Sirman APOLLO STANDARD User guide

12
CHAP. 7 - MAINTENANCE
7.1 - GENERALITIES
Before servicing the appliance you must disconnect the electricity supply plug
isolating the appliance from the main power source.
7.2 - FOOT SUPPORTS
In time the foot supports can detriorate loosing their elastic properties causing
instability. If this is the case replace them.
7.3 - POWER SUPPLY LINE
Periodically check wear in the power cable and if necessary contact the
“SERVICE CENTRE” for a replacement.
CHAP. 8 - SCRAPPING
8.1 - OUT OF SERVICE
If the appliance for some reason is to be put out of service, make sure it can no
longer be used: disconnect and remove all electrical connections.
8.2 - SCRAPPING
Once the appliance is out of service it can be scrapped. Contact a specialised
company to scrap it conforming to the materials used for manufacturing the
various components. (refer to chap.1 para. 3.2).
SERVICE CENTRE
AUTHORISED DEALER
1
USE AND MAINTENANCE INSTRUCTION MANUAL
CITRUS FRUIT-SQUEEZER

2
INTRODUCTION
• This instruction manual gives the customer all the necessary information
about the appliance and the manufacturing standards applied, as well as all
instructions for use and maintenance so that the appliance can be used
correctly maintaining its efficiency in time.
• This instruction manual is for the end user and for service personnel.
INDEX
CHAP. 1 - INFORMATION ABOUT THE APPLIANCE pag. 4
1.1 - GENERAL WARNINGS
1.2 - SAFETY FEATURES INSTALLED
1.2.1 - mechanical safety protections
1.2.2 - electrical safety protections
1.3 - APPLIANCE DESCRIPTION
1.3.1 - general description
1.3.2 - constructive characteristics
1.3.3 - appliance elements
CHAP. 2 - TECHNICAL DATA pag. 6
2.1 - OVERALL DIMENSIONS, WEIGHT, CHARACTERISTICS ...
CHAP. 3 - CONSIGNING THE APPLIANCE pag. 7
3.1 - TRANSPORTING THE APPLIANCE
3.2 - CHECKING PACKAGING UPON CONSIGNMENT
3.3 - DISPOSING OF PACKAGING
CHAP. 4 - INSTALLING THE APPLIANCE pag. 8
4.1 - APPLIANCE LOCATION
4.2 - CONNECTING TO ELECTRICITY SUPPLY
4.3 - WIRING DIAGRAM
4.4 - FUNCTIONAL CHECK
CHAP. 5 - USING THE APPLIANCE pag. 9
5.1 - CONTROLS
5.2 - USING THE APPLIANCE
CHAP. 6 - REGULAR CLEANING pag. 11
6.1 - GENERALITIES
11
FIG.n°8 - Cleaning the components
CHAP. 6 - REGULAR CLEANING
6.1 - GENERALITIES
• the appliance must be cleaned at least once a day or if necessary more than
once.
• scrupulously clean all the various components of the fruit-squeezer whether
they come in direct contact with the food product or not.
• never clean the fruit-squeezer with a pressurised water-jet or industrial
cleaner, brushes or any other type of cleaning utensil that could damage the
surface of the appliance. Use water and a neutral detergent.
Before cleaning you must:
a) remove the electricity supply plug isolating the appliance from the main
power circuit.
b) switch the on/off switch (ref.1 FIG. n°6) to “0”;
c) turn the knob (ref.2 FIG. n°6) to the minimum speed (only for models VV).
6.2 - PROCEDURE TO FOLLOW FOR CLEANING THE APPLIANCE
6.2.1 - cleaning the squeezer and juice container
To clean these two items proceed as follows:
a) carefully remove the squeezer from the main structure;
b) now remove the juice container.
Once these components have been removed wash them using warm water and a
neutal detergent.
6.2.2 - general cleaning
N.B.: disconnect the electricity supply
To clean the main structure use neutral detergent and a damp cloth and remember
to frequently rinse with clean water. Once all components are washed, dry them
well.

10
5.2 - USING THE SQUEEZER
To squeeze the fruit follow the below instructions:
1. switch the switch to “I”;
2. Always stand in the correct position to avoid accidents. Your body must be
perpendicular to the work surface (see FIG. n°7); do not force any of the
components with your hands or obstruct them in any way.
3. Be careful that your body or any part of it does not come in contact with
the squeezer when working;
4. for mod. STANDARD: position the cut fruit to be squeezed on the squeezer
and gently push to activate the appliance. If necessary increase speed by
turning the knob clockwise (ref.2 FIG.n°6) until reaching the required speed
(only for mod. VV).
N.B.: the appliance automtically stops when the squeezer is not pressed.
5. for mod. LEVER: position the cut fruit to be squeezed on the squeezer and
then gently lower the lever and press until the fruit has been completely
squeezed. If necessary increase speed by turning the knob clockwise (ref.2
FIG.n°6) until reaching the required speed (only for mod. VV).
N.B.: the appliance automtically stops when the squeezer is not pressed.
6. when you have finished using the fruit-squeezer switch the on/off switch to
“0”.
FIG.n°7 - Correct position
3
6.2 - PROCEDURE TO FOLLOW FOR CLEANING THE APPLIANCE
6.2.1 - cleaning the squeezer and juice ontainer
6.2.2 - general cleaning
CHAP. 7 - MAINTENANCE pag. 12
7.1 - GENERALITIES
7.2 - FOOT SUPPORTS
7.3 - POWER SUPPLY CABLE
CHAP. 8 - SCRAPPING pag. 12
8.1 - OUT OF SERVICE
8.2 - SCRAPPING
FIGURE INDEX
FIG. n°1 - general view of the appliance pag. 6
FIG. n°2 - overall dimensions pag. 6
FIG. n°3 - packaging pag. 7
FIG. n°4 - technical data and serial number plate pag. 8
FIG. n°5 - wiring diagram single-phase pag. 9
FIG. n°6 - controls pag. 9
FIG. n°7 - correct position pag. 10
FIG. n°8 - cleaning the fruit-squeezer pag. 10

4
CHAP. 1 - INFORMATION ABOUT THE APPLIANCE
1.1 - GENERAL WARNINGS
• The appliance must only be used by personnel who has carefully studied this
manual and understood all the safety standards described herein.
• If there should be a turnover in personnel, it is necessary that this manual is
carefully studied before using the appliance.
• Before cleaning or servicing the appliance, disconnect the electricity power
supply.
• When cleaning or servicing the appliance (safety protections removed) take
into consideration all possible hazards- Residual Risks.
• When servicing or cleaning the appliance always concentrate on what you are
doing and avoid any possible distractions.
• Check the electricity power cable on a regular basis; a worn or damaged cable
causes a dangerous electrical hazard
• If the appliance has a presumed malfunction or does not work correctly, do not
use it or repair it. Contact the “Service Centre”.
• Do not use this appliance for frozen food products and non-food products
• The manufacturer cannot be held responsible for the following situations:
⇒ if the appliance or safety devices are tampered with byunauthorised personnel
⇒ if non original
spare parts are used;
⇒ if the instructions given in this manual are not carefully and correctly
followed or respected;
⇒ if unsuitable cleaning products are used to clean the appliance
1.2 - SAFETY FEATURES INSTALLED
1.2.1 - mechanical safety features
Regarding the mechanical safety featrures the appliance described herein
conforms with the EU directives EEC 89/392 and EEC 91/368, 92/31, 93/44,
93/68.
The safety protection is a micro-switch that activates the appliance when the
squeezer is pressed.
9
4.4 - FUNCTIONAL CHECK
To check the appliance works correctlyproceed as follows:
1. check that the appliance works when the squeezer is pressed;
2. for models VV check that the number of revs increase (ref.2 FIG.n°6), when
the knob is turned;
CHAP. 5 - USING THE APPLIANCE
5.1 - CONTROLS
The controls for the citrus fruit-squeezer are shown in the below diagram.
FIG. n°6 - Controls
4.3 - WIRING DIAGRAM
FIG. n°5 - Wiring diagram Mn
2 1
1. on/off switch:
position I start
position 0 stop
2. speed variator (mod. VV)
Power sorce
230V./50Hz
MOTORE
Variable speed device

8
3.2 - CHECKING PACKAGING UPON CONSIGNMENT
When the goods are received proceed with opening the packaging if there are no
signs of damage, and make sure that inside there are all the listed items (see Fig.
n°3). If when the goods are delivered there are signs of damage to the packaging,
such as dents or if they have been dropped, immediately inform the forwarding
agent or courier, and within three days from the date indicated on the documents
draw up a detailed list and report of all damage to the goods. Do not turn the
packed goods upside down!! When transporting the package make sure its four
main points are firmly secured (maintain the goods parallel to the ground).
3.3 - DISPOSING OF PACKAGING
The various items used for packaging (cardboard, plastic straps) are normal urban
waste products and can be disposed of without difficulty.
If the appliance is destined to countries where there are specific standards
regarding waste, dispose of packaging respecting the standards and laws in force.
CHAP. 4 - INSTALLING THE APPLIANCE
4.1 - APPLIANCE LOCATION
The work surface where the appliance will be located must be suitable for its size,
please refer to the measurements given in Tab. 1. (depending on the model). The
work surface must be level dry, smooth, solid and stable.
The appliance must be located in a non-salty environment with a max humidity
value of 75% and with a temperature between +5° and +35°C; and however,
always in areas and environments that do not cause any type of malfunction to the
appliance.
4.4.2 - CONNECTING TO THE ELECTRICITY SUPPLY
The fruit-squeezer comes supplied with a 3 x 1,5 mm2 section (thickness) and ≅
1.5 m long power cable and with a SHUKO plug.
Connect the appliance to a 230V./50Hz power supply, interposing a differential
-thermo magnetic switch type 10A, ∆I = 0.03A. At this point make sure the main
earth circuit functions correctly.
Also check that the information given on the
technical data and serial number plate (FIG.
n°4) corresponds to the information given in the
accompanying documents.
FIG. n°4 - Technical data & serial number
5
1.2.2 - electrical safety features
Regarding electrical safety features, this appliance conforms to the EU directives
EEC 73/23, 89/336, EEC 91/368, 92/31, 93/44, 93/68 and to standards EEC EN
60335-1, EN 55014.
Although the appliance is fitted out with electrical and mechanical safety
protections that conform to the standards in force (these protections are for when
the appliance is working and when it is being cleaned or serviced) there are
however, RESIDUAL RISKS (EEC 89/392 point 1.7.2) that cannot be
completely eliminated and are indicated by the wording CAUTION
in this
manual. These risks refer to the risk of being cut or injured by sharp components.
1.3 - APPLIANCE DESCRIPTION
1.3.1 - General Description
- We have designed and manufactured this fruit-squeezer for squeezing fruit
guaranteeing:
- the maximum of safety when using, cleaning and servicing;
- the maximum of hygiene thanks to a meticulous selection of the materials that
come in contact with the food product, and thanks to the elimination of any
sharp and rough edges that come in contact with the product, cleaning is easy
and thorough and components can be easily removed;
- robust and stable components and structure
- maximum reduced noise level ;
- easy to handle.
1.3.2 - Constructive Characteristics
The fruit-squeezer is made from either white or chrome-plated shock-resistant
ABS. The juice container is made from stainless steel and the squeezer is made
from ABS suitable for food products. The main structure is in steel.

6
CHAP. 2 - TECHNICAL DATA
2.1 - MEASUREMENTS, WEIGHT, CHARACTERISTICS ...
FIG. n°2 - Overall dimensions
1.3.3 - Appliance Components
FIG. n°1 - general view of the appliance
LEGEND: 5 - Foot supports
1 - Main structure 6 - Switch
2 - Base 7 - Power supply cable
3 - Juice container 8 - Cover
4 - Squeezer 9 - Lever
A
B
C
2
1
3
4
5
6
7
BA
C
STANDARD APOLLO APOLLO WITH LEVER
8
9
7
CHAP. 3 - CONSIGNING THE APPLIANCE
3.1 - TRANSPORTING THE APPLIANCE (see FIG. n°3)
The fruit-squeezer leaves our warehouse carefullypacked; packaging consists in:
a) a resistant cardboard box;
b) the appliance;
c) this manual;
d) CE Certificate of Conformity.
TAB. n°1 - MEASUREMENTS AND TECHNICAL CHARACTERISTICS
FIG. n°3 - Packaging
Model u.m
.APOLLO STANDARD APOLLO VV APOLLO STANDARD
(with lever)
APOLLO
VV (with
lever)
Length A mm 210 210 265 265
Width B mm 210 210 210 210
Max. height C mm 280 280 325+60 325+60
Revolutions rev/
1’ 320 280÷750 320 280÷750
Motor W 150 150 150 150
Power supply Mn 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz
Net weight kg 2.7 2.7 3.5 3.5
Noise level dB ≤80 ≤80 ≤80 ≤80
c)
a)
d)
b)
CAUTION: the appliance is designed for the electrical specifications given on the
plate applied to the rear of the appliance; before connecting to the electricity
power supply refer to chapter 4.2 connecting to the electricity supply.
