Sirus Compact 3 Technical manual

C O M P A C T 3
MOBILE SOUND SYSTEM
OPERATION INSTRUCTION

This symbol warns the user of dangerous voltage levels localized within the enclosure.
This symbol advises the user to read all accompanying literature for safe operation of the unit.
Congratulations on your purchase of an SIRUS PRO COMPACT 3 high performance, self-contained portable audio system.
Your COMPACT 3 includes everything you will need for great sound. Anywhere. Carry your COMPACT 3 as a large sized suit
case. Flip open the speaker latches, and you'll discover two full-range speaker cabinets, a powered mixer, dynamic
microphones, plus all the cables you need to get started. Use your COMPACT 3's quick and easy set-up,its ability to cover
large audiences and simple operation are the hallmarks most desired value.
The COMPACT 3's control panel features four mono mic / line inputs and 2 stereo channels(6 channels total). The stereo input
channels can be used for either mono or stereo operation allowing superb flexibility in input use. Moreover, the tailored
speakers in each speaker enclosure deliver clear, full range sound with exceptional audience coverage and remarkable
feedback rejection. The self-powered mixer provides a total of 250 watts of high quality stereo sound.
For vocal operation, the COMPACT 3's Vocal Input Priority feature can be used to reduce or lower the background music level as
you begin to speak and then restore your background music when you have finished speaking. Experiment with the tone
controls, digital reverb and speaker placement and discover the COMPACT 3's incredible power and versatility.
IMPORTANT SAFEGUARDS:
- WARNING: TO PREVENT DAMAGE, FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
- NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
PERSONNEL AUTHORIZED.
- THIS UNIT MUST BE EARTH GROUNDED.
(2)
SIRUS PRO COMPACT 3
Mobile Sound System
INTRODUCTION
to/from your computer.
8-Channel powered mixer.
4 XLR MIC inputs.
2 TRS stereo Channels with RCA 3.5mm Stereo inputs.
Channels with 3-band EQ, EFX Send, Pan, Level.
USB Port connect to flash disk,MP3 player
USB connectivity: the USB port is used to connect the COMPACT 3 to a computer for recording or playing back
digital audio
Effects send on every channel with stereo return.
Internal 24-bit DSP effect processor with 16 selections and foot switch jack, including reverb ,delay and vocal
enhancement.
Effect parameter adjustment allows you to customize each effect selection.
2 wireless microphone receiver slots for optional wireless microphones
Dual 7-band system equalizer with switch.
2 five-segment LED meters.
Performance Indicators: Signal, Clip ,power and Protect.
300W (150W 8ohms per channel) stereo power amplifier built-in with dynamic Distortion processor, turn-on/turn-off,
thermal and short .
Speaker system with 1" compression driver and 10" woofer.
AC power or DC-DC conerter operation
storage compartment for cables and accessories.
Two 30 feet speaker cable.

SAFETY PRECAUTIONS
TRANSPORTATION LATCHES
The SIRUS PRO COMPACT 3 sound system is supplied with a detachable power cable with an IEC
female connector and a male AC connector. Depending on the territory in which the COMPACT 3
system is purchased, the power cable will be supplied with one of a number of male AC connectors
to accommodate the different safety and code requirements of specific countries. All AC cables
supplied with COMPACT 3 products are three pin grounded types.
Under no circumstances should the ground(earth)pin be disconnected or removed.
Your COMPACT 3 System features a Switch-Mode-Power-Supply designed to operate on any AC voltage and line frequency
to convert AC power with maximum efficiency.
When travelling abroad with the COMPACT 3 system, as a standard precaution, always check the local voltage and set the
voltage selector switch located adjacent to the socket on the rear of the mixer / amplifier to the appropriate operating range.
This check must be performed before connecting the power cable. The SIRUS PRO COMPACT 3 has two range settings:
115V or 230V .
Failure to select the appropriate voltage range will cause the unit to go into protect mode, void any warranty and may cause
damage to the unit.
For example, The United States of America is standardized at 117 volts / 60 Hz, Japan operates on 100 volts / 50 Hz. For
both of these countries the range selector must be set to 115V. Countries in the EEC have standardized at 230 volts / 50
Hz., However, there are different types of AC plugs used. For all these countries the selector should be at the 230V position.
When using plug adapters or operating in a territory other than the one in which the unit was purchased, take great care to
comply with local safety requirements and electrical codes of practice.
If you are not sure of the local voltage, wiring codes & colours, AC grounding, or correct procedures for
connection, consult a qualified technician.
Warning
Under no circumstances should the ground pin on the COMPACT 3 or on any of your electrical
equipment be lifted (cut off or disconnected).By following the correct procedures and safety
precautions, risks of severe shock hazard can be minimized. Best of all, avoid operating the
system in conjunction with ungrounded or improperly grounded electrical equipment.
To open and close your COMPACT 3 system, simply follow these guidelines:
1. Place your finger tip under the safety latch and gently lift. When the safety latch has disengaged, lift the main latch to
remove the speaker.
2. To replace, position the speaker on the tower foot ad bring the speaker in to close the engagement with the tower and
latch. Position the latch hook over the speaker notch and close the latch. The safety latch will automatically engage.
Note: These parts are precision engineered and no force is needed to secure them. Careful alignment of parts will ensure
easy operation.
(3)
SET-UP SYSTEM VOLUME AND LEVELS
To set system volume and operating levels, be sure to follow these simple set-up guidelines:
1.First,slowly raise the large Left and Right Master volume controls to their 12o'clock notched positions.
2.Use a microphone(or other source)in the same position as it will be used on stage and in the manner in which it will be
used for the event. Slowly bring up the appropriate channel input level control listening for the onset of feedback or howling
or until the required level is reached. Have a helper "walk"the audience area to make sure coverage and levels are sufficient
for your needs. The system's overall volume can be raised simply by rotating the Left and Right Master volume controls to
the desired level.
3. Consider the application and needs of the event and set the System EQ control appropriately. This is best achieved by
playing recorded material of the same type as your show program, or by having an assistant speak into the microphone
while you listen in the audlence area.
For public address (spoken voice), it is advisable to rotate the System EQ sticks up to enhance the mid and high
frequencies, and limit the low frequency content. For large outdoor spaces this will also give the maximum headroom and
output capability. Carefully consider the individual event's needs and set your control for the maximum effect.
POWER TOWER
In setting up the system, the COMPACT 3 Mixing console should ideally be placed where system performance can be
evaluated by the operator. If no ongoing adjustments will be necessary, the mixer may be placed conveniently and where the
cable lengths allow.
Take care to place the Power Tower there the cables will not trip anyone. All cables should be carefully secured.
The storage compartment in the rear of the Tower can hold cables, microphones and other system parts. To open simply
slide the catch upwards and pull open.
The mains (AC) fuse holder is under the IEC (power cord) socket on the right rear of the Tower. To change a fuse, remove the
IEC plug and, using an appropriate tool pull out the fuse holder, Note there is a spare fuse in the fuse holder; the COMPACT
3 utilizes a T6A 250V fuse. Only replace fuses with one of an identical value and size.
Frenquency Response
20 Hz to 20 kHz 1dB (at send output)
30 Hz to 20 kHz 1dB (at speaker output, with processor threshold exceeded)
Distortion <0.05%, 20 Hz to 20 kHz, 1 dB below rated output
System Signal to Noise Ratio > 80 dB @ 1w. "A" WTD
Power Output 150 W/ch continuous averate power, 8ohm, both channels driven with THD <1%
Input Impedance (Channels 1-2-3 and 4) "Mic" 2 k ohm
"Line" 33 k ohm
Input Impedance Stereo Channel 5/6,7/8) 33 k ohm
Max. Input Level Mic: -7dBu Line: 30dBu Stereo: 26dBu
Return Input Impedance 47k ohm
Fuse type T6A, 250V
COMPACT 3
System
Speakers
Power Tower
Microphone Dynamic Cardioid,balanced
Microphone Cable XLR - Male to XLR - Female
Speaker Cables 1/4 in. To 1/4 in .2x6m
L 280 MM W 348 MM H 478 MM
L 274 MM W 348 MM H 518 MM
L 778 MM W 348 MM H 478 MM
SPECIFICATIONS
Carrier frequency 794.00 MHz~813.6MHz
(10)
This wireless microphone can work normally with in the range of 50 meters.

BAL B AL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17 18192021222324
25
26
27
29
35
28
30
33 34
31
32
38
40 41
42
37
15
44
45
46
4749
48
43
39
36
(4)
REAR PANEL
REAR STORAGE COMPARTMENT
SET-UP AND CONNECTIONS
CONNECTOR / LINE CORD - The COMPACT 3 is equipped with a grounding type IEC supply cord to reduce the possibility
of shock hazard. Be sure to connect it to a grounded AC receptacle. DO NOT ALTER THE AC PLUG.
The power mains(AC) fuse and fuse holder are under the IEC(power cord) socket Replacement
fuses must be of the same rating(6A 250V) and size as originally equipped. To replace a blown
fuse, remove the IEC power cord. Pull out the fuse holder and find the spare fuse inside.
Your COMPACT 3 system is capable of running on battery power. The off-white plastic connector on the rear of your
COMPACT 3 is the DC power input connector for connecting the COMPACT 3 with +/- 48 V battery pack.
A small storage compartment can be found on the rear of the COMPACT 3 tower. To access this compartment, simply lift the
latch and pull open the storage door. This compartment is ideal for storing cables, microphones or other items when you are
transporting your COMPACT 3.
Before turning on the Power, please read and heed the safety warnings on page 3.
It is wise to establish a routine for connecting and powering up your sound system. Provided you have a properly grounded
AC outlet or outlet strip with sufficient power handling capacity, plug all sound system equipment into the same outlet or
strip. This will enhance system safety and performance. Take care that the AC circuit is capable of handling the peak power
demands of your system. Consult the product handbooks or a qualified electrician if in doubt.
When setting up, be sure to follow these simple set-up guidelines:
1.First,turn all channel Level, VIP(channel 1 ONLY)and Eff/Aux controls to their full counterclockwise(OFF) positions. Next,
place all EQ sticks in the middle position ("0" position), all Pan and Master controls at 12 o'clock in their center notched
positions. Be sure to set the appropriate input (mic / line switch position)for the source you are setting up.
2.Next,connect each speaker cable to the appropriate left & Right Speaker outputs on the rear tower and on each speaker
front panel with the enclosed cables.
3.Connect all sources such as microphones, tape decks, keyboards etc.,into the appropriate inputs.
4.Finally,check the local voltage and set the voltage selector switch located adjacent to the power input socket on the rear of
the mixer/amplifier to the appropriate operating range.(See Safety Precautions on page 3.)Plug the power cable into the
IEC(power cord)socket end to a properly grounded 3 wire AC power outlet.
POWERING UP
Turn the Power Switch to the ON position. The Power LED will illuminate green and the system will turn on. If other powered
equipment is to be attached to the system, it is always advisable to turn on your COMPACT 3 last. In this way any transient
spikes and thumps caused by other equipment will not be amplified and sent to your system speakers. For the same
reasons it is advisable to turn off your COMPACT 3 system first before turning off the attached equipment.
Should the Power LED not illuminate when the rear panel power switch is operated, check your power connections and
retry. Should the Power LED still fail to illuminate after you have confirmed the power connections, disconnect all cables
and check the COMPACT 3 fuses. Be sure to replace any blown fuses with fuses of the correct value. Reconnect the power
and speaker cables and turn the rear panel power switch on.
Re-set the system by turning on the power switch. If the power LED illuminates red, the system is indicating a thermal
protect mode or cooling problem .Be sure to check the air inlet filter at the base of the unit by removing it and making sure it
is clear of debris.
Turn power off and wait for a few minutes allowing heat to dissipate and the COMPACT 3 to reset itself. If after doing
so the Power LED continues to glow red this indicates a fault with your system and you should consult an authorized SIRUS
PRO service center.
If no audio is present in one of the speakers, check to see if your control settings are correct. Next, unplug the cable from
your working speaker and reconnect it to the other speaker. If the second speaker now works, this indicates that the first
cable is bad, and should be repaired or replaced.
(9)
FRONT

CONTROL FUNCTIONS
1) HIGH - Adjusts the relative level of the high frequency content. Rotating the knob counterclockwise decreases the high or
high frequency response. Likewise, rotating the knob clockwise increase the high or high response is "flat" with no
frequencies increased or decreased.
2) MID - Adjusts the relative level of the mid frequency content. Rotating the knob counterclockwise decreases the high or
mid frequency response. Likewise, rotating the knob clockwise increases the high or mid frequency response. When the EQ
controls are set at their middle position,. the channel frequency response is "flat" with no frequencies increased or
decreased.
3) LOW - Adjusts the relative level of the low frequency content of the channel 1. Rotating the knob clockwise increases the
bass or low frequency response. Likewise, rotating the knob counterclockwise decreases the bass or low frequency
response. Likewise, rotating the knob counterclockwise decreases the bass or low frequency response.
4) EFF / AUX - Adjusts the amount of signal sent to the Reverb processor, and to the EFF / AUX output jack. Reverb can be
used to enhance the sound quality of any performance where appropriate and desired. In the full left position there is no
level sent to the reverb processor or EFF / AUX jack. Care should be taken to set the Reverb return master control to a
middle position or above, before adjusting levels from the individual channel. When the reverb / auxiliary mix is set, overall
levels of reverb can be adjusted at the master control. Keep in mind that while Reverb or effects can enhance a musical
performance or presentation. Too much reverb can make the same performance or presentation unintelligible or
"muffled",Keep your audience in mind when setting reverb levels.
5) PAN - The Pan control features a notched position indicator and adjusts the perceived" position" of the mono signal from
the input within the stereo field created by the two speaker cabinets. Full Left or Right rotation of this control sends the
signal to the that channel only, with no signal sent to the other. The center position sends the same amount of signal to both
speakers.
6) LEVEL - Adjusts the volume level of the individual channel. Rotating the knob clockwise increases the respective
channel's contribution to the "Main Out" mix, while rotating it counterclockwise decreases the volume. Adjust this control
after the COMPACT 3's master output level volume has been set.
7) BAL - The balance control features a notched position indicator and adjusts the perceived"position" of the mono signal
from the input within the stereo field created by the two speakers. Full Left of Right rotation of this control sends the signal to
the that channel only, with no signal sent to the other. The center position sends the same amount of signal to both speakers.
DIGITAL EFFECTS
8) DSP display
9&10)CLIP/SIG LED-This LED will illuminate green when a signal is present at the High or Low Z inputs. When the signal
nears chipping, the LED will illuminate red.
11)
12)
13)
14&15) -The USB port is used to connect the COMPACT 3 to a
computer for recording or playing back digital audio to/from your computer.
16)
MASTER CONTROL
17,18,40,41) These LED metres monitor the output signal levels either the main or output signals. The red LED is illuminate
when the internal limiter is engaged to prevent the signal from being clipped. (Clipping results in overdrive distortion and
should be avoided.) If the Limiter LED is flash continuously or remain on constantly during use, reduce the output signal
levels until they flash only on strong signal peaks.
Turning the knob, choose the right effect you are willing to display, the press down once confirmed.
EFF Level- input level adjustment
EFF Level- output level adjustment
USB port, and output level adjustment for recording
Input level adjustment for USB recording
(5)
(8)
BACK

(6) (7)
32) FOOT SWITCH - The Foot switch connector allows the internal reverb retum to be muted, or shout off, through the use of
a simple foot operated switch. The foot switch should be wired to connect the tip to the sleeve to turn the reverb off, and
requires a standard speaker or instrument cable.
33 & 34) AMPLIFIER SEND / RETURN JACKS - Each channel of the amplifier has a Send and Retum jack. These jacks
provide a point to patch in an equalizer, or other processor into the sound system. The signal at the send jack is located after
the mixer section and before the power amplifier. The send jack should be connected to the output of the external device.
36 ) SPEAKER OUTPUTS - These are speaker level (powered) output jacks designed to feed each of your COMPACT 3
speaker enclosures. Use the enclosed cables(or other speaker cable) to connect the COMPACT 3's speakers to the power
tower.
38) EFF/AUX RETURN - Plug your external effects signal processor's output signal in here. This 1 / 4 inch input stereo jack
is designed to accept signals from an external processing device, such as a digital delay or a chorus unit. This input can also
be used as a stereo input with the volume controlled at the master volume knobs.
39) POWER SWITCH - Turns the AC power ON and OFF. When the switch is in the OFF position, your COMPACT 3 is
completely shut down.
42) POWER LED INDICATOR
This LED illuminates when the power is turned "ON".
43) PROTECT LED INDICATOR
This LED illuminates if the power sound system is output connection is shorted or the load impedance is too low.
MP3 PLAYER
44)
45)
46)
47)
48)
49)
Play and Pause press button
Press button for the previous audio item as well as volume decrease
Press button for the next audio item as well as volume increase
Mode set up for MP3 player
USB flash disk port- for USB disk with MP3 or other music file
LED indicator- showing the working status of the USB port.
19 & 20 ) MASTER VOLUME LEVEL CONTROLS - The Left and Right Master Volume Controls adjust the output volume of
the COMPACT 3. The Master controls feature notched position indicators. For the majority of applications the COMPACT 3
system has been balanced to operate with these controls at their notched 12 o'clock positions. In situations where more
volume is required the master controls can provide an additional 6 dB of gain when turned to the right of the center position.
Set the system up in the normal manner and adjust levels as necessary. Raise the master volume controls beyond their 13
o'clock positions only after increasing the individual channel level controls. COMPACT 3's internal amplifiers have on-board
processing designed to optimize the system ,s performance when used with the custom designed COMPACT 3 speakers.
21) STEREO / DUAL SELECTOR SWITCH - Allows the COMPACT 3's power amps to be configured as stereo or "dual -
mono". In the Stereo mode, the system operates as a traditional stereo power mixer / amplifier. In the Dual mode, the
channel level controls control set the level for the Main mix(LEFT master volume control) The Rev / Aux controls set the
individual channel levels for the Monitor(RIGHT master volume control). When the Dual mode position is selected with the
switch, the Pan and Balance controls become in operative (you have selected a mono setting for the output). Additionally,
the internal reverb is only sent to the MAIN speaker output. Reverb is not available to the MONITOR speaker output. The
reverb level sends for the MAIN mix are also controlled from the channel DSP / AUX channel controls. The overall reverb
level to the MAIN mix is controlled by the Reverb Master Control.
22)EQ CONTROL - Adjust the EQ sliders the 7 band EQ is connected into the system, when turn off the EQ button, the EQ is
off the audio signal will go directly to the system without EQ.
23) SYSTEM EQUALIZER - Adjust the amount of frequency increase or decrease in the channel. The left and right channels
are adjusted simultaneously at same time and same pace. Set frequencies are at 60Hz,160Hz,400Hz,1KHz, 2.5KHz,6KHz,
16KHz , adjusting range within +/-12dB; When the sliding stick is at the middle position, the frequency response is "flat" with
no frequencies increased or decreased; When sliding the stick up increases the frequency response of that band, when
sliding the stick down decrease that band's frequency response. To set the EQ, start with this control from the middle("0dB"
marked) position. Simply slide the sticks until your desired sounds are there.
WIRELESS MICROPHONE
24)LEVEL -Use this control to set the channel is signal level.
25) RF indicator light
MIC/LINE STEREO INPUTS
26) MIC INPUT JACK - Plug your microphone in here. This three pin XLR balanced female input in put signals from in put
signals from bass impedance microphones.
27) LINE INPUT JACK - Plug your instrument in here. This 1/ 4inch balanced input jack suited for use with items having a
line level output such as high impedance microphones, keyboards, drum machines, outboard effects, etc. It accepts both
balanced and unbalanced cables.
28& 37) STEREO INPUTS - Stereo phono (7/50"TRS) input jacks and 1/4" TRS jacks (wired for Tip=Left, Ring=Right and
Sleeve= Ground,the standard format of commercially available cables) designed for use with a tape player, DVD player, or
any other stereo source. Use these jacks for connecting the output of a computer sound card or other similar device to your
COMPACT 3. Adapters that convert an 1 / 8" male plug to RCA male phono plugs are readily available at electronics stores.
Note: These connectors are set at a constant"line level".
29& 35) STEREO INPUTS - Stereo phono (RCA) input jacks and 1/4" TRS jacks (wired for Tip=Left, Ring=Right and Sleeve=
Ground,the standard format of commercially available cables) designed for use with a tape player, DVD player, or any other
stereo source. Use these jacks for connecting the output of a computer sound card or other similar device to your COMPACT
3. Adapters that convert an 1 / 8" male plug to RCA male phono plugs are readily available at electronics stores. Note: These
connectors are set at a constant"line level".
30) STEREO OUT - The Tape Out RCA jacks provide a mix output that is independent of the Master Level Controls. Connect
these to the inputs of a recording device, such as a cassette or DAT recorder, to record your event. Changes made during
the performance, to the input level controls, channel EQ, and reverb controls will be heard in the Tape Out mix. Changes
made to the master level controls will not effect the level of the recording. Adjust recording levels according to the
instructions on your recording device.
31) EFF / AUX SEND - Plug your external effects signal processor in here . Although the COMPACT 3 is already equipped
with on -board digital reverb, an external effects signal processor in here. Although the COMPACT 3 is already equipped
with on -board digital reverb ,an external effects signal processor can be incorporated into the COMPACT 3's signal flow.
This 1 / 4 inch output jack is designed to feed the COMPACT 3's effects bus signal to an external signal processing diver,
such as a digital delay or a chorus.
AUX AND FOOT SWITCH JACKS
