants to the original retail purchaser of this product that should this
product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from
the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company’s option)
without charge for parts and repair labor. To obtain repair or replacement within the terms of this Warranty, the product is to be delivered
with proof of warranty coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to the location shown below
under WARRANTY RETURN.
This Warranty does not extend to the elimination of externally generated static or noise, to correction of antenna problems, to costs
incurred for installation, removal or reinstallation of the product, or to damage to tapes, compact discs, speakers, accessories, or
vehicle electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion of the Company, has suffered or been damaged
through alteration, improper installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial
number/bar code label(s). THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR
OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE
PRICE PAID BY PURCHASER FOR THE PRODUCT. This warranty is only for this specified model and not for any other model of
Sirius satellite radio.
WARRANTY RETURN: To obtain repair or replacement within the terms of this Warranty, please return product to an authorized
Streamer GTR retailer or call Warranty Support at 1-800-848-6560; proof of purchase and description of defect are required. Products
to be returned to an approved warranty station must be shipped freight prepaid.

© 2005 Brix Labs
Brix Labs
541 Division Street
Campbell, CA 95008
[phone]
SIR-GTRH1 (Rev. 1, Aug 2005)
