Siruba Sew Reach F007KD User manual

F007KD/FFT
使用說明書與零件圖
INSTRUCTION BOOK & PARTS LIST

1. 規格 1. Specification
規格 Specifications
針棒行程 Needle bar stroke
左針高度 Left needle height
送具高度 Feed dog height
押具揚程 Presser foot lift
使用針 Needle
上送齒上下行程 Top and bottom stroke for top feed teeth
上送齒前後行程 Front and back stroke for top feed teeth
啟動扭力 Start up torque
最高轉速 Maximum speed
噪音值 Noise level
上送齒與下送具最小距離 The minimum distance
between top feed teeth and bottom feed dog
上叉高度 Spreader height
標準值 Standard value
33±0.5 mm
9.5 mm
0.8~1.2 mm
5 mm
UYX128GAS#10
4 mm
1~5.5 mm 可調式 adjustable
4.5 kg-cm 以下 Below 4.5 kg-cm
4500 s.p.m
80dB(A) 以下 Below 80dB(A)
0.5 mm
9.5mm
上送齒前後行程
front and back stroke for
top feed teeth
上送齒與下送具最小距離
The minimum distance between
top feed teeth and bottom feed
dog
上叉高度
Spreader height
上送齒上下行程
Top and bottom stroke for top
feed teeth
左針高度
Left needle height
Introduction
P1
產品規格 PRODUCT SPECIFICATION

圖1 / Fig. 1
1
3
2
O
1
上送行程調整鈕
O
2
上送具
O
3
刻度調整手輪
O
1
Top feed stroke adjust button
O
2
Top feed dog
O
3
scale adjustment hand wheel
P2
各部件名稱 PART NAMES

1. 上送齒行程大小之調整 (圖2)
行程大小由1.5~5.5mm無階段性調整
(1. ) 用左手壓下按鈕
O
A
，再以右手轉動手輪直
到左手手指感覺按鈕崁入到機器內部卡槽。
(2. ) 持續轉動手輪選擇所需之行程大小對準
O
B
，然後放開按鈕。
(3. ) 配合下送齒縫距，依手輪上紅色刻度
O
C
調
整上送齒所需行程即可。
1. Adjust the top feed stroke (Fig. 2)
Adjust the stroke from 1.5 to 5.5mm without
periodic adjustment
(1. ) Press button
O
A
with left hand，and turn the
hand wheel with right hand until the left hand
finger feel the button enters the machine slot.
(2. ) Keep turning the hand wheel until
O
B
pointed
at the required stroke level , and release the
button.
(3. ) Adjust the required top feed stroke according to
red mark
O
C
on the hand wheel in coordination
with bottom feed teeth distance.
圖2 / Fig. 2
ABC
Introduction
P3
調整 ADJUSTMENT

2. 壓具壓力強度之調整
在布料推送順暢且縫合完美的情況下，盡量
使壓具壓力輕一點。
＊鬆開螺帽
O
2
，將螺桿
O
1
順時針旋轉壓力
變大，反之則變小。(圖3)
3. 上送齒壓力強度之調整
在布料推送順暢且縫合完美的情況下，上送
齒應盡量穩固，故壓力須稍大。
＊鬆開螺帽
O
4
，將螺桿
O
3
順時針旋轉壓力
變大，反之則變小。 (圖3)
2. Adjust the presser foot strength
Lighten the presser foot as much as possible
when the fabric can be fed smoothly and
stitched perfectly.
＊Loose the screw nut
O
2
. When the screw rod
O
1
is rotated clockwise, the pressure is bigger, and
when rotated counterclockwise, the pressure
is smaller. (fig. 3)
3. Adjust the top feed teeth strength
The top feed teeth should be as stable as
possible when the fabric is fed smoothly and
stitched perfectly.
Thus adjust the pressure level as big as possible.
＊Loose the screw nut
O
4
. When the screw rod
O
3
is rotated clockwise, the pressure is bigger,
and when rotated counterclockwise, the
pressure is smaller. (fig. 3)
圖3 / Fig. 3
2
1
3
4
P4

P5

P6

P7

P8

P9

P10

P11

P12

P13

由於對產品的改良及更新 , 本產品使用說明書中與零件圖之產品及外觀的修改恕不事先通知 !
The specification and/or the equipment described in the instruction book and parts list
are subject to change because of modification with out previous notice
FFT66.FEB.2014
